Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
1,000-plus different models now appear in 11 groups1
Thank you for purchasing your Kramer VS-81H 8x1 HDMI Switcher. The
VS-81H is ideal for conference room presentations and advertising
applications, as well as for rental and staging.
that are clearly
defined by function.
Note, that the Kramer VS-81H is identical to the VS-81HDMI; just the
name has changed replacing the suffix “HDMI” by “H” (according to
the HDMI Guideline).
Each package includes the following items:
•VS-81H 8x1 HDMI Switcher
•Power cord, rack “ears” and null-modem adapter
•Windows®-based Kramer control software2
•Windows®-based Ethernet Configuration Manager and Virtual
Serial Port Manager
•Kramer Infrared Remote Control Transmitter (including the
required batteries and a separate user manual3)
•This user manual3
2 Getting Started
We recommend that you:
•Unpack the equipment carefully and save the original box and
packaging materials for possible future shipment
•Review the contents of this user manual
•Use Kramer high performance high resolution cables4
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;
GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;
GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products
2 Downloadable from our Web site at http://www.kramerelectronics.com
3 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com
4 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

Getting Started
KRAMER: SIMPLE CREATIVE TECHNOLOGY
2
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.

Overview
3
3 Overview
The VS-81H is a high-performance switcher for HDMI signals. It reclocks
and equalizes the signal and switches one of the 8 inputs to a single HDMI
output.
In particular, the VS-81H features:
•Support for up to 2.25Gbps bandwidth per graphic channel1
•Eight input selector buttons
•HDCP support (High Definition Digital Content Protection)
•HDMI support – HDMI (V.1.4 with Deep Color, x.v.Color™, Lip
Sync, HDMI Uncompressed Audio Channels, Dolby TrueHD,
DTS-HD, CEC)
•EDID pass-through that passes EDID/HDCP signals from source
to display
•3D pass-through
•An OFF button to disconnect the output and a PANEL LOCK
button to prevent unwanted tampering with the buttons on the
front panel
•Installation in one vertical space of a standard 19” professional
rack enclosure
Control the VS-81H using the front panel buttons, or remotely via:
•RS-232 serial commands transmitted by a touch screen system,
PC, or other serial controller
•The Kramer infrared remote control transmitter
•The ETHERNET
3.1 Defining EDID
The Extended Display Identification Data (EDID2
) is a data-structure,
provided by a display, to describe its capabilities to an HDMI source. The
EDID enables the VS-81H to “know” what kind of monitor is connected to
the output. The EDID includes the manufacturer’s name, the product type,
the timing data supported by the display, the display size, luminance data
and (for digital displays only) the pixel mapping data.
1 Suitable for resolutions up to UXGA at 60Hz, and for all HD resolutions
2 Defined by a standard published by the Video Electronics Standards Association (VESA)

Overview
KRAMER: SIMPLE CREATIVE TECHNOLOGY
4
3.2 About HDMI
High-Definition Multimedia Interface (HDMI) is an uncompressed all digital1
In particular, HDMI:
audio/video interface, widely supported in the entertainment and home cinema
industry. It delivers the highest high-definition image and sound quality. Note
that Kramer Electronics Limited is an HDMI Adopter and an HDCP Licensee.
•Provides a simple2interface between any audio/video source, such as
a set-top box, DVD player, or A/V receiver and video monitor, such
as a digital flat LCD / plasma television (DTV), over a single
lengthy3
•Supports standard, enhanced, high-definition video, and multi-
channel digital audio
cable
4
•Transmits all ATSC HDTV standards and supports 8-channel digital
audio, with bandwidth to spare to accommodate future enhancements
and requirements
on a single cable
•Benefits consumers by providing superior, uncompressed digital
video quality via a single cable5
•Is backward-compatible with DVI (Digital Visual Interface)
, and user-friendly connector
•Supports two-way communication between the video source (such as
a DVD player) and the digital television, enabling new functionality
such as automatic configuration and one-button play
HDMI has the capacity to support existing high-definition video formats
(720p, 1080i, and 1080p/60), as well as standard definition formats such as
NTSC or PAL.
1 Ensuring an all-digital rendering of video without the losses associated with analog interfaces and their unnecessary digital-
to-analog conversions
2 With video and multi-channel audio combined into a single cable, the cost, complexity, and confusion of multiple cables
currently used in A/V systems is reduced
3 HDMI technology has been designed to use standard copper cable construction at up to 15m
4 HDMI supports multiple audio formats, from standard stereo to multi-channel surround-sound. HDMI has the capacity to
support Dolby 5.1 audio and high-resolution audio formats
5 HDMI provides the quality and functionality of a digital interface while also supporting uncompressed video formats in a
simple, cost-effective manner

