Life Smart LS123BL User manual

Smart Light Switch
Setting up your LifeSmart Smart Light Switch
User Guide V 1.0
Model. LS123BL/123WH/124BL/124WH/125BL/125WH
Simply, Brilliant

PRODUCT INTRODUCTION
The LifeSmart Smart Light Switch replaces your ordinary
switch with smart home technology to make your life easier.
With the help of LifeSmart Smart Station and the free
LifeSmart App, you will gain infinite control possibilities. Just
one touch, you will be able to turn on your televisions,
stereos, air conditioners, heaters, and lighting separately or
together instantly.
Forget to turn off the lighting when you leave home? Want to
turn on the air conditioner or the heater before arriving
home? No Problem! All the LifeSmart devices, or other
ordinary devices connecting to the LifeSmart Smart
Switches can be controlled intelligently.

Disposal And Recycling Information
This symbol indicates that this product and/or battery
should not be disposed of with household waste. When you
decide to dispose of this product and/or its battery, do so in
accordance with local environmental laws and guidelines.
PRODUCT INTRODUCTION
The best part is that all the devices can be controlled
through LifeSmart App anywhere and anytime. Integrated
with RGB LEDs, Smart Light Switches are capable of
providing over 16 million colors with adjustable brightness.
Let the lights adjust to your needs, not the other way around.
Get yourself ready to experience the smart home!

SPECIFICATIONS
Size
Weight
Wireless Distance
Wireless Protocol
Static Power Consumption
Working Voltage
Loads
120*72*35mm
110g
400m (open field)
CoSS
Max 1.5W
AC 100～240V 50/60Hz
IN YOUR PACKAGE
Smart Light Switch
1
User Guide
1
Screw
2
Regulatory Certification
Resistive Load：< 500W per channel
Inductive/Capacitive Load：< 200W
per channel

SMART LIGHT SWITCH
N: Switch-in Neutral Wire Connector L: Switch in Live Wire Connector
L1: Switch-out Live Wire 1 L2: Switch-out Live Wire 2
L3: Switch-out Live Wire 3
ＮLL1 L2 L3
Live Wire Connector
Neutral Wire Connector

INSTALLATION STEPS
Cut off the power and ensure that there is no electricity
leakage before the installation.
Take out the switch, stretch the panel edge to separate
the switch and the panel.
Connect the wires by following the diagram above. We
strongly advise to put insulating tape over the screws
that fix the wires. Please ensure that the N line and L line
are not crossed. Please ensure that the screws and the
metal box are not contacted.
1
2
3

Please put all the wires neatly back to the switch box.
Fix the switch with two screws.
Close the panel and clip it properly. The mal-installa-
tion may harm the switch connection.
Turn on the power, check if the indicator light is on or
not and test. If the indicator light is not on, please
check the L and N line. if there is no response to the
touch, please re-start the power supply and try again.
4
5
6
INSTALLATION STEPS

APP SETUP
The device requires a LifeSmart Smart Station and the LifeSmart App
to operate. Please download the App and set up your Smart Station
before proceeding. The App is available by scanning the following QR
Code, or go to the Google Play Store or iOS App Store directly.
1Method 2Method
m.ilifesmart.com/getapp.html
m.ilifesmart.com/getapp.html
LifeSmart App is required for operating with this device. Minimum
operating system requirements iOS 7.0 or Android 4.0.

APP SETUP
1
Open the LifeSmart App, initiate “add a device”
process and follow the instructions.
For technical support or FAQ's please visit us at
www.ilifesmart.com and find out how to contact our team
in your region.

Thank you for purchasing LifeSmart products. In order to
protect your rights, please read the following content
carefully: The warranty period of our company's products is
one year from the date of purchase. Or longer if local laws
impose a longer minimum term, in which case the minimum
term is the warranty period. During the warranty period, any
faults caused by the product itself or for quality problems that
arise under normal usage, LifeSmart will provide a free
replacement.
WARRANTY DESCRIPTION

The following conditions are not covered by the warranty:
Product failure or damage caused by installation, use, and
maintenance that is not in accordance with the product instructions;
Products beyond the warranty period;
Products that have the barcode tampered with or removed;
Devices that have been tampered with or customized outside of
LifeSmart Terms Of Service as on the LifeSmart App and website;
User-caused damage, such as inappropriate voltage input, high
temperature, accidental spillage, physical damage, etc;
Product failure or damage caused by force majeure such as
earthquakes, fires, or floods;
Product failure or damage caused by other problems except the
product itself.
ATTENTION

DECLARATION
LifeSmart is a trademark of Hangzhou LifeSmart Technology
Co., Ltd. As for the trademarks, product logos and product
names from other companies presented within this manual,
they are possessed by their own right holders.
Without our written permission, no entity or individual shall
extract, copy or disseminate in part or the whole of the
manual contents in any form. Due to product version
upgrades or other reasons, content of this manual may
change. Our company reserves the right to change the
contents of this manual without any notice. This manual is
used only for instructional purposes. We strive to provide
accurate information in this manual, but we are not able to
ensure that the content of this manual is current.

DECLARATION
Statements, information and advice in this manual do not
constitute any expressed or implied assurance. Updated
manuals are available on our website at www.ilifesmart.com
or by contacting our Team.

Copyright © 2018 LifeSmart Inc. All Rights Reserved.
