General vacon • 3
24-hour support [phone] • Email: [email protected] 1
1. GENERAL
Using these instructions, you can enhance the enclosure protection class of your IP21 class frequency
converter to IP54. Such a higher protection level may be necessary when the frequency converter is
used in such ambient conditions that might constitute a risk for the proper functioning of the
converter (moist, dust).
According to standard IEC 60529 (EN 60 529), the IP54 frequency converter enclosure provides
protection against dust and water sprayed from all directions. Limited ingress of both is permitted.
2. VACON IP54 KIT CONTENTS
The contents of the IP54 kits for different frames are shown in the following pictures.
2.1 FR4 (Type designation code: NXIP54FR4)
Figure 1. Contents of IP54 kit for FR4
1IP54 enclosure for FR4
2IP54 cable cover with fan
3Cable entry flange with rubber grommets
4Cable extension for fan
5Plastic sealing
6Screws (4x10)
7Warning sticker
NOTE: An IP54 enclosure does not protect the frequency converter against strong jets of water or
the effects of immersion.
1
2
3
5
6
7
4

4 • vacon Vacon IP54 kit contents
Tel. [phone] • Fax [phone]
2
2.2 FR5 (Type designation code: NXIP54FR5)
Figure 2. Contents of IP54 kit for FR5
1IP54 enclosure for FR5
2IP54 cable cover with fan
3Cable entry flange with rubber grommets
4Cable extension for fan
5Rubber sealings
6Screws (4x10)
7Warning sticker
2.3 FR6 (Type designation code: NXIP54FR6)
Figure 3. Contents of IP54 kit for FR6
1IP54 enclosure for FR5
2IP54 lid with fan
3Cable entry flange with rubber grommets
4Cable extension for fan
5Rubber sealings
6Screws (4x10)
7Warning sticker
1
5
1
2
3 6
7
5
2
3
5
6
7
7
4
4

Installation vacon • 5
24-hour support [phone] • Email: [email protected] 3
3. INSTALLATION
These instructions guide you through the installation of the IP54 kit that you have purchased for your
FR4, FR5 or FR6 size frequency converter enclosure class IP21. NOTE: If you have purchased your
converter before March 2004, follow the installation instructions under Error! Reference source
not found..
Please note the white triangles in the lower left corners of the installation pictures. They designate
the frame(s) the picture applies to. If no triangles exist, the step is applicable to all frames.
3.1 Installation instructions #1
1. Detach the fan. 2a. Insert the plastic sealing (#4). 2b. Insert the rubber sealing
3. Carefully re-install the fan en-
suring that the connector clip fits
accurately. DO NOT SLAM, DO NOT
FORCE!!
4a. Remove the plastic cover of
the frequency converter and open
the small lid on the power unit
cover. Leave the opening uncovered.
4b. Remove the plastic cover of
the frequency converter and open
the small lid on the power unit cover.
5. Seal the air inlets with the rub-
ber sealings (#4). Leave the open-
ing uncovered.
6. Fix the IP54 lid with fan (#2) on
the power unit cover.
7. Open the control cable cover
and remove the cable entry flange.
FR4
FR6
FR4
FR5
FR5
FR4
FR5
FR5
FR6 FR4
FR5
FR6

6 • vacon Installation
Tel. [phone] • Fax [phone]
3
8. Remove the power cable cover
and detach the grounding rack
9. Take the IP54 cable cover and
connect the fan power cable to
connector marked with 'FAN'
10. Use the attached screws to fix
the IP54 cable cover with fan and
the grounding rack.
11. Open the cover of the FR6
power unit.
12. Connect the other end of the fan
cable extension to the +24V terminal
on the power board.
13. Push the other end of the
extension cable through the cover,
fix the cover and connect finally the
fan power cable to its extension.
14. Fix the IP54 cable entry flange
placing it with the old grommets
down and the new ones up. Fix the
lower side with screws from the old
flange.
15. Fit the IP54 cover in its place.
Keypad end first, then cable end.
16. Use the attached screws (#5) to
fix the IP54 cover on the upper end
of the converter.
17a. Then fix the screws (4x10) on
the lower end of the converter.
Note the different fixing places
for different frames.
17b. Tighten the four screws on the
IP54 cover to fix it in its place.
18. Attach the warning sticker
(#6/ #7) on the IP54 cover.
FR4
FR5
FR6
FR5
FR4
FR4
FR5
FR6FR6
FR6
FR4
FR5
FR4
FR5
FR4
FR5
FR4
FR5

Installation vacon • 7
24-hour support [phone] • Email: [email protected] 3
3.2 Information sticker
Each IP54 upgrade kit delivered by the factory includes a sticker (shown below).
Please check
IP54/Collar (1) and mark the installation date (2) on the sticker. Finally, attach the
sticker on your drive.
Drive modified:
Optionboard: NXOPT................
IP54 upgrade/ Collar
in slot:
Date:...................
A B C D E
EMC level modified: H to T/ Tto H Date:...................
Date:...................
1 2

Document ID:
Rev. A
Vacon Ltd
Member of the Danfoss Group
Runsorintie 7
65380 Vaasa
Finland
www.danfoss.com