Your VS-81H 8x1 Switcher
5
3.3 About HDCP
The High-Bandwidth Digital Content Protection (HDCP) standard1
3.4 Recommendations for Best Performance
, protects
digital video and audio signals transmitted over DVI or HDMI connections
between two HDCP-enabled devices to eliminate the reproduction of
copyrighted material. To protect copyright holders (such as movie studios)
from having their programs copied and shared, the HDCP standard provides
for the secure and encrypted transmission of digital signals.
To achieve the best performance:
•Use only good quality connection cables2
•Avoid interference from neighboring electrical appliances that
may adversely influence signal quality and position your Kramer
VS-81H away from moisture, excessive sunlight and dust
to avoid interference,
deterioration in signal quality due to poor matching, and elevated
noise levels (often associated with low quality cables).
4 Your VS-81H 8x1 Switcher
Figure 1 and Table 1 define the VS-81H.
1 Developed by Intel
2 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com

Your VS-81H 8x1 Switcher
KRAMER: SIMPLE CREATIVE TECHNOLOGY
6
Figure 1: VS-81H 8x1 HDMI Switcher

Your VS-81H 8x1 Switcher
7
Table 1: VS-81H 8x1 HDMI Switcher Features
#
Feature
Function
1 IR Receiver The red LED lights when receiving signals from the
Infrared remote control transmitter
2 POWER Switch Illuminated switch for turning the unit ON or OFF
3 OFF Button Press to toggle disconnecting the output
Blinks when the EDID of the connected monitor is
different from the last EDID that was saved
4 INPUT SELECTOR Buttons Press the INPUT button to select input (from 1 to 8)
5 PANEL LOCK Button Press to toggle disengaging the front panel buttons, to
acquire the EDID and to set to the PC/DVD mode
6 INPUT HDMI Connectors Connect to the HDMI sources (from 1 to 8)
7 RS-232 9-pin D-sub Port Connects to the PC or the RS-232 Remote Controller
8 ETHERNET Connector Connects to the PC or other Ethernet Controller
9 RESET Button Press the ETHERNET factory reset button to reset to the
factory default definitions1
10
:
IP number −192.168.1.39
Mask – 255.255.255.0
Gateway – 192.168.1.1
OUTPUT HDMI Connector Connect to the HDMI acceptor
11 Power Connector with Fuse AC connector enabling power supply to the unit
1 First, disconnect the power cord and then connect it again while pressing the RESET button. The unit powers up and loads
its memory with the factory default definitions

Installing the VS-81H on a Rack
KRAMER: SIMPLE CREATIVE TECHNOLOGY
8
5 Installing the VS-81H on a Rack
This section provides instructions for rack mounting the unit.

Connecting a VS-81H 8x1 HDMI Switcher
9
6 Connecting a VS-81H 8x1 HDMI Switcher
To connect the VS-81H 8x1 HDMI Switcher (as illustrated in Figure 2), do
the following1
1. If required:
:
Set the appropriate INPUTS to the DVD/PC mode (see section
7.1)
Acquire the EDID (see section 7.2)
2. Connect2the HDMI sources as follows3
A multimedia player to INPUT 1
:
A set top box to INPUT 2
A DVD player to INPUT 6
A DVD player to INPUT 8
3. Connect the OUTPUT HDMI connector to an HDMI acceptor (for
example, a plasma display).
4. If required, connect a PC and/or controller to the RS-232 port (see section
7.3)and/or the ETHERNET port (see section 7.3).
5. Connect the power connector to the mains electricity.
Press an INPUT SELECTOR button (from 1 to 8) to choose which HDMI
input to route to the output4
1 Switch OFF the power on each device before connecting it to your VS-81H. After connecting your VS-81H, switch on its
power and then switch on the power on each device
.
2 You can connect up to 8 HDMI sources
3 Alternatively, you can connect a PC to any of the inputs and set those inputs to the PC mode (see section 7.1)
4 The input button illuminates

