LINKRICH GH Series User manual

1
GH Series Electric Griddle
Thanks for choosing LINKRICH products:
We mainly produce food processing equipment, baking equipment, professional kitchen equipment, steel kitchen ware,
commercial refrigeration equipment and ice cream machine, more than 6 series, 127 kinds of products for you to choose.
They are environment-friendly with excellent designs. High technique to save power, complete functions, easy to operate,
LINKRICH products are more competitive than those of the same line in the international market.
ATTENTION
New user or repairing this product must be performed by the experts or qualified person or those who have gotten the
license of installation, or those who are authorized by the manufacturer.
When installation or maintenance, please obey the following instructions carefully to ensure the safety use of this
appliance.
Please keep this instruction Manual for future reference, or hand it to next user.
Put off the package to make sure none of the parts is missing or damaged. If there is any doubt about the product,
please do not use it, and consult it to the experts.
Keep the packing material out of reach of the children to avoid accident( Especially the plastic bag, screw etc)
This appliance could be only operated by the person who is familiar with the unit.
When not using the appliance or the operator is absent, please turn off the unit to avoid any accidental injury or
damage.
When it needs to be repaired, please ask for expert, and use the original fitted spare part. It will be dangerous if not
following the above requirements.
This appliance is just for commercial using, not for any other use, otherwise, it may be dangerous.
Do not rinse the equipment with water directly.
Clean the surface of stainless steel periodically with appropriate method to prevent any damage brought by oxidization
or any other chemical interference.
Warning
Any self-modification, wrong installation, adjustment or maintenance can lead to property loss or casualty. Please
contact the manufacturer for any adjustment or maintenance, and have the work done by a trained & qualified person.
For your safety sake, please keep the machine away from any liquid, gas or other object, which is flammable or
explosive.
This appliance should not be operated by those who have physiological, perceptual or mental disabilities or those who
have insufficient experience or knowledge (including children). Only in conditions of being given sufficient supervise &
guarantee of personal safety, as well as proper instructions & guidance, those who were mentioned above can make
some particular operation of this device.
Keep children away from the device.
Preserve this manual safely. When passing on/selling the device to a third party, the manuals must be handed over
along with the device. All users must operate the device complying with the user’s manual and related safety
guidelines.
Do not store or use gas, liquid or object that is flammable or explosive in the vicinity of the mounting position of the
appliance.
If this appliance is placed near walls, partitions or kitchen furniture and the like, it is advisable to make these facilities
with non-combustible material, otherwise cover them with non-combustible heat-resistant material, and pay attention
to fire prevention regulations.
Housing of the appliance should be grounded to ensure safety. Thanks for your cooperation!
Do not use extra power supply that not marked on the product. Before using, ground the appliance reliably to ensure
safety.
Do not destroy the furnace body surfaces with hard or sharp objects.

2
Functional Introduction
This product is manufactured by our company, which is combined with advantages from home and abroad. It is novel in
design, reasonable in structure, easy in operation, durable in using, fast in heating up and convenient in maintenance. The
thermostatic control makes the temperature freely adjustable at a certain range according to food requirement. Therefore,
it is the ideal equipment for hotel, supermarket, restaurant, western restaurant, fast-food restaurant and food industry.
Structure Schematic Diagram & Working Principle
Structure Schematic Diagram:
1--thermostat
2—heating indicator
3—power indicator
4—drip pan
5—furnace body
6—power cord
7—rubber foot
Structural & Functional Features:
1. Smooth plate surface treatment, easy to clean, very sanitary and clean.
2. Desired temperature can be set according to requirement and food condition.
3. Fast heating up, easy operation and convenient maintenance.
Electrical Diagram:

3

4
Basic Features & Parameters
Model
Voltage
(V)
Power
(Kw)
Cooking Surface
Size(mm)
Thickness of Hot
Plate (mm)
Temperature
(℃)
Net Weight
(kg)
Dimension
(mm)
GH-400
220
3
400×396
12
50~300
26.5
400×500×285
GH-550
220
3
546×348
12
50~300
32
550×495×270
GH-610
220
6
606×400
12
50~300
40
610×545×270
GH-760
220
6
756×400
12
50~300
48
760×545×270
Precautions & Recommendations
Transportation and Storage

