Lighting & Electronics Houselite Installation and operating instructions

WARNING:Disconnect fixture before any service is
performed. Do not open the fixture while it is still
plugged into the power source.
AssemblyInstructions
Clamp Mount:
Materials required:
1 - LED HouseliteTM/WorkliteTM
1 - Standard Theatrical Style Clamp
1 - Cupped Spring Washer
1 - 1/2-13 x 1-1/2 Hex Head Bolt
If the fixture is to be mounted with a clamp, it is attached to
the stud mounted on the top of the driver box by removing
the hex bolt on the bottom of the clamp and then spinning
the clamp onto the stud.
Yoke Mount (Pre-assembled):
Materials required:
1 - LED HouseliteTM/WorkliteTM
1 - Yoke
1 - 5/16-18 Tee Handles
1 - 5/16-18 Hex Bolt
2 - Cupped Spring Washers
2 - Fibre Washers
If the fixture is to be mounted with a yoke, it is attached to
the ends of the driver box using a tee handle on one side and
the hex bolt on the other, cupped washer, and fibre washers
according to the diagram above.
Pendant Mount:
Materials required:
1 - LED HouseliteTM/WorkliteTM
1 - Pendant Pipe
1 - Canopy
2 - Hex Nuts
For pendant mounting, remove the circular cover on top of
the fixture head. Pass the pendant pipe through the hole in
the cover and secure with a hex nut. Thread the cable from
the fixture head through the pipe until it exits the other end.
Insert the pendant pipe through the driver box and secure with
the second hex nut. Make the electrical connection within
the driver box and secure the cover on the head and box.
HouseliteTM/WorkliteTM
Congratulationson purchasing the LED
HouseliteTM/WorkliteTM. If this is your first LED
fixture, brace yourself for a whole new world of
convenience and control. With a design incorporat-
ing qualities any application can appreciate, we
present to you a light-weight, compact, customizable
light fixture to serve countless demands.
The HouseliteTM/WorkliteTM is an LED fixture
designed for performance, adaptability and conve-
nience. Already cool-running and versatile, LED
technology continues to improve and provide an
efficient source of light, ready to be worked into your
theatrical or architectural application. Minimum
maintenance and zero lamp replacement makes this
fixture ideal for hard-to-get-to places.
Eachfixtureincludes:
- LED HouseliteTM/WorkliteTM Fixture
- Assembly/Operation Instructions
- Mounting Hardware
Lighting & Electronics, Inc.
91 McKinley Street
Market Street Industrial Park
Wappingers Falls, NY 12590
Tel [phone]
Fax [phone]
[email protected]
www.le-us.com

LampAddressing-DMXonly
The LED HouseliteTM/WorkliteTM allows for
three sets of two rings each of LEDs to have a unique
DMX address, allowing for very localized control on a
DMX network. The addressing is completed by
setting the switches on the cover of the driver box
assembly. Addresses can be assigned per seperate
instruction information included with this fixture.
LampReplacement
Lamp replacement is not necessary. Your LED fixture
is equipped with LEDs with an expected life of greater
than 50,000 hours. If a LED fails, contact the factory
to determine warranty status and arrange for repair or
replacement.
WARNING:Do notattempt to repair or replace LEDs.
This action may void your warranty.
OperatingInstructions
Three basic versions of the LED HouseliteTM/
WorkliteTM are manufactured:
1. Version one is the Non-Dimming model of the
fixture. All of the standard attributes of the fixture in
terms of intensity, spread, voltage, wattage, estimated
life and color temperature are identical to the other
two versions with the exception of dimmability.
To operate, plug the fixture into a power source. The
fixture will simply turn on. Unplug the unit from the
power source to turn off. This fixture is not equipped
with control capabilities. (Model number: WKLT/
HSLT-LED-NON-DIM).
2. The second model is the 0-10 volt dimming
version. It has the same features as the non-dim
version but includes the dimming control feature.
Again, all of the standard attributes of the fixture in
terms of intensity, spread, voltage, wattage, estimated
life and color temperature are identical to the other
two versions.
To operate, plug the power cord into the power
source and connect the dimming cable to an appropri-
ate0-10V dimming module (not included). (Model
number:WKLT/HSLT-LED-DIM).
3. The third model is configured specifically to use
DMX 512 protocol. Again, all of the standard
attributes of the fixture in terms of intensity, spread,
voltage, wattage, estimated LED life and color
temperature are included in this model. In addition,
this version operates on 3 DMX channels allowing
maximumcontrol over the120 - 1.25wLEDs. The first
channel controls the inner-most two rings of LEDs,
the second channel controls the middle two rings and
the third, the outer-most two rings. This unit also has
power passthru and 5-pin M/F XLR.
To operate, the user can select the channels they
would like to use by manipulating the switches on the
face of the driver box cover. (See the separate
information sheet enclosed for driver specification
and channel setting procedures.) Plug the power
cord into the power source and connect the control
via DMX 5-pin cable to the fixture driver box. Mul-
tiple fixtures can be “daisy chained” together by
plugging the next fixture into the first and continuing
the DMX connection. (Model number: WKLT/HSLT-
LED-DMX512).
©Copyright 2012 Lighting & Electronics, Inc.
025-0XX [05.31.12] WKLT/HSLT SeriesM
SAVE THESE INSTRUCTIONS