Operating the VS-81H
KRAMER: SIMPLE CREATIVE TECHNOLOGY
10
Figure 2: Connecting a VS-81H 8x1 HDMI Switcher
7 Operating the VS-81H
This section describes:
•The PC mode and the DVD mode (see section 7.1)
•How to acquire the EDID (see section 7.2)
•How to control the machine via RS-232 (see section 7.3)
•How to control the machine via the ETHERNET port (see section 7.4)

Operating the VS-81H
11
7.1 The PC and DVD Modes
The VS-81H has two operation modes that are specific per input: the PC
mode1
•The PC mode is used when connecting a computer or several
computers to one or more of the inputs via a DVI-to-HDMI
converter cable
and the DVD mode:
2
•The DVD mode is used when connecting a DVD or several DVDs
to the inputs
When in the PC mode, the input has access to the EDID (default or
acquired) to prevent the computer from resetting if an output is not
connected. In the DVD mode, the EDID of the connected output is available
only when the input to which the DVD is connected, is switched to the
output.
The PC mode and the DVD mode can be applied to a single input or to
several inputs. For example, if you want to connect a computer to INPUT 1,
another computer to INPUT 2, and DVD machines to all the other inputs
(from INPUT 3 to INPUT 8), set INPUT 1 and INPUT 2 to the PC mode
and all the other inputs to the DVD mode.
To set the inputs to either the PC or the DVD mode, do the following:
1. Turn the POWER off.
2. Press the PANEL LOCK button while turning the POWER on again.
The INPUT buttons blink simultaneously.
3. Keep pressing and holding the PANEL LOCK button for a few seconds and
then release it.
The PANEL LOCK button blinks.
If an input button illuminates, this indicates that that input is set to the DVD
mode.
If an input button is not illuminated, this indicates that that input is set to the
PC mode.
4. Toggle between the PC mode (input button not illuminated) and the DVD
mode (input button illuminated) by pressing that input.
5. Press the PANEL LOCK button to exit this mode.
6. You can connect a computer to the input(s) that is set to the PC mode and a
DVD to the input(s) that is set to the DVD mode.
1 The default
2 For example, the Kramer C-HM/DM series in various lengths (3”, 6”, 10” and 15”)

Operating the VS-81H
KRAMER: SIMPLE CREATIVE TECHNOLOGY
12
Table 2 summarizes the differences between the PC mode and the DVD
mode:
Table 2: DVD Mode and PC Mode Characteristics
PC Mode
DVD Mode
The input is connected to a computer The input is connected to a multimedia application,
such as a DVD, a set top box and so on
The EDID is available at all times (to prevent
computer reset)
The EDID is available only when that input is
connected to an output
The input EDID source is the default EDID
or an acquired EDID (see section 7.2)
The input EDID source is acquired directly from the
connected output
7.2 Acquiring the EDID
The acquired EDID is used when an input is set to the PC mode.
To acquire the EDID, do the following:
1. Turn the POWER off.
2. Press the PANEL LOCK button and the INPUT 8 button while turning the
POWER on again.
The INPUT buttons blink in sequence until the unit has completed to read
the EDID.
3. Release the PANEL LOCK and INPUT 8 buttons.
If an output was connected, the output EDID is read to all the inputs. If an
output was not connected to the machine, the default EDID is read to the
inputs.

Operating the VS-81H
13
7.3 Connecting a PC
You can connect to the VS-81H via an RS-232 connection using, for
example, a PC. Note that a null-modem adapter/connection is not required.
To connect to the VS-81H via RS-232:
•Connect the RS-232 9-pin D-sub rear panel port on the VS-81H
unit via a 9-wire straight cable (only pin 2 to pin 2, pin 3 to pin 3,
and pin 5 to pin 5 need to be connected) to the RS-232 9-pin
D-sub port on your PC
7.4 Controlling the VS-81H via the ETHERNET Port
You can connect the VS-81H via the Ethernet, using a crossover cable (see
section 7.4.1) for direct connection to the PC or a straight through cable (see
section 7.4.2) for connection via a network hub or network router.
7.4.1 Connecting the ETHERNET Port directly to a PC (Crossover
Cable)
You can connect the Ethernet port of the VS-81H to the Ethernet port on
your PC, via a crossover cable with RJ-45 connectors.
This type of connection is recommended for identification of the factory default
IP Address of the VS-81H during the initial configuration
After connecting the Ethernet port, configure your PC as follows:
1. Right-click the My Network Places icon on your desktop.
2. Select Properties.
3. Right-click Local Area Connection Properties.
4. Select Properties.
The Local Area Connection Properties window appears.
5. Select the Internet Protocol (TCP/IP) and click the Properties Button (see
Figure 3).

