Vantage®300
EN INE DRIVEN WELDERS
Compact, Multi-Process, Excellent Value
ENGINE DRIVEN WELDERS
The Vantage®300 is an ideal choice for construction teams, pipe rig
owners and rental fleet managers. oused in a compact, corrosion-
resistant stainless steel case, this rugged welder/generator features
Lincoln Chopper Technology®to deliver great arc starts and a
smooth arc for stick, TIG or wire welding.
The quiet, smooth-running 1800 rpm water-cooled 4 cylinder Kubota®
or Deutz®diesel engine generates 12,500 watts of 3 Phase or 11,500
watts of 1 Phase auxiliary power. And, it’s loaded with convenience
features you’ll wish you had on your last welder! It all adds up—top
arc performance, a smooth reliable engine, plenty of auxiliary power,
compact case and tough materials that are built to last!
Publicatio E6.206 4/06
Web Update 5/08
www.li col electric.com
TECHNICAL SPECIFICATIONS
• Compact Case With Stainless Steel Enclosure
- Small size and light weight is suitable for many pickup trucks.
Standard stainless steel roof, side panels and engine-access door
deliver added protection and durability.
• Multi-Process Welding, Simple to Operate
- Select one of four Process Modes, including CC-Stick (up to
3/16"), Downhill Pipe (for stick), Touch-Start TIG®or CV-Wire
(up to 5/64"), and then dial in the desired output.
- Digital Weld Meters included.
• Plenty of AC Generator Power
- 12.5 kW peak (11 kW continuous) 3-Phase 240V AC
generator power. Will power industrial equipment such as a
plasma cutter, pump or inverter welder.
- 11.5 kW peak (10 kW continuous) 1-phase AC generator
power for common construction tools.
• Arc Gouging
- Arc gouging with up to 1/4" carbons.
• eliable Engines
- 4 cylinder 1800 RPM Kubota®or Deutz®diesel engines run
smooth and quiet. Standard engine gauges allow you to monitor
performance at a glance.
• Innovative Service Access
- Lockable, removable sliding engine access door provides
ample space for engine and oil filter work without requiring a
large clearance space on your truck. 55% more access than
competitive product.
- Battery drawer on front of machine and top-mounted
radiator cover provide convenient access to these systems.
- Patented tilt down control panel for easy servicing
of internal components.
ated Output
Current/Voltage/Duty Cycle
300A/32V/100%
350A/28V/100%
Output
ange
30-400A DC
40-300A Pipe
20-250A DC TIG
14-32V CV
3-Phase AC Power:
12.5 kW Peak
11.0 kW Continuous
1-Phase AC Power:
11.5 kW Peak
10.0 kW Continuous
Engine
Model
Kubota®V1505
Diesel
EPA Tier 4i
Deutz®
D2008L4
Diesel
EPA Tier 4i
No. of
Cyl.
4
HP & Speed
(rpm)
22@1800
24@1800
Dimensions
HxWxD
Inches (mm)
35.9 x 25.3 x 60.0
(913 x 642 x 1524)
Net
Weight
lbs (kg)
1035
(469)
1150
(522)
Product
Name
Vantage®300
CV
CC
12.5
kWP
D
Output
Input
Stick, TIG, MIG, Flux-Cored, Gouging
Processes
Advantage Lincoln

0
100
200
250
300
400
11000 27
8500 20
5700 14
3500 8
800 2
00
PERFORMANCE
Arc Performance
• 300 amps @100% duty cycle with output range up to 400 amps.
All ratings are at temperatures of 104°F/40°C.
• Arc ouging – The Vantage®300 is capable of gouging with up
to a 1/4" carbon.
• CC-Stick mode is optimized for general purpose stick using
E7018 low hydrogen electrode.
• Built-in “hot” start for easier starts and restrikes minimizing the
electrode “sticking” to the work.
• Downhill pipe mode with active arc force control - enhanced
downhill pipe welding mode. Excellent for cellulosic electrodes.
Fast travel speeds, especially on fill passes. Arc control
adjustment for a soft, buttery arc or a more forceful digging arc.
• Standard DC Touch-Start TI ®welding, not scratch start, for
easy arc starting that avoids tungsten contamination and the use
of high-frequency.
• Excellent CV wire welding with cored-wire and MI (CO2and
blended gas).
