Lightspeed CAT 860 User manual

User Manual
Classroom Audio System
860
CAT 860

TABLE OF CONTENTS
SECTION 1: 6 Important Safety Instructions
Overview 8 System Components and Unpacking
10 Optional Components
11 CAT 860 Front Panel Controls
12 CAT 860 Rear Panel Controls
13 Infrared Sensor / Receiver (ISR) Connections
14 REDMIKE Controls and Connections
15 Cradle Charger Controls and Connections
SECTION 2: 16 Step 1. Location of the Amplifier
Set-up & Use 17 Step 2. IR Sensor / Receiver (ISR) Installation
20 Step 3. Installation of Amplifier Wall-Mount Bracket
20 Step 4. Speaker Installation
21 Step 5A. Connect the Power Supply
21 Step 5B. ISR Connection
22 Step 5C. Speaker Connection(s)
22 Step 5D. Audio Input Connections
23 Step 6. Audio Integration
24 Step 7. Charging the REDMIKE
25 Step 8. Set-up and Operation of REDMIKE
26 9. Audio Equalization of the CAT 860
27 10. Output to Personal Assistive Listening Device
28 11. Using the REDMIKE to Amplify External Audio
Equipment
29 12. PageFirst: Priority Mute
30 13. RS-232 Serial Interface Programming
30 Serial Interface Protocol
30 RS-232 Data Signals
31 Connector Signal Wiring
31 Command Structure
32 Summary of Command & Response
Transactions
34 Control Character Hex Value and Definition
34 General Format for Action Command Exchange
for Basic and Advanced Command Set:
35 General Format for Query Command
Exchange:
35 General Format for Aborted Command
Exchange (Both Basic and Advanced Command
Sets:

36 14. RS-232 Serial Interface Command Definition
Basic Command Set for Audio Switcher
Operations
Audio Input Functions for the A/V Source
Group
36 1. Enable Audio/Video Source Command
37 2. Increment Audio/Video Sources
Command
38 3. Decrement Audio/Video Sources
Command
39 4. Increment Microphone Audio Inputs
Command
40 5. Mute Audio/Video Sources Command
41 6. Un-mute Enabled Audio/Video Source
Command
42 7. Mute Microphone Audio Inputs Command
42 8. Un-mute Microphone Audio Inputs Command
43 9. Toggle Mute for Enabled Audio/Video Source
Command
44 10. Toggle Mute for Microphone Audio Inputs
Command
45 11. Query Enabled Audio/Video Source
Command
46 12. Query Absolute Volume Audio/Video Source
Command
47 13. Query Absolute Volume Microphone Audio
Input Command
48 14. Query Mute for Audio/Video Source
Command
49 15. Query Mute for Microphone Audio Inputs
Command
Advanced Command Set for Audio Mixer
Operations
Audio Input Functions for the A/V Source Group
50 1. Select Audio Input Command
51 2. Query Selected Audio Input Command
Audio Input Functions for the A/V Source Group
52 1. Differentially Increase Volume for Selected
Audio Input Command
53 2. Differentially Decrease Volume for Selected
Audio Input Command
54 3. Set Absolute Volume for Selected Audio Input
Command
55 4. Query Absolute Volume for Selected Audio
Input Command
56 5. Select Audio Output Command
54 6. Differentially Increase Volume for Selected
Audio Output Command
TABLE OF CONTENTS CONT’D

