LIFOS GO 200Ah User manual
FRONT
Disposal
Disposal of a used or damaged Lifos Go 200Ah battery must be done at a certied recycling
location. There are many of these nationwide – please see www.lifos.co.uk for details.
Warranty
A Lifos Go 200Ah battery is supplied with a 5-year warranty from the date of purchase (please keep
your proof of purchase) or 2750 battery cycles, whichever comes rst. Note a full battery cycle is
determined by a fully discharged Lifos Go 200Ah (down to 10% of its gross capacity) and charged to
100%. The 5 year warranty period assumes no more than one full cycle per 24hr period. In the event
of a valid warranty claim the manufacturer will, at its discretion, supply a new or re-conditioned Lifos
Go 200Ah battery dependent on how many years have passed since the date of purchase or how
many cycles the battery has undertaken. This warranty is not transferable.
Conditions
a. Any warranty claim can only be validated by a proof of purchase.
b. The warranty is invalid if the battery has been subject to misuse, abuse or physical damage.
c. This Lifos Go 200Ah battery must be of the correct size, design and capacity for the intended
application.
d. The warranty is invalid if the correct size fuse is not tted to all cables connecting to the
+ terminals on Lifos Go 200Ah.
e. The battery should be installed and operated at a temperature not exceeding the batteries
design limits as noted on the previous page and on the battery itself.
f. The warranty shall be voided if the battery becomes unserviceable due to: re, freezing, abuse,
alteration, modication or it suffers from an over discharged state.
g. Installation of the battery must be performed by a responsible adult.
Warranty claims
1. Contact the original point of purchase for instructions.
2. The battery must only be returned in compliance with the transport and packaging regulations
ruling at the date of return. Failure to do this may result in the carrier refusing to ship the battery.
Lifos Go 200Ah safety and product limitations
•Keep out of the reach of children
•Do not under any circumstances disassemble this battery
•Do not immerse the battery in liquid
•Do not use the battery with damaged cables or terminals
•This battery is not designed for cranking and starter Applications
• Do not expose the battery to re or crush or puncture its casing
•Do not mix Lifos Go 200Ah batteries with other brands of batteries, whether in series or parallel
• Do not short circuit battery positive (+) and negative (-), which can cause spark, re, or even explosion.
Limited liability
The manufacturer nor any of its employees, agents,
distributors or resellers are liable for any third-party
damage howsoever caused. The extent to which the
manufacturer is liable to a customer is limited to the
purchase price paid by the customer for the Lifos battery.
We want your photos and videos! Here is your chance for you and your Lifos battery to be a star!
Just send in pics or videos of you and your Lifos in a great location and if selected we will not only give you
everlasting recognition on our online favourite users wall of fame but we will send you send you an Official Lifos Mains
Charger worth £20 completely free! Please send to [email protected]o.uk including your address details and best of luck!
Note – we cannot guarantee to publish every entry and only those selected by our marketing department for publication
will be awarded an Official Lifos Mains Charger. By providing your images you automatically grant us the right to use these
images/videos howsoever we see fit.
www.lifos.co.uk
BACK FRONT
200Ah
Lifos Go 200Ah quick user guide
This guide should be read in conjunction with the main instructions included overleaf,
but the following points will enable speedy deployment of your Lifos Go 200Ah battery.
1. Your Lifos Go 200Ah will be supplied partially charged. This is because transportation regulations
prohibit shipping a fully charged lithium battery. Please ensure the battery is fully charged before
rst use.
2. Please ensure you depress the On/Off button before its rst charge. It will be clear the battery
is active because the indicator will glow green. If you intend to deactivate the battery or leave
it for long periods without using it, please press the button again to turn it off. This process helps
prevent natural power loss and will keep your battery in top condition. Note, if the power button is
in the On position but has not had any charge or discharge for a period of 12hrs the indicator light
will turn off. This conrms the battery is in a dormant state to conserve energy but will instantly
switch back on again once a load or charge is recognised.
3. Lifos Go 200Ah can be charged by a solar panel (via a suitable charge controller), vehicle
alternator (via a suitable DC to DC converter) and any lead acid or lithium iron phosphate battery
charger. In general, any charger with a voltage range of 11.2v to 14.7v will charge Lifos, however, be
aware that some chargers that do not reach 14.7v may not 100% fully charge your Lifos battery.
Do not use chargers with an upper cut-off voltage higher than 14.7V i.e. those for designed for
4. The Battery Management System (BMS) within each Lifos Go 200Ah battery may give inaccurate
data via the Bluetooth App until ten charge and discharge cycles have taken place. This is
because during these ten cycles the BMS is balancing and calibrating the four lithium cells within
Lifos Go 200Ah.
5. If more than one Lifos Go 200Ah has been purchased and you wish to connect them in series,
parallel or both please see page 1 of this manual for detailed instructions.
6. Always use an appropriate sized cable and fuse based upon the expected current of your load.
This ensures the electrical circuits within the load and the battery are protected at all times. Fit
the fuse/s as close to the Lifos Go + terminal as possible. If in doubt consult a qualied electrician
Data sheets, MSDS, other documents and FAQ’s can be accessed from www.lifos.co.uk
User manual
Lithium Iron
Phosphate Battery
(LiFePO4)
Important: please read before rst use. Technical helpline 01684 774 000
Accessing the Lifos App
The App is available for all Apple and Android devices. Search the
Apple App store for Lifos and down load for free. If using an Android
device go to Google Play search Lifos and down load for free. The
App will give you full visibility of your Lifos Go 200Ah battery and its
performance. Your device connects to the Lifos App via Bluetooth so
you need to be within 10m of the battery to access its data. Each time
you wish to view the data you will need to log on via the App but this is
quick and easy.
