Lindsay GROWSMART User manual

Variable Rate Irrigation
Installation Manual
P/N 1600043 Rev M (ECN 34095)

P/N 1600043 Rev M (ECN 34095) VRI Installation Manual
Table of Contents
VRI General Safety Instructions.....................VRI-1
Product Warnings.................................................VRI-6
Federal Communications Commission (FCC)
Statement...............................................................VRI-7
Industry Canada Compliance Statement............VRI-7
Product Specications...............................................................VRI-8
Dimensional Data and Weight .................................................VRI-10
VRI Installation........................................................1
Introduction..................................................................1
What is Variable Rate Irrigation?......................................................1
How Variable Rate Irrigation works..................................................1
Installation....................................................................2
Installing the VRI System..................................................................2
VRI Power Supply. 1608401 ..............................................................9
Wiring to the Standard Tower Panel ..............................................10
Main Controller Enclosure Mounting.............................................11
Wiring Main Enclosure....................................................................14
VRI BASIC Control Panel Wiring....................................................15
VRI VISION/BOSS Control Panel Wiring........................................16
VRI Main Panel Wiring.....................................................................18
VRI for Pivot Control, Non-Zimmatic Main Panel
Wiring..........................................................................18
VRI Main Panel Set-Up...............................................19
Test Tab.............................................................................................19
Setup.................................................................................................22
Initial Start-Up ............................................................26
Troubleshooting.........................................................28
Appendix– VRI.............................................APDX-1
Node Wiring for New Zealand................................................APDX-1
Wireless Communication for New Zealand..........................APDX-2

P/N 1600043 Rev M (ECN 34095) VRI Installation Manual

VRI-1 VRI Operation/Installation Manual
General Safety Instructions
VRI General Safety Instructions
WARNING
Personal Safety:Through out this manual and on all safety signs, the precautionary statements
(“DANGER”, “WARNING”, “CAUTION” and “NOTICE”) can be found, followed by a hazard description
and preventative actions to be taken. These precautions are intended for the personal safety of the operator and
those within the vicinity of the machinery. Please take time to read these precautions.
Hazard Severity Panels
Background
Color of
Panel
Contrast
Color Meaning/Use Hazard Severity Panel Illustration
Red White Indicates a hazardous situation, that, if not
avoided, will result in death or serious injury.
Orange Black Indicates a hazardous situation, that, if not
avoided, could result in death or serious injury.
Yellow Black Indicates a hazardous situation, that, if not
avoided, could result in minor or moderate
injury.
Blue White Indicates information considered important, but
not hazard-related (e.g. messages relating to
property damage).
NOTICE
Machine Integrity:Additional precautionary statements (“ATTENTION” and “IMPORTANT”) are intended
for machine integrity and are followed by specic instructions.
ATTENTION: The word “ATTENTION” is used to warn the operator of potential machine damage if a certain pro-
cedure is not followed.
IMPORTANT: The word “IMPORTANT” is used to provide the reader with information necessary to prevent minor
machine damage if a certain procedure is not followed.
WARNING: All maintenance and service must be performed by a Lindsay Dealer.

VRI-2 VRI Operation/Installation Manual
General Safety Instructions
WARNING
Lock Out/Tag Out: Disconnect all sources of energy and lock out machine before doing any
maintenance or repairs to the machine. Proper Lock Out procedures will prevent the energy source from
starting the machine or allowing parts to move unexpectedly as well as prevent the machinery from being
accidentally turned on or restarted. Shut off and Lock Out all sources of potential or kinetic energy. These may
include, but are not limited to, electrical, mechanical or hydro energy sources.
Lock Out is a procedure used for placing an actual locking device on the power source, preventing unexpected
start up or accidental release of energy. Lock Out is the preferred method of accident prevention.
Tag Out procedure is used when the power can not be disconnected. Tag Out does not shut down the power
source, Tag Out only provides a warning about the danger of activating the machine.
Never try to operate machinery that is locked out or tagged out. Never attempt to remove these locks or tags on
machinery. Doing so will result in injury to personnel working on the machine. Only the initiator of the Lock Out or
Tag Out procedure may remove locks and tags.
Sometimes it may be necessary to energize the system to test or position equipment during maintenance or
repair. Such application must be performed only by a qualied technician and all Lock Out removal steps must be
followed before power is turned on.
WARNING
Main Disconnect: The main power disconnect is located at the main service breaker or
generator. The disconnect at the panel is not the main disconnect. A fuseable service disconnect device
must be placed previous to this panel with the fuses sized for the load being supplied and installed in accordance
to NEC codes.
It is important to understand the differences between the Pivot Enable switch (if installed), High Voltage On/Off
switch and the service breaker On/Off throw switch.
The power company service disconnect provides the ability to turn off or return full service to the equipment from
the power company service line. This switch must be turned off and locked out when performing maintenance and
repairs on the system.
The High Voltage On/Off provides the ability to turn off or return power to the equipment from the service discon-
nect. This switch must be turned off and locked out in conjunction with the service disconnect switch. The High
Voltage switch only disconnects the power in the control panel, as energy is still coming in from the main power
line.
The Pivot Enable switch (if installed) provides power to the system controls. When enabled, the entire system and
the controls will power up. When turned off, the controls and system will not be energized. However, there will be
power in the panel circuitry. The Pivot Enable switch is NOT a disconnect and should not be treated as such.

