3" ELEMENTS
927
COOPER LIGHTING
IRIS®
COOPER LIGHTING
E3OVAL 2" Oval - Adjusts To 45°
Add Flange style
Lamp: P3MR, RPN3MR, P3MR REMOTE: 50W MR16
PN3MR, PN3MR REMOTE: 71W MR16
Dimensions: OD: 5 1/8" (130mm)
E3PINRD 1 3/4" Adjustable Pinhole with Radius Edges -
Adjusts To 45°
Add Flange Style
Lamp: P3MR, RPN3MR: 50W MR16
P3MR REMOTE, PN3MR, PN3MR REMOTE: 71W MR16
Dimensions: OD: 5 1/8" (130mm) Aperture: 2" (51mm)
E3SA Super Adjustable 15° - 75° Tilt
(Includes Hex cell Louver)
Lamp: P3MR, RPN3MRSA: 50W MR16
P3MR REMOTE, PN3MR, PN3MR REMOTE: 71W MR16
Dimensions: OD: 5 1/8" (130mm)
E3LWW Lensed Wall Wash
Add Cone Color and Flange style
Lamp: P3MR, RPN3MR, P3MR REMOTE: 50W MR16
PN3MR, PN3MR REMOTE: 71W MR16
Dimensions: OD: 5 1/8" (130mm) Aperture: 3 1/2" (89mm)
E3AASR Wet Location Angle Cut Reflector - Adjusts To 45°
Add Cone Color and Flange style
Lamp: P3MR, P3MR REMOTE, RPN3MR: 50W MR16
PN3MR, PN3MR REMOTE: 71W MR16
Dimensions: OD: 5 1/8" (130mm) Aperture: 3 1/2" (89mm)
E3AASRPIN Wet Location 2" Adjustable Pinhole - Adjusts To 45°
Add Flange Style
Lamp: P3MR, P3MR REMOTE, RPN3MR: 42W MR16
PN3MR, PN3MR REMOTE: 71W MR16
Dimensions: OD: 5 1/8" (130mm) Aperture: 2 (51mm)
E3SR Wet Location 50° Cutoff Reflector
Add Cone Color and Flange style
Lamp: P3MR, P3MR REMOTE, RPN3MR: 50W MR16
P3MR REMOTE, PN3MR, PN3MR REMOTE: 71W MR16
Dimensions: OD: 5 1/8" (130mm) Aperture: 3 1/2" (89mm)
Cone Finishes:
C=Clear Specular Alzak
H=Haze Clear Semi-Specular Alzak
G=Champagne Gold Specular Alzak
B= Specular Black Alzak
WMH =Warm Haze Semi-specular Alzak with a
hint of gold to add visual warmth
GP = Graphite Gunmetal grey, specular Alzak
GPH = Graphite Haze Graphite, semi-specular Alzak
W= Gloss White Paint
MW = Matte White
K= Cognac Warm copper color, specular Alzak
KH = Cognac Haze, semi-specular Alzak
Baffle Options
BB=Black Baffle
WB = White Baffle
Flanges
Blank = Matte white die-cast flange ring, removable
for field painting
RAW = Die cast trim ring, mill finish
SF = Self Flange (4 7/8" OD) (flange color matches
reflector cone) Not recommended for use with
RPN3MR.
SFWF = Self Flange painted Matte White (4 7/8" OD)
E3PIN and E3OVAL
Blank = Matte White painted die-cast trim ring with
black oculus (when present)
W= Matte White painted die-cast trim ring with white
oculus (when present)
POL = Polished Aluminum with Black Oculus
SAL = Satin Aluminum with Black Oculus
ELEMENT OPTIONS
Example:
E3MR
Cone
Finish
Flange
Type and
Finish
Example:
E3MR
Baffle
Finish
Flange Type and
Finish (self flange
not available)
Example:
E3PIN
Flange Type and
Finish (self flange
not available)
3" WALL WASH ELEMENTS