Generator Performance
• 3-Phase 240V AC generator power rated at 12.5 kW peak
(11 kW continuous) output to power industrial equipment such as a
plasma cutter, pump or inverter welder. Simultaneously weld and use
3-Phase AC power - for example, up to 5,300 watts can be delivered
while welding at 200 amps. Compare to competitive product which
does not have 3-Phase power.
• 3-Phase 240V receptacle on control panel eliminates the need to
hard-wire the connections.
• The Vantage®300 provides added value at the job site by
delivering up to 11.5 kW peak (10 kW continuous) watts of
1-Phase AC auxiliary power for equipment such as a Lincoln
plasma cutter. Also use for lights, grinders and other common
construction tools. And, you can simultaneously weld and have
access to AC power – 3,500 watts can be delivered while
welding at 250 amps. Compare to competitive product which
has no AC generator power at 225 amps welding and above.
• AC generator voltage is constant at 120V or 240V at any weld
dial setting.
• Two 120V FCI duplex receptacles.
• All receptacles are circuit breaker protected.
Va tage®300
www.li col electric.com
[2]
A CLOSER LOOK
Patented and award-winning Lincoln Chopper Technology®
delivers superior DC arc welding performance for general purpose
stick, Downhill Pipe, DC TI , MI , cored-wire and arc gouging.
Benefits of Chopper Technology®include:
- Easy arc starting
- Smooth arc action
- Low spatter levels
- Excellent bead appearance
Traditio al weld co trol is more
variable arou d the desired output.
Chopper Tech ology®
delivers extremely fast respo se
for smoother output co trol.
WHAT IS CHOPPER TECHNOLOGY? WHAT IS TOUCH-START TIG®?
Touch-Start TI ®uses a very low voltage to sense when
the tip of the tungsten electrode is touched to the
work piece. When this occurs, a complete circuit is estab-
lished. When the tungsten is then raised from the work piece,
the circuit senses a change in voltage and initiates the
appropriate welding current and voltage to support the TI
welding process.
Enjoy the added benefits of Lincoln’s Touch-Start TI ®when
DC TI welding. Not only do you avoid tungsten contamina-
tion when arc starting, but you also don’t need extra high
frequency equipment.
10000 42
8300 35
5300 22
3500 15
400 2
0 0
10000 -
8300 -
5300 -
3500 -
400 -
0-
Weld Amps 1 Phase
Watts Amps
SIMULTANEOUS WELDING AND AUXILIARY POWER
3 Phase
Watts Amps
Simultaneous 1 and 3 Phase
Watts Amps
AND OR OR

Va tage®300
www.li col electric.com
[3]
A CLOSER LOOK
Key Controls
20
21
14
13
1211
10
1
5
6
8
9
18
17
16
1. low Plug Button
2. Weld Mode Selector Switch
3. Run/Stop Switch
4. Hour Meter
5. Start Pushbutton
6. Engine Idler Switch
7. Fuel Level, Engine Temperature and
Oil Pressure auges
8. Engine Protection Light
9. Engine Battery Charging Light
10. Circuit Breakers, except 240 VAC 3-Phase
11. 120 VAC FCI Receptacles
12. 120/240 VAC Full-KVA 1-Phase Receptacle
13. 240 VAC Full-KVA 3-Phase Receptacle
14. 240 VAC 3-Phase Circuit Breaker
15. Covered Weld Output Terminals + and -
16. round Stud
17. 14-Pin Wire Feeder Connector
18. 6-Pin Remote Control Connector
19. Arc Force & Inductance/Pinch Control Dial
20. Welding Terminals Control Switch
21. Wire Feeder Voltmeter Polarity Switch
22. Digital Amps and Volts Output Meters
23. Output Control Dial
Note: Control panel door not shown.
FEATURES
23
22
19
2
4
15
3
7
Single-side engine access
with lockable sliding door.
Fuel, Oil Pressure and Engine
Temperature gauges help you
monitor performance.
Latched and lockable
radiator cap cover.
Convenient battery tray below
control panel.
Handy oil drain valve and tube
makes oil changes neat.
Output switches to remote
mode when remote device
is connected.
• Simple Controls – Keeps training time to a minimum. The flip-down
control panel door keeps less frequently used dials out of the way.
Scratch-resistant Lexan®nameplate.