If you are using more than one Lifos Go 200Ah battery, you will not be
able to identify each battery separately if they are in close proximity
to one another.
If you have connected your batteries in parallel then you only need to
look at any one battery (it does not matter which one) to see the total
power for the complete battery bank (SOC).
If you have connected your batteries in series then you also only need
to look at one battery to see the total power for the complete battery
bank, however you will only see the voltage of the battery bank from
the single battery and not the battery bank as a whole.
If you have any questions about this connectivity please visit
www.lifos.co.uk for help.
NOTE – only one Apple/Android device at a time can be connected
to each battery.
Lifos Go 200Ah battery load limitation
The Lifos Go 200Ah battery is perfectly suited to heavy DC loads such as motor movers, but its
Battery Management System (BMS) will not allow any load higher than 150A or 1875w at 12.5vDC
or 1500w at 230vAC through an inverter. It should be noted that inductive loads, even if rated at
1875w may not be powered by the Lifos Go 200Ah because the inrush current of these devices
can often be many times the rated load during initial start up. Examples of inductive loads are
microwave ovens.
Resistive AC loads (via a suitable 12vDC to 230AC inverter) that can be powered by Lifos Go
200Ah include: toasters, travel kettles, travel irons, hair dryers, heaters etc (Max 1500W).
NOTE – in the event an AC load higher than 1500w is connected to Lifos Go 200Ah the battery
will shut down and will not power the device but the battery will not be damaged because its
BMS will protect it. In this circumstance the Lifos Go 200Ah will be instantly reset so it is able to
power loads within its approved power range as noted above.
Connecting up your Lifo s Go 200Ah battery
When connecting to the Lifos Go 200Ah using the bolts and washers provided, we recommend a
torque setting of 8Nm.
Please connect the Positive (+) connection rst before connecting the Negative (–) connection.
In all circumstances, an appropriate sized fuse must be tted to all positive cables being
connected to the + terminals of Lifos Go 200Ah as failure to do so could result in damage to
either load circuit or Lifos battery in the event of an accidental dead short etc. Please consult a
qualied electrician if guidance is needed regarding fuse or cable size appropriate to your load.
Disconnection is the reverse process, Negative (–) rst, Positive (+) last. (This is standard
disconnection procedure for connection and disconnection of batteries and will help to avoid
short circuits).
Thank you for purchasing this advanced lithium iron
phosphate (LiFePO4) battery. Combining the very
best lithium cells along with an outstanding battery
management system ensures this battery will
provide you with incredibly long-lasting power in
a super lightweight package.
A few tips on how to get the best from your Lifos Go 200Ah battery:
•Protect the battery from direct sunlight although it will work well in
a wide temperature range (-20 to +60 degrees C).
•Lifos Go 200Ah has an IP rating of 54. This means that water splashes from
all directions, such as light rain, and dust ingress will not damage the battery.
This does not mean the battery is waterproof and should be protected from
the elements particularly if permanently used outdoors.
•Observe the correct polarity otherwise permanent damage could be caused
– the battery casing is marked with + and –.
•Don’t short circuit Lifos Go 200Ah otherwise permanent damage could be caused.
•Lifos Go 200Ah can be connected in Parallel (Fig.1). You are able to connect
up to 4 Lifos Go 200Ah batteries in parallel giving you a battery bank capacity
of 420Ah (105A x 4).
•Lifos Go 200Ah can be connected in Series (Fig.2). You are able to connect up
to 4 Lifos Go 200Ah batteries in series giving you a battery bank voltages of
12v (single battery), 24v (2 x batteries) 36v (3 x batteries) or 48v (4 x batteries).
•Lifos Go only generates limited heat and no noxious gases.
The Lifos Go 200Ah can be connected up in parallel or series when needed but
only in the below congurations:
Please note – when connecting multiple batteries, fully charge each battery and
allow at least 6 hours to ‘settle’ and then check each is within 50mV of each other.
Once all are within this tolerance they may be connected to one another.
•Most mains lead acid battery chargers will charge the Lifos Go 200Ah but some
smart chargers might only charge up to 85%. If this is the case we recommend getting
a new charger, please see our website for recommendations on the FAQ pages. However you
will not cause any damage to the battery if using your old charger. For DC – DC charging
please also check our website for recommendations on the FAQ pages.
•Lifos Go 200Ah can be used if it is positioned on its side but will give best performance
if it is positioned with its terminals facing upward.
NOTE – do not mix new Lifos Go 200Ah batteries with old batteries, whether in series or parallel.
Storage of Lifos Go 200Ah
Lifos Go 200Ah has an extremely low rate of self-discharge but if you intend not to use the battery for
an extended period please charge the battery to approx. 80% and turn the power button off prior to
storage. It is recommended to re-charge the Lifos Go 200Ah once every 3 months.
NOTE – allowing the battery to over discharge (+3 months since its last charge) can lead to
a shortened life, could damage the battery and invalidate your warranty.
Technical helpline 01684 774 000
Lifos App
Lifos App Icon
Fig.1
A
C
B
D
LOAD
Fig.2
LOAD
A
C
B
D
Parallel Series
1 (12v) 2 (24v) 3 (36v) 4 (48v)
1 YES YES YES YES
2 YES YES YES YES
3 YES YES NO NO
4 YES YES NO NO
