LifeMist 0011 Series User manual

Part No. 097084-
Series: 0011
Printed in Canada
February 2002
LifeMist Water
Distillers
Owners’ Guide
For Models:
COMPACT NT PRO ELITE
Series: 0011
LifeMist Home Products
Headquarters
9024-100th Street
Westlock, AB, Canada
T7P 2L4
http://www.lifemist.com
Phone: [phone]
FAX: [phone]
MODEL:LM-COMPACT MODEL:LM-NT MODEL:LM-PRO MODEL:LM-ELITE
Please Read Owners’ Guide
Completely before installing or
operating your LifeMist Water Distiller

2
Page
Table of Contents ………………………………………………………….......... 2
Introduction ………………………………………………………………………. 3
Records …………………………………………………………………………… 4
Life Mist Water Distiller Warranty …………………………………………….. 5
Important Safety Precautions …………………………………………………. 6
LifeMist Water Distiller Owners’ Summary ………………………………….. 7
Water Distiller Features ………………………………………………………… 8
10 Factors That Will Affect Your Water Distiller Production …………….. 9
Understanding How Pure Water is Produced ………………………………. 11
Finding a Good Installation Location …………………………………………12
Unpacking Your Water Distiller ……………………………………………….. 13
Water Distiller Installation Tools ………………………………………………16
Storage tank Assembly ………………………………………………………….17
Manual Drain Valve and Tube Installation ……………………………………18
Water Distiller Levelling ………………………………………………………... 19
Feed Water Fill Connection ……………………………………………………. 20
Boiling Tank Lid Installation …………………………………………………… 23
Storage Tank Lid Removal and Installation…………………………………. 23
Water Distiller Wall Stabilizer …………………………………………………. 24
Operation …………………………………………………………………………. 25
Controls –Power, Fan, Water, Overheat Reset and Fuse …………………………….. 25
Storage Tank Drain Valve…………………………………………………………………. 27
Before Initial Water distiller Operation …………………………………………………… 28
Normal Operation …………………………………………………………………………. 29
Maintenance and Cleaning ..............................................................................30
Regular Inspection and Cleaning of Boiling Tank ………………………………………..30
Cleaning the Boiling Tank using the Cleaner Descaler ………………………………….31
Replacing Charcoal in Charcoal Canister Filter ………………………………………….33
Sterilization ……………………………………………………………………………....... .34
Liquid Sterilization of Storage Tank and Optional Pump Water Line System .34
Steam Sterilization of Water Distiller Head ……..……………………………....35
Steam Sterilization of Water Distiller Head, Canister Filter and Storage Tank.37
Maintenance Schedule Table …………………………………………………….38
Owner Maintenance Record Table ………………………………………………38
Troubleshooting …………………………………………………………………..39
Optional Accessories …………………………………………………………….44
Pump Kits …………………………………………………………………………………. .44
APK-1 Pump Kit …………………………………………………………………. .44
APK-2 Pump Kit …………………………………………………………………. .45
Pump Kit Installation ……………………………………………………………………. .46
Automatic Electric Drain Kit Installation …………………………………………….. .54
Additional Options…………………………………………………………………………58
Sediment Pre-Filter, Charcoal Post-Filter Assembly, Pressure Accumulator,
Water Distiller Cleaner and Descaler, Pure Activated Coconut Charcoal for
Refillable Canister Filters and Tee Valve ……………………………………… 58
Specifications and Technical Information …………………………………....60
Wiring Lists and Schematics ……………………………………………………………... .61
Index…………………………………………………………………………………65
Warranty Registration Card ……………………………………………………..67
Table of Contents