VRI-3 VRI Operation/Installation Manual
General Safety Instructions
WARNING
Follow Safety Instructions:Carefully
read all safety messages in this manual and safety
sings on the machinery. Keep safety signs in legible
condition. Replace any missing or damaged safety signs.
Learn how to operate the machine and controls properly. Do
not allow anyone to operate the machinery without proper
instructions.
Keep the machine in proper working condition. Only have the
machine serviced by a trained service technician on a routine
basis. Unauthorized modications to the machine may impair
the function and/or safety and reduce the life of the machine.
CAUTION
Practice Safe Maintenance: Understand maintenance procedures before doing work.
Always follow proper Lock Out/Tag Out procedures before performing any maintenance.
Never lubricate or service machine while it is moving. Keep hands, feet and loose clothing from power-driven
parts. Disengage all power and operator controls to relieve pressure. Allow all heat-generating units to cool.
Keep all parts in good condition. Remove any build up of grease, oil and debris. Ensure that all parts have been
properly installed by a certied technician.
Tower alignment, pressure switch adjustment and tower control switch adjustment must be performed by a quali-
ed service technician.
WARNING
Electric Shock: Follow these precautions to prevent serious injury or death.
DO NOT allow moisture to enter the main panel. Moisture can allow voltage to conduct across surfaces, creating a
shock potential.
Dangerous voltage potential may be present at lightning arrester. Visually inspect arrester before each operation.
If lightning arrester shows signs of impairment, contact a Lindsay Dealer.
WARNING
Electrical Connections: Keep all sparks and ames away from battery, as gases given off by
electrolyte are explosive. Avoid sparks by connecting the ground cable last and disconnecting it rst.
WARNING
Inspecting the System Prior to Operation:Always inspect the system before opera-
tion. If the system appears impaired, do not operate the machinery and contact a Lindsay Dealer.
CAUTION
Area Lighting:The owner shall provide area lighting as may be required.

VRI-4 VRI Operation/Installation Manual
General Safety Instructions
WARNING
Repairing the System: In the event that the Zimmatic System needs to be repaired; discon-
nect the power source, depressurize the system and contact the Lindsay Dealer.
Only a Lindsay Dealer should make necessary repairs to the system.
Ensure that only Genuine Lindsay Parts are used on the system.
WARNING
Overhead Maintenance: Overhead maintenance should be performed by a Lindsay Dealer.
Never attempt to climb on an irrigation machine for any reason.
WARNING
Lifting Components:Extreme care is needed for lifting components during installation/assem-
bly. Only a Lindsay Dealer using the proper lifting equipment may perform this task.
Use caution when lifting heavy objects. Components weighing in excess of 50 lbs. (22.7 kg.) must be lifted with
the assistance of another individual or mechanical lifting device.
Do not work or stand under system or components during assembly. Due to the weights involved, severe injury or
death can result if components should fall.
WARNING
Dismantling the System:If it is ever necessary to dismantle a Zimmatic System, extreme
care must be taken. As with installation and assembly, dismantling must only be performed by a Lindsay
Dealer.
WARNING
Impaired Safety Protection:Do not attempt to operate if protection may be impaired. If the
equipment appears to have been changed or operates abnormally, protective devices may be impaired.
Do not attempt to operate and have the equipment serviced by a Lindsay Dealer.
WARNING:Wear appropriate PPE (Personal Protective Equipment)
WARNING:Ensure that power is turned off/disconnected before removing any protective covers.
WARNING: Do not use this product in a manner not specied in this manual.
WARNING:The power switch in the VRI main panel (14-9957-0) is not the main disconnect for the
system. The main disconnect is in the irrigation system main control panel.

