PR TANGO 750 FRAMING User manual

1
TANGO 750 FRAMING
PR-6630A
The user manual contains important information about the safe installation and use of a projector. Please read
and follow these instructions carefully and keep the manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com

2
INDEX
1.
SAFETYAND WARNINGS……………………………………………………………………………………
3
2.
INSTRUCTIONS………………………………………………………………………………………………
4
3.
APPEARANCE………………………………………………………………………………………………
5
4.
INSTALLATION………………………………………………………………………………………………
5
5.
SETUPAND CONFIGURATION………………………………………………………………………………
8
6.
OPERATION MENU……………………………………………………………………………………………
9
7.
DMX PROTOCOL………………………………………………………………………………………………
13
8.
TECHNICALDATA……………………………………………………………………………………………
19
9.
CIRCUIT DIAGRAM……………………………………………………………………………………………
22
10.
COMPONENT ORDER CODES………………………………………………………………………………
24
The following items are supplied with a projector and please check:
Name
Quantity
Unit
Remark
Safety cord
2
Pc
User manual
0
Pc
QR code
Power Cable
1
Pc
XLR connector
1
Set
Male and female
Please note that as part of our ongoing commitment to continuous product development, specifications are
subject to change without notice. Whilst every care is taken in the preparation of the manual we reserve the right
to change specifications in the course of product improvement. The publishers cannot be held responsible for the
accuracy of the information herein, or any consequence arising from them.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or
the unit are in good condition before installation and use. Should there be any damage caused by transportation,
consult your dealer and do not use the unit. Any damage caused by improper use will not be assumed by the
manufacturer and / or dealer.
Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the
delivery date but the light source is not within the warranty.

3
1. SAFETYAND WARNINGS
NOTE
Before a projector’s installation, power-on, operation and maintenance, please carefully read
the safety information hereinafter!
The following safety signs are used in the user manual.
Warning
User
Manual
Electrical
shock
Goggles
Protective
Gloves
Flames
High
Temperature
● When unpacking , check if there is any damage caused by transportation before using a projector. Should there
be any damage, consult your dealer and do not use it.
●The manufacture is not responsible for any loss caused by a user not following the manual or changing a
projector as he/she likes.
●Please be noted that any damage caused by changing the projector at will is not warranted.
● Do not hesitate to contact the dealer or the manufacturer if any questions or advice.
● The projector rated for IP66.
● The projector can be used in damp, over-heat and over-dusty places.
● A projector should be kept away from high temperature, fire, electrical surge, vibration and strong light while
being operated.
● A projector is only intended for installation, operation and maintenance by a qualified person. And the
operation must strictly follow the procedures in the manual.
● A projector is not for a user to make any replacements and the user shouldn't open a projector for repair and
maintenance.
● Don’t look straightly into the light sources especially for epileptics, otherwise eyes will be burned..
● Do not connect this device to any type of dimmer pack.
● If the light source, lens and screen protective cover of the a projector have obvious damage, i.e., to the extent
that it hurts the performance like cracking or deformation, please stop using it and replace them with the original
parts, otherwise its performance will be compromised.
● For the location of a projector, it shouldn’t be seen in the distance of less than 4 meters.
● Before operation, please confirm that all covers(housing) are on and screws tightened. It’s forbidden to use a
projector while its covers(housing)are off .
● Keep the light source clean and do not touch it with bare hands.
● While operating it, wear protective items like goggle and gloves.
●Any electrical connection must be carried out by a qualified person .
● Before installation, please confirm the voltage supplied matches what is required for a projector.
● Each projector must be properly earthed and installed as per related electrical standards.
● Do not use power cord with its insulator damaged and connect the power cord with other cables.
● If a projector is not used or under cleaning,, please hold its plug and unplug it. Do not unplug it forcefully or by
pulling the power cable.
●All power cords must conform to related safety and regulations.
● While being operated, if a projector is not waterproof and dust-proof, it should not be under rains or in humidity
to avoid being short.
● Do not switch on and off a projector constantly in very short intervals, otherwise its light source’s and other
electrical parts’ life will be shortened .