3
Introduction
Congratulations on the purchase of the most advanced water distiller
in the industry! When installed and maintained properly, your LifeMist
water distiller will provide years of safe, trouble free service. It is
important to observe and follow the safety and maintenance
instructions carefully. If you have any questions or concerns
regarding installation or operation of your water distiller, please
contact your dealer.
All 120 VAC LifeMist Water distillers are certified to cCSAus Classes
2831-02 and 2831-82 under the Canadian and American Electrical
Code.
All Water distillers are factory tested with a high voltage ‘Dielectric
Strength Test’ to check for short circuits in the water distiller prior to
shipping.
LifeMist water distillers have been tested by EnviroTest Laboratories
which found the water distillation units to be very effective water
treatment systems capable of removing both harmful pathogens and
toxic chemicals from water. In their study all pathogens were
eliminated and none were found in the distilled water. The water
distillation system also effectively removed all of the soluble inorganic
chemicals tested. Removal efficiencies of 99% or greater were
achieved for almost every chemical tested.
All LifeMist water distillers are operated and tested at the factory and
have produced distilled water to make sure all components are
functioning properly. All water distillers are wiped clean before
shipping, but there may be a water ring inside the boiling tank. There
may also be an off-colour line at the seams of the storage and boiler
tank. This is caused by the TIG welding process used during
manufacturing. This is normal and is not a sign of a problem. Follow
all the Before Initial Water Distiller Operation procedures and you
will have pure water in no time.
Your LifeMist Water Distiller must be installed according to any Local
or State Regulations.

4
Records
Please record all of the important information below to assist you and the service
centre in case there is any service work required in the future. All of the
information is required to properly identify your water distiller and will make
servicing much easier. The information is located on the serial plate on the side
of the water distiller head. The Serial Plate Location Diagram below shows a
sample serial plate.
Serial Plate Location Diagram
LifeMist Model: Compact NT Pro Elite 
Series: eg: 0001
Serial Number: eg: 0123012
Date of Purchase: ___________________________________________________
Optional Pump Kit Model: APK-1 APK-2
Optional Pump Serial No: __________________________________________
Series: __________________________________________
Optional Drain Serial No: __________________________________________
Series: __________________________________________
SERIAL PLATE LOCATION DIAGRAM

5
LifeMist Water Distiller Warranty
-The warranty for your LifeMist Distiller covers defects
in materials for five (2) years on all parts and labor
to the original purchaser.
-Stainless Steel parts are further warranted for 15
years. This covers all stainless steel parts such as
the boiling and storage tank. With this warranty it
is the responsibility of the distiller owner to properly
maintain the distiller. If there is any mis-use or
abuse the lifetime warranty will be void.
-LifeMist Home Products does not warrant any
transportation charges incurred to complete the
repair. The distiller owner is responsible for all
shipping charges to and from the service center.
-Warranty is void if the distiller is found to have been
consumer damaged or misused, caused by acts of
God, unauthorized alteration, repair or vandalism.

6
Important Safety Precautions
When using electrical appliances, basic safety precautions should always be
followed including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against electrical shock do not immerse cords or plugs in
water or other liquid.
4. Close supervision is necessary when any appliance is used near
children.
5. Do not allow children to operate this appliance.
6. Unplug from outlet when not is use and before cleaning. Allow to cool
before putting on or taking off parts.
7. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions or has been damaged in any manner. Return
appliance to the nearest service facility for examination, repair or
adjustment.
8. The use of accessory attachments not recommended by the appliance
manufacturer may cause injuries.
9. Do not use outdoors.
10.Do not let cord hang over edge of table counter, or touch hot surfaces.
11.Do not place on or near a hot gas or electric burner, or in a heated
oven.
12.Extreme caution must be used when moving an appliance containing
hot water.
13.Always attach plug to appliance first, then plug cord into the wall
outlet. To disconnect, turn any controls to “off”, then remove plug
from wall outlet.
14.This appliance is intended for household use.
15.Save these instructions.
Additional Safety Recommendations
1. Always unplug appliance before servicing.
2. Do not use extension cords with appliance.
3. Ensure there is adequate air space around the appliance to allow the heat
from the appliance to be removed and supply adequate fresh air for
cooling.

7
LifeMist Water Distiller Owners’ Summary
The following is a summary of the information contained
in this Owners’ Guide and required to install and operate
your Water Distiller
1) Find a good location for installing your Water
Distiller –See Finding a Good Installation
Location.
2) Unpack the water distiller and parts - See
Unpacking
3) Assemble the Water Distiller –See
Storage Tank Assembly
Manual Drain Valve and Tube Installation
Distiller Levelling (NT, Elite and Pro
Models)
Feed Water Line Connection
Boiling Tank Lid Installation
Wall Mounting
4) Install all purchased Options - See Optional
Accessories for installation instructions.
5) Steam sterilize boiling tank and storage tank –
See Steam Sterilization in the Maintenance
and Cleaning section.
6) Load Charcoal Filter Canister –See Replacing
Charcoal in Charcoal Canister Filter in the
Maintenance and Cleaning section.
7) Enjoy pure, distilled water!

