Lilin CMG1086 series User manual

MERIT LILIN ENT. CO., LTD
http://www.meritlilin.com
INSTRUCTION MANUAL
CMG1086/1088 N/P
66-CMG108CSE
D/N ATR 700TVL CAMERA

IMPORTANT SAFEGUARDS
GRAPHIC SYMBOL EXPLANATION
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated "dangerous voltage" within the product's enclosure
thatmaybeofsufficientmagnitudetoconstituteariskofelectric
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance(servicing)instructionsintheliterature
shocktopersons.
accompanying the unit.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION：
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NOUSERSERVICEABLEPARTSINSIDE.
REFERSERVICINGTOQUALIFIED
SERVICE PERSONNEL.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSEOFUSEDBATTERIESACCORDING
TOTHEINSTRUCTIONS

CAUTION
Do not drop or strike this equipment.
Do not install the equipment near any naked flames or heat
sources.
Do not expose this unit to rain or excessive moisture, avoid
smoke and dust.
Do not cover cloth or to install this unit in poorly ventilated
places.
Do not continue to operate if there appears to be fault.
Do not touch the power connection with wet hands.
Do not damage the power cord or leave it under pressure.
Sensitive electronics inside are vulnerable to excessive shock.
Excessive heat could damage this unit.
Please the camera in an environmental housing for protection.
If the camera gets wet, unplug it and have it checked by
qualified service personnel.
This may lead to overheating.
If the unit ceases to function, contact qualified service
personnel for help.
Risk of short circuit or electric shock.
Risk of fire or shock circuit.

CONGRATULATIONS
Thank you for purchasing this D/N ATR 700TVL Camera. You now
own one of the many fine CCTV products we manufactured. This
product has been carefully inspected under rigid quality control
and should reach you in perfect condition. With reasonable care,
it will provide years of reliable performance.
We recommend that you read this installation and operation
manual thoroughly before installing and operation your new
system.
Here you will find all the information you need to set up and use
the system. If any questions are not answered in the manual,
please contact your dealer.
Before proceeding, please read and observe all instructions and
warnings contained in this manual. Retain this manual with the
original bill of sale for future reference and, if necessary, warranty
service.
When unpacking your new camera, check for missing or damaged
items. If any item is missing, or if damage is evident,
I. Contact your dealer for
assistance.
DO NOT
NSTALL OR OPERATE THIS PRODUCT

WARRANTY INFORMATION
Please complete the following product purchase information. The
factory will requests this information when contacted for technical
support, or warranty repair. It is also valuable in case of loss or
theft.
Purchase Date
Serial Number
Model Number
：
：
：

TABLE OF CONTENTS
FEATURES
PART DESCRIPTION
INSTALLATION
CONFIGURATION OF THE MENU
SETTING MENU AND FUNCTIONS
To Open and Exit the Menu screen
LENS
SHUTTER/AGC
WHITE BAL (White Balance)
BACKLIGHT (Backlight Compensation)
PICTADJUST(PictureAdjust)
ATR (Adaptive Tone Reproduction)
MOTION DET
PRIVACY
DAY/NIGHT
NR (Noise Reduction)
CAMERA ID
SYNC
LANGUAGE
CAMERA RESET
SPECIFICATIONS
1
3
9
12
14
14
14
15
18
20
21
22
22
24
25
26
27
27
28
29
30

The CMG1086/1088 series Day&Night Adaptive Tone Reproduction 700TV
Lines Resolution Camera introduces supremacy in video quality. This compact
yet full functional color DSP camera use high sensitive 1/3" Exview HAD interline
transfer CCD. The camera achieves superb quality color images at 700TV lines
resolution. With ultralow light levels of 0.025 Lux(F1.2) and enhanced noise
reduction technology, it enables noise-free, clear image monitoring day and night.
By adopting a diagonal 6mm(1/3") 480K(NTSC) pixel, 570K(PAL) pixel CCD,
the camera produces clear picture quality with a horizontal resolution of 700TV
lines for color.
Improves the visibility of the entire picture by providing the optimum gradation
compensation for the image.
Reduces the image noise in order to improve the image quality of the camera.
In particular, it reduces the noise which is generated under low-brightness
shooting conditions and other high-gain states.
Improves the visual recognition of license plates and other such objectsby
suppressing or masking strong light sources (such as the headlights of
automobiles) in dark places.
Suppresses the color rolling which arises when there are slight deviations
between the blinking frequency of non-inverter fluorescent lights and the drive
frequency of the image sensor devices.
FEATURES
RESOLUTION OF 700TV LINES
ADAPTIVE TONE REPRODUCTION(ATR)
NOISE REDUCTION(2D-NR)
HIGH LIGHT COMPENSATION(HLC)
COLOR ROLLING SUPPRESSION(ANTI CR)
1

