Lightolier 83ED17R SERIES User manual

8307U ED17 Open/Square Lytespot
for Unprotected Lamp
8317U ED17 Enclosed/Round Lytespot
for Unprotected Lamp
READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE INSTALLING FIXTURE
This fixture is intended for installation in accordance with the National Electrical Code and local regulations.
To assure full compliance with local codes and regulations, check with your local electrical inspector before
installation. To prevent electrical shock, turn off electricity at fuse box before proceeding.
Retain these instructions for maintenance reference.
INSTRUCTION SHEET NO.
IS:83ED17
C0104 Page 1 of 2
INSTRUCTIONS FOR ATTACHING 83ED17R SERIES REFLECTORS TO
POWERARC MODULAR ED17 LYTESPOT (ROUND OR SQUARE FRONT)TM
LIGHTOLIER a GENLYTE THOMAS company.
631 Airport Road, Fall River, MA 02720
INSTRUCTIONS FOR ATTACHING 83ED17R SERIES
REFLECTORS TO A PowerArc ED17 SPOT:
(See chart below for compatible luminaires)
NOTE: Reflectors must be installed prior to lamps. After
reflector is installed, see IS:83S for installation, lamp-
ing, and operating instructions.
1. Orienting LABEL in the UP position, hold REFLECTOR
by the LIP and push into REFLECTOR CUP until
REFLECTOR SPRINGS engage. (See FIG. 6 and 7).
2. Rotate REFLECTOR clockwise until the REFLECTOR
SPRINGS hit the ROTATION STOPS on the REFLEC-
TOR CUP. (See FIG. 7)
To remove REFLECTOR:Remove lamp, rotate
REFLECTOR counterclockwise until REFLECTOR
SPRINGS snap into REMOVAL SLOTS. Pull REFLEC-
TOR out of REFLECTOR CUP. (See Fig. 7)
COMPATIBLE LUMINAIRES
Cat. No. Product Group Description
8307 Lytespan Track
ED17 Open/Square Lytespot
for Protected Lamp
8317 ED17 Enclosed/Round Lytespot
for Protected Lamp
REMOVAL
SLOT ROTATION
STOP
REFLECTOR
SPRING
REFLECTOR
LIP
REFLECTOR
SPRINGS
REFLECTOR
REFLECTOR
CUP
ED17
SPOT
REFLECTOR
LABEL
FIG. 6
FIG. 7
(UP POSITION)

COMPATIBLE LUMINAIRES
Cat. No. Product Group Description
8387 ED17 50W Magnetic HID Lytespot
8387E ED17 50W Electronic HID Lytespot
8388 Lytespan Track ED17 70W Magnetic HID Lytespot
8388E ED17 70W Electronic HID Lytespot
8389E ED17 100W Electronic HID Lytespot
PDE17 Series ED17 HID Pull-Down
SRE17 Series Calculite ED17 HID Semi-Recessed
Fig. 1
REFLECTOR
REFLECTOR
SPRINGS
REFLECTOR
CUP
ACCESS
KNOB ED17 LYTESPOT
ACCESSORY
CARTRIDGE
LIP
READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE INSTALLING LUMINAIRE.
This luminaire is intended for installation in accordance with the National Electrical Code and local regulations.
To assure full compliance with local codes and regulations, check with your local electrical inspector before
installation. To prevent electrical shock, turn off electricity at fuse box before proceeding.
Retain these instructions for maintenance reference.
INSTRUCTION SHEET NO.
IS:83ED17
C0104 Page 2 of 2
INSTRUCTIONS FOR ATTACHING 83ED17R SERIES REFLECTORS TO
ED17 HID LYTESPOTS SERIES LUMINAIRES.
LIGHTOLIER a GENLYTE THOMAS company.
631 Airport Road, Fall River, MA 02720
INSTRUCTIONS FOR ATTACHING 83ED17R SERIES REFLECTORS TO AN HID
ED17 LYTESPOT LUMINAIRE:
(See chart below for compatible luminaires)
NOTE: Reflectors must be installed prior to lamps. After reflector is assem-
bled, see IS:8387 for Lytespot installation, lamping, accessory, and operating
instructions.
1. If Lytespot is already attached onto a track, make sure power to the
track is turned off before proceeding.(Lytespan Track luminaire is
shown in Figs. 1 & 2. Instructions 2-4 are the same when using
Calculite luminaire.
2. Holding ACCESSORY CARTRIDGE, loosen ACCESS KNOB a few turns
until ACCESSORY CARTRIDGE opens. SWING the CARTRIDGE open
for access to REFLECTOR CUP (See Fig. 1).
3. Holding REFLECTOR by the LIP, push REFLECTOR into REFLECTOR CUP
until REFLECTOR SPRINGS engage (See Fig. 2)
4. Rotate REFLECTOR clockwise until the REFLECTOR SPRINGS
hit the ROTATION STOPS on the REFLECTOR CUP (See fig. 2).
To remove REFLECTOR, remove lamp, rotate REFLECTOR
counter-clockwise until REFLECTOR SPRINGS snap off into
REMOVAL SLOTS. Pull REFLECTOR out of REFLECTOR CUP
(See fig. 2).
Fig. 2
REFLECTOR
REFLECTOR
SPRINGS
ROTATION
STOP
REMOVAL
SLOT
