Lightolier ProSpec Linear Downlight PE3M1675 User manual

11
45°Beveled Flange
Top View
7
9
1
8
2
3
10
45
6
14 3/4"
9 3/4"
26 3/4"
18 3/4"
8 3/4"
Depth
1 3/4"
15" L x 5" W Opening
16 1/16" x 6 3/16" Ceiling Cutout
24 3/8" L x 10" W
4 7/8" OC 4 7/8" OC
ProSpec®Linear Downlight PE3M1675
Page 1 of 2 3 Light MR 16 Series E
ßJob Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2004 Genlyte Thomas Group LLC (Lightolier Division) • B0304
Features
1. Mounting Frame: Provides clean support for Elbow and overlapping flange
installation. Extruded aluminum and aluminum plate, rigidly welded together
on all corners. Matte white finish.
2. Elbow: Seamless; diecast aluminum. Allows 358° horizontal and 70° verti-
cal adjustment.
3. Stepped Baffle: Diecast aluminum. Matte black finish for low brightness.
4. Tortiontite Spring: For easy installation of mounting frame.
5. Housing: Die-formed 22 ga. steel. Finish: Black.
6. Mounting Brackets: Adjustable vertically from outside of housing.
7. Thermal Protector: Meets NEC / UL & CEC / CSA requirements.
8. Lampholder: Steatite for GX/GY 5.3 Bi-Pin MR-16 lamps. 250° C Teflon®
leads.
9. Junction Box: 14 ga. steel, 4" x 3 1/2" x 3" box. Allows inspection from
below.
10. Lamp Guard: Heat resistant clear glass. May be replaced with solid glass
accessory. Lamp manufacturers’ requirement.
11. Transformer Housing: Die-formed steel.
Electrical
Electronic Transformers: Offer reliable operation and are accessible from
below for servicing. 12V. Secondary 75 VA. each lamp.
Dimming Controls: Use only dimmers specifically designed for use with
electronic transformers. Low Voltage fixtures may produce audible sound when
used with dimmers, which may be objectionable in acoustically critical areas.
UL/cUL listed for through branch circuit wiring with maximum of
(4) no. 12 AWG, 90°C.
Finish
All painted finishes are powder coated baked enamel.
Options & Accessories
Accessories: Lamp guard may be replaced with 2”dia. series filters and lenses
only. The use of accessories reduces the lamp wattage rating to 50W. maximum.
Ceiling Cutout: 16 1/16" L x 6 3/16" W
Ordering Information: MR 16 Series E
Cat. No. Lamp Ceiling Trim Aperture Finish
PE3M167EBL (3) 75W MR 16* Overlap White with Black aperture
PE3M167EWL *50W MR16 when used with accessories Black with Black aperture
Labels
UL/cUL (Suitable for Damp Location), I.B.E.W.
Teflon®is a registered trademark of E.I. DuPont.
Add a “1” for 120v or “2” for 277v at the end of the catalog number for voltage

DFC L W DC FC L W DC FC L W DC FC L W
MR16 LOW VOLTAGE HALOGEN BI-PIN LAMPS
Lamps Beam Spread CBCP Rated
(To 50% CBCP) Life (Hrs.)
(FC) is initial footcandles at center of beam.
Beam length (L) and beam width (W) are to
where the candlepower is reduced to 50%
of the center beam candlepower.
CBCP is center beam candlepower.
(C) is distance to the center of the beam.
Lamp data shown is typical, and is based on
bare lamp photometrics. Contact lamp man-
ufacturers for availability and performance.