8
Water Distiller Front View
Water Distiller Rear View
Water Distiller Features
DISTILLER FEATURES REAR VIEW DIAGRAM
LM-NT AS SHOWN
PANTRY FAUCET
OPTIONAL PUMP KIT
FLOOR DRAIN
ACCESSORY
PUMP
CONNECTION
ACCESSORY
DRAIN
CONNECTION
DRAIN TUBE
IMPURITIES DRAIN
BALL VALVE
(OPEN POSITION)
REPLACEABLE
FUSE
CONTROL
CABLE
CONNECTION
OPTIONAL AUTOMATIC
ELECTRIC DRAIN
DISTILLER FEATURES DIAGRAM, LM-NT
CONDENSING COIL (INSIDE)
GAS RELEASE VENT (HIDDEN)
BOILING TANK LID KNOB
BOILING TANK (INSIDE)
BOILING TANK LID
POWER SWITCH
FAN SWITCH
WATER SWITCH
OVERHEAT RESET SWITCH
CHARCOAL FILTER
CANISTER BODY
STORAGE TANK LID
STORAGE TANK
SIGHT GAUGE AND
DRAIN VALVE
STORAGE TANK LEGS
ADJUSTABLE APPLIANCE FEET
WATER DISTILLER HEAD
CONDENSING COIL SHIPPING STRAP
(REMOVE BEFORE USE)

9
1. Water Volume Measurement
a) How are your measuring your water? The most accurate is by weight.
1 litre of pure water = 1 kg = 1000 g = 2.2046 lbs
b) Water distillers are rated in US gallons, NOT Imperial Gallons.
1 US Gallon = 3.785 litres = 3.785kg = 8.344 lbs = 0.833 Imp. Gallons
c)Mostdistilled water holdingtanksdonotcompletelydrainfromthetaporpump.
Ensurethisvolume ofwaterisincludedin your calculationbycompletelydrainingthe
tankorstartingyourproductioncheckwiththisvolume pre-filled.
2. Line Voltage
The line voltage at the outlet where the distiller is connected should be checked
with a voltmeter. Line voltage is often much less than expected, especially in
rural areas. Line voltage will also usually drop off dramatically when the daily
commercial load hit the grid from approximately 8 am to 5 pm (often when the
distiller owner is not home and unable to check the line voltage). Line voltage
lower than the distiller rated voltage (on the serial plate) will drastically lower the
water production.
3. Feed Water Temperature
The water feeding the machine may affect the water production. Cooler feed
water will take more time/energy to heat to the boiling point. Using a water
supply from the outlet of a hot water heater is not recommended as the benefit of
using hot water is very small because only small amounts of water enters the
boiling tank of the water distiller.
4. Ambient Air Temperature
Water distillers with cooling fans must have sufficient ventilation so that the boiled
water can be cooled and condensed into distilled water. Restriction of air flow
(such as a closed cupboard) will result in a hot ambient air build up which will not
allow all of the steam to condense into distilled water and some water production
may escape as steam into the atmosphere through the charcoal filter or volatile
gas release vent. This steam loss can also occur in hot summer periods or very
warm climates.
5. Heating Element and Boiler Cleanliness
As the water distiller removes impurities some of the impurities may cling to the
boiler tank and the heating element. Any of this scale may build up around the
heating element and actually insulate it, which will drastically decrease the
thermal efficiency of the heating element and require more time/energy to boil the
water, which will decrease the water production.
10 Factors That Will Affect Your Water Distiller
Production