• Digital meters for amps and volts output make it easy to precisely set
your procedures.
• Large 15 gallon (57 liter) fuel tank provides run time for an extended
day–13 hours of welding at 300A/32V/100% duty cycle output, or 37
hours at high idle.
• Kilowatts available for Multi-Weld™350 use: 4.8 KW @ 60 VDC,
7.0 KW @ 58 VDC.
• Two reat Engine Choices – Kubota®V1505 or Deutz®D2008L4.
Both are 22 horsepower water-cooled 4 cylinder diesel engines. Both
engines also have an automatic idler for greater fuel economy and
reduced noise.
• Engine hour meter for scheduled maintenance.
• LN-25 PRO Arcoss-the-Arc wire feeder is a recommended option.
• 14-pin connector for Lincoln wire feeders with control cables:
LF-72, LF-74, LN-7, LN-8, LN-15, LN23P, LN-25, and LN-742. Also
compatible with Magnum®S Spool un System.
• Two Vantage®300 units can be paralleled in the CC-Stick Mode to
increase output.

• Simple wire harnessing keeps connections to a minimum for greater
reliability. Lead and harness strain reliefs on all control connections
help ensure trouble-free performance.
• Engine Protection System includes automatic shutdown for low oil
pressure or high engine temperature.
• Indicator light turns on for low oil pressure or high engine
temperature. A second indicator light turns on if the engine
battery charging system malfunctions.
• Circuit breaker protection on the battery ignition system provides
added component protection.
• Environmental friendly engine! Engine has a closed breather
system to keep the engine compartment and ground clean. This
system eliminates oil mist from collecting inside the engine
compartment, especially on surfaces that would lower engine
cooling efficiency.
• Self-bleeding engine simplifies startup if your fuel tank runs dry.
• Kubota®and Deutz®engine camshafts are gear-driven. No timing
belt maintenance.
• Printed circuit boards are environmentally-
shielded using Lincoln’s engineered potting
and protective frame trays.
• Dependability and long life aided by
all-copper windings in rotor and stator
with high quality insulation.
• Standard stainless steel roof, side panels and engine-access door
deliver added protection, durability and corrosion-resistance.
Eliminates the need to paint or replace rusting panels.
• Approved by the Canadian Standards Association (CSA).
• Manufactured under a quality system certified to ISO 9001
requirements and ISO 14001 environmental standards.
• Three-Year Lincoln Warranty (parts and labor) on welder.
(Engine is warranted separately by the manufacturer.)
Dimensions (6)
Product Ordering CC/Pipe- ated DC Output(1) CV ated Output(1) H x W x L Weight
Name Information Description Current/Voltage/Duty Cycle Current/Voltage/Duty Cycle AC Power(3)(4) inches (mm) lbs. (kg)
Vantage®300 K2409-2 300 Amp DC Welder with DC Constant Current DC Constant Voltage(2) 12,500 Peak 35.9 x 25.3 x 60.0 in 1035 lbs.
Kubota®Engine Gauges 300A/32V/100% 300A/32V/100% Watts, 60 z (913 x 642 x 1524mm) (469 kg)
350A/28V/100% 350A/28V/100%
Vantage®300 K2499-2 12,500 Watts Peak 30-400 Amps Two 120V 1150 lbs
Deutz®11,000 Watts 14-32V Duplex GFCI (522 kg)
Continuous AC Power DC Pipe Current Single Dial Receptacles
3-Phase 300A/32V/100% Continuous Control 20A Per Duplex
40-300A 40A Total (5)
11,500 Watts Peak Touch-Start TIG®ange Wire Feeder Power 1-Phase
10,000 Watts 250A/30V/100% 120V/60 z Full KVA
Continuous AC Power 20-250 Amps 42V/60 z Receptacle
1-Phase 42A@240V
Single Dial 42A@120V Each
Continuous Control Branch Circuit(5)
60V DC Max OCV
@1890 RPM 3-Phase
Full KVA
Receptacle
27A@240V
Va tage®300
www.li col electric.com
[4]
A CLOSER LOOK
MACHINE SPECIFICATIONS
(1) igh Altitude: For maximum rating, derate the output 2.5% to 3.5% for every 1,000 ft. (300 m). igh Temperature: For maximum rating, derate 2 volts for every 18°F (10°C)
above 104°F (40°C).