7’ 167 0.9’ 0.9’
10’ 82 1.2’ 1.2’
13’ 49 1.6’ 1.6’
16’ 32 2.0’ 2.0’
6’ 3.5’ 148 1.0’ 0.8’
9’ 5.2’ 66 1.5’ 1.3’
12’ 6.9’ 37 2.0’ 1.7’
15’ 8.7’ 24 2.3’ 2.1’
4’ 4.0’ 181 1.0 0.7’
6’ 6.0’ 81 1.5 1.0’
8’ 8.0’ 45 2.0 1.4’
10’ 10.0’ 29 2.5 1.7’
2’ 3.5 256 1.0’ 0.5’
3’ 5.2’ 114 1.5’ 0.7’
4’ 6.9’ 64 2.0’ 1.0’
5’ 8.7’ 41 2.5’ 1.2’
8200 3000
20W MR16
VNSP (EZX) 7˚
6’ 100 1.4’ 1.4’
8’ 56 1.8’ 1.8’
10’ 36 2.3’ 2.3’
12’ 25 2.7’ 2.7’
5’ 2.9’ 94 1.5’ 1.3’
7’ 4.0’ 48 2.1’ 1.8’
9’ 5.2’ 29 2.7’ 2.4’
11’ 6.4’ 19 3.4’ 2.9’
3’ 3.0 141 1.4’ 1.0’
5’ 5.0 51 2.3’ 1.6’
7’ 7.0’ 26 3.2’ 2.3’
9’ 9.0’ 16 4.2’ 2.9’
2’ 3.5’ 113 1.9’ 0.9’
3’ 5.2’ 50 2.8’ 1.4’
4’ 6.9’ 28 3.8’ 1.8’
5’ 8.7’ 18 4.7’ 2.3’
3600 5000
20W MR16
NSP (ESX) 13˚
7’ 178 1.5’ 1.5’
10’ 87 2.1’ 2.1’
13’ 51 2.7’ 2.7’
16’ 34 3.4’ 3.4’
6’ 3.5’ 157 1.7’ 1.5’
9’ 5.2’ 70 2.5’ 2.2’
12’ 6.9’ 39 3.4’ 2.9’
15’ 8.7’ 25 4.2’ 3.6’
4’ 4.0’ 192 1.7’ 1.2’
6’ 6.0’ 85 2.6’ 1.8’
8’ 8.0’ 48 3.4’ 2.4’
10’ 10.0’ 31 4.3’ 3.0’
2’ 3.5’ 272 1.7’ 0.8’
3’ 5.2’ 121 2.6’ 1.3’
4’ 6.9’ 68 3.5’ 1.7’
5’ 6.7’ 44 4.3’ 2.1’
8700 4000
35W MR16
NSP (FRB) 12˚
8’ 205 1.3’ 1.3’
12’ 91 1.9’ 1.9’
16’ 51 2.5’ 2.5’
20’ 33 3.1’ 3.1’
7’ 4.0 174 1.5’ 1.3’
10’ 5.8’ 85 2.1’ 1.8’
13’ 7.5’ 50 2.7’ 2.4’
16’ 9.2’ 33 3.4’ 2.9’
5’ 5.0’ 185 1.6’ 1.1’
7’ 7.0 95 2.2’ 1.6’
9’ 9.0’ 57 2.8’ 2.0’
11’ 11.0’ 38 3.5’ 2.4’
5’ 5.0’ 163 1.8’ 1.2’
7’ 7.0 83 2.5’ 1.7’
9’ 9.0’ 50 3.2’ 2.2’
11’ 11.0’ 34 3.9’ 2.7’
3’ 5.2’ 182 1.9’ 0.9’
4’ 6.9’ 102 2.6’ 1.3’
5’ 8.7’ 66 3.2’ 1.6’
6’ 10.4 45 3.8’ 1.9’
13100 3500
42W MR16
VNSP (EZY) 9˚
8’ 159 2.0’ 2.0’
12’ 71 2.9’ 2.9’
16’ 40 3.8’ 3.9’
20’ 26 4.9’ 4.9’
7’ 4.0’ 135 2.3’ 2.0’
10’ 5.8’ 66 3.3’ 2.8’
13’ 7.5’ 39 4.3’ 3.7’
15’ 9.2’ 28 5.3’ 4.5’
5’ 5.0’ 144 2.5’ 1.7’
7’ 7.0’ 74 3.5’ 2.4’
9’ 9.0’ 45 4.5’ 3.1’
11’ 11.0’ 30 5.5’ 3.8’
3’ 5.2’ 142 3.1’ 1.5’
4’ 6.9’ 80 4.1’ 2.0’
5’ 8.7’ 51 5.1’ 2.5’
6’ 10.4’ 35 6.2’ 2.9’
10200 4000
50W MR16
NSP (EXT) 14˚
2’ 131 1.5’ 1.5’
3’ 58 2.2’ 2.2’
4’ 33 2.9’ 2.9’
5’ 21 3.6’ 3.6’