Audio Input Functions for the Infrared Source
Group
56 1. Select Infrared Input Command
57 2. Differentially Increase Volume for Selected
Infrared Input Command
58 3. Differentially decrease volume for selected
infrared input Command
59 4. Set Absolute Volume for Selected Infrared
Input Command
60 5. Query Absolute Volume for Selected Infrared
Input Command
Input Muting Functions Group
66 1. Mute Selected Audio Input Command
67 2. Un-Mute Selected Audio Input Command
System Management Functions Group
68 1. Query Model and Software Version Command
67 2. Un-Mute Selected Audio Input Command
System Management Functions Group
68 1. Query Model and Software Version Command
SECTION 3: 71 REDMIKE VC: Controls and Connections
Optional Accessories 72 Charging
72 Initial Set-Up
73 LT-71: Controls and Connections
74 Charging
75 Initial Set-Up
76 REDMIKE Share: Controls and Connections
77 Charging
78 Initial Set-Up
79 iR Media Connector: Initial Setup
80 Audio Integration
80 Other Optional Accessories
SECTION 4: 81 Troubleshooting Guide
Troubleshooting 82 Tips to Obtain Optimal Audio Performance
SECTION 5: 83 Warranty Statement
Warranty &
Specifications
85 Safety Warnings and Certifications
86 System Specifications
TABLE OF CONTENTS CONT’D
55 7. Differentially Decrease Volume for Selected
Audio Output Command
56 8. Set Absolute Volume for Selected Audio
Output Command
57 9. Query Absolute Volume for Selected Audio
Output Command

1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use the apparatus near
water.
6. Clean only with dry cloth.
7. Do not block any ventilation
openings. Install in accordance
with the manufacturer’s
instructions.
8. Do not install near any heat
sources such as radiators,
heat registers, stoves, or other
apparatus (including amplifiers)
that produce heat.
9. Do not defeat the safety purpose
of the polarized or grounding-type
plug. A polarized plug has two
blades with one wider than the
other. A grounding- type plug has
two blades and a third grounding
prong. The wide blade or the third
prong is provided for your safety. If
the provided plug does not fit into
your outlet, consult an electrician
for replacement of the obsolete
outlet.
10. Protect the power cord from
being walked on or pinched
particularly at plugs, convenience
receptacles, and the point where
they exit from the apparatus.
11. Only use attachments/ accessories
specified by the manufacturer.
12. Use only with a cart, stand, tripod,
bracket or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used,
use caution when moving the cart/
apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during
lighting storms or when unused for
long periods of time.
14. Refer all servicing to qualified
service personnel. Servicing is
required when the apparatus has
been damaged in any way, such
as power-supply cord or plug is
damaged, liquid has been spilled
or objects have fallen into the
apparatus, the apparatus has been
exposed to rain or moisture, does
not operate normally, or has been
dropped.
15. When the mains plug or appliance
coupler used as the disconnect
device, it shall remain readily
operable.
16. Please keep the unit in a good
ventilation environment.
IMPORTANT SAFETY INSTRUCTIONS
6

8
1. Overview 3. Optional
Accessories 4. Troubleshooting 5. Warranty, Safety
& Specifications
2. Setup & Use
Amplifier Power
Supply
SECTION 1:
OVERVIEW
SYSTEM COMPONENTS AND UNPACKING
The standard configuration of the CAT 860 will contain:
ISR Infrared Sensor/
Receiver and Cable
Charging Cradle and
Power Supply
REDMIKE®
Classroom
Microphone
CAT 860 Amplifier
860

9
1. Overview 2. Setup & Use 3. Optional
Accessories 4. Troubleshooting 5. Warranty, Safety
& Specifications
Speakers and Speaker Wire
Systems can be configured with a variety of different speaker types,
including the following:
Standard Components
AMP-860 Audio amplifier/mixer
PS-24V-2.5 24V/2.5A power supply for CAT 860
RX-ISR Infrared sensor/receiver with mounting bracket
CA-PSE50 50’ plenum-rated Cat 5e cable
RMT REDMIKE classroom microphone with battery
BA-NH2A27 AA NiMH rechargeable sensing battery for REDMIKE
AC-RMLC2 REDMIKE lavaliere cord
BC-RMCC REDMIKE cradle charger
PS-5V-1.0 5V/1.0A power supply for cradle charger
SPEAKERS Contact Lightspeed at 800.732.8999 for speaker info
NXQ (x 1)
WMQ (x 4)
DRQ (x 4)
MCQ (x 1)