Operating the VS-81H
KRAMER: SIMPLE CREATIVE TECHNOLOGY
14
Figure 3: Local Area Connection Properties Window
6. Select Use the following IP Address, and fill in the details as shown in
Figure 4.
7. Click OK.
Figure 4: Internet Protocol (TCP/IP) Properties Window
7.4.2 Connecting the ETHERNET Port via a Network Hub (Straight-
Through Cable)
You can connect the Ethernet port of the VS-81H to the Ethernet port on a
network hub or network router, via a straight through cable with RJ-45
connectors.

Technical Specifications
15
7.5 Configuring the Ethernet Port
To control several units via the Ethernet, connect the Master unit
(Machine # 1) via the Ethernet port to the LAN port of your PC. Use your
PC initially to configure the settings (see section 7.3).
8 Technical Specifications
Table 3 includes the technical specifications:
Table 3: Technical Specifications1
INPUTS:
of the VS-81H
8 HDMI connectors
OUTPUT: 1 HDMI connector
BANDWIDTH: Supports up to 2.25Gbps bandwidth per graphic channel
COMPLIANCE WITH
HDMI STANDARD:
Supports HDMI and HDCP
RESOLUTION: Up to UXGA; 1080p, deep color
POWER SOURCE: 100−240V AC; 50/60Hz, 12VA
CONTROLS: Front panel buttons, infrared remote control transmitter, RS-232, Ethernet
DIMENSIONS: 19’ x 7” x 1U W, D, H
WEIGHT: 2.5kg (5.5lbs) approx.
ACCESSORIES: Power cord, rack “ears”, null-modem adapter, IR remote control
OPTIONS: Kramer HDMI cables
2
1 Specifications are subject to change without notice
2 For best results, use Kramer cables such as the C-HM/HM series, the C-HM/DM series and/or our HDMI over fiber optics
C-FOHM/FOHM series

Kramer Protocol 2000
KRAMER: SIMPLE CREATIVE TECHNOLOGY
16
9 Kramer Protocol 2000
The VS-81H is compatible with Kramer’s Protocol 20001
Table 4: Protocol Definitions
(version 0.50)
(below). This RS-232/RS-485 communication protocol uses four bytes of
information as defined below. For RS-232, a null-modem connection
between the machine and controller is used. The default data rate is 9600
baud, with no parity, 8 data bits and 1 stop bit.
MSB LSB
DESTI-
NATION
INSTRUCTION
0
D
N5
N4
N3
N2
N1
N0
7
6
5
4
3
2
1
0
1st byte
INPUT
1
I6
I5
I4
I3
I2
I1
I0
7
6
5
4
3
2
1
0
2nd byte
OUTPUT
1
O6
O5
O4
O3
O2
O1
O0
7
6
5
4
3
2
1
0
3rd byte
MACHINE NUMBER
1
OVR
X
M4
M3
M2
M1
M0
7
6
5
4
3
2
1
0
4th byte
1st BYTE: Bit 7 – Defined as 0.
D – “DESTINATION”: 0 - for sending information to the switchers (from the PC);
1 - for sending to the PC (from the switcher).
N5…N0 – “INSTRUCTION”
The function that is to be performed by the switcher(s) is defined by the INSTRUCTION (6 bits). Similarly, if a function is
performed via the machine’s keyboard, then these bits are set with the INSTRUCTION NO., which was performed. The
instruction codes are defined according to the table below (INSTRUCTION NO. is the value to be set for N5…N0).
2nd BYTE: Bit 7 – Defined as 1.
I6…I0 – “INPUT”.
When switching (ie. instruction codes 1 and 2), the INPUT (7 bits) is set as the input number which is to be switched.
Similarly, if switching is done via the machine’s front-panel, then these bits are set with the INPUT NUMBER which was
switched. For other operations, these bits are defined according to the table.
3rd BYTE: Bit 7 – Defined as 1.
O6…O0 – “OUTPUT”.
When switching (ie. instruction codes 1 and 2), the OUTPUT (7 bits) is set as the output number which is to be switched.
Similarly, if switching is done via the machine’s front-panel, then these bits are set with the OUTPUT NUMBER which was
switched. For other operations, these bits are defined according to the table.
4th BYTE: Bit 7 – Defined as 1.
Bit 5 – Don’t care.
OVR – Machine number override.
M4…M0 – MACHINE NUMBER.
Used to address machines in a system via their machine numbers. When several machines are controlled from a single serial
port, they are usually configured together with each machine having an individual machine number. If the OVR bit is set, then
all machine numbers accept (implement) the command, and the addressed machine replies.
1 You can download our user-friendly “Software for Calculating Hex Codes for Protocol 2000” from our Web site:
http://www.kramerelectronics.com

