Lightolier Lytespan DRL11 User manual

Ordering Information
Catalog No. Finishes Track Mounting Lamp
DR2LS11WH White Compatible with Lytespan Basic, Radius and Advent Track Systems; and all AR111, 75W Max.
DR2LS11BK Black Multipoint and Monopoints. PAR36 12V, 75W Max.
DR2LS11SL Silver DO NOT USE with Extension Wands, Sloped Ceiling Adapter or ProSpec Track.
8292WE
0400
Lytespan®Track Lighting System DRL11
Page 1 of 2 Director®Low Voltage Spot PAR36/AR111
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 •[phone] •Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2004 Genlyte Thomas Group LLC (Lightolier Division) •03/15/04
Description
Remote controlled spotlight that can be mounted anywhere along the track
and remotely aimed through the use of a hand-held controller.
Features
1. Full remote control of pan and tilt movement to aim at any object below
the luminaire.
2. Lamp brightness can be adjusted in 1% steps.
3. Compatible with external dimming systems.
4. Positions and dim setting can be recorded for future use.
5. Continuous movement and sequencing option.
6. Die-cast aluminum housing.
7. Electronic low voltage transformer.
Options & Accessories
Accepts 2 accessories max.
AF3 Diffusion Filters
ADF3 Color Filters
AL3HC Hex Cell Louver
Labels
cULus Classified
( ) Denotes dimensions in mm
11 11/16”
(297)
4 3/4”
(120)
2”
(50)
6 11/32”
(161)
6 5/32”
(156)
Requires Laser
Remote Control
for Operation

Lytespan®Track Lighting System DRL11
Page 2 of 2 Director®Low Voltage Spot PAR36/AR111
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 •[phone] •Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2004 Genlyte Thomas Group LLC (Lightolier Division) •03/15/04
Job Information Type:
Lighting Data
LAMP 0˚ AIMING ANGLE A=30˚ AIMING ANGLE A=45˚ AIMING ANGLE A=60˚ AIMING ANGLE
Aiming Angle 0˚ 30˚, 45˚ or 60˚ Horizontal 30˚, 45˚ or 60˚ Vertical
LBeam Length
WBeam Width
CDistance to center beam
DDistance
AAiming Angle
FC Footcandles
Land Ware the outer points where the candle
power drops to 50% of the maximum. FC are the
initial footcandles at the center of the beam.
L
W
FC
D
FC
D
LC
A
WL
W
FC
D