4
● There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety cord
supplied through the safety cord holes for safety support.
● Before any installation, maintenance and cleaning work, please ensure a projector is disconnected from power
mains.
● While being in stable working state under normal ambient temperature, the temperature of the surface of the
metallic housing of a projector including heat sink will reach 70℃.
● While its lamp is stricken for the first time, there will be smoke and strange smell. It’s normal and does not
mean a projector has some defects.
● While a projector running, do not touch the metallic housing to avoid being burned.
● Do not mount a projector directly on inflammable surface.
● Do not project the beam straightly on combustible items and the minimum distance between it
and illuminated items is 10m.
● A projector should be installed with good ventilation and the minimum distance between it and walls is 50cm.
At the same time, please ensure the fans and air inlets and outlets are workable.
● Do not let the front lens expose to sunlight or other strong light sources at any angle, otherwise the focused
beam inside can result in fire potentially.
● The product meets The General Technical Requirements and Standards for Recycle and Use Of
ExpiredAppliance and Electronic Products.
● When the product meets disposal standards and needs to be disposed, a client needs to dispose and recycle it.
2. INSTRUCTIONS
●CLEANINGAND MAINTENANCE
The accumulation of oil, smoke and dust on the lens will compromise the light output. Cleaning a projector is very necessary to
ensure a reliable use of it. The projector is rated for IP66. Unless confirmed by a professional technician for some internal
component replacement, it’s forbidden to dismantle a projector.
Cleaning frequency is to be decided by operations and its environment. Use soft cloth and normal detergent for glass for cleaning
work. It’s advised external optical system be cleaned every 20days. Keep lens clean and do not touch optical parts with bare hands.
SPECIALNOTE
While water-proof projectors are in use, it’s normal there will be some minor mist on the front lens.
●Before any maintenance and cleaning, please ensure a project is off the power.
●Only a qualified person is allowed to do maintenance.
●During maintenance and before maintenance, a projector must be off power.
●To avoid sunlight or other light penetrating into the head via the front lens, resulting in high temperature internally
causing damages to a projector. Before power-off, please use Tilt channel to move the head and make it facing
downward.
● Do not use alcohol or other organic solvent to clean the housing to avoid damage.
● Do not use any solvent with chemical elements to clean color filters or hot mirror.

5
●TROUBLESHOOTING
PROBLEM
ACTION
Aprojector can’t be switched on
Check if the fuse is burned
Check if the power cord is connected well
Check if the switching power supply is bad or not connected well. A
professional technician is required for the repair
Check if the control board is connected well. .A professional technician
is required for the repair
Aprojector can be switched on , but the LED
lamp’s brightness can’t be controlled
Check if the LED driver board is connected well. A professional
technician is required for the repair
Aprojector can be switched on normally, but not
controlled by the DMX controller
Make sure that its start address is right
Replace or repair the XLR signal cable.
The beam is not bright and its brightness
decreases sharply
Make sure the fans are working well orfans and their shields are not blocked
bydust.
Make sure thattheinternalopticsareclean.
Aproject image appears to have a halo
Carefully clean the LED lamp, optical lenses and other components.
Heavily Defective Beam
Check if lens are in good condition(not cracked)
Clean dust or grease on the lens.
3.APPEARANCE
4. INSTALLATION
●PLACED ONAFLAT SURFACE
While placing a projector on a flat surface, tighten the head after loosening its screw and adjusting its angle till desired.
Note
It’s advised to use inner hexagon screws with nonskid
washers to ensure secure installation. Whatever screws may
be used, it mustn’t be more than 2 pairs.
Head
Arm