VRI-5 VRI Operation/Installation Manual
General Safety Instructions
CAUTION
Prepare for Emergencies: Be prepared for any emergency that may occur. Keep emergency
numbers for doctors, hospital, ambulance service and re department near your telephone.
The following symbols indicate grounding connections that can be found on irrigation systems..
Earth Ground Protective Earth Ground Frame or Chassis Ground

VRI-6 VRI Operation/Installation Manual
General Safety Instructions
Product Warnings
Node Power Supply
VRI Power Supply Assembly, 1608401
A readily accessible disconnect device shall be provided for permanently connected equipment.
Disconnect all power before servicing.
The disconnect for this device is located at the irrigation systems main panel.
Over current protection shall be provided, externally, to the equipment. It shall be capable of providing no
more than 6.3 Amps of continuous current draw.
Installation of the AC main connection requires the protective earth conductor to be trimmed “longer” than
the Line and Neutral conductors.
Equipment is to be installed securely before operation.
Burn Hazard: Disconnect all power for a minimum of 15 minutes prior to servicing.
VRI Controller
VRI Panel, Main Controller Assembly, 1499570
All hazardous live (greater than 42 Vrms 60 Vdc) input and output connections must be separated from
AC mains through an approved isolation transformer, meeting the requirements for reinforced insulation
of 2660 Vac.
Powered only from an approved Class 2 power source.
This product shall only be interconnected to other Class 1 or Class 2 devices.
A disconnect device is not provided. A readily accessible disconnect device shall be incorporated exter-
nally to the equipment. The system disconnect device is at the irrigation systems main panel.

VRI-7 VRI Operation/Installation Manual
General Safety Instructions
Federal Communications Commission (FCC) Statement
NOTE: This equipment has been tested and found to comply within the limits for a Class B digital device pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer-
ence when the equipment is operated in a commercial environment. This equipment generates, uses and radiates
radio frequency energy and, if not used in accordance with the manufacturer’s instruction manual, may cause
harmful interference with radio communications.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
These limits are designed to provide reasonable protection against harmful interference. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interfer-
ence with radio or television reception, which can be determined by turning the equipment on and off, try to correct
the interference by one or more of the following measures:
• Reorient or relocate the antenna of the radio/television receiver.
• Increase the separation between this equipment and the radio/television receiver.
• Plug the equipment into a different outlet so that the equipment and the radio/television receiver are on different
power mains branch circuits.
• Consult a representative of Lindsay Corporation for additional suggestions.
Industry Canada Compliance Statement
This Class B digital apparatus meets the requirements of the Canadian Interference-Causing Equipment Regula-
tions.
Cet appareil numerique de la Classe B respecte toutes les exigences du Relement sur le Materiel Brouilleur du
Canada.
The statements on this page apply to the following:
P/N 1608401, Power Supply Assembly, VRI
P/N 1605647, Node Ass’y, Standard, VRI
P/N 1609171, Panel, Main Control, VRI

VRI-8 VRI Operation/Installation Manual
General Safety Instructions
Product Specications
Standard Node Assembly Ratings:
2000 Meters Altitude
24V 0.75A 18W
Class III Control (IEC 60730-1)
IP44
Operating Temperature (C): 0T 40
Storage Temperature (C): -40T 75
Pollutions Degree 1
Overvoltage Category III
FCCID: TYOJN5168M3
IC: 7438A-CYO5168M3
Control Type: Electrically Operated Control Type 1 Action
SELV Circuit Rated
1. Circuits ≤ 42.4 VDC
2. Power source must be isolated from mains supply by reinforcing insulation equal to or greater
than 2660 VAC
VRI Controller Ratings:
2000 Meters Altitude
120 VAC, 5A Max. Short circuit protection of 5 Amp located in Irrigation
System Main Control Panel
Class III Control (IEC 60730-1)
IP44
Operating Temperature (C): 0T 40
Storage Temperature (C): -40T 75
Pollutions Degree 1 w/cover closed
Overvoltage Category III
FCCID: TYOJN5168M3
IC: 7438A-CYO5168M3
VRI Power Supply Ratings:
2000 Meters Altitude
400/415/480 V ~ 2A
3Φ 50/60 Hz
IP44
Operating Temperature (C): 0T 40
Storage Temperature (C): -40T 75

