QUICK START GUIDE FOR DEMONSTRATION CIRCUIT 1339
LOW NOISE, 500KSPS, 12-BIT ADC
1
DESCRIPTION
LTC2302
Demonstration circuit 1339 features the LTC2302
low noise, 500ksps, 12-Bit, ADC. The LTC2302 has
an SPI compatible serial interface that can be used
to select channel polarity and unipolar or bipolar
settings. DC1339A demonstrates the DC and AC
performance of the LTC2302 in conjunction with the
DC590B QuikEval and DC890B Fast DAACS data
collection boards. Alternatively, by connecting the
DC1339A into a customer application, the
performance of the LTC2302 can be evaluated
directly in that circuit.
Design files for this circuit board are available. Call
the LTC factory.
LTC is a trademark of Linear Technology Corporation
Figure 1. DC1339A Connection Diagram

QUICK START GUIDE FOR DEMONSTRATION CIRCUIT 1339
LOW NOISE, 500KSPS, 12-BIT ADC
2
DC890B QUICK START PROCEDURE
Connect DC1339A to a DC890B USB High Speed
Data Collection Board using connector J2. Connect
DC890B to a host PC with a standard USB A/B cable.
Apply 6V-9V DC to the 6V-9V and GND terminals.
Apply a low jitter signal source to IN+ on connector
J1. Apply a low jitter clock with a maximum
frequency of 40MHz to connector J3. The clock can
be a sine wave or square wave with maximum
amplitude of 14dBm. Note that J3 has a 50•
termination resistor to ground, which will prevent
most logic from driving this pin directly. Run the Fast
DAACS software (Pscope.exe version K51 or later)
supplied with DC890B or download it from
www.linear.com. Complete software documentation
is available from the Help menu. Updates can be
downloaded from the Tools menu. Check for updates
periodically as new features may be added.
PSCOPE SOFTWARE CONFIGURATION
The Pscope software will recognize DC1339A and
configure itself automatically. The default
configuration is for IN+ with respect to IN- in
unipolar mode. Make sure that the jumpers are set
as shown in Figure 2. If bipolar mode is desired, it
will be necessary to change the Pscope ADC
configuration setting as well as jumpers JP3 and
JP5. From the front page of the software select ADC
Configuration from the Configure menu. Select 12-
Bits, Alignment 12, FPGA Ld Serial 2308 Class, 1-
Channel. Do not check Positive Edge Clk. Check
Bipolar if the JP5 UNI jumper is set to GND. An
example of the ADC configuration menu is shown in
Figure 3. JP3 should be changed from GND to
VREF/2 in bipolar mode, so that the minus input is
biased halfway between ground and Vref.
Click the Collect button (See Figure 4) to begin
acquiring data. Depending on which board was
previously used by Pscope it may be necessary to
press Collect a second time. The Collect button then
changes to Pause, which can be used to pause data
acquisition.
Figure 2. Jumper Settings Figure 3. User Configure Menu

QUICK START GUIDE FOR DEMONSTRATION CIRCUIT 1339
LOW NOISE, 500KSPS, 12-BIT ADC
3
DC590B QUICK START PROCEDURE
Connect DC1339A to a DC590 USB serial controller
using the supplied 14-conductor ribbon cable.
Connect DC590 to a host PC with a standard USB
A/B cable. Run the evaluation software supplied with
DC590 or download it from www.linear.com. The
correct control panel will be loaded automatically.
Version K73 of QuikEval or higher should be used for
this board. Click the COLLECT button to begin
reading the ADC. Change the range (unipolar or
bipolar) by right clicking over the range indicator in
the display. See Figure 5.
HARDWARE SET UP
SIGNAL CONNECTIONS
J1 SMA connector for IN+. Limit input swings to
0V-4.096V. For optimum performance, the input
should be band limited to the frequencies of interest.
See schematic for details.
J2 FastDAACS interface to DC890B. Do not use J4 at
the same time.
J3 Conversion Clock Input. This input has a 50•
termination resistor, and is intended to be driven by
a 14dBm sine or square wave. To achieve full AC
performance of this part, the clock jitter should be
kept under 20ps. This input is capacitively coupled
to a clock buffer so that level shifting is not required.
To run at maximum conversion rate, apply a 40MHz
signal to this connector. J3 is used only for DC890B.
DC590B generates its own clock signal.
J4 Quick Eval interface to DC590B. Do not use J2 at
the same time. This connector can also be used to
drive the ADC directly. See schematic for details.
JUMPERS
JP1 (OVDD) connects the OVDD pin of the ADC to 5V
or to an external voltage. The SDO pin swings from
ground to OVDD.
JP2 contains CONV, SDI, SCK and a buffered SDO
signal. This connector is intended to monitor these
signals. For for those who want to drive the ADC
directly use J4.
JP3 (IN-) selects whether the IN- pin of the ADC is to
be cleanly grounded near the ADC or connected to
VREF/2.
JP4 (VREF) selects onboard or external reference for
the ADC
JP5 (DIN Word) selects the channel configuration
and unipolar/bipolar settings of the ADC. (JP5 is
used by the DC890B only. It is ignored by the
DC590B.)
GROUNDING AND POWER CONNECTION
Connect a 6V to 9V power supply to the 6-9VDC and
GND posts when using DC890B. If the DC590B is
used it will provide power to the DC1339.