6
The size of the screws are to be decided by the customer based on the size of mounting holes in the arms, the following sizes in the table
are only for reference
●POWER CONNECTION
Connect the power cord as follows:
L (live) =brown
E (earth) =yellow/green
N (neutral) =blue
Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each
projector be connected with power separately so that they may be individually switched on and off.
●The earth wire(yellow/green) must be connected to the ground. And electrical connection must be in
accordance with the standards concerned.
●If any questions about the electrical installation, do not continue but consult a qualified electrician.
●A projector uses naked wires. For wiring please use waterproof junction box with IPclass not lower
than IP66.
●THE WIRING OF CONTROL SIGNAL
The colors of signal wires responds to their respective functions:
Blue color –A+
White color –B-
Black color –Shield wire
The shielded 2-core wire between a projector and a controller or between projectors should be not less than 0.5mm in diameter
and the maximum number of projectors in a DMX chain should be less than 32 pieces.
●DMX TERMINATOR
In the Controller mode, at the last fixture in the chain, its female DMX output has to be connected with a DMX terminator.
The DMX terminator is simply a Canon connector with a 120(ohm) resistor connected across pin A+ and pin B-, which prevents
electrical noise from disturbing and corrupting the DMX control signals. Before DMX terminator connection, please make proper
insulation and waterproof treatment.
NO
NAME
SIZE
QTY
REMARKS
1
Inner hexagon screw
M12
3
Prepared by the customer
2
Washer
Coupled with the inner
hexagon screws
3
Prepared by the customer

7
●GOBO FILTER REPLACEMENT
Lock the tilt and loosen the 4 fast-fit screws on the upper cover ,After removing the cover, you will see the structures as the figure above.
To replace a gobo on the rotating gobo wheel: take the rotator from the wheel in the sequence of 1→2 , take the gobo out from the
rotator by removing the tightening spring. Put the new gobo back to the rotator, then tighten it with the spring. Please ensure the spring is
in the narrow location of the rotator, which is the internal ring of it and flatten it. At last, pull up the spring strip using proper tool and put
the rotator back to the wheel with the assistance by another hand. Its installation is of the opposite sequence of removal(（2→1）.
NOTE: Do not touch the glass gobo with bare hand. Place clean and soft paper or cloth between hand and glass gobos.
Tighten 4 inner hexagon screws after the cover is on. Unlock the tilt.
●FIXING THE FRAMING MODULE
Remove the small cover after locking Tilt after adjusting the framing blades. Unplug the plug on the left after tightening the
screw against the module till it can’t move . At last, install the small cover.
If the framing blades need to be adjusted, plug the plug into its original place after loosening the tightening screw, then repeat
Step 1.
Plug
Tightening screw for module
rotation
Rotating gobo wheel
Gobo assembly
Rotator
Gobo
Spring

8
DANGER!
BEFORE REPLACEMENT OF GOBOS/COLOR FILTERS, APROJECTOR MUST BE OFF THE POWER!
5. SETUPAND CONFIGURATION
●FRONT PANELOPERATION
To browse through or change a projector’s settings, open the small cover in the head and a LCD control panel appears as the
figure shown above. Launch the projector and press button ENTER for more than 3 seconds to unlock the panelafter power on. Then
press UP or DOWN button for menus desired. Each main menu has its own sub-menus. And each menu is for a special
function. For more details, please refer to Operation Menu in section five.
1. At the page for setup of functions, press UP or DOWN button for functions desired;
2. While setting up menus, press ENTER button to save the changes or enter into submenus; press UP or DOWN
buttons to change values( increase or decrease values)
Press button ESCAPE button, it will return to the upper menu. If the button not pressed, the system will go back to initial display
status.
●DMX STARTADDRESS
Each unit must be given a DMX start address so that the correct projector responds to the correct control signals.This DMX start address
is the channel number from which the projector starts to “listen” to the digital control information being sent out from the controller. The
unit has 3 DMX modes. There are standard mode ,short mode and extended mode. For example standard mode has 30 channels, so set
the No. 1 projector’s address 001, No. 2 projector’s address 031, No. 3 projector’s address 061, No.4 projector’s address 91, and so on.
Launch the projector. Press button ENTER more than 3 seconds to unlock panel.
Press button ENTER to display DMX address;
Press button UPor DOWN, the DMX address can be set;
Press button ENTER to confirm to save the address automatically.After powered on next time, the default will be last value saved
Press button ESCAPE, it will return to the upper menu.
●STAND-ALONE MODE
Operate the projector without connecting with a controller, enable the master mode through the operation panel, the
projector will run in Stand-Alone mode automatically.
DMX address can be set at any number within 512.
●MASTER/SLAVE MODE
Many projectors can run synchronously in the Master/Slave mode by linking them with each other. First,
connect the first fixture’s DMX output to the second fixture’s DMX input using XLR-XLR control cable and then connect the second
Escape
Enter
Down
Up

