LINK-MI LM-WIH1 User manual

LINK-MI LM-WIH1 HDMI Adapter
Operation manual

Introduction
LM-WIH1, a converter for the Wii console, outputs video and audio in full digital
HDMI format and supports all Wii display modes (NTSC 480i 480p, PAL 576i). With
just one HDMI cable, plug and play for true-to-life video/audio effects on your
TV/monitor.
Features
1. Video and audio in full digital HDMI format, no transmission loss!
2. Works with DVI monitor.
3. Hassle Free! Plug and play as you go.
4. Supports all Wii display modes (NTSC 480i 480p, PAL 576i).
5. Provides advanced signal processing with great precision. Colors, resolutions!
6. No power adaptor, no messy cords—just one HDMI cable.
Specification
Input Connector
Wii AV Multi Out Plug x 1
Output Connectors
HDMI Connector x 1
3.5mm Stereo Audio Jack x 1
Supported Video input Mode
Includes all the display modes of the Wii console
(480i, 480p, 576i)
Supported HDMI output Mode
Outputs pure digital HDMI video/audio signals
Power Consumption
below 2W
Dimensions
34 x 73 x 14 mm
Weight
15g

Setups for Connecting to a TV/Monitor with HDMI Input
1. Make sure that the Wii console is powered Off. Then insert the AV Multi Out Plug of
the LM-WIH1 into the AV Multi Out Connector in the back of the Wii console.
2. Plug one end of the HDMI cable into the LM-WIH1 HDMI output, and plug the other end to the
HDMI input on the TV/monitor.
3. Turn on the TV/monitor and switch the video input of the TV to match the HDMI
input connector used by the LM-WIH1. Then you should be able to see the Wii screen after you turn
on the Wii console.
Note: In order to obtain the best display quality, we strongly recommend that you set the Wii video
output to 480p mode (progressive mode). For more details, please refer to the “Set the Wii Video
Output to 480p Mode” section.

Set the Wii Video Output to 480p Mode
Under 480p mode, the image data is double what it is under the 480i mode. Therefore,
the 480p mode can provide you with much better display quality. In addition, as long as your
TV/monitor has HDMI input, it is technically compelled to support the 480p mode; and even though
most of the TVs/monitors support the 480i mode, it is not the usual standard. In conclusion, 480p is a
better mode for higher display quality, as well as a better solution to avoid compatibility problems
with TVs/monitors. Therefore, we
strongly recommend that when you use the LM-WIH1, you set the Wii video output to 480p mode.
The detailed setups are as follows:
1. Make sure that the Wii console is powered off and that no disc is in the tray.
2. Power on the Wii console to reach the Wii Channel menu. Then, click on the "Wii"
button on the lower lefthand side.
3. On the next screen, select the “Wii Settings” on the right-hand side.
4. From the “Wii System Settings 1” screen, select the “Screen” button.
5. From the “Screen” screen, select the “TV Resolution” button.
6. From the “TV Resolution” screen, select the “EDTV or HDTV (480p)” button, and
click the "Confirm" button on the lower righthand side. At this point, you should have
successfully set your Wii video output to 480p mode.
Setups for Connecting to a TV/Monitor with DVI Connector
Unlike HDMI, DVI cannot carry audio data. Therefore, in addition to a HDMI-to-DVI cable, you will
also need a 3.5mm plug to the 2RCA audio cable.
1. Make sure that the Wii console is powered off. Then insert the AV Multi Out Plug of the LM-WIH1
into the AV Multi Out Connector in the back of the Wii console.

2. Plug the HDMI end of the HDMI-to-DVI cable into the LM-WIH1 HDMI output, and the DVI end to
the DVI input on the TV/monitor.
3. Connect the 3.5mm plug end of the audio cable to the 3.5mm stereo audio jack on the LM-WIH1,
and connect the other end of the audio cable to the RCA connectors on the TV/monitor or stereo
equipment. Usually, there are red and white RCA connectors that need to be connected.
4. Turn on the TV/monitor; switch the video input of the TV to match the DVI input
connector used by the LM-WIH1. Then you should be able to see the Wii screen after you turn on
the Wii console.
Note I: In order to obtain the best display quality, we strongly recommend that you set
the Wii video output to 480p mode (progressive mode). For more details, please refer to the “Set the
Wii Video Output to 480p Mode” section.
Note II: If the audio input connector on your TV/monitor or stereo equipment is a 3.5mm audio jack
rather than RCA connectors, then you will need to have a 3.5mm to 3.5mm male-to-male stereo
audio cable instead.

FAQ
Q: Can LM-WIH1 improve the display quality?
A: The correct answer is both “Yes” and “No”!
If you have always used the composite cable (in the package when you purchased the Wii
console) or SCART cables, which support only 480i mode, then you will notice a major
improvement after using LM-WIH1.
The LM-WIH1 doesn’t have de-interlacing or scaling functionality, but it faithfully converts the
video signals from the Wii console to HDMI signals. Therefore, there is no obvious difference if
you compare the HDMI signals with the 480p signals displayed under the best conditions. On the
other hand, because the HDMI signal output from the LM-WIH1 is in digital video/audio format, no
quality degrading problem occurs during transmission. Therefore, compared with the analogue
signals, which degrade along with distance, the digital HDMI signals output from the LM-WIH1
can provide you with superior display quality without transmission loss!
Q: I already set the Wii video output to 480p mode, but why does the LM-WIH1 still output video
in 480i mode?
A: The output mode depends on several factors: 1) theWii console, 2) LM-WIH1, 3)
theTV/monitor, and 4) the gaming software. The first two items can correctly support 480p without
any problem, and all HDMI TV/monitors are required to support 480p mode. Therefore, if you
have already set the display mode on the Wii console to 480p,but it still outputs in 480i mode,
then the only possibility remains with your Wii gaming software, which may not support 480p
mode.
The great majority of the Wii gaming software supports 480p mode, including most newly
released games. Nonetheless, a few games still do not support 480p.
Q: My Wii console is a European version with 576i format option. I wonder if the LM-WIH1 will
work with it?
A: LM-WIH1 does support 576i format. If your HDMI TV/monitor also supports 576i format, then
you may choose to display in 576i format. However, 576i and 480i mode belong to the interlace
format; therefore, the display quality is not as good as 480p which is a progressive scan type.
Thus, for better display quality and compatibility, we still suggest using 480p mode.