2
The camera automatically identifies when it is either day or night time and
switched accordingly. During daylight the camera will switch to color to obtain
excellent image clarity, while at night the camera will switch to monochrome to
obtain improved picture definition.
Color temperature is adjusted automatically to produce clean, natural and rich
color images. ATW, PUSH, USER1, USER2, MANUAL and PUSH LOCK Modes
are available to obtain most suitable selection.
This camera provides an on screen display(OSD) setup menu where all
advanced functions can be selected and setup via OSD.
Privacy zones prevent objects and areas such as windows and doors which
are within the camera's viewing range but not in the scope of surveillance,
8 masking areas per screen simultaneously.
To set up proper shutter speed for auto iris lens, which is applied for catching
the image of the object moving at middle-low speed. The various shutter
speeds for options: 1/100sec.(1/120sec.), 1/150sec., 1/200sec., 1/250sec.,
1/300sec., 1/350sce., 1/400sec., 1/450sec.
Since the camera detects motion without any additional external sensor, you
can monitor activity more efficient.
DAY&NIGHT(IR CUT REMOVABLE)
WHITE BALANCE
ON SCREEN DISPLAY CONTROL(OSD)
PRIVACY ZONE
SHUTTER
MOTION DETECTION

PART DESCRIPTION
3

4
CMG1086
12
D/N EXT
GND
NC
NO
COM
0 1
1
2
3
4
5
6
AC24V / DC12V
VIDEO
SHUTTER AUDIOPOWER
SYNC
INT LL
INT D / N EXT
NO
COM
NC
D/NEXT
GND
13
CMG1088
D/N EXT
GND
NC
NO
COM
0 1
1
2
3
4
5
6
AC100~240V
VIDEO
SHUTTER AUDIO
POWER
SYNC
INT LL
INT D/NEXT
14

LENS MOUNT CAP
FOCALLENGTH ADJUSTMENT RINGAND LOCKINGSCREW
MICROPHONE
AUTO IRIS CONNECTOR(4PIN SOCKET)
POWERLED
AUDIO OUTPUT RCA CONNECTOR
SYNCHRONIZATION SELECTION SWITCH(INT/LL)
DAY/NIGHT SELECTION SWITCH (INT/EXT)
Prevent damages to the image sensor and to keep dust away.
Usethis ring to adjusts the back-focaldistance or picture focus. Rotatethis ring
clockwise or counterclockwise for a CS-mount lens.
Use the locking screw to lock the focal length.
Built-in highly sensitive capacitive microphone.
Supplies power and control signals to an auto iris lens(jack not supplied).
PowerON/OFFindicator.
Audio signal output.
Selects the camera synchronization mode from internal sync(INT) mode or line-
lock(LL) mode (Must be operated with OSD menu setting. Please refer to page
27and28.).TheLLmode is available only withACpowersource.
INT: Sets to internal 2:1 interlace.
LL:SetstoLine-Lockmode.
Selects the camera DAY/NIGHT mode triggered by internal or external (Must be
operatedwithOSDmenusetting.Pleaserefertopage25and26).
INT:SettingthroughcamerainternalOSDmenu.
3 options: AUTO, COLOR, B/W.
EXT: Triggered by the external device (Infrared Illuminator). Please set the DAY
/NIGHT mode to COLOR on the SETUP MENU menu.
1
2
3
4
5
5
6
7
8

