VP PARABOLIC ADS8G16MS140
Page 1 of 2 8”x48” RECESSED FLUORESCENT16 CELL PARABOLIC LOUVER
STATIC IES RP24 PREFERRED
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
PERFORMANCE
In an installation of 2 lamp 32W luminaires in a room cavity ratio of 1
reflectance 80% ceiling, 50% post-wall, 20% floor the CU. shall no be less than
0.69. To prevent glare the VCP shall not be less than 88 either lengthwise or
crosswise (at 100 fc level) and that the average luminance will conform with the
IES RP-24 preferred standard, and have a fixture efficiency of not less than 60%.
MATERIALS
Chassis parts are die-formed 20 gauge cold rolled steel.
LOUVER
Post-anodized aluminum.
FINISH
Louver - Low iridescense specular post-wall, anodized vertical grain sheet or
Low iridescence reflector matte post-anodized vertical grain sheet. Chassis exte-
rior white baked polyester powder coat.
ELECTRICAL
Rapid start HPF thermally protected class “P”ballast CBM certified by ETL if
K.O. is within 3”of ballast use wire suitable for at least 90”.
LABELS
Listed by CSA/UL.
•Meets IES RP-24 Preferred Practice.
•Ideal for intensive VDT use areas.
•Only 5.5”deep.
•Utilizes CFI Advance Technology Reflector Louver.
•Precise fitting reflector louver.
•Louver securely held with CFI concealed torsionite spring clips
•Fixture Efficiency 62.4%
Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] •Fax [phone]
631 Airport Road, Fall River, MA 02720 •[phone] •Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902 Section 2/Folio G09-10

VP PARABOLIC ADS8G16MS140
Page 2 of 2 8”x48”RECESSED FLUORESCENT16 CELL PARABOLIC LOUVER
STATIC IES RP24 PREFERRED
40116G8SAD
Advance
Technology
Full Width
Refector Louver
48”in length
Fixture Width
8 = 8
Ceiling Type
G = Grid
(Lay in T-Bar)
Number of
Cells Louver finish
MS-Low
Iridescence
Reflector Matte
PS-Low Iridescence
CFI Anodized
Specular
Lamp Quantity
Lamp
Length
40 = 48”
Voltage
120
277
347
Ballast Type
OC = T8
SO = Electric
T8
DI = dimming
Options
Add appropriate
suffix to calalog
no., ie HRD)
Body Style
S=Static
Consult factory for availability of louver finishes.
SPECIFICATIONS
PERFORMANCE: In an installation of 2 lamp 32W luminaires in a room cavity
ratio of 1 reflectance 80% ceiling, 50% post-wall, 20% floor the CU. shall no be
less than 0.69. To prevent glare the VCP shall not be less than 88 either length-
wise or crosswise (at 100 fc level) and that the average luminance will conform
with the IES RP-24 preferred standard, and have a fixture efficiency of not less
than 60%.
MATERIALS: Chassis parts are die-formed 20 gauge cold rolled steel.
LOUVER:Post-anodized aluminum.
FINISH: Louver - Low iridescense specular post-wall, anodized vertical grain
sheet or Low iridescence reflector matte post-anodized vertical grain sheet.
Chassis exterior white baked polyester powder coat.
ELECTRICAL: Rapid start HPF thermally protected class “P”ballast CBM certi-
fied by ETL if K.O. is within 3”of ballast use wire suitable for at least 90”.
LABELS:Listed by CSA/UL.