9
fixture’s DMX output to the third fixture’s DMX input, and so on until all projector are connected in this way. Eventually connect the last
fixture’s DMX output to a DMX terminator. Set 1st projector as the master and others are Slaves. It’s advised that the
maximum quantity of projectors in a DMX chain be less than 32.
Start Addresses of all Slaves are 001; Operation mode of the Master can be set any mode for a Master’ and Slaves’ operation mode can
be set accordingly.
After Powered on, the group will run in Master/Slave Mode.( The number of projectors in a DMX chain is 32pcs at maximum)
6. OPERATION MENU
1st LEVEL
2nd LEVEL
3rd LEVEL
4th LEVEL
5th LEVEL
DMX setting
DMX Address
Short :1-486
Standard :1-483
Extended :1-468
Reset
Total Reset
Really Reset?
Confirm/Cancel
Colour System
Really Reset?
Confirm/Cancel
Gobo Reset
Really Reset?
Confirm/Cancel
Zo.Fo. Fr.
Really Reset?
Confirm/Cancel
Other Reset
Really Reset?
Confirm/Cancel
Config Set
DMX Channel Mode
Short 27 CH
Standard 30 CH
Extended 45 CH
View Channel
001 Strobe
…
Loss of DMX
Normal timeout
Hold Last
Disp. Config
Display Mode
Off Delay
OnAlways
Display Inv.
Invert OFF
Invert ON
Language Set
English
Chinese
Temp. Unit
Celsius
Fahrenheit
Factory reset
Factory reset ?
Confirm/Cancel
Option Set
Invert Set
Zoom Inv.
OFF/ ON
CYM Inv.
OFF/ ON
CTO Inv.
OFF/ ON
Dimmer Set
Gamma Curve
Gamma 2.0/2.2/2.4/2.6
LED Ref. Rate
1200/2400/4800/10000/1200
0/15000/20000/25000Hz

10
Dimmer Speed
Fast/Medium/Slow Speed
Fan Set
Standard/Theatre
Blade Detect
Detect Disable/ Detect Enable
Information
View DMX Values
Channel Value
Strobe XXX
Dimmer XXX
Dimmer Fine XXX
CMY Macro XXX
Cyan XXX
Cyan Fine XXX
Yellow XXX
Yellow Fine XXX
Magenta XXX
Magenta Fine XXX
CTO XXX
CTO Fine XXX
Color Wheel XXX
Color Wheel Fine XXX
Fixed gobo wheel XXX
Ro. Gobo wheel XXX
Gobo Rota. XXX
Gobo Rota. Fine XXX
Blade 1 Left XXX
Blade 1 Left fine XXX
Blade 1 Right XXX
Blade 1 Right Fine XXX
Blade 2 Left XXX
Blade 2 Left Fine XXX
Blade 2 Right XXX
Blade 2 Right Fine XXX
Blade 3 Left XXX
Blade 3 Left Fine XXX
Blade 3 Right XXX
Blade 3 Right Fine XXX
Blade 4 Left XXX
Blade 4 Left Fine XXX
Blade 4 Right XXX
Blade 4 Right Fine XXX
Framing module R. XXX
Framing Module R.F. XXX
Prism XXX
Prism Rotation XXX
Effect Wheel XXX
Effect Wheel Ro. XXX
Frost XXX
Focus XXX
Focus Fine XXX
Zoom XXX
Zoom Fine XXX
Control Function XXX
Total Hours
XXX
Temperature
Display XXX
Driver 1 XXX
Driver 2 XXX
Driver 3 XXX
Effect Board
Fan Board XXX
LED XXX
Software Version
Display
Driver 1
Driver 2
Driver 3
Effect Board
Fan Board
Electronic SN
Electronic SN=
************
RDM Device Label
ANSI E1.20 RDM
*******