VRI-9 VRI Operation/Installation Manual
General Safety Instructions
High Powered Node Assembly Ratings:
2000 Meters Altitude
24V 0.75A 18W
Class III Control (IEC 60730-1)
IP44
Operating Temperature (C): 0T 40
Storage Temperature (C): -40T 75
Pollutions Degree 1
Overvoltage Category III
FCCID: TYOJN5168M6
IC: 7438A-CYO5168M6
Control Type: Electrically Operated Control Type 1 Action
SELV Circuit Rated
1. Circuits ≤ 42.4 VDC
2. Power source must be isolated from mains supply by reinforcing insulation equal to or greater
than 2660 VAC
Regulatory Compliance Standards
United States & Canada
FCC Part 15
CISPR 22 Class B
European Union
93/68/EEC–CE
2006/42/EC–MD
• EN 909:1998+A1:2009
• EN 60204-1:2009
• EN 60529:1991+A1:2000
2006/95/EC–LVD
• EN 60204-1:2009
• EN 60950-1:2010
• EN 60730-1:2010
2004/108/EC–EMCD
• EN 61000-6-1:2007
• EN 61000-6-4:2001
• EN 55022
• EN 55024
1995/5/EC–RTTE
• ETSI EN 301 489-1 V1.8.1 (2008-04)
• ETSI EN 301 489-7 V1.3.1 (2005-11)

VRI-10 VRI Operation/Installation Manual
General Safety Instructions
Dimensional Data and Weight
1608401, Power Supply Assembly, VRI
Height x Width x Depth: 14” x 12” x 8” (356 x 305 x 203 mm)
Weight: 8.5 lbs (3.9 kg)
1605647, Node Assembly, Standard, VRI
Height x Width x Depth: 8.25” x 6.29” x 3.94” (210 x 160 x 100 mm)
Weight: 5.73 lbs (2.6 kg)
1499570, Panel, VRI Main Control
Height x Width x Depth: 24.75” x 16.75” x 8.50” (629 x 425 x 210 mm)
Weight:52.0 lbs (23.6 kg)

P/N 1600043 Rev M (ECN 34095) 1 VRI Installation Manual
VRI Installation
Introduction
What is Variable Rate Irrigation?
Variable Rate Irrigation (VRI) is a controller added to a mechanized irrigation system. This controller regulates the
amount of water to be applied along any part of the irrigator path.
Past irrigation practices attempted to maximize efciency using blanket irrigation, where water is applied as
uniform as possible under the length of irrigator. This has not been found to be the most efcient way to irrigate
by today’s standards. Variables such as drainage, soil texture and type, different crop requirements, and in some
cases, several acres within a eld would require no watering at all but still lie in the irrigator’s path; all of these situ-
ations can produce undesired results with blanket irrigation.
With Variable Rate Irrigation, the correct quantity of water can be applied in the precise location where it’s needed.
How Variable Rate Irrigation works
VRI provides precision control of all sprinklers on a center pivot irrigation system by pulsing each individual sprin-
kler on and off. This allows the application rate to be modied along the entire length of the system.
First, a map of the eld to be irrigated is uploaded to the VRI program. This can either be drawn in from aerial pho-
tographs (such as Google Maps), using soil maps, or from points that have been recorded using a handheld GPS.
From the images, “management area boundaries” can be created, where specied zones needing less water can
be marked.
Next, the amount of water to be applied to each area must be dened. The VRI software allows the operator to
establish this application amount and program it into the system for each established “irrigation zone”. Once the
design is completed, the operator must upload the VRI program to the controller at the center pivot. (USB “Thumb
Drives” are the typical method of le transfer.)
Each sprinkler has a latching solenoid valve that is pulsed on or off by a controlling node. Each node controls four
sprinklers with individual control of each valve.

P/N 1600043 Rev M (ECN 34095) 2 VRI Installation Manual
Installation
Installing the VRI System
Installing Valves
Install valves and drop in one of the three following congurations. Make sure to install the valve with the ow
direction arrow stamped on the body pointing in the correct direction of ow.
Valve
1608320
3/4” Gooseneck
3/4” Steel Nipple
or
Senninger 3/4” Poly Nipple
Valve 1608320
3/4” Gooseneck
Hose Drop
Extension
3/4” Gooseneck
Hose-Vice
Hose Drop
Valve 1608320
Preferred Method Alternate Method-B, for
Poly-Lined Pipe Only
Alternate Method-A