VIDEO OUTPUT CONNECTOR
EXTERNAL DEVICE CONNECTORS
USER OSD SETTING
Compositevideosignaloutput.
Setting switches and Functions.
1. (UP)
2. (LEFT)
3. (RIGHT)
4. (DOWN)
5. SET : Executes selections and displays a submenu for an item with the
mark.
1. NO(Normal Open) & COM(Common) & NC(Normal Close)
Alarm Connection
Connect to the alarm input of an external device such as a buzzer or lamp
to this connector. When the camera detects motion, the alarm output signal
is supplied to the connected external device.
Contact Ratings
Maximum load current is 500mA.
Don't connect any system or device that
has over 80Vp-p(DC60V) bias voltage on
the contact connector.
●
●
＊
＊
9
10
11
6
: Press to move the cursor upwards
or to select items.
: Press to move the cursor to the left
and to select or adjust the parameters
of the selected item. The parameters
changeseachtimethisbuttonis pressed.
: Press to move the cursor to the right and to select or adjust the
parameters of the selected item. The parameters changes each
time this button is pressed.
: Press to move the cursor downwards or to select items.
If you use the NO&COM&NC connectors, you should set the MOTION DET option
to ON on the SETUP MENU menu.
NOTE
External
Device
NO
COM
NC
RIGHTLEFT
DOWN
UP
SET

2.D/NEXT&GND
Thecamerawill be triggered to switch betweenDAY(Color)or NIGHT
(Monochrome)modebyexternaldevice.
DAY Mode
When you supply the HIGH(+3V~+5V) Potential, the DAY/NIGHT function
issetto DAYmode.
NIGHT Mode
When you supply the LOW(0V) Potential, the DAY/NIGHT function is set
to NIGHT mode.
●
●
External
Device
D/N EXT. 0V
GND GND
NIGHTMode
External
Device
D/N EXT. +3V~+5V
GND GND
DAY Mode
If you use the D/N EXT connectors, you should set the DAY/NIGHT SELECTION
SWITCH to "EXT", also set the DAY/NIGHT mode to COLOR on the SETUP MENU
menu.
NOTE
SHUTTER SELECTION SWITCH
Available only with auto iris lens. Please set the MODE to SHUT+AUTO IRIS on
the AUTO SETUP menu.
12
7
AUTO SETUP
SHUT+AUTOIRIS
024
AGC
x0.50
HIGHLUMINANCE
BRIGHTNESS
LOW LUMINANCE
MODE
BRIGHTNESS
RETURN
MODE

AC24V/DC12VCOMPATIBLEINPUTTERMINAL
AC INPUT
AC24V(AC24V 10%)orDC12V(DC12V 10%, Non-Polarity input) power input.
AC(AC100~240V)powerinput.
± ±
14
SHUTTERSELECTION
SWITCH
1
0
1
1
1
1
1
1
1
1
2
0
1
1
1
1
1
1
1
1
3
0
0
0
0
0
0
1
1
0
4
0
0
0
1
1
0
0
0
0
5
0
0
0
0
1
1
0
1
1
6
0
0
1
1
1
1
0
0
0
1/60sec.(1/50sec.)~1/100,000sec.
1/100sec.(1/120sec.)
1/300sec.
1/400sec.
1/450sec.
1/350sec.
1/200sec.
1/250sec.
1/150sec.
SHUTTER SPEED
13
8
SetstheSHUTTERSELECTIONSWITCH:

INSTALLATION
The lens must be either a C or CS mount type. The protrusion behind the
mounting surface must be within the following limits:
SUITABLE LENSES
C - mount lens CS-mountlens
9mm or less 4mm or less
9

FITTINGTHELENS
Removethelensmountcap.
Screw in the C mount ring(not supplied), until it is secured. When using a
CS mount lens skip step2.
Screw in the lens, until it is secured.
Insert the lens plug in the AUTO IRIS connector, when fitting a manual-
iris lens, skip step4.
Adjust the focal length by turning the focal length adjustment ring.
(Using hexagon screw driver, loose and tighten the screw.)
1
2
3
4
5
CAUTION
Keep the lens mount cap on the camera when not attaching a lens.
10

11
1. The mounting hole on the top or bottom of the camera.
2.Tightenthescrewtothe mounting hole. Please refertothefollowing
drawing.
FITTINGTHECAMERA
Connect to the power supply.
Please refer to the right drawing.
CONNECTION OF POWER SUPPLY CABLE (AC24V or DC12V)
AC24V (10%)
or
DC12V (10%)
±
±
AC24V / DC12V
NOTE
Makesuretouse AC24Vor DC12V
(Non-Polarity input) power supply.