QUICK START GUIDE FOR DEMONSTRATION CIRCUIT 1339
LOW NOISE, 500KSPS, 12-BIT ADC
4
Figure 4. DC1339A Pscope Screenshot

QUICK START GUIDE FOR DEMONSTRATION CIRCUIT 1339
LOW NOISE, 500KSPS, 12-BIT ADC
5
Figure 5. DC1339A QuikEval Screen Shot

QUICK START GUIDE FOR DEMONSTRATION CIRCUIT 1339
LOW NOISE, 500KSPS, 12-BIT ADC
6
C14
1uF
C33
0.1uF
R5
3.01K
1%
5V
E10
GND
R3
49.9
1%
(Opt)
5V
E8
5V
U6
LT1790ACS6 4.096
6
12
4
35
VOUT
GNDGND
VIN
DNCDNC
C34
0.1uF
U3
SN74AHCT1G04DCKT
42
5
3
C6
0.1uF
CONV_AT_ADC
E7
2.5V
C12
1uF
J1
IN+
0V 4.096V
C8
1uF
16V
E4
VREF
R8
10
C1
10uF
6.3V
MUX
EXPOSED
CONVST
SDO
SCK
SDI
VREF
GND
OVDD
VDD
PAD
IN+
IN
LTC2302CDD
U1
2
1
9
8
4
5
103
6711
U4
LT1761ES5 2.5
1
2
43
5
IN
GND
ADJSHDN
OUT
2.5V
5V
JP1
EXT
OVDD
5V
1
3
2
E2
IN+
5V
JP4
EXT REF
VREF
4.096V
1
3
2
R1
100
C15
47uF
10V
E5
VREF/2
R7
4.99K
1%
C16
1uF
16V
E6
EXT REF
U2
NC7SVU04P5X
42
5
3
SDO_AT_590
JP2
DO
CLK
CNV
DI
1
3
2
4
65
7 8
E1
OVDD
E9
6V 9V
E3
IN
R4
100
C11
0.01uF
SCK_AT_ADC
C17
10uF
C7
10uF
6.3V
5V
U5
LT1761ES5 5
1
2
43
5
IN
GND
ADJSHDN
OUT
SDI_AT_ADC
C4
47pF
SDO_AT_BUF
C2
0.1uF
JP3
GND
IN
VREF/2
1
3
2
C13
0.01uF
C10
0.1uF
C5
47pF
2.5V
C3
0.1uF
R2
301 1%
C9
10uF
6.3V
R6
4.99K
1%

QUICK START GUIDE FOR DEMONSTRATION CIRCUIT 1339
LOW NOISE, 500KSPS, 12-BIT ADC
7
5V
C27
0.1uF
SHDN#
R11
49.9
1%
+
-
U13
LT1719CS6
3
1
5
4
26
+
-
U11
LT1719CS6
3
1
5
4
26
R20
4.99K
1%
7V
R21
4.99K
1%
SHDN
+
-
U12
LT1719CS6
3
1
5
4
26
R12
1K
R24
2.49K
1%
5V
SHDN
R13
33
J2
EDGE CON 100
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
54
56
58
60
62
64
66
68
70
72
74
76
78
80
82
84
86
88
90
92
94
96
98
100
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
53
55
57
59
61
63
65
67
69
71
73
75
77
79
81
83
85
87
89
91
93
95
97
99
SHDN
E17
SCK
C22
0.1uF
U8
NC7SVU04P5X
42
5
3
OE
AB
U9
NC7SZ66P5X
1
3 5
2
4
CONV_AT_ADC
C19
0.1uF
C24
0.1uF
R23
2.49K
1%
SDI_AT_ADC
2.5V
C23
0.1uF
R14
33
E12
CNVCLK
R19
4.99K
1%
1.25V E13
MISO
R10
33
MISO
E16
CNVST
CONV_AT_ADC
C28
0.1uF
UNI
5V
E15
LATCH
5V
C31
0.1uF
E11
CONV
VCC_IN
R9
1K
C30
0.1uF
C18
0.1uF
SHDN#
E14
MOSI
CLK_IN
OS
R16
4.7K
2.5V
SDO_AT_590
Array
EEPROM
U16
24LC025 I /ST
5
8
1
2
3
4
7
6
SDA
VCC
A0
A1
A2
VSS
WP
SCL
7V C29
0.1uF
J4
87831 1420
Molex
7 9 1 2 6 4 10 5 11
12
14
3
13
8
MOSI/SDA
EESDA
VUNREG
5V CS
SCK/SCL
EEVCC
MISO
EESCL
EEGND
NC
GND
GND
GND
SHDN
SDI_AT_ADC
R15
33
C26
0.1uF
1.25V
C25
0.1uF
U14
NC7SZ04P5X_NL
42
5
3
C20
0.1uF
1.25V
5V
SDO_AT_590
JP5
1
3
5
6
4
7
9
11
13
8
10
12
14
2
15
24
16
17
20
18
19
21
22
23
5V
SHDN
SCK_AT_ADC
SCK_AT_ADC
1.25V
LATCH
U15
NC7SZ04P5X_NL
42
5
3
R22
4.99K
1%
R18
2.00K
1%
5V
J3
CONV
R17
33
U10
NL17SZ74USG
2
1
5
3
8 7
4 6
D
CP
Q
Q
VCC
PR
GND CLR
5V
5V
MOSI
U7
NC7SZ04P5X_NL
42
5
3
C32
2.2uF
16V
2.5V
CNVST
C21
0.1uF
SDO_AT_BUF
2.5V