10
1. Overview 3. Optional
Accessories 4. Troubleshooting 5. Warranty, Safety
& Specifications
2. Setup & Use
OPTIONAL COMPONENTS
Optional equipment which may be part of your CAT 860 system:
REDMIKE® VC
Volume Control
Microphone
REDMIKE Share
Handheld Mic &
Charger Cable
LT- 71
LT-71 LightMic
and Charger
Cable
Optional Components
RMV REDMIKE VC microphone with battery
RMS REDMIKE Share handheld microphone with battery pack
LT71 LightMic microphone with batteries
BA-NH2A27 AA NiMH rechargeable sensing battery for REDMIKE
BA-NH2APK NiMH rechargeable battery pack for REDMIKE Share
BA-NH1 AA NiMH rechargeable battery for LT71 (2 per microphone)

11
1. Overview 2. Setup & Use 3. Optional
Accessories 4. Troubleshooting 5. Warranty, Safety
& Specifications
860
FRONT PANEL CONTROLS
1. POWER SWITCH/INDICATOR:
Press this button to turn the CAT
860 ON (pushed in) or OFF. When
the POWER is switched on, the
blue LED indicator will light.
2. AUDIO INDICATORS: These
lights flash red when audio (voice)
from the microphone is detected.
3. A VOLUME: Controls the volume
of the teacher microphone (set to
channel A).
4. B VOLUME: Controls the volume
of the student or second teacher
microphone (set to channel B).
5. AUDIO INPUT VOLUMES:
Control the volume of the audio
coming from the media source
(computer, TV/VCR, CD/DVD, etc.)
connected to the corresponding
input on the rear panel.
6. ALD OUTPUT AND VOLUME:
This jack sends mixed audio to
external equipment such as an
assistive listening device (Personal
FM System) or recording device.
Use the volume control to set
the optimum signal level for the
device.
2
2
1
34
5
6

12
1. Overview 3. Optional
Accessories 4. Troubleshooting 5. Warranty, Safety
& Specifications
2. Setup & Use
RS-232 IN
Front Panel RS-232
Control Select
12
++--
RS-232 IN
Front Panel RS-232
Control Select
12
++--
1. CONTROL SELECT: Both
microphone and aux input volume
can be adjusted from the front
panel controls or remotely from
a controller via the RS-232 Serial
Interface. This switch selects either
front panel control or RS-232
control. Front panel controls are
ignored during RS-232 operation.
2. RS-232 IN: A 9 pin connector
to connect the CAT 860 to an
external controller.
3. SPEAKER OUTPUTS (1–4): These
binding post connectors are used
to connect the CAT 860 to the
speakers. Depending on speaker,
all outputs may not be used.
*Note: Wiring to these terminals
should follow the Class 2 wiring
methods as outlined in the
National Electric Code.
4. CHARGERS: These jacks can
be used to charge the optional
LightMic or handheld mic as an
alternative to connecting them to
the REDMIKE cradle charger.
5. DC POWER: Plug the 24 V power
supply into this jack.
6. PAGING INPUT AND ADJ:
Connect the input from optional
PageFirst sensor here when
interface with a buildings paging
system. Use the ADJ control to
adjust the sensitivity if needed.
7. EQUALIZER (4-BAND): Adjust
these controls upon installation to
properly equalize the system to
produce optimium audio quality
from the microphone(s).
8. AUX OUT AND VOL: This jack
sends audio to external equipment
such as an assistive listening
device (Personal FM System) or
recording device. Use the volume
control to set the optimum signal
level for the device.
9. AUDIO INPUTS: These
connections accept an audio
signal from other technology so
all multimedia can be distributed
evenly throughout the classroom.
10. SENSOR INPUT: The infrared
microphone audio from the ISR is
connected to this input via CAT 5
cable. Connect additional sensors
to the CAT 860 to cover large or
odd-shaped classrooms.
11. SENSOR SHORT: This LED glows
red when there is a short in the
ISR or cable. The system will not
operate, but is protected from
damage when the LED is lighted.
REAR PANEL CONTROLS
12
3
4
10
11
7
8
9
5
4