(2) DC Constant Voltage capability provides convenience and added safety when welding in electrically hazardous conditions.
(3) When welding, available auxiliary power will be reduced. Output voltage is within +/- 10% at all loads up to rated capacity.
(4) 120V will operate either 60 z or 50/60 z power tools, lights, etc.
(5) Circuits cannot be wired in parallel to operate the same device. (6) eight is to top of case. Add 5 in. (127 mm) to top of exhaust elbow for Kubota®and for Deutz®.
QUALITY AND RELIABILITY
ENGINE SPECIFICATIONS
(7) Kubota®warranty is 2 years/2,000 hours for machines shipped within the U.S., Canada, Pacific Ocean region and Western Europe. Warranty is 1 year/1,000 hours for Central
and South America, Asia, Africa and Middle East.
(8) Deutz®warranty is 2 years/2,000 hours for all components, 3 years/3,000 hours for major components.
Product Horsepower & Operating Fuel
Name Description Displacement Capacities Speeds Consumption
Kubota®V1505 (7) 4 Cylinder, 4 Cycle 22 P@1800 RPM FUEL: 300A Load 1.2 Gal/ r
Water-Cooled Diesel Engine, 15 gals (57 ltrs) 1800 RPM 4.4 Ltr/ r
12V Electric Start, 91 cu in OIL: High Idle 0.4 Gal/ r
Dry Type Air Cleaner, (1.5 ltrs) 6.4 qts (6.0 ltrs) 1890 RPM 1.5 Ltr/ r
Fuel Filter with Water Separator RADIATOR COOLANT: Low Idle 0.3 Gal/ r
EPA Tier 4i 7.2 qts (6.8 ltrs) 1350 RPM 1.1 Ltr/ r
Deutz®D2008L4 (8) 4 Cylinder, 4 Cycle 24 P@1800 RPM FUEL: 300A Load 1.2 Gal/ r
Water-Cooled Diesel Engine, 15 gals (57 ltrs) 1800 RPM 4.4 Ltr/ r
12V Electric Start, 95 cu in OIL: High Idle 0.5 Gal/ r
Dry Type Air Cleaner, (1.6 ltrs) 7.8 qts (7.4 ltrs) 1800 RPM 1.8 Ltr/ r
Fuel Filter with Water Separator RADIATOR COOLANT: Low Idle 0.3 Gal/ r
EPA Tier 4i 7.9 qts (7.5 ltrs) 1400 RPM 1.3 Ltr/ r

Va tage®300
www.li col electric.com
[5]
A CLOSER LOOK
SYSTEM SELECTION
One-Pak®Welding Packages
Order a Lincoln One-Pak®and get everything you need to
complete a welding package - all with one order number.
(One-Pak®Packages require assembly.)
Each UNASSEMBLED Package Contains:
• Vantage®300 (See Order Number Below)
• Medium Welder Trailer (K2636-1)
• Duo-Hitch™2" Ball/Lunette Eye Hitch (included)
• Fender and Light Kit (K2639-1)
• Cable Rack (K2640-1)
• Cable Connectors - two (K2487-1)
• Electrode Cable 2/0, two 50 ft. (15.3 m) lengths (K2485-2)
• Electrode Cable 2/0, 10 ft. (3 m) (K2483-2)
• Work Cable 2/0, 50 ft. (15.3 m) (K2484-2)
• 300A Electrode Holder (K909-7)
• 300A Work Clamp (K910-1)
Order:
K2452-3 Vantage®300 Kubota®One-Pak®Package
K2506-3 Vantage®300 Deutz®One-Pak®Package
Ready-Pak®Welding Packages
Order a Lincoln Ready-Pak®Package and get an assembled welding package.
Each COMPLETELY ASSEMBLED Package Contains:
• Vantage®300 (See Order Number Below)
• Medium Welder Trailer (K2636-1)
• Duo-Hitch™2" Ball/Lunette Eye Hitch (included)
• Fender and Light Kit (K2639-1)
• Cable Rack (K2640-1)
• Cable Connectors - two (K2487-1)
• Electrode Cable 2/0, two 50 ft. (15.3 m) lengths (K2485-2)
• Electrode Cable 2/0, 10 ft. (3 m) (K2483-2)
• Work Cable 2/0, 50 ft. (15.3 m) (K2484-2)
• 300A Electrode Holder (K909-7)
• 300A Work Clamp (K910-1)
Order:
K2453-3 Vantage®300 Kubota®Ready-Pak®Package
K2507-3 Vantage®300 Deutz®Ready-Pak®Package
K2636-1 Medium Welder Trailer
Va tage®300
Duo-Hitch™2" Ball/Lu ette Eye Hitch
(i cluded)
K2640-1 Cable Rack
Completely Assembled Ready-Pak®Pkg.

