Linksys WUSB11 ver. 2.6 Original operating instructions

A Division of Cisco Systems, Inc.
®
Model No.
Quick Installation for Windows XP
Model No.
Wireless
1
APower on your PC.
BThe Adapter comes with the
USB cable you will use to
connect the Adapter to your
PC.
Connect one end of then
included USB cable to the USB
port of the Adapter.
CConnect the other end of the
USB cable to one of the USB
ports on your computer.
The Power LED should light up
when the Adapter is plugged
in.
DRaise the antenna. Make sure
the antenna is positioned
straight up into the air, at a 90°
angle from the Adapter. This
will ensure optimum wireless
operating range and
performance.
After connecting the Adapter to your
computer, you will install the driver
and configure the Adapter.
AWindows XP will automatically
detect the Adapter. Insert the
Setup CD-ROM into your
computer’s CD-ROM drive.
Click the radio button next to
Install the software
automatically
(Recommended). Then click
Next.
BThe Hardware Installation
screen may appear and
indicate that the Adapter has
not passed Windows Logo
testing. This Adapter has been
tested and found to work with
Windows XP. Click Continue
Anyway to proceed with the
installation.
CWhen Windows has finished
installing the driver, click Finish.
Connect the Wireless-B USB
Network Adapter
WUSB11
USB Network Adapter
Package Contents
• Wireless-B USB Network Adapter
• USB Cable
• Wall Mount
• Setup CD-ROM with User Guide
• Quick Installation
• Registration Card
Wireless-B
GHz
2.4
802.11b
2Install the Driver
B
D
A
B
C

Model No.
CEnter the network’s WEP key in
the Network key field, and re-
enter it in the Confirm network
key field. Click Connect, and
go to step D.
DThe Zero Configuration icon will
indicate a wireless connection
when your connection is
active.
Congratulations! The installation of
the Wireless-B USB Network Adapter
is complete.
AThe Windows XP Wireless Zero
Configuration icon will appear
in your computer’s system tray.
Double-click the icon.
BThe screen that appears will
show any available wireless
network. Select the network you
want.
If your network uses a wireless
security feature called Wired
Equivalent Privacy (WEP)
encryption, go to
step C.
If this network does not have
WEP encryption enabled,
make sure the box next to
Allow me to connect to the
selected wireless network,
even though it is not secure is
checked. Click Connect, and
go to step D.
For additional information or troubleshooting
help, refer to the User Guide on the Setup CD-
ROM. You can also call or e-mail for further
support.
24-hour Technical Support
800-326-7114
(toll-free from US or Canada)
E-mail Support
[email protected]
Website
http://www.linksys.com or
http://support.linksys.com
RMA (Return Merchandise Authorization)
http://www.linksys.com/support
FTP Site
ftp://ftp.linksys.com
Sales Information
800-546-5797 (800-LINKSYS)
A Division of Cisco Systems, Inc.
®
Linksys is a registered trademark or trademark of
Cisco Systems, Inc. and/or its affiliates in the U.S.
and certain other countries. Copyright © 2004
Cisco Systems, Inc. All rights reserved.
WUSB11_V4-XP_QI-40712NC JL
3Configure the Wireless-B USB
Network Adapters
C
B
A
D
