Linksys WGA11B Original operating instructions

A. Plug the included Ethernet network cable into the Game Adapter’s LAN port.
B. Plug the other end of the Ethernet network cable into your game console’s RJ-45 port.
C. Verify that the Game Adapter’s crossover (X - II) switch is set appropriately. If the Game Adapter is not trans-
mitting or receiving data appropriately, try flipping the switch to its other setting.
D. Plug the supplied power cable into the Game Adapter’s Power port. Then, plug the other end into an electrical
outlet, preferably a surge protector.
E. Start your game console.
The Game Adapter can be set up by holding down the Channel Selector button until it flashes and then clicking the button
to cycle to the appropriate setting on the LED display, as shown.
When playing Head-to-Head: Set both Game Adapters to the same channel, 1-11.
When playing over the Internet: Set the Game Adapter to IN when using a simple wire-
less network with no WEP encryption settings and
SSID enabled.
Connecting the Game Adapter
A
D
Setting Up the Game Adapter
WWW.LINKSYS.COM
QI-wga11b-30609NC KL
For additional information or troubleshooting help, refer to the User Guide on the Setup CD-ROM.
You can also call or email for further support.
24-hour Technical Support 800-326-7114 (toll-free from US or Canada)
E-mail Support [email protected]
Website http://www.linksys.com or http://support.linksys.com
FTP Site ftp://ftp.linksys.com