Va tage®300
www.li col electric.com
[6]
RECOMMENDED OPTIONS
120V
120V
GENERAL OPTIONS
Power Plug Kit (20A)
Provides four 120V plugs rated at 20
amps each, and one dual voltage,
full KVA (1-Phase) plug rated at
120/240V, 50 amps. 120V plug may
not be compatible with common
household receptacles.
Order K 02N
Power Plug Kit (15A)
Provides four 120V plugs rated at 15
amps each, and one dual voltage,
full KVA (1-Phase) plug rated at
120/240V, 50 amps. 120V plug is
compatible with common household
receptacles.
Order K 02R
Full-KVA Power Plug (1-Phase)
One dual voltage plug rated at
120/240V, 50 amps. NEMA 14-50P.
Order T12153-9
Full-KVA Power Plug (3-Phase)
One plug rated at 240V, 50 amps.
NEMA 15-50P.
Order T12153-10
Medium Welder Trailer
For heavy-duty road, off-road,
plant and yard use. Includes
pivoting jack stand, safety chains,
and 13" wheels. Stiff .120"
welded rectangular steel tube
frame construction is phosphate
etched and powder coat painted
for superior rust and corrosion
resistance. Low sway suspension
gives outstanding stability with
manageable tongue weight.
Wheel bearings are packed with
high viscosity, high pressure, low
washout Lubriplate®grease.
Includes a Duo-Hitch™– a 2"
Ball/Lunette Eye combination
hitch. Overall width 60".
Order:
K2636-1 Trailer
K2639-1 Fender &Light Kit
K2640-1 Cable Rack
Four-Wheeled Steerable
Yard Trailer
For off-road, plant and yard use.
Includes an automatically engaging
drawbar lock when the drawbar is
raised to the verticle position. 13"
wheels. Wheel bearings are packed
with high viscosity, high pressure,
low washout Lubriplate®grease.
Stiff 3/16" welded rectangular steel
frame construction is phosphate
etched and powder-coat painted
for superior rust and corrosion
resistance. Also includes a Duo-
Hitch™–a2" Ball/Lunette Eye com-
bination hitch. Overall width: 55"
Order K2641-2
Spark Arrestor Kit
Mounts to Muffler Exhust Tube.
Virtually eliminates spark emissions.
Order K1 9 -1
Digital Weld Meters Kit
Easy-to read digital meters for volts
and amps. Easy to install. (Included on
Kubota model (K2409-2).
Order K2467-1
STICK OPTIONS
Accessory Kit
Includes 35 ft. (10.7 m) 2/0 electrode
cable with lug, 30 ft. (9.1 m) 2/0 work
cable with lugs, headshield, filter plate,
cover plate, work clamp and electrode
holder. 400 amp capacity.
Order K704
Remote Output Control
Consists of a control box with choice
of two cable lengths. Permits remote
adjustment of output.
Order K 57 for 25 ft. (7.6 m)
K 57-1 for 100 ft. (30.5 m)
TIG OPTIONS
Pro-Torch®PTA-26V TIG Torch
Air-cooled 200 amp torch (2 piece)
equipped with valve for gas flow
control. 25 ft. (7.6 m) length.
Order K17 3-9
Magnum®Parts Kit for PTA-26V
TIG Torch
Magnum®Parts Kit provides all the
torch accessories you need to start
welding. Parts kit provides collets,
collet bodies, a back cap, alumina
nozzles and tungstens in a variety of
sizes, all packaged in an easy to carry
reclosable sack.
Order KP509
Foot Amptrol®
Provides 25 ft. (7.6 m) of remote output
control for TI welding. (6-pin plug
connection).
Order K 70
Hand Amptrol®
Provides 25 ft. (7.6 m) of remote
current control for TI welding. (6-pin
plug connection). Velcro straps secure
torch.
