Lightronics FXLD136RGB User manual

Page 1 of 6
FXLD136RGB LED FIXTURE
Version0.1 OWNERSMANUAL 12/29/2010
www.lightronic.com
Lightronics Inc. 509 Central Drive Virginia Beach, Va 234354 757 486 3588
FEATURES AND SPECIFICATIONS
LEDS: 36 1 Watt LEDs ( 12 red, 12 green, 12 blue)
Beam angle: 25 º
Control system: DMX-512
DMX channels: 3
DMX connectors: 3 pin XLR
LED lifetime: 60,000 hours
Voltage: 90 - 259 VAC / 24 VDC
Max power consumption: 50 Watts
Size: 9.75"D x 9"W x 7.5"H
Body material: plastic
Body color: silver
Weight: 4 lbs
DESCRIPTION
The FXLD136RGB is a PAR style RGB LED lighting
fixture. It is suitable for stage, disco, night club, and
other artistic applications. It has several stand alone
control modes, a master/slave mode, and can operate
via a DMX-512 external signal.
A double yoke enables it to be operated in several
positions.
INSTALLATION
LOCATION
The FXLD136RGB is rated IP20 and is intended for
INDOOR USE ONLY.
Locate the unit in a well ventilated area away from
moisture and heat. Holes are provided on the yokes to
install a lighting bar pipe clamp. A safety cable should
also be used.
POWER CONNECTIONS
The FXLD136RGB has a line cord for connection to a
120 VAC, 15 Amp, 60Hz, grounded service.
The safety ground pin on the power cord must be used.
DMX CONNECTIONS
A system using DMX control should be connected as a
chain of devices. In other words the control signal
cable should proceed from the controller to the first
receiving device and then to others in a continuous
"daisy chain" fashion.
The fixture has a DMX IN and a DMX OUT connector
to be used to connect the chain. The control cable
should NOT be split into a multiple run star
arrangement with a cable running from the controller
directly to each receiving device pack.
DMX CONNECTOR PIN ASSIGNMENTS
There are two different connectors which can be used
for DMX control. They are both XLR type connectors.
Some units use 3 pin connectors. Others use 5 pin
connectors. The FXLD136RGB receives a DMX signal
on the 3 pin MALE connector on the back of the unit.
The 3 pin FEMALE connector is used to connect the
next DMX device on the control chain. If your console
uses a 5 pin connector you can make up an adapter
cable to accommodate this. The table below shows the
pin assignments for BOTH the 3 pin and 5 pin
connectors.
IN # SIGNAL NAME
1 DMX COMMON
2 DMX DATA -
3 DMX DATA +
4 NOT USED
5 NOT USED
CAUTION
RISK OF ELECTRIC SHOCK

Page 2 of 6
FXLD136RGB LED FIXTURE
Version0.1 OWNERSMANUAL 12/29/2010
www.lightronic.com
Lightronics Inc. 509 Central Drive Virginia Beach, Va 234354 757 486 3588
DMX TERMINATION
A DMX chain should be terminated at the last
receiving device on the chain. This is done by
installing a commonly available 1/4 Watt, 120 Ohm
resistor across the DATA - and DATA + wires at the
last device. If you have only a few fixtures very close
together and a very short run to the controller then you
may be able to operate without the terminator.
OPERATION
Operating options are set using the LED display and 4
buttons
(MENU, ENTER, UP, DOWN) on the rear of
the fixture.
Push
MENU to access the operating options. Then use
UP and DOWN to scroll through the available choices.
When you reach the option you want to set or change -
push
ENTER .Now you can view the current setting
for the option and or change it. Push
ENTER to save
your changes. Push
MENU to return to the current
option display. See the "MENU NAVIGATION"
diagram for additional details.
There are 5 main operation modes: DMX, Manual,
Auto, Sound, Master/Slave
DMX OPERATION
Use the ADDR menu to set the starting address of the
unit. You can set the starting address of the unit with
the UP and DOWN buttons.
The fixture uses three channels with allocations as
follows:
CHANNEL 1: 0 - 255 Red level (255 = maximum)
CHANNEL 2: 0 - 255 Green level (255 = maximum)
CHANNEL 3: 0 - 255 Blue level (255 = maximum)
MANUAL OPERATION
For manual operation the level red, green, and blue
LEDs may be independently controlled. Use the rL-
- ,
gL--, and bL--, menus to set the levels. The range is
from 00 (OFF) to 12 (Full On).
AUTO OPERATION
Auto operation includes 3 sub modes: Flash (strobe),
Auto Fade, and Auto Sequence.
AUTO FLASH
The Auto Flash mode flashes the current color. Use
the FLAS menu to set the flash speed and activate the
option. The range is from 00 to 12. 12 is fastest.
AUTO FADE
The Auto Fade mode cycles smoothly through a
sequence of seven colors. Use the FADE menu to set
the speed and activate the option. The range is from 00
to 12. 12 is fastest.
AUTO SEQUENCE
The AUTO SEQUENCE mode switches through a
sequence of seven colors. Use the ASC- menu to set
the sequence speed and activate the option. The range
is from 00 to 12. 12 is fastest.
SOUND OPERATION
Sound operation has a Color and a Flash submode.
Use the SOUA menu to invoke the Sound Color
option. The unit will sequence through a series of
colors in sync with music base notes.
Use the SOUF menu to invoke the Sound Flash
option. The unit unit will flash through a series of
colors in sync with music base notes.
MASTER/SLAVE OPERATION
Connect the units together using DMX cables. Set all
FXLD136RGB REAR VIEW

