Lightolier EXTENSION WAND User manual

I
P5
READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE INSTALLING FIXTURE INSTRUCTION SHEET NO.
Thisfixture is intended for installation in accordance with the National Electrical Code and local regulations.
To assure full complianm with local codes and regulations, check with your local electrical inspector before
installation. Toprevent electrical shock, turnoff electricity at fuse box before proceeding. IS:6074
Retain these instructions for maintenance reference. ROI 93 Page 1of 2
INSTALLATION FOR AITACHING EXTENSION WAND TO LYTESPAN TRACK
FOR USE WITH LYTESPAN@TRACK SYSTEMS ONLY
Lytespot extension wand can be mounted on any Basic, Advent, Multipoint or Monopoint Track. It is intended for insulation on level ceilings only. Do not
mount on slope ceilings or walls unless when used with extension wand sloped ceiling adapter (6079WH, BK) ordered separately. Will fit Lytespot fixtures
with Squat Adaptors, Low Voltage Adapters and Standard “T” Adaptors. NOTE: Do not exert sideward pressure on fixture,
NOTE: This Extension Wand is equipped with aflex joint to prevent damage by accidental impact. Heavy asymetric lighting equipment
should NOT BE used on this device.
1.Grasp FllllNG at top of EXTENSION WAND and insert it into the LYTESPAN TRACK. The LOCKING LEVER must be on the same side of the track as the BEAD,
(See Fig. 1.)
2. Rotate the top FITTING 90° clockwise, )See Fig. 2), until LOCKING LEVER snaps and locks in place. (See Fig. 3.) Do not rotate wand from STEM or
BOllOM HOUSING,
3. To Remove: Depress LOCKING LEVER; then rotate TOP FITTING 90° counter-clockwise. Do not rotate wand from STEM or BOITOM HOUSING,
LYTESPAN
TRACK
BEAD FITTING
LOCKING
LEVER CLO
.1 IG. 2
INSTRUCTIONS FOR CONVERTING Fll_llNG TO OPERATE ON BRASS CONTACT
2CIRCUIT TRACK SYSTEMS
See Fig. 4. BRASS CONTACT can be raised or lowered, Broken line indicates position for 1circuit
track or lower circuit of 2circuit track system. LOCKING
To convert attachment FllTING for upper circuit of 2circuit track, raise BRASS CONTACT to high LEVER
position by lifting CONTACT as high as stop permits and CONTACT clicks into place. FIG. 4
INSTRUCTIONS FOR AllACHING LYTESPOW FIXTURES USING SQUAT ADAPTER TO BOllOM OF LYTESPAN@ WAND
1. Insert the FIXTURE FITTING into the WAND SOCKET,
The LOCKING LEVER must start on the same side as the bead located at the bottom of the wand (See Fig. 5.) Rotate the FIXTURE FITTING 90° clockwise
until LOCKING LEVER snaps and Iockd into place. (See Fig, 5,6, &7).
2. To remove, depress LOCKING LEVER and rotate FllllNG 90° counterclockwise,
BEAD BRASS CONTACT
Lf~;~RG ~
\a/
k,
CAUTION: SUPPORT THE LOWER WAND HOUSING WHENEVER MANIPULATING THE FIXTURE.
B. I<5 n-l 7-<>L IE R“
EiHy!ii&y&&

I
v
INSTRUCTION SHEET NO.
1S:6074 INSTALLATION FOR AITACHING EXTENSION WAND TO
LYTESPAN TRACK
RO193 Page 2of 2FOR USE WITH LYTESPAN@TRACK SYSTEMS ONLY (Cent’d)
INSTRUCTIONS FOR ATTACHING LOW VOLTAGE LYTESPOT TO LYTESPAN” WAND
1,insert the FIXTURE FITTING into the WAND SOCKET,
The LOCKING LEVER must start on the same side as the bead located at the bottom of the WAND SOCKET (See Fig. 8,) Rotate the FIXTURE
FllliNG 90° clockwise. (See Fig. 8,9, &10),
2. To remove, rotate FllllNG 90° counterclockwise,
.
WAND –
SOCKET r-l n
BEAD
IMPRG _CLOCKWISE
(@m
t\
{f“ 1\
FIG. 8FIG. 9FIG. 10
INSTRUCTIONS FOR AllACHING LYTESPOF WITH “T” ADAPTOR TO LYTESPAN@ WAND
1. Align BEAD on WAND SOCKET with GROOVE in FITTING before inserting into WAND SOCKET, see Fig. 11, (BEAD is NOT aligned
apotential hazard may result,)
2, Position LEVER as shown in Fig. 11.
3, Insert FllTING into WAND SOCKET. Turn LEVER 90° to make mechanical and electrical connection. See Fig. 12.
4. To remove: reverse procedure.
‘4
CONTACT HUB
WAND
SOCKET .._~
$
GROUNDING SPRING
BEAD _REMOVE CORK AND ._ ————
PAINT (IF PRESENT)
-“
*
FROM THIS AREA
-“ ;\t:;UDIE PROPER =... LOCK
GASKET -.-J
1
3
GROOVE \RELEASE
LEVER
FITTING
FIG. 11 FIG. 12 FIG. 13
NOTE:If “T” ADAPTOR has afull gasket on top, remove 1/2” strip of cork between contact hub and grounding spring. If there is no
gasket, and atighter fit to the WAND is desired, remove backing from enclosed GASKET. When centered on FllllNG apply pressure
on GASKET to secure it.
\
—