Kramer Protocol 2000
17
For a single machine controlled via the serial port, always set M4…M0 = 1, and make sure that the machine itself is
configured as MACHINE NUMBER = 1.
Table 5: Instruction Codes for Protocol 2000
Note: All values in the table are decimal, unless otherwise stated.
INSTRUCTION
DEFINITION FOR SPECIFIC INSTRUCTION
NOTE
#
DESCRIPTION
INPUT
OUTPUT
1 SWITCH VIDEO Set equal to video input which is to
be switched
(0 = disconnect)
Set equal to video output which is
to be switched
(0 = to all the outputs)
2, 15
30 LOCK FRONT PANEL 0 - Panel unlocked
1 - Panel locked
0 2
31 REQUEST WHETHER
PANEL IS LOCKED
0 0 16
61 IDENTIFY MACHINE 1 - video machine name
2 - audio machine name
3 - video software version
4 - audio software version
5 - RS422 controller name
6 - RS422 controller version
7 - remote control name
8 - remote software version
9 - Protocol 2000 revision
0 - Request first 4 digits
1 - Request first suffix
2 - Request second suffix
3 - Request third suffix
10 - Request first prefix
11 - Request second prefix
12 - Request third prefix
13
NOTES on the above table:
NOTE 2 - These are bi-directional definitions. That is, if the switcher receives the code, it will perform the instruction; and if
the instruction is performed (due to a keystroke operation on the front panel), then these codes are sent. For example, if the
HEX code
01 85 88 83
was sent from the PC, then the switcher (machine 3) will switch input 5 to output 8. If the user switched input 1 to output 7
via the front panel keypad, then the switcher will send HEX codes:
41 81 87 83
to the PC.
When the PC sends one of the commands in this group to the switcher, then, if the instruction is valid, the switcher replies by
sending to the PC the same four bytes that it was sent (except for the first byte, where the DESTINATION bit is set high).
NOTE 13 - This is a request to identify the switcher/s in the system. If the OUTPUT is set as 0, and the INPUT is set as 1, 2,
5 or 7, the machine will send its name. The reply is the decimal value of the INPUT and OUTPUT. For example, for a 2216,
the reply to the request to send the audio machine name would be (HEX codes):
7D 96 90 81 (i.e. 128dec+ 22dec for 2nd byte, and 128dec+ 16dec for 3rd byte).
If the request for identification is sent with the INPUT set as 3 or 4, the appropriate machine will send its software version
number. Again, the reply would be the decimal value of the INPUT and OUTPUT - the INPUT representing the number in
front of the decimal point, and the OUTPUT representing the number after it. For example, for version 3.5, the reply to the
request to send the version number would be (HEX codes):
7D 83 85 81 (i.e. 128dec+ 3dec for 2nd byte, 128dec+ 5dec for 3rd byte).
If the OUTPUT is set as 1, then the ASCII coding of the lettering following the machine’s name is sent. For example, for the
VS-7588YC, the reply to the request to send the first suffix would be (HEX codes):
7D D9 C3 81 (i.e. 128dec+ ASCII for “Y”; 128dec+ ASCII for “C”).
NOTE 15 – When the OVR bit (4th byte) is set, then the “video” commands have universal meaning. For example, instruction
1 (SWITCH VIDEO) will cause all units (including audio, data, etc.) to switch. Similarly, if a machine is in “FOLLOW”
mode, it will perform any “video” instruction.
NOTE 16 - The reply to the “REQUEST WHETHER PANEL IS LOCKED” is as in NOTE 4 above, except that here the
OUTPUT is assigned with the value 0 if the panel is unlocked, or 1 if it is locked.

