DEMO MANUAL DC1333A
DESCRIPTION
LTC2640
Single 12-Bit SPI VOUT DAC
with Internal Reference
Demonstration circuit 1333A features the LT C
®
2640, a
12-bit SPI DAC. This device establishes a new bench-
mark for size and integration of 12-bit DACs and onboard
reference.
The DC1333A may be connected directly to the target
application’s analog signals while using the DC590 USB
serial controller board and supplied software to measure
L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks and
QuikEval is a trademark of Linear Technology Corporation. All other trademarks are the property
of their respective owners.
BOARD PHOTO
performance. After evaluating with Linear Technology’s
software, the digital signals can be connected to the end
application’s processor
Design files for this circuit board are available at
http://www.linear.com/demo/DC1333A
Figure 1. DC1333A Connection Diagram
DAC
CONNECTIONS
RIBBON CABLE
TO DC590
CONTROLLER
dc1333a F01
DEMO BOARD VARIATIONS
DEMO BOARD TYPE LTC2640 VARIATION RESOLUTION (BITS) POWER-UP FULL-SCALE
DC1333A-A LTC2640AITS8-LM12 12 Mid-Scale 2.5V
DC1333A-B LTC2640AITS8-LZ12 12 Zero 2.5V
DC1333A-C LTC2640AITS8-HM12 12 Mid-Scale 4.096V
DC1333A-D LTC2640AITS8-HZ12 12 Zero 4.096V
Downloaded from Arrow.com.

2
DC1333afa
DEMO MANUAL DC1333A
QUICK START PROCEDURE
1. ConnecttheDC1333AtoaDC590USBserialcontroller
using the supplied 14-conductor ribbon cable.
2. Connect the DC590 to the host PC with a standard
USB A/B cable.
3. Run the QuikEval™ evaluation software supplied
with the DC590 or download it from www.linear.
com/software. The correct program will be loaded
automatically.
Options are available to display the DAC output in voltage,
hex code, or decimal count. Additionally, the reference
voltage may be changed to reflect an actual measured
value, such that the output voltage matches the theoreti-
cal output voltage. The reference mode may be changed
from internal reference to external reference.
Features may be periodically added to the software. See
the software’s help menu for the latest information.
Figure 2. QuikEval Software
Downloaded from Arrow.com.Downloaded from Arrow.com.

3
DC1333afa
DEMO MANUAL DC1333A
HARDWARE SETUP
JUMPERS
_CLR/REF_SEL: On the B and D versions of the demo
board, this is not populated. On the A and C versions of the
demo board, this is used to determine the reference input.
ANALOG CONNECTIONS
DAC outputs are provided on the row of turret posts at
the edge of the board.
GROUNDING AND POWER CONNECTIONS
Power (VCC): Normally, the DC1334A is powered by the
DC590 controller. VCC can be supplied to the 5V turret,
howeverthe power supply on the DC590 must be disabled!
Refer to the DC590 Quick Start Guide for more details on
this mode of operation.
Grounding: Three ground posts are provided.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

4
DC1333afa
DEMO MANUAL DC1333A
Information furnished by Linear Technology Corporation is believed to be accurate and reliable.
However, no responsibility is assumed for its use. Linear Technology Corporation makes no representa-
tion that the interconnection of its circuits as described herein will not infringe on existing patent rights.
Figure 3. LTC2640 Schematic Diagram
SCHEMATIC DIAGRAM
5 5
4 4
3 3
2 2
1 1
D D C C B B A A
HDR2X7-079-MOLEX
-C
LTC2640 - LZ12 LTC2640 - HM12
U1
LTC2640 - HZ12
-A
LTC PART#
*
-B
LTC2640 - LM12
-D
Assy Table
*
1
0
_CLR/REF_SEL
R3JP1 4.99K 4.99K NO NO
JP1 NO NO JP1
*
*
A
DC1333A-A/B/C/D
Tuesday, September 23, 2008
11
HELEN 9/12/07
Leo Chen 9/12/07
Single 12/10/8-Bit SPI Vout DAC LTC2640-LM12/LZ12/HM12/HZ12
SIZE
SCALE:
CAGE CODE DWG NO REV
SHEET OF
FILENAME:
TITLE
CONTRACT NO.
APPROVALS DATE
DRAWN CHECKED APPROVED ENGINEER DESIGNER
TECHNOLOGY
1630 McCarthy Blvd. Milpitas, CA 95035 Phone: [phone] Fax: [phone]
 
       

E7 _CLR/REF_SEL
SDI
J1
1 2
3
4 5 6 7
8
9 10 11 12
13
14
VUNREG
5V
GND
SCK/SCL
MISO
CS
MOSI/SDA
GND
EESDA
EEVCC
EESCL
EEGND
GND
NC
JP1
1
2
3
R2
4.99K
R1
4.99K
C2
0.1uF
E3 GND E1 VCC
U1
LTC2640
1 3 2
7
46
8
5
_CS/LD SDI SCK
VOUT
GND REF
_CLR/REF_SEL
VCC
E2 REF
_CS/LD
R3
OPT
C1
0.1uF
E5 GND
SCK
Array
EEPROM
U2 24LC025-I/ST
5 6
7
4 8
3 2 1
SDA SCL
WP
GND VCC
A2 A1 A0
E4 VOUT E6 GND
R4
4.99K
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

5
DC1333afa
DEMO MANUAL DC1333A
REVISION HISTORY
BOARD REV DATE DESCRIPTION PAGE NUMBER
A 04/16 Corrected Part #s
Removed BOM
1
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

6
DC1333afa
DEMO MANUAL DC1333A
Linear Technology Corporation
1630 McCarthy Blvd., Milpitas, CA 95035-7417
[phone] ●FAX: [phone] ●www.linear.com
 LINEAR TECHNOLOGY CORPORATION 2013
LT 0416 REV A • PRINTED IN USA
