LINEAR SOUND LTS.CDPRO User manual

Linear Technologie • 11 rue du Puits Rochefort • 42 100 Saint-Etienne
Tél: [phone] • Fax: [phone] • www.lineartech.fr V.2017
CD / MP3 / USB PLAYER LTS.CDPRO
Operation manual

2
1. Safety precautions
2. Description
3. Specications
4. Front panel
5. Rear panel
Page 3
Page 3
Page 4
Page 4
Page 5
TABLE OF CONTENTS

3
When installing the unit :
• Do not expose the unit to rain or an environment where it may be splashed by water or
other liquids, as doing so may result in re or electric shock.
• Use the unit only with the voltage specied on the unit. Using a voltage higher than that
which is specied may result in re or electric shock.
• Do not cut,kink otherwise damage nor modify the power supply cord. In addition, avoid
using the power cord in close proximity to heaters, and never place heavy objects -
including the unit itself - on the power cord, as doing so may result in re or electric shock.
• Avoid installing or mounting the unit in unstable locations, such as on a rickety table or a
slanted surface. Doing so may result in the unit falling down,causing personal injury and
/ or property damage.
• Never connect the power supply with wet hands.
• Do not block the ventilation outlet.
When the unit is in use :
• Should the following irregularity be found during use, immediately switch o󰀨 the power :
- If you detect smoke or a strange smell coming from the unit.
- If water or any metallic object gets into the unit.
- If the unit falls or the unit case breaks.
- If the power supply cord is damaged (exposure of the core, disconnection, etc.)
- If it is malfunctioning (no tone sounds.)
1. SAFETY PRECAUTIONS
This CD / USB / MP3 player 1U has, in the front face, an integrated disc loader type «slot»
anti shock. An LCD display, wide and full, informs the user of the read current state.
The CDPRO embeds all useful functions for professional use as :
• Auto pause
• Play single or continuous
• Pitch knob +/- 12 with return to zero by pressing the knob
• USB port and USB / CD switch in the front face
• Full function Loop
• Direct access to the rst 10 tracks through the knob
• Program selection key
On the rear panel, the CDPRO o󰀨ers a balanced stereo XLR output with adjustable level on
by channel or RCA and an output for headphone with adjustable volume and a SCHUKO
type power connector.
This player reads CD formats / CD-R / CD-RW / MP3 / USB. An IR remote control (optional)
incorporates the functions of CDPRO.
2. DESCRIPTION

4
1. Power switch : Press the button. The red light indicates the unit is on.
2. Eject key : Press this button to load or eject a CD.
3. CUE key : Press this button to save the current search point as the starting point of the
next search.
4. Play / Pause
5. Back key
6. Skip forward key
7. Track selection key
8. Remote control : Infrared receiver for remote control.
9. Switch to switch from CD to USB function
10. Repeat key
11. Single / continuous mode
12. Time key : To select the time mode.
13. IN key : To stall the start of the loop.
14. OUT key : To stall the end of the loop.
15. To launch the last programmed list
16. Pitch key
17. Punctual slowdown key
18. Punctual acceleration key
19. Control pitch
20. USB input
21. LCD display screen
Frequency response 20 Hz ~ 20 KHz
Distortion < 0.01%
S/N ratio 96 dB
Sampling 44.1 kHz
Audio output XLR symmetric 200 mV and RCA 200 mV
Headphone output Jack 6.35 stereo 200 mV
Dynamic range <98 dB
Supply AC 100 ~ 240V - 50 / 60 Hz
Power consumption 9 - 16W
Dimensions (19’’ x 1U) 483 x 250 x 44.5 mm
Weight 3.90 kg
3. SPECIFICATIONS
4. FRONT PANEL

5
1. Power supply input
2. Right symmetric output : XLR audio output.
3. Left symmetric output : XLR audio output.
4. & 5. Output level adjustment keys
6. Analog output jack
7. Jack headphone plug 6.35 mm
8. Headphone volume control
5. REAR PANEL