11
Fan Status
Head Fan XXX
Service
Manual Effect Control
Channel Value
Strobe XXX
Dimmer XXX
Dimmer Fine XXX
CMY Macro XXX
Cyan XXX
Cyan Fine XXX
Yellow XXX
Yellow Fine XXX
Magenta XXX
Magenta Fine XXX
CTO XXX
CTO Fine XXX
Color Wheel XXX
Color Wheel Fine XXX
Fixed gobo wheel XXX
Ro. Gobo wheel XXX
Gobo Rota. XXX
Gobo Rota. Fine XXX
Blade 1 Left XXX
Blade 1 Left fine XXX
Blade 1 Right XXX
Blade 1 Right Fine XXX
Blade 2 Left XXX
Blade 2 Left Fine XXX
Blade 2 Right XXX
Blade 2 Right Fine XXX
Blade 3 Left XXX
Blade 3 Left Fine XXX
Blade 3 Right XXX
Blade 3 Right Fine XXX
Blade 4 Left XXX
Blade 4 Left Fine XXX
Blade 4 Right XXX
Blade 4 Right Fine XXX
Framing module R. XXX
Framing Module R.F. XXX
Prism XXX
Prism Rotation XXX
Effect Wheel XXX
Effect Wheel Ro. XXX
Frost XXX
Focus XXX
Focus Fine XXX
Zoom XXX
Zoom Fine XXX
Factory Test
Operation
Mode
DMX Mode
Change Operation Mode?
Confirm/Cancel
Master Mode
Preset Memory
Change Operation Mode?
Confirm/Cancel
User Memory 1
Change Operation Mode?
User Memory 2
Change Operation Mode?
Stand-Alone Mode
Preset Memory
Change Operation Mode?
User Memory 1
Change Operation Mode?
User Memory 2
Change Operation Mode?
Static Scene
Change Operation Mode?
User
Memories
Edit User Memory
Edit User Memory 1
/Edit User Memory 2
Scene XX
（1~16Scene
s）
Paste?
Confirm
Channel Value
Strobe XXX
Dimmer XXX
Dimmer Fine XXX
CMY Macro XXX
Cyan XXX
Cyan Fine XXX
Yellow XXX
Yellow Fine XXX
Magenta XXX
Magenta Fine XXX
CTO XXX
CTO Fine XXX
Color Wheel XXX
Color Wheel Fine XXX

12
Fixed gobo wheel XXX
Ro. Gobo wheel XXX
Gobo Rota. XXX
Gobo Rota. Fine XXX
Blade 1 Left XXX
Blade 1 Left fine XXX
Blade 1 Right XXX
Blade 1 Right Fine XXX
Blade 2 Left XXX
Blade 2 Left Fine XXX
Blade 2 Right XXX
Blade 2 Right Fine XXX
Blade 3 Left XXX
Blade 3 Left Fine XXX
Blade 3 Right XXX
Blade 3 Right Fine XXX
Blade 4 Left XXX
Blade 4 Left Fine XXX
Blade 4 Right XXX
Blade 4 Right Fine XXX
Framing module R. XXX
Framing Module R.F. XXX
Prism XXX
Prism Rotation XXX
Effect Wheel XXX
Effect Wheel Ro. XXX
Frost XXX
Focus XXX
Focus Fine XXX
Zoom XXX
Zoom Fine XXX
Fade time XXX
Hold time XXX
Delay unit ms/s/min
Next scene XXX
Edit Static Scene
Paste?
Confirm
Channel Value
Strobe XXX
Dimmer XXX
Dimmer Fine XXX
CMY Macro XXX
Cyan XXX
Cyan Fine XXX
Yellow XXX
Yellow Fine XXX
Magenta XXX
Magenta Fine XXX
CTO XXX
CTO Fine XXX
Color Wheel XXX
Color Wheel Fine XXX
Fixed gobo wheel XXX
Ro. Gobo wheel XXX
Gobo Rota. XXX
Gobo Rota. Fine XXX
Blade 1 Left XXX
Blade 1 Left fine XXX
Blade 1 Right XXX
Blade 1 Right Fine XXX
Blade 2 Left XXX
Blade 2 Left Fine XXX
Blade 2 Right XXX
Blade 2 Right Fine XXX
Blade 3 Left XXX
Blade 3 Left Fine XXX
Blade 3 Right XXX
Blade 3 Right Fine XXX
Blade 4 Left XXX
Blade 4 Left Fine XXX
Blade 4 Right XXX
Blade 4 Right Fine XXX
Framing module R. XXX
Framing Module R.F. XXX
Prism XXX