10
6. Altitude
The water distiller is rated at the altitude of the manufacturer, which is
approximately 675m (2214ft) above sea level. Locations lower than this (closer
to sea level) will have reduced water production due to the higher boiling point of
water at higher atmospheric pressures at lower altitudes.
7. Operating Time, Warm-up Period & Suitable Storage
Whencheckingthe water distiller production,the starttimeshouldbewhenthefirstfew
drops of waterhave enteredthe charcoalfilter canister. Do not start timingwhen the
distillerturnsonas ittakesafewminutesfortheheatingelement,boiler tank andwaterto
heatup. Thedistiller production ratingdoes NOT accountforthistime butratherthe
continuousproductionafterthedistiller isuptotemperature. Ensurewhenchecking
production that you have suitable waterstoragefor holding the amount of water that will
beproduced (i.e.8or12US gallons),asmanydistillersdo nothavetankslargeenough
tostore24hoursofwaterproduction.
8. Manual Fill Boiling Tank Fill Level
When checking the water distillation production on manual fill water distillers (or
in automatic fill water distillers being used as manual fill) the amount of water
initially poured into the boiling tank will affect the production. Water should be
filled to the water level pin so that once the water is hot the maximum amount of
water can be distilled without having to refill. Under-filling the boiler will decrease
the amount of water distilled. Again, the warm-up time should not be included in
the production rate.
9. Boiling Tank Heating Element
In rare occasions the heating element voltage may not be correct. Ensure that
the voltage stamped onto the heating element flange on the outside front of the
heating element matches the voltage on the water distiller serial plate. Always
replace heating elements with the manufacturers supplied heating elements.
Other elements are available from hardware stores, home repair centres etc. that
look like the same element but they are almost always not the same. Even if the
voltage and wattage are the same, they usually have different wattage densities
and most likely different element sheath materials, which will result in premature
heater burnout in continuous water distillation of raw water. These heating
elements will also likely affect your water distillation capacity.
10. Combination of the above Factors
Often a reduced water distiller’s production is a combination of many or all of the
above factors. To ensure maximum production from your water distiller, keep
your water distiller clean and operate it in a well-ventilated area and use room
temperature feed water where possible.

11
Your water distiller operates the same as Nature’s hydrological cycle. See
the Hydrological Cycle Diagram below. Nature uses the heat of the sun to
vaporize surface water and draw it into the atmosphere leaving the impurities
behind. As the vapour cools it condenses and returns back to the earth as rain or
snow. When rain or snow falls it passes through smog, dust and many other
types of contaminants. These contaminants can be picked up by the falling rain
or snow. Additional contamination of water can occur when it moves through the
ground.
Hydrological Cycle Diagram
Water Distillers complete their own hydrological cycle. The advantage of
a water distiller over Nature is that the water is produced in a closed environment
free of pollution and contaminants.
Your water distiller uses the boiling tank to heat the feed water to create
steam. The steam rises from the boiling tank leaving almost all of the impurities
behind. The steam enters the condensing coil and is cooled by the fan. As the
steam cools it condenses into pure distilled water and is stored in a stainless
steel storage tank. The charcoal filter between the condensing coil and storage
tank removes any contaminants that boil at lower temperatures than the boiling
point of water. The impurities from the process remain in the boiling tank and are
drained to a suitable drain.
CONDENSATION
EVAPORATION
SMOG, DUST, ETC.
ROCK DEEP PERCOLATION
GROUND WATER
SURFACE WATER
HYDROLOGICAL CYCLE DIAGRAM
PRECIPITATION
Understanding How Pure Water is Produced

12
Before installing your water distiller it is important
to find a good location. Following the points listed
below will provide the best location for your water
distiller:
1. The water distiller must be plugged directly into a dedicated 110VAC, 15
Amp wall outlet.
2. The water distiller requires sufficient airflow around it to operate. The air
is used to cool the water distiller condensing coil. Locate the water
distiller in an area that will provide enough room for good air flow. Do not
place the water distiller in an enclosed area like a closet.
3. When using the Automatic Feed Water Line Connection to the water
distiller, locate the water distiller close to a household cold water line (after
a water softener if available).
4. Locate the water distiller where a pail or suitable container can be used
for the impurities drain. Close to a floor drain (sewer) is best especially if
the Automatic Drain Kit is installed.
5. When unpacking the water distiller and options note the sizes and
consider this when picking a installation location.
6. Locate the water distiller away from a bedroom or other area where the
noise of the water distiller may be undesirable.
7. Locate the water distiller close to the kitchen faucet area if the automatic
pump option is being used.
8. Locate the water distiller in an area that is clean and free of dust so the
cooling coils remain clean when the fan is drawing fresh air.
Finding a Good Installation Location

13
Your Water distiller has been shipped in one box. Any optional
accessories have been shipped in a separate box(s). The Water Distiller Box
Components Diagram below shows all of the parts that will be in the water
distiller box.
Water Distiller Box Components Diagram
Water Distiller Box Check List
Check
List
(A) 1 –Water Distiller Head and Storage Tank
(B) 1 –Sight gauge with valve (packed in cardboard) (Elite Model
Only)
(C) 1 –Parts Box with UNPACKING INSTRUCTIONS
(Water Distiller Parts Box Components Diagram is shown below)
(D) 4’ – 1” x 1 ¼” Drain Tube
(C) 1x
UNPACKING DISTILLER BOX DIAGRAM
(A) 1x
(B) 1x
(D) 1x
Unpacking Your Water Distiller