P/N 1600043 Rev M (ECN 34095) 3 VRI Installation Manual
Installing Nodes, Looms and GPS Units
The nodes and cable looms have been cut to length, making it imperative that they are installed in the correct
order. Refer to the sprinkler chart for the node location and cable length. All node boxes should be mounted to the
same side of the irrigation span pipes so there is less interference with the wireless communications.
The correct node order is:
Pivot Point ► Node 1 ► Node 2 ► Node 3 ► etc.
The valve order is:
Pivot Point ► 1A ► 1B ► 1C► 1D► 2A► 2B► 2C► 2D► etc.
Note: The node enclosures are mounted on the same outlet as Valve B for each set of valves.
The nodes are set up to be connected via power cable in a “daisy chain” fashion. The power line from node 1 con-
nected to node 2; another power line connects node 2 to node 3 and so on, until reaching the 24V power supply at
the center of the system.
1605647 VRI
Standard Node
Assembly
1605863 VRI Hanger Bracket
#10-24 Screws
Fasten to threaded holes in back of panel.
(Tabs are not longer present.)
Slots in hanger bracket
are for adjusting to the
various pipe diameters.
Worm Gear style
Hose Clamps
GPS Unit (Last Node Only)
Found in Kit 1498710
GPS Mounts via magnetic base to the
hanger. For added support, the GPS can
be bolted to the hanger, with the screw
and lock washer provided, at this mount
hole location.

P/N 1600043 Rev M (ECN 34095) 4 VRI Installation Manual
It’s important when installing the cables to keep them clear of any sharp edges or moving components so as not to
damage the cables. Cables should be tied down tightly at 4 foot (1.2 meters), or less, intervals. Any excess cabling
should be bundled neatly out of the way of moving components and tied to the irrigation span cable.
Make a nal check that all cable glands are tightened properly.
Node Wiring for Most Locations (See Appendix A for Australia and New Zealand Wiring)
The node assemblies are factory wired. Only the 24VDC power connection needs to be wired at installation.
(Refer to the Standard Node Wiring Diagram below)
Note: Use shielded cable that is properly grounded for all external connections.
The red wire connects to the +24V terminal and the black wire connects to the ground terminal (GND).
Note: The black wire should never be connected to the irrigation system ground.
The valve plugs have been pre-wired and only need to be plugged onto the correct valve and to the correct posi-
tion on the Node board. Node boards installed prior to March 2015 (P/N’s 1500000, 1605633 and 1605847) must
be replaced with PCB Node Kit 1609494 (shown below.)
CAUTION: Do not reverse the polarity of the 24VDC supply.
Blue
Orange
Blue
Orange
Valve A Valve B Valve C Valve D
Negative In–Out
Black Positive In–Out
Red
Orange
Orange
Blue
Blue
MAC Address

P/N 1600043 Rev M (ECN 34095) 5 VRI Installation Manual
Tornado Board
GPS Antenna Cable
GPS Installation
The end node (at the farthest end of the system) will have a Global Positioning System (GPS) receiver and a GPS
interface board (Tornado board) that must be plugged into the programming port on the Printed Circuit Board
(PCB). The GPS antenna plugs into the Tornado board as shown below.
It is important that all power and valve wires be kept low and as far away from the antenna wiring as much as pos-
sible to prevent interference with the antenna.
Excess GPS antenna cable must not be left inside the node box. Tie excess antenna cable to the node panel sup-
port bracket.
Each node circuit board has a set of DIP switches. Switches 1 through 4 set the radio communication channel.
Every set of DIP switches in a single system must be set the same. Other nearby pivot systems equipped with VRI
control should be set to a different channel to eliminate any cross-talk between the two pivots.
Flip the DIP switch down for deactivation of a channel and ip the switch up to activate the channel.
The DIP switch marked ”GPS” is for enabling nodes with GPS connected. Enable GPS by activating the GPS DIP
switch only on the node with GPS. Make sure all other nodes in the system have the GPS DIP switch deactivated.
DIP switches are set at the factory but must be veried during installation.
Before closing the door on the node panel box, ensure:
• The circuit board is securely fastened to the standoffs.
• Use cable ties to fasten all wires close to the bottom of the node enclosure to prevent electrical interference
with the node antenna and antenna wiring.
GPS Antenna Cable
Connection

P/N 1600043 Rev M (ECN 34095) 6 VRI Installation Manual
Valve Assembly
There are three parts to the valve plugs:
• Plug Housing
• Seal
• Mounting Screw
Every plug needs to be tted with a seal and secured to the coil using a mounting screw.
Note: For Australia and New Zealand the wire colors and wiring
are as follows:
White wire goes to #1 on DIN Insert
Black wire goes to #2 on DIN Insert
