Linksys WUSBF54G Operation manual

Model No.
Product Data
Wireless
WUSBF54G
All-in-One USB Network Adapter and Wi-Fi Finder
High-speed Wireless-
G networking for your
desktop or notebook
computer
Wireless communications
are protected by up to
128-bit WEP or WPA
encryption
Built-in Wi-Fi Finder
detects Wireless-G
and Wireless-B signals
Easy to read display
shows network name,
channel, signal strength,
and security on/off
The Wireless-G USB Adapter with Wi-Fi Finder is a handy, pocket-sized device that combines an easy-to-
use wireless network scanner with a USB-connected Wireless-G network adapter. Now you can scan for
available wireless connectivity before turning on your computer. If the scanner does find a network, just
plug it into your PC and get connected.
The Wi-Fi Finder detects Wireless-G and Wireless-B networks with a simple push of a button. It displays all
pertinent information such as the wireless network's name (SSID), signal strength, the channel used, and
whether wireless security is enabled or not. The information is displayed on an easy-to-read LCD display
and can be set up to look for only open networks, all networks, or a specific named network. Discovered
networks are listed in order of signal strength.
The advanced wireless search technology filters out 2.4GHz interference given off by microwave ovens,
cordless phones, and Bluetooth devices to provide readouts only on working Wireless-G or -B networks.
With the Wi-Fi Finder built into the unit, you no longer need to power on your PC to determine if there's a
wireless network connection available.
Public wireless hotspots are springing up all over in coffee shops, airport lounges, hotels and convention
centers. The Wireless-G USB Adapter with Wi-Fi Finder from Linksys makes it easy to find, and connect to,
those hotspots.
USB Network Adapter with Wi-Fi Finder
Wireless-G

Model No.
Product Data
Model No.
Linksys
A Division of Cisco Systems, Inc.
18582 Teller Avenue
Irvine, CA 92612 USA
E-mail: [email protected]
[email protected]
Web: http://www.linksys.com
Linksys products are available in more than 50
countries, supported by 12 Linksys Regional Offices
throughout the world. For a complete list of local
Linksys Sales and Technical Support contacts, visit
our Worldwide Web Site at www.linksys.com.
WUSBF54G
Package Contents
• Wireless-G USB Network Adapter with
Wi-Fi Finder
• Setup Wizard CD-ROM
•UserGuideonCD-ROM
• Quick Installation
Wireless-G
Minimum Requirements
• PC with 400MHz or Faster Process
• 128MB RAM Memory
• CD-ROM Drive
• Available USB Port
• Windows 98SE, Me, 2000 or XP with
Service Pack 1 (or later)
Specifications
Model Number WUSBF54G
Standards IEEE 802.11b, IEEE 802.11g, USB 1.1, USB2.0
Channels 11 Channels (US, Canada)
13 Channels (Europe)
14 Channels (Japan)
LEDs Power, Link
Transmitted Power 18dBm (Typical)@11Mbps, 16dBm (Typical)@54Mbps
Receive Sensitivity -84dBm (Typical)@11Mbps, -73dBm (Typical)@54Mbps
Power Consumption Active: TX 380mA (Max.) & RX 200mA (Max.)
Battery Built-in rechargeable Li-ion Polymer battery
Security features WEP Encryption, WPA Security
Environmental
Dimensions 3.78" x 0.63" x 1.14"
W x H x D (96 mm x 16 mm x 29 mm)
Unit Weight 0.81 oz. (0.023 kg)
Certifications FCC, Wi-Fi
Operating Temp. 32ºF to 104F (0ºC to 40ºC)
Storage Temp. -4ºF to 158ºF (-20ºC to 70ºC)
Operating Humidity 0% to 70% Non-Condensing
Storage Humidity 10% to 90% Non-Condensing
Warranty Hardware: Three-Year Limited Warranty
Battery: One-Year Limited Warranty
WUSBF54G-DS-51011A BW
Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2005
Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders.
USB Network Adapter with Wi-Fi Finder
Features
• Built-in Wi-Fi Finder detects
available wireless networks
without turning on your PC
• Built-in rechargeable Lithium
battery
• Compatible with 802.11g
and 802.11b (2.4GHz) Stan-
dards
• Supports USB 2.0 with up to
54Mbps, High-Speed Data
Transfer Rate with Automatic
Fallback
• Supports up to 128-bit WEP
Encryption and WPA Security
• Plug-and-Play Operation Pro-
vides Easy Setup
• Compatible with Microsoft
Windows 98SE, Me, 2000, and
XP
