Lightcloud LCLC3/D10 User manual

Luminaire Controller
LCLC3/D10
®
1 (844) LIGHTCLOUD
1 (844) 54 4-4825
[email protected]
WE ’R E HERE T O HELP :

Hello
Lightcloud is a wireless lighting
control system. The Lightcloud
Luminaire Controller is a
remotely controlled switching
and dimming device that can
be installed into luminaires.
Product Features
Wireless Control & Configuration
Switching up to 3A
0-10V Dimming
Power Monitoring
Patent Pending

Contents
Actuator Module, P/N 24586
Radio Module, P/N 24572
Wire Nuts
x 4 x 2
Instruction Manual
O-ring
1.5 in
3.7 in
1.3 in
2.0 in
2.0 in
1.0 in

What You Need
Lightcloud Gateway
A Lightcloud installation requires
at least one Lightcloud Gateway
to manage your devices.
Specifications & Ratings
PART NUMBER
LCLC3/D10
INPUT
120/277VAC, 50/60Hz
CURRENT DRAW
<0.6W(Standby)–1W(Active)
LOAD SWITCHING CAPACITY
LED, CFL, Tungsten 120/277VAC 500W; Magnetic
120VAC 264VA, 277VAC 500VA; Resistive/Induc-
tive 120VAC 500W
OPERATING TEMPERATURE:
-40ºC to +50ºC max temp
ACTUATOR MODULE OVERALL
DIMENSIONS:
3.7” x 1.5”x 1.3”
RADIO MODULE OVERALL
DIMENSIONS:
2” x 2” x 1”
WIRELESS RANGE
Line-of-Sight: 700 feet Obstructions: 70 feet
INDOOR USE ONLY
DAMP LOCATION
1 (844) LIGHTCLOUD
or 1 [phone]
[email protected]
WE ’RE HERE TO HELP:

Setup & Installation
1
1a
Turn Off Power
OFF
OFF
Find a Suitable Location
Use these guidelines when installing devices:
• If there is a clear line of sight between a Luminaire Controller and
another Lightcloud device they can be placed up to 700 ft apart.
• If a Luminaire Controller and another Lightcloud device are
separated by ordinary drywall construction, try to keep them
within 70 ft. of each other.
• Brick, concrete and steel construction may require additional
Lightcloud devices to go around the obstruction.
WARNING
Lightcloud Ga tewa y
<= 100 ft.
Add an additiona l Lightcloud
Device to extend network range
around corners BRICK,
CONCRETE OR
METAL WALL
DRYWALL
OR SIMILAR

2
2a
Install the Luminaire Controller
(For Luminaires Pre-Installed with the Luminaire
Controller, Skip to Step 3)
Fixture Installation with
Actuator Module Inside
If the interior of your luminaire can accommodate the dimen-
sions of the actuator module, install the actuator module inside
the housing, and attach the radio module to the outside of the
housing via a knockout.
PINK
PINK
RED
PURPLE
PURPLE
WHITE
INSIDE JUNCTION BOX
Load or
Fixture BLACK
LONG, BLACK
MODULAR CABLE
WHITE
/ RED
WHITE
BLACK
120-277 VAC
ACTUATOR
RADIO
SHORT, GREY
MODULAR CABLE
INSIDE LUMINAIRE
Load

Setup & Installation (cont’d)
Install Luminaire
3
Install the luminaire with integrated Luminaire Controller as
normal, allowing for any room to accommodate the external
radio module of the LCLC3/D10.
Installation with Junction Box
If the interior of your luminaire cannot accommodate the actuator
module, the Luminaire Controller can be mounted into a junction
box, with the radio module always outside any metal enclosure.
2b
PINK
PINK
RED
PURPLE
PURPLE
WHITE
INSIDE JUNCTION BOX
Load or
Fixture BLACK
LONG, BLACK
MODULAR CABLE
WHITE
/ RED
WHITE
BLACK
120-277 VAC
ACTUATOR
RADIO
SHORT, GREY
MODULAR CABLE
INSIDE JUNCTION BOX