Order K963-3 (one size fits all
Pro-Torch®TI Torches)

RECOMMENDED OPTIONS
LN-23P Wire Feeder
Portable CV unit for Innershield pipe
welding. Includes drive rolls and guide
tubes. Requires K2393-1 or -2 Input
Cable Assembly and Magnum®
Innershield®un.
Order K316L-2
Input Cable Assembly for LN-23P
8-socket to 14-pin control cable with
lugged electrode cable for K316L-2 LN-
23P Wire Feeder.
Order:
K2393-1 25 ft (7.6 m)
K2393-2 75 ft (22.9 m)
Magnum®350 Innershield®Gun
(for LN-23P)
Rated 350 amps, 60% duty cycle. For
.068"-5/64" (1.7-2.0 mm) Innershield®
wire and includes reduced speed
switch.
Order K345-10
Magnum®SG Spool Gun
Hand held semiautomatic wire feeder.
Requires S Control Module and Input
Cable.
Order K4 7-25
SG Control Module
The interface between the power
source and the spool gun. Provides
control of the wire speed and gas flow.
For use
with a spool gun.
Order K4
Input Cable
(For SG Control Module)
For Lincoln engine power sources with
14-pin MS-type connection, separate
115V NEMA receptacles and output
stud connections.
Order K691-10
PLASMA CUTTING
Pro-Cut®55
Cuts metal using the AC generator
power from the engine-driven welder.
Accepts 3-phase or 1-phase input
power. Requires the K1816-1 Full KVA
adapter kit, if connected for 1-phase
input power.
Order K15 0-1
Full-KVA Adapter Kit (1-Phase)
Provides convenient connection of
Lincoln Electric equipment having a
240V AC 1-phase plug (NEMA 6-50P)
to the full-KVA receptacle on Lincoln
engine-driven welders.
Order K1 16-1
Va tage®300
www.li col electric.com
[7]
Precision TIG®225
Ready-Pak®Pkg.
For AC TI Welding with square wave
performance use the AC generator of
the engine-driven welder to supply
the power (full rated output may not
be available). Easy setup. Includes
torch, Foot Amptrol®and as
Regulator &Hose. Re-quires the
K1816-1 Full KVA adapter kit.
Order K2535-1
Invertec®V205-T AC/DC
One-Pak®Package
For AC TI welding with square wave
performance, use the AC generator
of the engine-driven welder to supply
the power. Easy setup. Includes
torch, parts kit, regulator and hose
kit, Twist-Mate™torch adapter, work
cable with Twist-Mate end and foot
Amptrol®.Requires K1816-1 Full-KVA
Adapter Kit.
Order K2350-2
Full - KVA Adapter Kit (1-Phase)
Provides convenient connection of
Lincoln Electric equipment having a
240V AC 1-phase plug (NEMA 6-50P)
to the full-KVA receptacle on Lincoln
engine-driven welders.
Order K1 16-1
WIRE FEEDER OPTIONS
LN-25 PRO Wire Feeder
Portable CC/CV unit for flux-cored
and MI welding with MAXTRAC®
wire drive system. Includes gas
solenoid and internal contactor.
Order K2613-1
Magnum®350 Innershield Gun
(for LN-25 PRO)
For self-shielded wire with 15 ft.
(4.5 m) cable. For .062"-3/32"
(1.6-2.4 mm) wire.
Order K126-2
Drive Roll and Guide Tube Kit
(for LN-25 PRO)
For cored or solid steel wire.
Order KP1697-06
for .068"-.072" (1.8 mm)
KP1697-5/64
for 5/64" (2.0 mm)
Magnum®300 MIG Gun
For .035"-.045" (0.9-1.2 mm) gas-
shielded wire with 15 ft. (4.5 m) cable.
LN-25 PRO Order:
K1 02-1 (Includes Connector Kit)
Drive Roll and Guide Tube Kit
(for LN-25 PRO)
For .035" and .045" (0.9-1.1 mm)
solid steel wire.
