Lightolier Lytecaster 1171 User manual

Lightolier a Genlyte company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Group LLC • I1111
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
1171
Lytecaster®Recessed Downlighting 1171
Page 1 of 2 6 3/4" Aperture Basic White Reflector Reflector Trim
Features
1. Reflector: Hydroformed aluminum, .040" thick (18 ga.) ; non-yellowing,
scruff-resistant Perma White finish with 88% reflectance; white trim flange.
2. Frame-In Kit: (1102P1 standard frame shown). Other frames listed above
and shown on the right. See Frame-In Kit specification sheets for more
details.
Options & Accessories
Spread Lens: L56WWLENS - Proprietary spread lens for use with
combination of wall washer optics and LED Frame-In Kits.
Labels
UL (Suitable for Damp Locations), I.B.E.W.
1171/1100 DEEP IC Series
Incandescent Insulated Ceiling
9 1/4"
1171/1104ICR
0™Convertible
Remodeler IC/Non-IC
7 1/2"
1171/1104IC/N
0™Convertible
IC/Non-IC
7 1/2"
Reflector Trim Frame-In Kit — See Individual Frame-In Kit Specification Sheets
1171
Basic White
LED Fluorescent
Frame-In Kit Installation Type Lamping Height
Frame-In Kit Ceiling Type Lamping Height
L56LED Non-IC Retrofit LED 7 1/8" 1104F13 Series IC (1) Quad/Triple 13W (GX24q-1) 7 1/2"
Incandescent 1104F18 Series IC (1) Quad/Triple 18W (GX24q-2) 7 1/2"
Frame-In Kit Ceiling Type Lamping Height 1104F26* Series IC (1) Quad/Triple 26W (GX24q-3) 7 1/2"
1102P1
1103R
Non-IC
Non-IC Remodeler
100W A19
150W PAR38, BR40
250W R40
(heat lamp)
7 1/8"
7 1/8" 1100FTU Series Non-IC (1) Triple 26/32W (GX24q-3) 7 1/8"
1100IC
1100AICM
1100DICM
1100DAICM
IC
AirSeal®IC
Deep IC
Deep AirSeal® IC
60W A19
90W PAR38
100W BR40
7 5/16"
7 5/16"
9 1/4"
9 1/4"
1100AICMFT AirSeal®-IC (1) Triple 26/32W (GX24q-3) 6 7/8"
1104ICX/N AirSeal® IC 60W A19
100W PAR38
120W BR40
7 1/4" 1910XFH1 Conversion
Kit
(1) Quad 13W (GX23-2) 7 1/8"
1104IC/N
1104ICR
AirSeal®IC
IC Remodeler
52W A19
75W PAR38
85W BR40
7 1/2"
7 1/2"
1910XDH1 Conversion
Kit
(2) Quad 13W (GX23-2) 7 1/8"
1104IC/N
1104ICR
Non-IC
Non-IC Remodeler
75W A19
150W PAR38
120W BR40
7 1/2"
7 1/2"
* Lightolier recommends the use of triple tube lamps.
6 1/2"
7 9/16"
7 1/8
2
1
1" Max.
1171/1102P1 Series
Standard Incandescent
1171/1103R
0™Non-IC
Remodeler Ring
7 1/8"

Lightolier a Genlyte company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Group LLC • I1111
1171
Lytecaster®Recessed Downlighting 1171
Page 2 of 2 6 3/4" Aperture Basic White Reflector Reflector Trim
Job Information Type:
To convert lighting data for a lower wattage incandescent lamp of the same type, multiply the footcandle (or candlepower) values by the ratio of the lumens of the two lamps.
The coefficients of utilization remain the same.
Conversion Factor: 150W BR40 FL: C.U. x 1.0.