Labeling Your Device
When installing devices, it’s important to keep track of their De-
vice IDs, installation locations, panel/circuit #s, dimming function,
and any additional notes. To organize this information, use the
Lightcloud Installer Application (A) or Device Table (B).
Install the LC Installer Application:
LC Installer is available for iOS and Android.
Scan & Install Lightcloud Devices:
Scan each device and assign to a room. It’s recommended that
each device is scanned just before or just after being wired so no
devices are missed. The more notes that are given, the easier it is
to commission the system.
Send to RAB:
Once all of the devices have been added and organized, submit
the information for commissioning.
4
4a Lightcloud Installer Application
Device Scanner
Enter Manually
PLACE RECTANGLE TO FIT CODE ON LABEL
Scan Device Code
Device Info
SaveCancel
Device ID 0013A20040B62A4A
Location Office
Zone Name Office Lights
Dimmable
Power Monitoring
Enter Device Information Repeat for Additional Devices
Devices
Add DeviceSend to RAB
Office Light - ID 0013A20040B62A4A
Controller
Office Light - ID 0013A20040B62A4B
Sensor
Office Light - ID 0013A20040B62A4C
Dimmer
Office Light - ID 0013A20040B62A4D
Daylight
Office Light - ID 0013A20040B62A4E
Touch
Send to RAB
Device Scanner
Enter Manually
PLACE RECTANGLE TO FIT CODE ON LABEL
DE V I C E I D s
DEVICE 1D ZONE NAME
PANEL/
CIRCUIT # DIMMING

Confirm Device Connectivity
Confirm Status Indicator is Solid Green (see details on
the right)
6
Setup & Installation (cont’d)
Two Lightcloud Device Tables are provided with each Gateway: one
that you can attach to your panel and one to hand off to a building
manager. Attach the Device Identification stickers included with
each device to a row, then write in additional information, such as
Zone name, Panel/Circuit Number, and whether or not a Zone
uses dimming.
Power Up
To add devices to your Lightcloud network, call RAB at
1 (844) LIGHTCLOUD, or email us at [email protected]
5
Device Scanner
Enter Manually
PLACE RECTANGLE TO FIT CODE ON LABEL
Scan Device Code
Device Info
SaveCancel
Device ID 0013A20040B62A4A
Location Office
Zone Name Office Lights
Dimmable
Power Monitoring
Enter Device Information Repeat for Additional Devices
Devices
Add DeviceSend to RAB
Office Light - ID 0013A20040B62A4A
Controller
Office Light - ID 0013A20040B62A4B
Sensor
Office Light - ID 0013A20040B62A4C
Dimmer
Office Light - ID 0013A20040B62A4D
Daylight
Office Light - ID 0013A20040B62A4E
Touch
Send to RAB
Device Scanner
Enter Manually
PLACE RECTANGLE TO FIT CODE ON LABEL
D E V I CE I D s
DEVICE 1D ZONE NAME
PANEL/
CIRCUIT # DIMMING
4b Device Table

DEVICE IDENTIFICATION
BUTTON
POWER
• Press once to highlight this
device in the Lightcloud
Application
• Press twice to toggle circuit
on and off
• Press twice and hold to
set dim level
• Press and hold for 10 seconds
to remove this device from a
Lightcloud network
• Lit when device is on
SIGNAL INDICATOR
Illuminates when the device
receives a message and
indicates the strength of the
signal by number of blinks:
3 - Best signal
2 - Acceptable signal
1 - Unacceptable signal
Consult the “Finding a Location”
section for more information
STATUS INDICATOR
Solid GREEN when connected to
your Lightcloud network. Blink-
ing RED when not connected.
The device will automatically
continue trying to connect to a
network in Setup Mode.
Commission Your Devices
Log on to www.lightcloud.com or call
1 (844) LIGHTCLOUD
7
