Linksys LNE100M User manual

EtherFast®10/100
Managed Network
Adapter
his powerful auto-negotiating 10/100 Mbps Ethernet
interfacecardfeaturesnetworkmanagementfunctionsto
save you time and hassle. Configure, check error rates,
and keep an inventory of your network resources from one cen-
tralized location.
The Wake-On-LAN function remotely "wakes up" any PC on the
network, so you can handle maintenance chores during off-
hours. The 802.1Q support lets you optimize your network traf-
fic by dividing the network into smaller Virtual LANs, while
packet delivery is prioritized using 802.1P signaling.
• Easy to Use Plug-and-Play 10/100 PCI Network Adapter
• Adapter settings can be managed via SNMP using stan-
dard MIB browser
• Full Duplex Capability at Up To 200Mbps
• Connects to Both 10Mbps Ethernet and 100Mpbs Fast
Ethernet Networks
• Power On your PC from anywhere on the network with
Wake-On-LAN Management
• Complete 802.1Q VLAN support for use in segmented
networks
• Support for IP Checksum offloading built-into the adapter
driver
• 802.1p tagging support for Quality of Service (QoS)
• Configuration utility allows for complete management of
the network adapter settings
EtherFast®10/100 Managed Network Adapter
Model No.: LNE100M
Manage your network without running from
desk to desk
Features
Features
Benefits
Benefits
• 10/100 Auto-negotiating Ethernet interface,
with SNMP-based management
• Configure and monitor your network from one
centralized location
• Power-on any PC from anywhere on the net-
work with Wake-On-LAN support
• Optimize your network traffic with 802.1Q
VLAN support and 802.1p traffic prioritization
Instant EtherFast®Series
T

Package ContentsSpecifications
Model No: LNE100M
Standards IEEE 802.3, IEEE 802.3u, PCI 2.2,ACPI
Ports: 1 RJ-45 Port
Cabling Type Category 5 Ethernet Cable
LEDs 100, Collision, FDX, Link/Act
Environmental
Dimensions 7.3 x 6” x 1.8” (186mm x 154mm x 48 mm)
Unit Weight 2.4 oz. (.07 kg)
Power 5W Maximum
Certifications FCC Class B, CE Class B,VCCI Class B
Operating Temp 32ºF to 122ºF (0ºC to 50ºC)
Storage Temp -40ºF to 158ºF (-40ºC to 70ºC)
Operating Humidity 20% to 95%, Non-Condensing
Storage Humidity 20% to 95%, Non-Condensing
EtherFast®10/100 Managed Network
Adapter
• One EtherFast 10/100 Managed Network
Adapter
• One Installation CD
• One Quick Installation Guide
• One User Guide included on the Installation
CD
• One Registration Card
• 200Mhz or Faster Processor
• Available PCI 2.2 Slot
• CD-ROM Drive
• Windows 98/Me/NT 4.0/2000/XP
Minumum Requirements
DS-LNE100M-090402NC KL