5
During transportation, the machine should be carefully handled and do not put it upside down to prevent from damaging to
the shell and inside. The packaged machine should be stored in a ventilated warehouse without corrosive gas. If it needs to
be stored in open air temporarily, measurement against raining is needed.
Notice for Installment
1. The supply voltage should comply with the working voltage of the appliance.
2. During installation and operation, keep your hands dry. Plugs and switches etc. should be in dry contact.
3. The appliance is equipped with an earth bolt at its back, which should be connected with copper wire no less than
1.5mm² and earth wire that conforming to safety regulations reliably.
4. After installation, check that whether the connection is loose, whether the voltage is normal and whether the safety
grounding is reliable.
5. The appliance should be positioned at a stable area with a minimum clearance of 10cm away from non-combustible
substances (e.g. walls, windows etc.) on both sides, and 20cm at back side.
6. The fixed arrangement of wire should be equipped with an all-pole disconnecting switch with a contact opening of
3mm on its poles. It is advisable to install a grounding leakage protection switch. Do not pile up sundries in front of the
switch, for convenient operation sake.
7. Vicinity of the mounting position should not store flammable or explosive objects.
8. Installation of the appliance should be done by professional technicians.
Special Notice
1. This product is a commercial machine that needs to be operated by trained cook, not applicable for household use.
2. Do not sway or tilt the appliance during operation.
3. Do not dismantle or self-modify the machine. Dismantlement and self-modification may cause casualty.
4. Do not open the housing of the machine. This product contains high-voltage circuit, housing dismantlement may cause
electric shock.
5. Before cleaning, unplug and cut off the power supply.
6. During cleaning, do not aim at the appliance with water jet. Surfaces could be cleaned with soft towel. Water may
conduct electricity, that may cause electric shock due to leakage.
7. Do not pat the product or put any heavy objects onto it. Abnormal operation may cause damage and danger.
8. High temperature may cause scald. Do not touch the appliance with hands directly due to high temperature during or
after operation.
9. To prevent damage, turn off the switch ASAP when near the thunder zone.
10. After working, turn off the switch.
11. To avoid hazard caused by false reset of the thermal breaker, do not supply the appliance with external switch device,
e.g. Timer, or connect the appliance to circuit connected or disconnected by general components at regular time.
12. To avoid hazard caused by false reset of the thermal breaker, do not supply the appliance with external switch device,
e.g. Timer, or connect the appliance to circuit connected or disconnected by general components at regular time.
Working Instructions & Operation Flow
1. Before using, check that whether the power installation is correct. Making sure that the supply voltage complies with
the working voltage of the appliance.
2. Turn on the power switch, the green indicator illuminates, which indicates that the appliance is energized. Rotate the
thermostat clockwise to align the desired temperature scale value with the dot, at this time, the yellow indicator
illuminates, the heating elements are working. When desired temperature is reached, the thermostat will cut off the
power supply automatically with the yellow indicator off, the heating elements stop working. Once the temperature
drops a bit, the thermostat will connect the power supply automatically, the yellow indicator illuminates and the
heating elements restart working with the temperature rising. The procedure circulates to ensure the temperature
keep constant within the set range.
3. Griddle plate temperature can be freely adjusted at a certain range in accordance with food type to get an ideal effect.