13
Prism Rotation XXX
Effect Wheel XXX
Effect Wheel Ro. XXX
Frost XXX
Focus XXX
Focus Fine XXX
Zoom XXX
Zoom Fine XXX
Init User Memory
Reset User Memory 1
Reset User Memory?
Input Password123
Reset User Memory 2
Reset User Memory?
Input Password123
Reset Static Scene
Reset Static Scene?
Input Password123
7. DMX PROTOCOL
Short mode
Standard
mode
Extended
mode
Description
Decimal low
Decimal High
1
1
1
Strobe
Close
0
Pulse strobe from slow to fast
1
127
Strobe from slow to fast
128
225
2
2
2
Dimmer
Close
0
0
Linear dimmer (0-100%)
1
255
3
3
Dimmer in 16 bit
Dimmer in 16 bit adjustment
0
255
3
4
4
CYM macros
The following functions will disable CMY,CTO, color wheel
No function
0
7
Color macro1
8
9
Color macro2
10
11
Color macro3
12
13
Color macro4
14
15
Color macro5
16
17
Color macro6
18
19
Color macro7
20
21
Color macro8
22
23
Color macro9
24
25
Color macro10
26
27
Color macro11
28
29
Color macro12
30
31
Color macro13
32
33
Color macro14
34
35
Color macro15
36
37
Color macro16
38
39
Color macro17
40
41
Color macro18
42
43
Color macro19
44
45
Color macro20
46
47
Color macro21
48
49
Color macro22
50
51

14
Color macro23
52
53
Color macro24
54
55
Color macro25
56
57
Color macro26
58
59
Color macro27
60
61
Color macro28
62
63
Color macro29
64
65
Color macro30
66
67
Color macro31
68
69
Color macro32
70
71
Color macro33
72
73
Color macro34
74
75
Color macro35
76
77
Color macro36
78
79
Color macro37
80
81
Color macro38
82
83
Color macro39
84
85
Color macro40
86
87
Color macro41
88
89
Color macro42
90
91
Color macro43
92
93
Color macro44
94
95
Color macro45
96
97
Color macro46
98
99
Color macro47
100
101
Color macro48
102
103
Color macro49
104
105
Color macro50
106
107
Color macro51
108
109
Color macro52
110
111
Color macro53
112
113
Color macro54
114
115
Color macro55
116
117
Color macro56
118
119
Color macro57
120
121
Color macro58
122
123
Color macro59
124
125
Color macro60
126
127
Color macro61
128
129
Color macro62
130
131
Color macro63
132
133
Color macro64
134
135
Color macro65
136
137
Color macro66
138
139

15
Color macro67
140
141
Color macro68
142
143
Color macro69
144
145
Color macro70
146
147
Color macro71
148
149
Color macro72
150
151
Color macro73
152
153
Color macro74
154
155
Color macro75
156
157
Color macro76
158
159
Color macro77
160
161
Color macro78
162
163
Color macro79
164
165
Color macro80
166
167
Color macro81
168
169
Color macro82
170
171
Color macro83
172
173
Color macro84
174
175
Color macro85
176
177
Color macro86
178
179
Color macro87
180
181
Color macro88
182
183
Color macro89
184
185
Color macro90
186
187
Color macro91
188
189
Color macro92
190
191
Color macro93
192
193
Color macro94
194
195
Color macro95
196
197
Color macro96
198
199
CMY color mixing fade from slow to fast
200
255
4
5
5
Cyan
Cyan (Linear 0-100%)
0
255
6
Cyan in 16 bit
Cyan 16 bit adjustment
0
255
5
6
7
Yellow
Yellow (Linear 0-100%)
0
255
8
Yellow in 16 bit
Yellow 16bit adjustment
0
255
6
7
9
Magenta
Magenta (Linear 0-100%)
0
255
10
Magenta in 16bit
Magenta 16 bit adjustment
0
255
7
8
11
CTO

