Lincoln Electric Torchmate Flexcut 80 User manual

21
Flexcut 80 Torch Posioning Procedure
DOC #:7214-0-US70-080818-DS-02-02
Rev#:00
Rev Date:8/8/2018
[e-mail]
Proprietary & Confidential: This document contains proprietary information owned by Lincoln Electric Cutting Systems, Inc. and may not be duplicated, communicated to other parties, or used for any
purpose without the express written permission of Lincoln Electric Cutting Systems, Inc.
THIS DOCUMENT IS VALID FOR 24 HOURS AFTER PRINTING – Dated: 6/7/2018
Flexcut 80 Torch Posioning Procedure
Summary: The purpose of the instrucons below are to explain how change the
posion of the LC105/100M within the torch holder clamps, per OEM
specicaon.
Step 1: Datum the machine.
Step 2: Install the 40 amp consumable stack to the LC105/100M torch.
LC105M:
LC100M:
Step 3: Jog the machine, in the X and Y axis, to a posion between two slats.
Step 4: Jog the Z axis down to the end of its travel.

22
Flexcut 80 Torch Posioning Procedure
DOC #:7214-0-US70-080818-DS-02-02
Rev#:00
Rev Date:8/8/2018
[e-mail]
Proprietary & Confidential: This document contains proprietary information owned by Lincoln Electric Cutting Systems, Inc. and may not be duplicated, communicated to other parties, or used for any
purpose without the express written permission of Lincoln Electric Cutting Systems, Inc.
THIS DOCUMENT IS VALID FOR 24 HOURS AFTER PRINTING – Dated: 6/7/2018
Flexcut 80 Torch Posioning Procedure
Step 5: Jog the X and Y axis so that the
torch head is near one of the two
slats.
Step 6: Loosen torch clamps and slide torch down to where boom of shield cap is
approximately 1/8” below top of slat. Once adjusted ghten the torch
clamps
Step 6: Reset the Z Posion