6
4. During operation, if any anomaly occurs, please stop using immediately.
5. During operation, have your protective gloves worn. Caution scald.
Routine Inspection
It is necessary to check the machine daily.
Check the machine regularly can avoid serious accident happens.
Stop using if user feels that there are some problems in the circuit or machine.
Check the situation of the machine before or after using every day.
Before using: Whether the machine is tilted?
Whether the control panel is damaged?
Whether the power cord is aging, cracking or damaged?
During using: Whether there is strange odor or vibration noise?
Whether the micro switch is in bad contact?
Whether the temperature is out of control or any electric leakage?
Cleaning and Maintenance
1. Before cleaning, cut off the power supply first to prevent unexpected accidents.
2. After working everyday, clean the inner tank, body surface and power cord with wet towel containing non-corrosive
detergent. Do not aim at the appliance with water jet directly. Water infiltration may damage the electric performance
and cause electricity safety accident.
3. If not going to use the appliance at any time, turn off the thermostats and power switch.
4. If not going to use the appliance for a long period of time, clean it completely and store it in a well-ventilated
warehouse without any corrosive gases.
Failure Analysis &Trouble Shooting
Aforementioned troubles are just for reference. If any failure occurs, please stop using, and inform the professional
technicians to check and repair.
ONE YEAR PARTS WARRANTY
LINKRICH warrants to the original purchaser of every new LINKRICH product, under normal and proper use and
maintenance service as specified by LINKRICH and upon proper installation and start-up in accordance with the instruction
packet supplied with each LINKRICH unit. LINKRICH’s obligation under this warranty is limited to a period of one (1) year
from the date of original installation.
WARRANTY CLAIMS
Symptoms
Causes
Solutions
Power is connected and heating indicator is
on, but the plate does not heat up.
1. The thermostat is defective.
2. At least one of the heating
elements burns out.
1. Replace the thermostat.
2. Replace the burnt-out heating
element.
Connect the power and rotate the thermostat,
the heating indicator illuminates, but
temperature keeps rising without control.
1. The thermostat is
malfunctioning.
1. Replace the thermostat.
Power is connected and heating is normal, but
the indicator is not on.
1. The indicator is defective.
1. Replace the indicator.
The indicator is not on and the appliance does
not heat up.
1. Power supply is abnormal
or power is disconnected.
2. The fuse is fused.
1. Check the power supply and
connection to make it supply normally.
2. Replace the fuse.

7
All claims for parts must be made directly through LINKRICH. All claims should include:
Personal Details: Products Details:
Your name Model number
Your company Serial number of the product
Address Date of purchase
Email Proof of purchase
Phone
Pertinent information supporting the existence of the alleged defect.(Such as picture etc.)
Please send the above information to [e-mail] or Fax to [phone]
Our warranty departments will according to the actual situation and reply you within
24hours.
What is not conected by this Warranty
Linkrich’s sole obligation under this warranty is limited to replacement of parts, Subject to the additional limitations below.
This warranty neither assumes nor authorizes any person to assume obligations other than those expressly covered by this
warranty. This warranty is limited to replacement of parts, and the shipment charge is not included.
No consequential damages. Linkrich is not responsible for Economic loss; or special, indirect, or consequential damages,
including without limitation, losses or damages arising from food or product spoilage claims whether or not account of
refrigeration failure.
Warranty is not transferable. This warranty is not assignable and applies only in favor the original purchaser/user to whom
delivered. Any such assignment or transfer shall avoid the warranties herein made and shall avoid all warranties, express or
implied, including any warranty of merchantability or fitness for a particular purpose.
Improper usage . Linkrich assumes no liability for parts or labor coverage for component failure or other damages resulting
from improper usage or installation or failure to clean and/or maintain product as set forth in the warranty packet provided
with the unit.
Residential applications: linkrich assumes no liability for parts or labor coverage for component failure or other damages
resulting from installation in non-commercial or residential applications.
Alteration, neglect, abuse, issue, accident, damage during transit or installation, fire, flood, acts of god. Linkrich is not
responsible for the repair or replacement of any parts that linkrich determines have been subjected after the date of
manufacture to alteration, neglect, abuse, accident, damage during transit or installation, fire, flood, or act of god.
Improper electrical connections. Linkrich is not responsible for the repair or replacement of failed or damaged components
resulting from electrical power failure, the use of extension cords, low voltage, or voltage drops to the unit.
No implied warranty of merchantability or fitness for a particular purpose: there are no other warranties, expressed, implied
or statutory, except the one (1) year parts warranty as described above. These warranties are exclusive and in lieu of all
other warranties, including implied warranty and merchantability or fitness for a particular purpose. These are no warranty
which extend beyond the description on the face hereof.