2’ 1.2’ 85 2.0’ 1.7’
3’ 1.7’ 38 3.0’ 2.5’
4’ 2.3’ 21 4.1’ 3.4’
5’ 2.9’ 14 5.1’ 4.2’
2’ 2.0’ 46 3.4’ 2.1’
3’ 3.0’ 21 5.0’ 3.1’
4’ 4.0’ 12 6.7’ 4.1’
5’ 5.0’ 7 8.4’ 5.1’
1’ 1.7’ 66 4.8’ 1.5’
2’ 3.5’ 16 9.7’ 2.9’
3’ 5.2’ 7 14.5’ 4.4’
4’ 6.9’ 4 19.3’ 5.8’
525 5000
20W MR16
FL (BAB) 40˚
4’ 100 2.9’ 2.9’
6’ 44 4.4’ 4.4’
8’ 25 5.8’ 5.8’
10’ 16 7.3’ 7.3’
3’ 1.7’ 115 3.0’ 2.5’
5’ 2.9’ 42 5.1’ 4.2’
7’ 4.0’ 21 7.1’ 5.8’
9’ 5.2’ 13 9.1’ 7.6’
3’ 3.0’ 63 5.0’ 3.1’
4’ 4.0’ 35 6.7’ 4.1’
5’ 5.0’ 23 8.4’ 5.1’
6’ 6.0’ 16 10.1’ 6.2’
3’ 3.0’ 61 5.0’ 3.1’
4’ 4.0’ 45 6.7’ 4.1’
5’ 5.0’ 29 8.4’ 5.1’
6’ 6.0’ 20 10.1’ 6.2’
1’ 1.7’ 200 4.8’ 1.5’
2’ 3.5’ 50 9.7’ 2.9’
3’ 5.2’ 22 14.5’ 4.4’
4’ 6.9’ 13 19.3’ 5.8’
1600 4000
35W MR16
FL (FMW) 40˚
4’ 116 2.9’ 2.9’
6’ 51 4.4’ 4.4’
8’ 29 5.8’ 5.8’
10’ 19 7.3’ 7.3’
3’ 1.7’ 134 3.0’ 2.5’
5’ 2.9 48 5.1’ 4.2’
7’ 4.0’ 25 7.1’ 5.9’
9’ 5.2’ 15 9.1’ 7.6’
3’ 3.0’ 73 5.0’ 3.1’
4’ 4.0’ 41 6.7’ 4.1’
5’ 5.0’ 26 8.4’ 5.1’
6’ 6.0’ 18 10.1’ 6.2’
1’ 1.7’ 231 4.8’ 1.5’
2’ 3.5’ 58 9.7’ 2.9’
3’ 5.2’ 26 14.5’ 4.4’
4’ 6.9’ 14 19.3’ 5.8’
1850 6000
50W MR16
FL (EXN) 40˚
3’ 128 3.1’ 3.1’
5’ 46 5.2’ 5.2’
7’ 23 7.3’ 7.3’
9’ 14 9.4’ 9.4’
3’ 1.7’ 83 4.6’ 3.6’
5’ 2.9’ 30 7.6’ 6.0’
7’ 4.0’ 15 10.7’ 8.4’
9’ 5.2’ 9 13.7’ 10.8’
2’ 2.0’ 102 5.7’ 2.9’
3’ 3.0’ 45 8.6’ 4.4’
4’ 4.0’ 25 11.4’ 5.9’
5’ 5.0’ 16 14.3’ 7.4’
1’ 1.7’ 144 22.3’ 2.1’
2’ 3.5’ 36 44.5’ 4.2’
3’ 5.2’ 16 66.8’ 6.2’
4’ 6.9’ 9 89.1’ 8.3’
1150 4000
50W MR16
WFL (FNV) 55˚
6’ 108 2.1’ 2.1’
8’ 61 2.8’ 2.8’
10’ 39 3.5’ 3.5’
12’ 27 4.2’ 4.2’
5’ 2.9 101 2.4’ 2.0’
7’ 4.0’ 52 3.3’ 2.9’
9’ 5.2’ 31 4.3’ 3.7’
11’ 6.4’ 21 5.2’ 4.5’
3’ 3.0’ 153 2.2’ 1.5’
5’ 5.0’ 55 3.6’ 2.5’
7’ 7.0’ 28 5.1’ 3.5’
9’ 9.0’ 17 6.6’ 4.5’
3’ 3.0’ 137 2.8’ 1.9’
5’ 5.0’ 49 4.7’ 3.1’
7’ 7.0’ 25 6.5’ 4.4’
9’ 9.0’ 15 8.4’ 5.6’
2’ 3.5’ 122 3.1’ 1.4’
3’ 5.2’ 54 4.7’ 2.1’
4’ 6.9’ 30 6.2’ 2.8’
5’ 8.7’ 20 7.8’ 3.5’
3900 4000
35W MR16
SP (FRA) 20˚
6’ 94 2.9’ 2.9’
8’ 53 3.8’ 3.8’
10’ 34 4.8’ 4.8’
12’ 24 5.8’ 5.8’
5’ 2.9’ 88 3.3’ 2.8’