13
1. Overview 2. Setup & Use 3. Optional
Accessories 4. Troubleshooting 5. Warranty, Safety
& Specifications
INFRARED SENSOR/RECEIVER (ISR)
CONNECTIONS
1. POWER INDICATOR: This light
will glow blue when the ISR is
receiving power from the CAT 860.
2. A/B IR INDICATORS: These lights
glow when the corresponding
microphone (set to channel A or
B) is turned on and transmitting.
A steady light indicates a strong
signal.
3. SENSOR OUT: Connect the CAT 5
sensor cable to this connection to
send audio from the microphones
to the CAT 860 amplifier.
4. IR EXPANSION: Connect up to
three passive IR sensors (IR-SR70F)
to this connection for larger
classrooms. For more than one
additional sensor a 3-way coax
splitter is required (HS3).
1
2
3
4

14
1. Overview 3. Optional
Accessories 4. Troubleshooting 5. Warranty, Safety
& Specifications
2. Setup & Use
1. POWER BUTTON: Press this
button to turn the REDMIKE ON,
press again to turn it OFF (mute).
2. POWER/LOW BATTERY
INDICATOR: A BLUE light
indicates the REDMIKE is on and
fully charged. A RED light indicates
a charge is needed.
3. BATTERY COMPARTMENT: To
access the battery compartment,
slide the door downward. The
battery should only be replaced
by a Lightspeed AA rechargeable
sensing battery (part # BA-
NH2A27).
4. YELLOW PROTECTIVE TAB:
Slide the battery compartment
door open to remove this
disposable protective tab before
use. NOTE: do not attempt to
remove the tab without first
opening the compartment door, as
it may tear, leaving fragments.
5. AUDIO/MICROPHONE INPUT:
Use this input to plug in a laptop,
MP3 player or other audio
source to wirelessly transmit
audio to be played through the
system. Alternatively, an external
microphone can be connected.
6. CHANNEL SELECT SWITCH
(CH A/B): This switch allows
for selection between Channel
A or B. If you are using a single
microphone, we recommend using
Channel A.
7. CHARGER CONTACTS (+ -):
These contacts interface with the
charging tabs in the BC-RMCC
cradle charger for daily charging.
Simply place the REDMIKE in the
charger.
REDMIKE CONTROLS AND CONNECTIONS
1
2
3
5
6
7
S
li
d
e
b
at
t
e
ry
d
o
o
r
o
p
e
n
R
e
m
o
v
e
t
a
b
b
e
fo
r
e
u
s
e
4

15
1. Overview 2. Setup & Use 3. Optional
Accessories 4. Troubleshooting 5. Warranty, Safety
& Specifications
1. CHARGE INDICATORS: The light
glows RED while the REDMIKE is
charging. When fully charged, the
light will glow GREEN. A blinking
RED light indicates that no battery
is sensed, (REDMIKE Yellow
Protective Tab may not have been
completely removed—see page
10, item 4.) A blinking Green LED
means a non- Lightspeed battery
has been installed (possibly an
alkaline battery).
2. DC POWER PORT: Connect the
DC power cord here.
3. OPTIONAL CHARGING PORT:
Plug the charging cord for the
optional LT-71 or the REDMIKE
Share microphones here.
CRADLE CHARGER CONTROLS AND
CONNECTIONS
1
2
3

16
1. Overview 2. Setup & Use 3. Optional
Accessories 4. Troubleshooting 5. Warranty, Safety
& Specifications
First, find a suitable location to set-up the amplifier. It is best to put the amplifier
in a stable location near the other equipment to be used. It can be set in a
cabinet, on a tabletop, or mounted on the wall with the included bracket.
Media Cabinet Set-up
The included wall bracket is
specifically designed to support the
CAT 860.
Wall-mount Set-up
SECTION 2:
SET-UP & USE
1. LOCATION OF THE AMPLIFIER
Avoid Separated Set-ups
Components should be housed
together. Wires should be routed
back directly to the amplifier.

