E4Series Emergency Lighting E4
Page 1 of 2 6 Volt or 12 Volt, 18 to 250 Watts Steel Housing
Lightolier is a Philips group brand
The E4 Series provides egress lighting in a wide variety of wattages. The classical steel housing and high performance electronics make the units ideal for commercial or light industrial
applications.
18W - 50W Lead Calcium & Nickel
Cadmium
75W - 100W Lead Calcium 125W Lead Calcium
3.0”
7.6 cm
7.3”
18.5 cm
14.0”
35.6 cm
5.4”
13.7 cm
8.8”
22.4 cm
12.5”
31.8 cm 7.6”
19.3 cm
12.0”
30.5 cm
16.0”
40.6 cm
6.0”
15.2 cm
6.0”
15.2 cm
Features
1. Illumination: Allows up to three mounted lamp heads. The standard lamp
head incorporates a high performance parabolic reflector with a wedge base
tungsten lamp. Allows maximum spacing between units along a path of
egress.
2. Housing: Constructed of 20 gauge (18-100w) or 18 gauge (125w) steel with
a white corrosion-resistant, epoxy powder coat finish. Easily mounted with
keyhole slots or shelf mounting. Universal j-box mounting pattern on 18-50w
units.
3. Electronics: 120/277 VAC dual voltage input with surge-protected, solid-
state circuitry. Charging system is complete with low voltage disconnect, AC
lockout, brownout protection, AC indicator lamp and test switch.
4. Battery: Maintenance free, sealed lead calcium battery has an estimated
service life of 5 years, and an operating temperature range of 65°F (19°C) to
85°F (30°C). Maintenance free, sealed nickel cadmium battery has an esti-
mated service life of 10 years, and an operating temperature range of 20°F
(-7°C) to 95°F (35°C).
5. Input Power Requirements:
6 & 12 Volt Units
18-50 watt units: .15A (120 VAC), .65A (277 VAC)
75-125 watt units: .50A (120 VAC), .22A (277 VAC)
12 Volt Units
150-250 watt units: .67A (120 VAC), .29A (277 VAC)
Code Compliance
UL 924 listed.
Options
SD = Self-Diagnostics
SA = Self-Diagnostics with Alarm
V= Voltmeter 1
A= Ammeter 1
T1 = 120 VAC Time Delay (15 minutes)
T2 = 277 VAC Time Delay (15 minutes)
Options (continued)
LCK1 = Line Cord (6’, 120 VAC field installed)
F1 = 120 VAC Fuse
F2 = 277 VAC Fuse
P1 = 120 VAC Power Switch
P2 = 277 VAC Power Switch
DC = DC Power Switch
ST = Special Input Transformer (specify voltage and frequency)
Multiple option configurations may void UL listing. Consult factory for specifics.
Accessories
WG5 = Wire Guard (36-100w lead calcium, 25-50w nickel cadmium)
WG = Wire Guard (125-250w lead calcium, 100-150w nickel cadmium)
MLSHELFW = White Mounting Shelf (36-50w lead calcium, 25-50w nickel cadmium)
MJSHELFW = White Mounting Shelf (75-100w lead calcium)
MXSHELFW = White Mounting Shelf (125-250w lead calcium, 100-150w nickel cadmium)
6.0”
15.2 cm
How to Specify:
E4 1 W
SERIES VOLTAGE BATTERY/ # OF SUGGESTED HOUSING
DC WATTAGE LAMP HEADS LAMP HEADS C0LOR
NOTES:
1) Not available for use with SD, SA and SDTD options.
W = White6V, Tungsten, Wedge Base
RT6 = 5.4W
RT7 = 7.2W
RT9 = 9W
3 = Three
2 = Two
1 = One
Blank = No Heads
6V, Lead Calcium
18L = 18W
25L = 25W
36L = 36W
50L = 50W
75L = 75W
10L = 100W
12L = 125W
6V, Nickel Cadmium
25N = 25W
50N = 50W
1 = 6V
2 = 12V
E4 = Steel Emergency
Lighting Unit
Complete Fixture consists of unit and two lamp heads. * Select options and accessories below.
1

Job Information Type:
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • F0308
E4 Series Emergency Lighting E4
Page 2 of 2 66 Volt or 12 Volt, 18 to 250 Watts Steel Housing
Lightolier is a Philips group brand
Unit Battery Capacity
RT7 - 6 Volt, 7.2 Watt, Tungsten
Lamp Head Photometrics
RT9 - 6 Volt, 9 Watt, Tungsten
Warranty
Electronics: 3 years
Battery: 1 year full, 4 years pro-rata (lead calcium);
5 year full, 5 years pro-rata (nickel cadmium)
RT6 - 6 Volt, 5.4 Watt, Tungsten
* Per NEC Specifications
DC Suggested Watts to 871⁄2
Voltage Unit Lamp Head of Rated Voltage*
11⁄2 hrs. 2 hrs. 4 hrs. 8 hrs.
6 E4118L RT9 18 13.5 7 —
E4125L RT9 25 19 9.5 —
E4136L RT9 36 27 14 7.2
E4150L RT9 50 37.5 19 10
E4175L RT9 75 56.5 28.5 15
E4110L RT9 100 75 38 20
E4112L RT9 125 94 47.5 21.5
E4125N RT9 25 19 9.5 —
E4150N RT9 50 37.5 19 10