16
Linear CTO from high t low
0
255
12
CTO in 16 bit
CTO 16 bit adjustment
0
255
8
9
13
Color wheel
Continuous positioning
Indexing 0-360°
0
63
Positioning
Open /Color1
64
67
Color 1
68
71
Color1/Color2
72
75
Color2
76
79
Color2/Color3
80
83
Color3
84
87
Color3/Color4
88
91
Color4
92
95
Color4/Color5
96
99
Color5
100
103
Color5/Color6
104
107
Color6
108
111
Color6 /Color7
112
115
Color7
116
119
Color7 /Open
120
123
Open
124
127
Clockwise rainbow effect from slow to fast
128
191
Anti-clockwise rainbow effect from slow to fast
192
255
10
14
Color wheel in 16bit
Color wheel continuous positioning ,16bit adjustment
0
255
9
11
15
Rotating gobo wheel
Open
0
15
Gobo1
16
29
Gobo2
30
43
Gobo3
44
57
Gobo4
58
71
Gobo5
72
85
Gobo6
86
99
Gobo7
100
113
Gobo8
114
127
Clockwise rotation from slow to fast
128
147
Anti-clockwise rotation from slow to fast
148
167
Gobo1 shakes from slow to fast
168
178
Gobo2 shakes from slow to fast
179
189
Gobo3 shakes from slow to fast
190
200
Gobo4shakes from slow to fast
201
211
Gobo5shakes from slow to fast
212
222

17
Gobo6shakes from slow to fast
223
233
Gobo7shakes from slow to fast
234
244
Gobo8shakes from slow to fast
245
255
10
12
16
Gobo rotation
Indexing 0-360°
0
128
Clockwise rotation from slow to fast
129
188
Stop
189
195
Anti-clockwise rotation from slow to fast
196
255
13
17
Gobo rotation in 16 bit
Gobo rotation 16 bit adjustment
0
255
11
14
18
Framing blade 1 left
Linear Framing Blade 1 Left Change 0%-100%
0
255
19
Framing Blade 1 Left change in 16 bit
Framing Blade 1 Left change in 16 bit precision
0
255
12
15
20
Framing Blade 1 right
Linear Framing Blade 1 Right Change 0%-100%
0
255
21
Framing Blade 1 right change in 16 bit
Framing Blade 1 right change in 16 bit precision
0
255
13
16
22
Framing Blade 2 Left
Linear Framing Blade 2 Left Change 0%-100%
0
255
23
Framing Blade 2 Left change in 16 bit
Framing Blade 2 Left change in 16 bit precision
0
255
14
17
24
Framing Blade 2 Right
Linear Framing Blade 2 Right Change 0%-100%
0
255
25
Framing Blade 2 right change in 16 bit
Framing Blade 2 right change in 16 bit precision
0
255
15
18
26
Framing Blade 3 Left
Linear Framing Blade 3 Left Change 0%-100%
0
255
27
Framing Blade 3 Left change in 16 bit
Framing Blade 3 Left change in 16 bit precision
0
255
16
19
28
Framing Blade 3 Right
Linear Framing Blade 3 Right Change 0%-100%
0
255
29
Framing Blade 3 right change in 16 bit
Framing Blade 3 right change in 16 bit precision
0
255
17
20
30
Framing Blade 4 Left
Linear Framing Blade 4 Left Change 0%-100%
0
255
31
Framing Blade 4 Left change in 16 bit
Framing Blade 4 Left change in 16 bit precision
0
255
18
21
32
Framing Blade 4 Right
Linear Framing Blade 4 Right Change 0%-100%
0
255
33
Framing Blade 4 right change in 16 bit
Framing Blade 4 right change in 16 bit precision
0
255
19
22
34
Framing Module rotation
Framing Module Indexing(0-90 degrees)
0
255

