INSTRUCTION MANUAL
DUAL VOLTAGE COLOR DOME CAMERA
PIH-2026/2046
66-202CSE
DUAL VOLTAGE COLOR VARI-FOCAL CAMERA
PIH-2126X/2146X

IMPORTANT SAFEGUARDS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
GRAPHIC SYMBOL EXPLANATION
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated "dangerous voltage" within the product's enclosure
that may be of sufficient magnitude to constitute a risk of electric
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
shock to persons.
accompanying the unit.

PART DESCRIPTION & DIMENSION
VIDEO OUTPUT JACK
DC12V (NON-POLARITY INPUT) OR AC24V POWER INPUT
BASE
FIX RING
INSIDE COVER
DOME COVER
LENS
Unit mm
120

3. An extra RCA jack for easy installation. Plug the video input
of monitor to the RCA jack and adjust focus and zoom.
After finished, unplug the RCA jack.
Please refer to FIG.4.
4. Adjust DC iris level by turning the iris level VR.
Please refer to FIG.3.
ATTENTION: Adjust this VR with care so as not to cause
damage to the unit.
5. Put on the inside cover first, and followed by put on the dome
cover. Then tighten the fix ring(FIG.5).
INSTALLATION
1. Put the provided screws (M3.0 x 25, wooden screw) through
the holes marked as "a", and fix the base in the desired area
(FIG.1).
2. The direction of the lens is adjustable through the adjustable
Pan/Tilt brackets and rotatable round bracket for Azimuth.
The lens can be adjusted easily by hand without using screw
driver. Please refer to FIG.2 (PIH-2026/2046) and FIG.3
(PIH-2126X/2146X).

FIG. 1
a
a
a
FIG. 2 (PIH-2026/2046)
BRACKET
TILT
PAN
AZIMUTH

FIG. 3 (PIH-2126X/2146X)
FIG. 4
TILT
PAN
BRACKET
ZOOM ADJUSTMENT
FOCUS ADJUSTMENT
IRIS LEVER VR
SCREW DRIVER
AZIMUTH

FIG. 5
NOTE Point each "b" to each "c".
cc
bb

DUAL VOLTAGE COLOR DOME CAMERA
Model No.
Power Input Voltage
System
Sync. Mode
Pick Up Element
Effective Pixels
Chip Size
Scanning System
Resolution
Minimum Illumination
S/N Ratio
Auto Gain Control
Aperture Correction
Power Consumption
Shutter
Back Light Compensation
Video Output
Gamma Characteristic
Lens
Operating Temperature
Weight
Dimension
DC12V ( 10%) or AC24V ( 10%)
NTSC or PAL
Internal
1/3" Super HAD CCD Sensor
5.59mm (H) x 4.68mm (V)
2 1 Interlace
540TV Lines
0.5Lux (F1.8)
More Than 50dB (AGC OFF)
36dB Variable Gain
Horizontal , Vertical
2.5W (DC12V) , 2.0W (AC24V)
1/60(1/50)S ~ 1/100,000S(Auto)
Auto
CVBS 1.0Vp-p , 75ohm
=0.45
-10 ~ +50 (14 ~ 122 )
Dome: 98,Base&FixRing: 112x55mm
768(H) x 494(V) [NTSC]
752(H) x 582(V) [PAL]
15.734KHz / 59.94Hz [NTSC]
15.625KHz / 50Hz [PAL]
Horizontal & Vertical
Sync. Frequency
Focal Length
Iris
Angle of view
3.6mm 6.0mm
F2.0 F1.8
PIH-2046 3.6 PIH-2046 6
Option lens 8.0mm lens.
Design and specifications are subject to change without notice.
White Balance ATW
300g
SPECIFICATIONS
H
V
D
3.6mm 6.0mm
F2.0 F1.8
54.5 33.1
PIH-2026 3.6 PIH-2026 6
73 44.5
92 56
54.5 33.1
73 44.5
92 56
510(H) x 492(V) [NTSC]
500(H) x 582(V) [PAL]
380TV Lines
0.2Lux (F1.8)

DUAL VOLTAGE COLOR VARI-FOCAL DOME CAMERA
Model No.
Power Input Voltage
System
Sync. Mode
Pick Up Element
Effective Pixels
Chip Size
Scanning System
Resolution
Minimum Illumination
S/N Ratio
Auto Gain Control
Aperture Correction
Power Consumption
Back Light Compensation
Video Output
Gamma Characteristic
Lens
Operating Temperature
Weight
Dimension
DC12V ( 10%) or AC24V ( 10%)
NTSC or PAL
Internal
1/3" Super HAD CCD Sensor
5.59mm (H) x 4.68mm (V)
2 1 Interlace
540TV Lines
0.05Lux (F1.4)
More Than 50dB (AGC OFF)
36dB Variable Gain
Horizontal , Vertical
3.0W (DC12V) , 2.5W (AC24V)
Auto
CVBS 1.0Vp-p , 75ohm
=0.45
-10 ~ +50 (14 ~ 122 )
Dome: 98,Base&FixRing: 112x55mm
768(H) x 494(V) [NTSC]
752(H) x 582(V) [PAL]
15.734KHz / 59.94Hz [NTSC]
15.625KHz / 50Hz [PAL]
Horizontal & Vertical
Sync. Frequency
Focal Length
Iris
Angle of view
PIH-2146X N/P
Design and specifications are subject to change without notice.
White Balance ATW
300g
H
V
D
3~9mm
F1.4
66.3 ~ 23.9
PIH-2126X N/P
90.2 ~ 31.8
115.3 ~ 39.7
510(H) x 492(V) [NTSC]
500(H) x 582(V) [PAL]
380TV Lines
0.02Lux (F1.4)
66-202CSE-5