KRAMER: SIMPLE CREATIVE TECHNOLOGY
18
LIMITED WARRANTY
WHOIS PROTECTED?
WHATIS COVEREDAND WHATIS NOTCOVERED
WH AT WE WI LL PAY FOR AND W HAT WE WIL L NO T PAY F O R
HOW YOU CAN GET WARRANTY SERVICE
LIMITATIONOFIMPLIEDWARRANTIES
EXCLUSIONOFDAMAGES
CAUTION!
Kramer Electronics (hereafter ) warrants this product free from defects in material and workmanship under the
following terms.
Kramer
HOW LONGIS THE WARRANTY
Labor and parts are warranted for three years from the date of the first customer purchase.
Only the first purchase customer may enforce this warranty.
We will pay labor and material expenses for covered items. We will notpay for the following:
The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall
not be liable for:
This warranty gives you specific legal rights, and you may also have other rights, which vary from place to place.
All products returned to Kramer for service must have prior approval. This may be obtained from your dealer.
This equipment has been tested todetermine compliance with the requirements of:
EN-50081: "Electromagnetic compatibility(EMC);
generic emission standard.
Residential, commercial and light industry"
EN-50082: "Electromagnetic compatibility(EMC) generic immunity standard.
Part 1: Residential, commercial and light industry environment".
CFR-47: FCC* Rules and Regulations:
Part 15: “Radio frequency devices
Subpart B Unintentional radiators”
Except as below, this warranty covers all defects in material or workmanship in this product. The following are not covered
by the warranty:
1. Any product which is not distributed by Kramer, or which is not purchased from an authorized Kramer dealer. If you are
uncertain as to whether a dealer is authorized, please contact Kramer at one of the agents listed in the Web site
www.kramerelectronics.com.
2. Any product, on which the serial number has been defaced, modified or removed, or on which the WARRANTY VOID
TAMPERED sticker has been torn,
3. Damage, deterioration or malfunction resulting from:
i) Accident, misuse, abuse, neglect, fire, water, lightning or other acts of nature
ii) Product modification, orfailure to follow instructions supplied with theproduct
iii) Repair or attempted repair by anyone not authorized by Kramer
iv) Anyshipment of the product(claims must be presented tothe carrier)
v) Removal or installationof the product
vi) Any other cause, which does not relate to a product defect
vii) Cartons, equipment enclosures, cables or accessories used inconjunction with the product
1. Removal or installationscharges.
2. Costs of initial technical adjustments (set-up), including adjustment of user controls or programming. These costs are the
responsibility of the Kramer dealer from whom the product was purchased.
3. Shipping charges.
1. To obtain service on you product, you must take or ship it prepaid to any authorized Kramer service center.
2. Whenever warranty service is required, the original dated invoice (or a copy) must be presented as proof of warranty
coverage, and should be included in any shipment of the product. Please also include in any mailing a contact name,
company, address, and a description of the problem(s).
3. For the name of the nearest Kramer authorized service center, consult your authorized dealer.
All implied warranties, including warranties of merchantability and fitness for a particular purpose, are limited in duration to
the length of this warranty.
1. Damage to otherproperty caused by defects inthis product, damages basedupon inconvenience, loss of use of theproduct, loss
of time, commercialloss; or:
2. Any other damages, whether incidental, consequential or otherwise. Some countries may not allow limitations on how long an
implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitations and exclusions maynot applyto you.
Servicing the machines can only be done by an authorized Kramer technician. Any user who makes changes or
modifications to the unit without the expressed approval of the manufacturer will void user authority to operate the
equipment.
Use the supplied DC power supply to feed power to the machine.
Please use recommended interconnection cables to connect the machine to other components.
IF reattached, removed or otherwise interfered with.
* FCC and CE approvedusingSTPcable (for twistedpair products)
NOTE:
Part 1:
