Lytecaster® Recessed Downlighting 1131
Page 1 of 2 6 3/4" Aperture Shallow Slope Ceiling Reflector Trim 14°–30° Angle, 3/12–7/12" Pitch
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Reflector Trim Frame-In Kit — See Individual Frame-In Kit Specification Sheets
Incandescent
Frame-In Kit Installation Type Lamping Height
1131 Black Step Baffle 1100IC IC 75W PAR30 (Short Neck) 7 5/16”
1131WH White Step Baffle 1100AICM AirSeal® IC 65W BR30 7 5/16”
1131GD Specular Gold 1104ICX/N AirSeal® IC 75W PAR30 (Short Neck) 7 1/4”
1131CL Specular Clear 85W BR30
1131BK Specular Black
Features
1. Housing: Hydroformed aluminum, .040” thick; white trim flange.
2. Aperture: Conical aluminum step baffle, matte black or gloss white finish;
or hydroformed aluminum cone, specular finish. For ceiling slopes 14° - 30°
angle, 3/12 - 7/12 pitch.
3. Lamp Housing: Hydroformed aluminum, .040" thick; permits ± 7° vertical
adjustment for straight downlighting.
4. Frame-In Kit: See Frame-In Kit specification sheets for more details.
Options & Accessories
Extra Wide Flange Trim Ring: 1954 - 8 5/8" O.D.
Labels
UL (Suitable for Damp Locations), I.B.E.W.
1100IC Mounting Frame must be installed with
the J-Box on the “UPHILL” side.
1131/1100IC Series
Insulated Ceiling
1104ICX/N Mounting Frame must be installed
with the J-Box on the “DOWNHILL” side.
7 5/16”
1131/1104ICX/N
™ AirSeal® Insulated Ceiling
7 1/4”