18
35
Framing Module rotation in 16 bit
Framing Module rotation(0-90degrees) in 16 bit
0
255
20
23
36
Prism
No
0
16
Prism in
17
255
21
24
37
Prism rotation
Prism indexing
0
127
Stop
128
Clockwise rotation from slow to fast
129
191
Stop
192
Anti-clockwise rotation from slow to fast
193
255
22
25
38
Effect wheel
No
0
19
Effect wheel in
20
255
23
26
39
Effect wheel rotation
Clockwise rotation from slow to fast
0
127
Anti-clockwise rotation from slow to fast
128
255
24
27
40
Frost
Linear frost 0% - 100%
0
255
25
28
41
Focus
Linear focus
0
255
42
Focus in 16 bit
Focus 16 bit adjustment
0
255
26
29
43
Zoom
Linear Zoom
0
255
44
Zoom in 16 bit
Zoom 16 bit adjustment
0
255
27
30
45
Power/Special function
No function
0
4
Reserved
5
19
The following function must stay in the DMX range for more
than 5s to activate it
Display on
20
24
Display off
25
29
Reserved
30
44
Reserved
45
46
Fan standard mode
47
48
Fan theater mode
49
50
Reserved
51
52
Fast dimmer speed
53
54
Medium dimmer speed
55
56
Slow dimmer speed
57
58
Gamma curve 2.0
59
60
Gamma curve 2.2
61
62

19
8.TECHNICALDATA
ELECTRIC PARAMETERS
Input voltage : 200V~240VAC，50/60Hz
Input power : 750W @ 220VAC
Power factor : PF>0.9
Current at maximum: : 3.5A@ 220VAC
THE SPECIFICATIONSOF THE LIGHT SOURCE
Power : 500W White LED
Color temperature : 8000K
Rated life : 20000hrs
CRI: Ra≥70( Optional: Ra≥90)
COLORS
CMYlinear mixing system with macros
1 color wheel: 7 colors+ Open
Half color effect, rainbow effect with bi-directional and variable speeds,
Stepping/linear color changing
CTO
0-100% linear CTO
GOBO
1 Rotating Gobo Wheel: 8 replaceable gobos+ Open, Glass or Metal Gobo
Bi-directional Rotation with variable speeds
Gamma curve 2.4
63
64
Gamma curve 2.6
65
66
LED refresh rate 1200Hz
67
68
LED refresh rate 2400Hz
69
70
LED refresh rate 4800Hz
71
72
LED refresh rate 10000Hz
73
74
LED refresh rate 12000Hz
75
76
LED refresh rate 15000Hz
77
78
LED refresh rate 20000Hz
79
80
LED refresh rate 25000Hz
81
82
Reserved
83
149
Color wheel reset
150
159
Gobo wheel reset
160
169
Reserved
170
179
Zoom/Focus/Frost/Prism reset
180
189
Other（Effect wheel, Framing module）reset
190
199
Total reset
200
209
Reserved
210
255

20
With Indexing Function
Gobo Shake Effect with Variable Speeds
Bi-directional Scrolling with Variable Speeds
Gobo outer size: 24 mm Gobo image size: 18 mm
1 framing module rotates between 0° and 90° and produces graphics of different shapes and sizes
4 framing blades can produce full curtain effect
1#
2#
3#
4#
5#
6#
7#
8#
PRISM
1pc of 3 facet circular prism , Bi-directional rotation with variable speeds and indexing function
FROST
1pc frost filter, linear frost effect( 0%-100%)
EFFECT WHEEL
1pc, bi-directional rotation with variable speeds
FOCUS
DMX linear Focusing
DIMMER
0-100% Linear adjustment
STROBE
Electronic strobe, 0.3~25 F.P.S
TILTMOVEMENT
Tilt :140°
BEAMANGLE
linear zoom 6°-50° with 16 bit function (open hole)
linear zoom 5°-40° with 16 bit function (Gobo effective size)
CONTROL
International standard DMX512, 5 pin interfaces