Order KP1696-1

VANTAGE®300 KUBOTA®K2409-2
VANTAGE®300 KUBOTA®ONE-PAK®PKG. K2452-3
VANTAGE®300 KUBOTA®READY-PAK®PKG. K2453-3
VANTAGE®300 DEUTZ®K2499-2
VANTAGE®300 DEUTZ®ONE-PAK®PKG. K2506-3
VANTAGE®300 DEUTZ®READY-PAK®PKG. K2507-3
RECOMMENDED GENERAL OPTIONS
Power Plug Kit - 20 amp K802N
Power Plug Kit - 15 amp K802R
Full-KVA Power Plug (1-Phase) T12153-9
Full-KVA Power Plug (3-Phase) T12153-10
Medium Welder Trailer with Duo-Hitch™2" Ball/Lunette Eye Hitch K2636-1
- Fender and Light Kit K2639-1
-Cable Rack K2640-1
Four-Wheeled Steerable Yard Trailer K2641-2
(with Duo-Hitch™:2" Ball/Lunette Eye Hitch)
Spark Arrestor Kit K1898-1
Digital Weld Meters Kit (standard on K2409-2) K2467-1
RECOMMENDED STICK OPTIONS
Accessory Kit K704
Remote Output Control
-25 ft. (7.6m) K857
- 100 ft. (30.5m) K857-1
RECOMMENDED TIG OPTIONS
Pro-Torch®PTA-26V TI Torch K1783-9
Magnum®Parts Kit For PTA-26V TI Torch KP509
Foot Amptrol®K870
Hand Amptrol®(All Pro-Torch®TI torches) K963-3
Precision TI ®225 Ready-Pak®Pkg. (for AC TI Welding) K2535-1
Invertec®V205-T AC/DC One-Pak®Pkg. (for AC TI welding) K2350-2
- Full KVA Adapter Kit (required for K2535-1 and K2350-1) K1816-1
RECOMMENDED WIRE FEEDER OPTIONS
LN-25 PRO Wire Feeder K2613-1
Magnum®350 Innershield®un K126-2
Drive Roll and uide Tube Kit .068"-.072" (for LN-25 PRO) KP1697-068
Drive Roll and uide Tube Kit 5/64" (for LN-25 PRO) KP1697-5/64
Magnum®300 MI un (for LN-25 PRO) (includes Connector Kit) K1802-1
Drive Roll and uide Tube Kit (for LN-25 PRO) KP1696-1
LN-23P Wire Feeder K316L-2
- Input Cable Assembly, 25 ft. (7.6 m) K2393-1
- Input Cable Assembly, 50 ft. (15.2 m) K2393-2
Magnum®350 Innershield®Welding un K345-10
Magnum®S Spool un®K487-25
- S Control Module (required) K488
- Input Cable (required) K691-10
RECOMMENDED PLASMA CUTTING OPTIONS
Pro-Cut®55 K1580-1
- Full KVA Adapter Kit (required for 1-phase input power) K1816-1
TOTAL:
THE LINCOLN ELECTRIC COMPANY®
22801 St. Clair Ave., Cleveland, OH 44117-1199 • 216.481.8100 • www.lincolnelectric.com
VANTAGE®300 ORDER FORM
PRODUCT DESCRIPTION ORDER NUMBER QUANTITY PRICE
CUSTOMER ASSISTANCE POLICY
The business of The Lincoln Electric Company®is manufacturing and selling high quality welding equipment, consumables, and cutting equipment. Our challenge is to meet the needs of
our customers and to exceed their expectations. On occasion, purchasers may ask Lincoln Electric for information or advice about their use of our products. Our employees respond to
inquiries to the best of their ability based on information provided to them by the customers and the knowledge they may have concerning the application. Our employees, however, are not
in a position to verify the information provided or to evaluate the engineering requirements for the particular weldment. Accordingly, Lincoln Electric does not warrant or guarantee or assume
any liability with respect to such information or advice. Moreover, the provision of such information or advice does not create, expand, or alter any warranty on our products. Any express or
implied warranty that might arise from the information or advice, including any implied warranty of merchantability or any warranty of fitness for any customers’ particular purpose is
specifically disclaimed.
Lincoln Electric is a responsive manufacturer, but the selection and use of specific products sold by Lincoln Electric is solely within the control of, and remains the sole responsibility of the
customer. Many variables beyond the control of Lincoln Electric affect the results obtained in applying these types of fabrication methods and service requirements.
Subject to Change – This information is accurate to the best of our knowledge at the time of printing. Please refer to www.lincolnelectric.com for any updated information.