12
CONFIGURATION OF THE MENU
SETUP
MENU LENS
SHUTTER/
AGC AUTO
AUTO
MANUAL
MANUAL
HIGH LUMINANCE
LOW LUMINANCE
MODESHUT+AGC－
SHUTTER1/60(1/50)1/100(1/120)1/250~1/10000－//
AGC6.0012.0018.0024.0030.0036.0042.0044.80－///////
MODE
MODEAGCOFF－/
BRIGHTNESS(000~255)
BRIGHTNESSx0.25x0.50x0.75x1.00－///
AUTO IRIS/SHUT+AUTO IRIS
SHUT(NOTES2)＊
MODEAUTOOPENCLOSE－//
SPEED(000~255)
TYPEDC/VIDEO－
WHITE BAL
ATR
PICT ADJUST
BACKLIGHTBLCHLCOFF－//
ATW
OFF
MIRROROFF/ON－
B-GAIN(000~255)
B-GAIN(000~255)
LUMINANCELOWMIDHIGH－//
SPEED(000~255)
PUSH
ON
BRIGHTNESS(000~255)
CONTRAST(000~255)
SHARPNESS(000~255)
HUE(000~255)
GAIN(000~255)
R-GAIN(000~255)
R-GAIN(000~255)
CONTRASTLOWMIDLOWMIDMIDHIGHHIGH－////
DELAY CNT(000~255)
USER 1
USER 2
ANTI CR
MANUALLEVEL(000~255)－
PUSH LOCK
ATW FRAMEx0.50x1.00x1.50x2.00－///
ENVIRONMENTINDOOROUTDOOR－/
(NOTES1)＊

13
PRIVACY
DAY/NIGHT
MOTION DET
OFF
AUTO
OFF
AREA SEL1/8~8/8－
BURSTOFF/ON－
DETECT SENSE(000~127)
ON
COLOR
B/WBURSTOFF/ON－－
ON
TOP [000~244(NTSC), 000~288(PAL)]
DELAY CNT(000~255)
DAYNIGHT(000~255)→
NIGHTDAY(000~255)→
BLOCK DISPOFF/ON/ENABLE－
BOTTOM [000~244(NTSC), 000~288(PAL)]
MONITOR AREAOFF/ON－
LEFT [000~474(NTSC), 000~468(PAL)]
AREA SEL1/4~4/4－
RIGHT [000~474(NTSC), 000~468(PAL)]
TOP [000~244(NTSC), 000~288(PAL)]
BOTTOM [000~244(NTSC), 000~288(PAL)]
LEFT [000~474(NTSC), 000~468(PAL)]
RIGHT [000~474(NTSC), 000~468(PAL)]
COLOR(1~8)
TRANSP0.000.500.751.00－///
MOSAICOFFON－/
NR NR MODEY/COFF/Y/C－/
Y LEVEL(000~015)
C LEVEL(000~015)
CAMERA ID
SYNC
LANGUAGEENGLISH－//////
/
日本語
中文 DEUTSCHFRANCAISPYCCK PORTUGUES ESPANOL
OFF
ON
NN
^
~
^
CAMERA RESET
INT
LLPHASE [000~524(NTSC), 000~624(PAL)]－
＊
＊1: Set the LENS mode to AUTO on the SETUP MENU menu. 2: Set the LENS mode to MANUAL on the SETUP MENU menu.
NOTES

SETTING MENU AND FUNCTIONS
14
TO Open and Exit the Menu screen
1. Press "SET" button.
The Menu screen appears on the monitor. Check the current settings on
the menu.
2. Pushorbutton to select the options then useorbutton to select a
mode.
NEXT: To the next setup menu.
BACK: Return to the previous.
RETURN: Return to the previous.
SAVE ALL: Used to save the various setting of the internal OSD menu
in the EEPROM together.
EXIT: Exit the setup menu.
SETUP MENU
AUTO
AUTO
ATW
BLC
OFF
OFF
LENS
SHUTTER/AGC
WHITEBAL
BACKLIGHT
PICTADJUST
ATR
MOTION DEL
NEXT
EXITSAVEALL
SETUP MENU
AUTO
OFF
INT
ENGLISH
OFF
PRIVACY
DAY/NIGHT
NR
CAMERAID
SYNC
LANGUAGE
CAMERARESET
BACK
EXITSAVEALL
LENS
This function is used to set the mechanical iris of the lens.
1. Select [LENS] option.
2. Pushorbutton to select a mode.
LENS mode changes as follows:
AUTO: Select the auto iris lens.
MANUAL: Select the manual iris lens.
3. Select an AUTO then press "SET" button.
The AUTO IRIS menu appears.
AUTO MANUAL→
AUTO IRIS
DC
AUTO
080
TYPE
MODE
SPEED
RETURN
