LIFEtool SOLUTIONS IntegraMouse Plus User manual

IntegraMouse Plus
®
Quick Guide (v1.0)
to
COMMISSIONING
CLEANING
CONTROLLING
English (EN)

2
Quick Guide COMMISSIONING
Mounting of IntegraMouse Plus
Install mounting system
2
Remove the locknut
3
Choose one of the 3 openings in
the bracket
4
Tighten the locknut
5
Bring the device into the desired
working position
6
Insert mouthpiece in a straight
movement
1

3
Turn the computer on
7
Plug the USB-cable into the
IntegraMouse Plus
8
Plug the USB-cable into the
computer
9
Your IntegraMouse Plus is ready to use!
Look at www.youtube.com for detailed training videos.
IntegraMouse Plus in cable-connected mode
Die Inbetriebnahme der
IntegraMouse Plus im Funkmodus
lesen Sie auf der nächsten Seite
All further steps are executed
automatically:
• Charging the battery of
IntregraMouse Plus
• IntegraMouse Plus turns on
automatically (green LEDs light up)
• IntegraMouse Plus calibrates shortly
(green and blue LEDs flash
alternately)
Please do not touch the
IntegraMouse Plus during
calibration!
• Your computer installs the
IntegraMouse Plus as a standard
mouse
You will find a Quick Guide to setting the IntegraMouse Plus up in wireless mode on the
next page.

4
Quic
k
Guide to Commissioning in Wireless Mode
Using IntegraMouse Plus Connect (IM+ Connect)
Insert IM+ Connect into one of the
computer´s USB ports
2
Connection is established, green
LED on the IM+ Connect lights up
Turn on the IntegraMouse Plus by
pressing the On/Off button
1
IntegraMouse Plus calibrates,
the LEDs flash alternately
Charge the battery with the
enclosed power pack
When both LEDs light up green,
the battery is fully charged
In order to use wireless mode, make sure the battery of IntegraMouse Plus is
charged!

5
General Notes on Cleaning
Use of IntegraMouse Plus in the clinical sector
• In the clinical sector use the mouthpiece, the membrane and the
silicone tube as disposable products
• The interval between changes of the mouthpiece must be
determined by a doctor or by specialist staff
• In case of suspected infectious diseases please take special safety
precautions
Disinfection by wiping
• Use only surface disinfectants which are suitable for LEXAN
polycarbonate and aluminium
• We recommend by Schülke & Mayr (www.schuelke.com):
− Mikrozid Sensitive Liquid or
− Mikrozid Sensitive Wipes
Do not use steam sterilization
• The mouthpiece and other components of the IntegraMouse Plus
are not allowed to be cleaned with steam, wet or gamma
sterilization
Do not use aggressive cleaning agents
• Never use aggressive cleaning agents, this will destroy the surface of
the components
Do not immerse in water
• Never immerse the IntegraMouse Plus and their electronic
components in water and never use running water – otherwise you
could destroy the device
More detailed information can be found in the original instuctions.
Correct cleaning of components
• The parts of IntegraMouse Plus, mouthpiece, IM+ Connect, power
pack including cable and stand can be cleaned by wiping with a
damp, lint-free cloth
• Clean the components once a week

6
QuickGuide CLEANING the mouthpiece
& REPLACING the membrane
Pull mouthpiece off in straight
movement
1
Remove the membrane and
dispose of it
2
Bring water to the boil
3
Insert mouthpiece with a spoon
4
Cleaning- and disposal-interval of the mouthpiece:
Cleaning:- at least once a week
- more often in case of illness
Dispose: - if damaged or signs of wear visible
- within six months
Disposal-interval of the membrane:
Always dispose of the membrane, no cleaning is recommended

7
Ensure the mouthpiece is
completely covered with water
5
Leave mouthpiece for at least 5
minutes
6
Remove mouthpiece with a spoon
7
Leave mouthpiece to dry and cool
8
Place new membrane on
mouthpiece
9
Insert mouthpiece in a straight
movement
10

8
M - Mouse J - Joystick C - Cursor
Enter-
ke
y
Butto
n 2
Button
1
CALIBRATE
User: puff 3 sec. – sip 3 sec.
Assistant: press ON/OFF briefly
Functionality of IntegraMouse Plus
The IntegraMouse Plus offers three operating modes, standard mode is
mouse mode
More detailed information can be found in the instructions for use .
Sip
Puff
DOUBLE CLICK
Briefly sip 2x
Move mouthpiece UP
Move mouthpiece DOWN
Move mouthpiece LEFT
Move mouthpiece RIGHT
Left
click
Right
click
Space-key
ESC
Puff 3 sec. – sip 2x – puff 1x
CHANGE MODES
Puff 2x – sip 2x – puff 1x
LEDs start blinking
DRAG & DROP
Sip and keep air in the mouthpiece
AWAKE
move the mouthpiece
Energy-saving-mode starts, when
device is not used for 30 secs. (LEDs
go out)
POWER OFF
Press ON/OFF 3 sec.
Switch off: only in battery-mode and
mouse must be active (green LEDs
on)