WiringInformation
The LED HouseliteTM/WorkliteTM wire diagrams
are outlined below. The On/Off model is wired very
similarly to the 0-10v fixture. In fact, the same driver is
used in both of those models.
The DMX model contains an internal power supply
unit and a 3 channel driver that passes the DMX
signal and power throughout the LEDs in the fixture.
Both the power and the DMX have parallel passthru
to the next fixture.
On/OffWire Diagram
0-10VDimming Wire Diagram
DMX512 WireDiagram
Maintenance
The LED HouseliteTM/WorkliteTM requires a
minimum amount of maintenance. However,ALLmainte-
nance must be performed by qualified personnel only!
WARNING:Disconnect fixture before any service is
performed. Do not open the fixture while it is still
plugged into the power source.
WARNING: Do not open the head of the fixture that
consists of the LEDs, lenses, glass cover and heatsink.
Trying to perform maintenance on these components may
void your warranty.
Some simple checks should be made:
1. Remove dust that may collect from the baffles on the
heatsink. Over time the collection of dust may inhibit the
cooling capacity of the heatsink. A simple dusting can
ensure proper cooling.
2. Hardware must be checked, wire connections tightened
and electrical insulation inspected for damage.
3. The LED driver and power supply should be inspected
and may require replacement periodically. Both of these
components are located in the driver box that is either
attached to the top of the fixture or has been remoted from
the fixture.
To ensure against future hazards, any wear detected must be
reversed either by repair or replacement. It is the equipment
user's responsibility to keep the equipment in proper, and
safe, working condition.
Ensure fixtures are properly secured to their means of
support. Fixtures hanging for extended periods should be
checked periodically. IMPORTANT: Underwriters
Laboratories (UL) requires that an approved safety cable be
employed when portable stage and studio lighting equipment
is used in a suspended position.
This equipment was created to be used in
compliance with the NEC and local codes.
Any modification to, or misuse of this fixture
will void any warranty or liability claims
either explicit or implied. It is the responsibil-
ity of the user to be sure this unit is used in
compliance with the NEC and local codes.
NEC and are registered
trademarks of the National Fire
Protection Association (NFPA).

Warranty
Equipment manufactured by Lighting & Electronics,
Inc. is guaranteed to be free of defective material and
workmanship for a period of one year from date of
shipment. During this period, equipment returned to
our factory will be repaired or replaced (at our option)
at no charge except freight, unless damaged by
abusive use.
Equipment not of our manufacture is warranteed only
to the extent warranted to us by the manufacturer, and
then only to the extent we are able to enforce such
warranty.
Parts List - DMX Model
119-1000 Strain Relief
124-8803 Cast Handle w/ Stud (Yoke Model Only)
127-1610 Power Cord
127-7210 XLR Male Assembly
127-7210 XLR Female Assembly
260-1605 Spring Washer
420-0220 Receptacle 5-15R snap-in
430-0001 150W LED Head Assembly
430-0060 Power Supply
430-0061 LED DMX Driver
CVEB-01C Cover (C Clamp Mount Only))
HSEB-01C Housing (C Clamp Mount Only)
HSEB-02C Housing (Yoke Mount Only)
PLEB-01C Driver Mount Plate
WSCOMN-01C Washer Fibre
YK8620-01C Yoke
HangTuff HangTuff Clamp (C Clamp Mount Only)
©Copyright 2012 Lighting & Electronics, Inc.
025-0XX [05.31.12] WKLT/HSLT SeriesM
Accessories available:
-Egg Crate
-Color Holder
-Square Trim Ring
-Round Trim Ring
-Yoke
-Get-A-GripTM pipe clamp
- HangTuffTM pipe clamp
Lighting & Electronics, Inc.
91 McKinley Street
Market Street Industrial Park
Wappingers Falls, NY 12590
Tel [phone]
Fax [phone]
[email protected]
www.le-us.com
SAVE THESE INSTRUCTIONS
PartsList - Dimand Non-Dim Models
119-1000 Strain Relief
124-8803 Cast Handle w/ Stud (Yoke Model Only)
132-2497 Double D Hole Plug (Non-Dim Only)
132-8806 6P 3-4 Bushing (Dim Only)
127-1610 Power Cord
260-1605 Spring Washer
430-0001 150W LED Head Assembly
430-0062 0-10V/Non-Dim Driver
CVEB-03C Cover
HSEB-03C Housing (C Clamp Mount Only)
HSEB-04C Housing (Yoke Mount Only)
WSCOMN-01C Washer Fibre
YK8620-01C Yoke (Yoke Model Only)
HangTuff HangTuff Clamp (C Clamp Mount Only)