17
1. Overview 2. Setup & Use 3. Optional
Accessories 4. Troubleshooting 5. Warranty, Safety
& Specifications
2. IR SENSOR/RECEIVER (ISR) INSTALLATION
Next, find a suitable location for the ISR. Poor location will cause substandard
performance of the CAT 860 Classroom Audio System. The ISR should be as
high as possible in the room – the ceiling is the best location, centered along the
longest wall in the room. When possible, use a conduit to protect the wires (not
included). Poor choices for placement are corners, on walls at heights lower than
7 feet (2 meters), or in places where the line of sight from the ISR to the receiver
is or could be obstructed.
Good placement
Conduit is Recommended
Best placement
Avoid!

18
1. Overview 2. Setup & Use 3. Optional
Accessories 4. Troubleshooting 5. Warranty, Safety
& Specifications
2. IR SENSOR/RECEIVER (ISR) INSTALLATION
CONT’D
Once you find a suitable location for the ISR, follow these instructions to mount
it. There are different instructions for mounting depending on if the ISR will be
mounted to a suspended ceiling grid or secured to a wall / solid vertical surface.
1. Attach the bracket to the ceiling
tile grid (t-bar).
a. Slide the tabs onto the outsides
of the t-bar, starting with one
corner.
b. Attach the second tab around
the other side of the t-bar.
c. Repeat with the other side of
the bracket so it is connected at
all four points.
2. Slide the ISR onto the bracket until
it “clicks” into place.
a. Guide the mounting rails onto
the bracket, oriented as
pictured.
b. Once secure, the ISR locks into
place.
c. To remove the ISR, press the
release bar down and slide the
ISR off the bracket.
3. Uncoil the Cat 5 sensor cable.
Connect one end of the cable to
the ISR. Secure wire overhead and
route it back to the system.
4. Connect the other end of the Cat
5 sensor cable into the SENSOR
INPUT jack on the CAT 860
amplifier.
Suspended Ceiling Mount
clip connects to t-bar on ceiling
Release Bar

19
1. Overview 2. Setup & Use 3. Optional
Accessories 4. Troubleshooting 5. Warranty, Safety
& Specifications
1. Screw the bracket to a place high
on the wall or in the middle of the
solid ceiling. Mount the bracket
horizontally as shown above.
2. Uncoil the Cat 5 sensor cable.
Connect one end of the cable to
the ISR. Route the wire back to
the CAT 860 amplifier, securing
it along with way using surface
raceway where possible.
3. Slide the ISR onto the bracket until
it “clicks” into place.
2. IR SENSOR/RECEIVER (ISR) INSTALLATION
CONT’D
Wall/Solid Ceiling Mount
a.Guide the mounting rails onto
the bracket, oriented as
pictured.
b. Once secure, the ISR locks
into place.
c. To remove the ISR, slide a ruler
or screwdriver behind the ISR to
press the release bar down and
slide the ISR off the bracket
4. Connect the other end of the Cat
5 sensor cable into the SENSOR
INPUT jack on the CAT 860
amplifier.

20
1. Overview 2. Setup & Use 3. Optional
Accessories 4. Troubleshooting 5. Warranty, Safety
& Specifications
The CAT 860 systems include a bracket for optional wall-mounting.
4. SPEAKER INSTALLATION
3. INSTALLATION OF AMPLIFIER WALL-
MOUNT BRACKET
1. Locate the speaker installation
instructions packed with your
speaker(s).
2. Follow instructions and mount
speaker(s).
3. Return to this manual to complete
the set up of your system.
A. Determine the location:
a. It should be located near a
power outlet.
b. Height should allow for access to
front control panel, but also be
in compliance with building and
ADA regulations.
B. Screw the bracket to the wall at
the two screw hole points with
the included hardware. Attach
to a stud when possible; use the
drywall mollies when studs are not
available.
C. Slide the CAT 860 onto the bracket
using the channel on the bottom
of the amplifier.
D. Secure the CAT 860 to the bracket
by tightening the screw on the
bottom.
E. Now that the CAT 860 is secure,
it can be slowly pulled out and
pivoted for better access to the
back panel. Push the CAT 860 back
in, to lock into place.
F. The power supply can be set
on the back of the bracket and
secured with ties if desired.