14
Water Distiller Parts Box Components for Compact, NT and Pro Models
Diagram
Water Distiller Parts Box Check List (Compact, NT and Pro Models)
Check
List
Part No.
(A) ---------- 1 –Sight Gauge and Valve
(B) 530159 1 –Sample Descaler / Cleaner
(C) 530158 1 –Sample Coconut Charcoal
(D) 530164 1 –Elbow –Valve Assembly, 1” MPT, Drain
(E) 530211 1 - Stainless Steel Canister
(F) 036005 1 –Valve Kit, Self Piercing
(G) 500319 1 –Boiling Tank Lid
(H) 054020 1 –1 ¼” Distiller Support Clip
(I) 010008 1 –No. 10 x 1” Screw
(J) 034014 1- 3/8” Stem Plug
(K) 080121 1 –1 ¼” Gear Clamp
(L) 052000 16’ – ¼” Feed Line
(M) 052002 4’–Sterilization Drip Tube
(N) 500282 1 –JG Removal Tool
(E) 1x
UNPACKING PARTS BOX COUNTER TOP MODEL DIAGRAM
(C) 1x(A) 1x
(H) 1x (I) 1x (J) 1x (K) 1x (N) 1x
(F) 1x(B) 1x (G) 1x
(M) 1x(L) 1x
(D) 1x

15
Water Distiller Parts Box Components for ELITE Model Diagram
Water Distiller Parts Box Check List (ELITE Model)
Check
List Part No.
(A) 530159 1 –Sample Descaler / Cleaner
(B) 530158 1 –Sample Coconut Charcoal
(C) 530164 1 –Elbow-Valve Assembly, 1” MPT, Drain
(D) 530211 1 - Stainless Steel Canister
(E) 036005 1 –Valve Kit, Self Piercing
(F) 500319 1 –Boiling Tank Lid
(G) 054020 1 –1 ¼” Distiller Support Clip
(H) 010008 1 –No. 10 x 1” Screw
(I) 080121 1 –1 ¼” Gear Clamp
(J) 052000 16’ – ¼” Feed Line
(K) 052002 4’–Sterilization Drip Tube
(L) 500282 1 –JG Removal Tool
1. Remove all loose pieces from the water distiller box and save all
packaging until all the parts are identified and located.
2. Check inside boiler tank and storage tank for any parts that may be
shipped in that area. If any parts are missing or if you have been given
the wrong part, DO NOT return the water distiller unit. Contact your dealer
for the required parts. They will be pleased to assist you.
3. Remove all protective plastic from water distiller head, storage tank,
boiling tank lid and storage tank lid.
(D) 1x
UNPACKING PARTS BOX FLOOR MODEL DIAGRAM
(E) 1x(B) 1x(A) 1x
(G) 1x (H) 1x (I) 1x (L) 1x
(F) 1x
(K) 1x(J) 1x
(C) 1x

16
Shipping Tie Removal Diagram
4. Refer to Shipping Tie Removal Diagram above. Cut/Remove the
shipping tie located on the top of the water distiller head. Be careful not to
scratch the water distiller when removing. This tie supports the cooling
coil during shipping only.
TOOLS REQUIRED FOR DISTILLER INSTALLATION
(A) (B) (C) (D)
10"
TOOLS REQUIRED:
For Water Distiller Installation
(A) Phillips screwdriver
(B) Slotted screwdriver
Water Distiller Installation Tools
SHIPPING TIE REMOVAL DIAGRAM
COIL SUPPORT TIE
WATER DISTILLER HEAD