7’ 4.0’ 45 4.6’ 3.9’
9’ 5.2’ 27 5.9’ 5.0’
11’ 6.4’ 18 7.2’ 6.1’
3’ 3.0’ 134 3.1’ 2.0’
5’ 5.0’ 48 5.1’ 3.4’
7’ 7.0’ 25 7.1’ 4.8’
9’ 9.0’ 15 9.2’ 6.1’
2’ 3.5’ 106 4.6’ 1.9’
3’ 5.2’ 47 7.0’ 2.9’
4’ 6.9’ 27 9.3’ 3.6’
5’ 8.7’ 17 11.6’ 4.8’
3400 6000
50W MR16
NFL (EXZ) 27˚
6’ 180 1.4’ 1.4’
12’ 80 2.1’ 2.1’
16’ 45 2.8’ 2.8’
20’ 29 3.5’ 3.5’
7’ 4.0’ 152 1.6’ 1.4’
10’ 5.8’ 75 2.3’ 2.0’
13’ 7.5’ 44 3.0’ 2.8’
16’ 9.2’ 29 3.7’ 3.2’
3’ 5.2’ 160 2.1’ 1.0’
4’ 6.9’ 90 2.9’ 1.4’
5’ 8.7’ 58 3.6’ 1.7’
6’ 10.4’ 40 4.3’ 2.1’
11500 4000
37W MR16 IR
NSP 10˚
6’ 97 2.7’ 2.7’
8’ 55 3.5’ 3.5’
10’ 35 4.4’ 4.4’
12’ 24 5.3’ 5.3’
5’ 2.9’ 91 3.0’ 2.6’
7’ 4.0’ 46 4.2’ 3.6’
9’ 5.2’ 28 5.4’ 4.6’
11’ 6.4’ 19 6.6’ 5.6’
2’ 3.5’ 109 4.2’ 1.8’
3’ 5.2’ 49 6.2’ 2.7’
4’ 6.9’ 27 8.3’ 3.5’
5’ 8.7’ 18’ 10.4’ 4.4’
3500 4000
37W MR16 IR
NFL 25˚
4’ 128 2.9’ 2.9’
6’ 57 4.4’ 4.4’
8’ 32 5.8’ 5.8’
10’ 21 7.3’ 7.3’
3’ 1.7’ 148 3.0’ 2.5’
5’ 2.9’ 53 5.1’ 4.2’
7’ 4.0’ 27 7.1’ 5.9’
9’ 5.2’ 16 9.1’ 7.6’
1’ 1.7’ 258 4.8’ 1.5’
2’ 3.5’ 64 9.7’ 2.9’
3’ 5.2’ 28 14.5’ 4.4’
4’ 6.9’ 16 19.3 5.8’
2050 4000
37W MR16 IR
FL 40˚
8’ 219 1.4’ 1.4’
12’ 97 2.1’ 2.1’
16’ 55 2.8’ 2.9’
20’ 35 3.5’ 3.5’
7’ 4.0’ 186 1.6’ 1.4’
10’ 5.8’ 91 2.3’ 2.0’
13’ 7.5’ 54 3.0’ 2.6’
16’ 8.2’ 36 3.7’ 3.2’
5’ 5.0’ 198 1.8’ 1.2’
7’ 7.0’ 101 2.5’ 1.7’
9’ 9.0’ 61 3.2’ 2.5’
11’ 11.0’ 41 3.8’ 2.7’
3’ 5.2’ 194 2.1’ 1.0’
4’ 8.9’ 109 2.9’ 1.4’
5’ 8.7’ 70 3.6’ 1.7’
6’ 10.4’ 49 43’ 2.1’
14000 4000
73W MR16
SP 10˚
0° Aiming Angle 30° Aiming Angle 30° Aiming Angle 45° Aiming Angle
4’ 156 2.5’ 2.6’
6’ 59 3.8’ 3.8’
8’ 39 5.2’ 5.2’
10’ 25 6.5’ 6.5’
3’ 1.7’ 180 2.7’ 2.3’
5’ 2.9’ 65 4.5’ 3.8’
7’ 4.0’ 33 6.3’ 5.3’
9’ 5.2’ 20 6.1’ 6.6’
3’ 3.0’ 98 4.4’ 2.8’
4’ 4.0’ 55 5.8’ 3.7’
5’ 5.0’ 35 7.3’ 4.6’
6’ 6.0’ 25 6.7’ 5.5’
1’ 1.7’ 313 3.8’ 1.3’
2’ 3.5’ 78 7.5’ 2.6’
3’ 5.2’ 35 11.4’ 3.9’
4’ 6.9’ 20 15.2’ 5.2’
2500 4000
73W MR16
FL 36˚
Accent Lighting Performance Data
ProSpec®Linear Downlight PE3M1675
Page 2 of 2 3 Light MR 16 Series E