Page 3 of 6
FXLD136RGB LED FIXTURE
Version0.1 OWNERSMANUAL 12/29/2010
www.lightronic.com
Lightronics Inc. 509 Central Drive Virginia Beach, Va 234354 757 486 3588
the units to be slaved to ADDR 001. Set the master
unit to any auto operation option. The slave units will
sync to the master sequence.
MAINTENANCE AND REPAIR
TROUBLESHOOTING
Check that you have power applied to the unit.
Check the fuse.
Check the DMX control cable.
Check the address settings of the unit and the
controller.
REPAIR
The only FXLD136RGB user serviceable part is a
5mm x 20mm externally accessible fuse.
DISCONNECT THE UNIT FROM POWER BEFORE
CHECKING OR REPLACING THE FUSE
Replace fuse ONLY with 1.0 Amp, 250VAC, fast
blow fuse.
Internal service on the unit by other than Lightronics
authorized agents will void the warranty. If service is
required, contact the dealer from whom you purchased
the item, or contact the Lightronics, Service
Department, 509 Central Drive, Virginia Beach, VA
23454. Tel: [phone].
CAUTION DO NOT OPEN UNIT
RISK OF ELECTRIC SHOCK
RISK OF FIRE

Page 4 of 6
FXLD136RGB LED FIXTURE
Version0.1 OWNERSMANUAL 12/29/2010
www.lightronic.com
Lightronics Inc. 509 Central Drive Virginia Beach, Va 234354 757 486 3588
MENU NAVIGATION

This product is warranted for a period of TWO YEARS from the date of purchase against defects in
materials and workmanship.
This warranty is subject to the following restrictions and conditions:
A) If service is required, you may be asked to provide proof of purchase from an authorized
Lightronics dealer.
B) This warranty is valid only for the original purchaser of the unit.
C) This warranty does not apply to damage resulting from abuse, misuse, accidents, shipping,
and repairs or modifications by anyone other than an authorized Lightronics service
representative.
D) This warranty is void if the serial number is removed, altered or defaced.
E) This warranty does not cover loss or damage, direct or indirect arising from the use or
inability to use this product.
F) Lightronics reserves the right to make any changes, modifications, or updates as deemed
appropriate by Lightronics to products returned for service. Such changes may be made
without prior notification to the user and without incurring any responsibility or liability for
modifications or changes to equipment previously supplied. Lightronics is not responsible
for supplying new equipment in accordance with any earlier specifications.
G) This warranty is the only warranty either expressed, implied, or statutory, upon which the
equipment is purchased. No representatives, dealers or any of their agents are authorized
to make any warranties, guarantees, or representations other than expressly stated herein.
H) This warranty does not cover the cost of shipping products to or from Lightronics for
service.
I) Lightronics Inc. reserves the right to make changes as deemed necessary to this warranty
without prior notification.