17
1. Remove the sight gauge with valve from the cardboard packaging or parts
box.
Sight Gauge Installation Diagram
2. Refer to Sight Gauge Installation Diagram above. Remove the plastic
hex jam nut from the threaded body of the valve (leaving water gasket on
threads).
3. Remove the storage tank lid by holding down on the lid and turning the
black knob counter clockwise approximately five turns. Slide the lid to one
side and turn the knob and lid together while tilting. This should allow the
Tee Bar bracket under the lid to come out of the tank opening. Slide the
lid out.
4. Push the gasket tightly up against the valve.
5. Insert the threaded valve end with gasket attached through the hole on
the front of the storage tank.
6. While holding the sight gauge with valve in the storage tank hole with one
hand, insert your other hand with the plastic hex jam nut through the
storage tank lid opening.
7. Place the hex nut onto the threaded end of the valve.
8. Hand tighten the hex nut clockwise onto the valve.
Storage Tank Assembly
3/8" JAM NUT
#10-24 MACHINE SCREW
STAINLESS SCREW
GASKET
THREADED FAUCET END
SIGHT GAUGE
DRAIN VALVE
VALVE HANDLE
STORAGE TANK
SIGHT GAUGE INSTALL DIAGRAM

18
Tightening Sight Gauge Nut Diagram
9. Refer to the Tightening Sight Gauge Diagram above. To fully tighten the
nut, turn the valve counter-clockwise1/4 of a turn to the start position and
ensure that the jam nut is still hand tight. Holding the jam nut, turn the
valve clockwise until upright at the finish position.
10.Remove the #10-24 screw from the sight gauge support and install
through the inside of the storage tank using a Phillips screwdriver.
Tighten until snug only.
11.Make sure the storage tank is free from any dust or material and replace
the storage tank lid.
12.Check for leaks when storage tank begins filling.
1. Refer to the Manual Drain Valve and Tube Installation Diagram below.
Thread the ball valve assembly onto the drain elbow nipple assembly and
turn clockwise until tight. Position as shown.
NOTE: The sight glass is fragile, do not push on the gauge (push on
bottom near threaded area).
Manual Drain Valve and Tube Installation
NOTE: If you have purchased the Automatic Electric Drain Kit, Go to the
Automatic Electric Drain Kit Installation section of the guide and install
it now.
SIGHT GAUGE INSTALLATION DIAGRAM

19
Manual Drain Valve and Tube Installation Diagram
2. Push the drain tube onto the ball valve assembly and secure with gear
clamp using a slotted screwdriver. Run the drain tube to a container or
suitable floor drain like the sewer.
Water Distiller Leveling Diagram
Water Distiller Leveling
(NT, Elite and Pro Models Only)
BACK OF THE
DISTILLER
MANUAL DRAIN VALVE INSTALL DIAGRAM
DRAIN ELBOW & NIPPLE ASSEMBLY
(SHIPPED WITH MACHINE)
GEAR CLAMP
(SHIPPED IN PARTS BOX)
TUBE
BALL VALVE ASSEMBLY
(SHIPPED IN PARTS BOX)
LEVELING APPLIANCE FEET DIAGRAM
See Water Distiller Leveling Diagram.
Screw the rear adjustable appliance feet
in or out so the water distiller is level and
does not rock and is secure on all four
legs.

20
1. Select a household water line to supply the water distiller with feed water,
be sure to use a cold water line and pick a suitable location closest to the
water distiller location.
Feed Water Line Installation Diagram
Feed Water Line Connection
TOOLS REQUIRED:
For Feed Water Line Connection
(A) Slotted Screwdriver
(B) Drill with 1/8” drill bit (For
Steel or Brass Tubing)
(C) ½” Open End Wrench or
(D) Pliers
(E) JG Removal Tool
(F) Utility Knife
NOTE: If you have a water softener be sure to connect the water distiller
feed line on the outlet side of the softener as soft water will reduce
cleaning and maintaining of the water distiller. Using a water supply from
the outlet of a hot water heater is not recommended as the benefit of using
hot water is very small because only small amounts of water enters the
boiling tank of the water distiller.
AUTO WATER FILL INSTALL DIAGRAM
1/4" WATER FEEDLINE
ELBOW
COLLET
LOCKING CLIP
BOLTSSADDLE VALVE COMPRESSION
NUT
INSERT
FERRULE
RUBBER
SEAL
LOWER CLAMP
NUTS COPPER TUBE-NO DRILLING
*STEEL TUBE-DRILL 1/8"Ø
*BRASS TUBE-DRILL 1/8"Ø
*SHUT OFF WATER SUPPLY
WATER SUPPLY TUBE
TOOLS REQUIRED FOR WATER FEEDLINE CONNECTION
(A) (C) (D)
1/2"
OR
(B) (E) (F)
