Instant EtherFastIITM
10/100 Switches
ith its advanced switching technology, the
new Instant EtherFast IITM 10/100 Switches
boost your network performance with much
more than just full duplex data transfer and dedicated
bandwidth. Its non-blocking, maximum wire speed
ensures optimal internal processing, while data flow
control filters out faulty packets and address learning
and aging prevents data transfer errors. Plus your
growing network can link to switches up to 2000
meters (6560 feet) away in full duplex mode, simply by
plugging a fiber module into your Switch’s expansion
port!
No matter how intensive your network demands, the
Instant EtherFast IITM Switches’ advanced chipset sup-
ports your needs with an affordable and efficient net-
working solution you can count on. Rack mountable
and equipped with an uplink button and fiber module
port, the Instant EtherFast IITM Switches will enhance
and expand your network productivity in countless
ways.
•16 and 24-Port 10/100 Full Duplex,Autosensing Ports
•Run Blazing Speeds of up to 200Mbps at Full Duplex
•Perfect for Running 10BaseT, 100BaseTX and
100BaseFX Hardware Together Seamlessly
•Optional 100BaseFX Fiber Optic Module Sends Data Up
to 2000 Meters (6560 feet) Away in Full Duplex Mode
•Data Flow Control Filters Out Faulty Data Packets
•Address Learning and Aging Prioritizes Packet Delivery
•CAM-based MAC Table Support Prevents Data Transfer
Errors
•Internal Bandwidth of 2.7Gbps
•Advanced Store-and-Forward Data Packet Switching
•Works with Virtually All Major Network Operating
Systems
•Optional Rack Mounting for Convenient Storage
•VLSI Components Support Hardware Reliability
•FreeTechnical Support—24 Hours a Day,7 Days aWeek
for North America Only
•5-Year Limited Warranty
Instant EtherFast IITM 10/100 16-Port Switch (EF2S16 v2)
Instant EtherFast IITM 10/100 24-Port Switch (EF2S24 v2)
Fiber Modules:
EtherFast IITM Switch 100BaseFX SC Module (EF2SSC)
EtherFast IITM Switch 100BaseFX ST Module (EF2SST)
W
Advanced Switching Technology Arrives with
Data Flow Control and Fiber Expandability
Features
Features
Benefits
Benefits
• 10/100 Autosensing Ports Run 10BaseT &
100BaseTX Hardware Together Seamlessly
• Run Blazing Speeds of 200Mbps in Full Duplex
Mode
• Optional 100BaseFX Fiber Module Gives You
Maximum Expandability
• Address Learning and Aging Prioritizes Packet
Delivery
• Data Flow Control Filters Out Packet Errors
• Free Technical Support—24 Hours a Day, 7
Days a Week for North America Only
• 5-Year Limited Warranty
DDaattaaFFlloowwCCoonnttrrooll&&
FFiibbeerrEExxppaannddaabbiilliittyy

DS-EF2S16 v2_24-01218A KL
Specifications
Model Numbers EF2S16 v2, EF2S24 v2
Standards IEEE 802.3 and IEEE 802.3u
Protocol CSMA/CD
Ports 16 or 24 10/100 RJ-45 Ports
Button MDI/MDIX
Expansion Slot One Expansion Slot for a 100BaseFX Fiber
Module (Independent Port)
Speed Per Port 10 or 100 (Half Duplex)
(Mbps) 20 or 200 (Full Duplex)
MAC Addresses 8k (EF2S16 v2), 4k (EF2S24 v2)
Max Frame Size 1522 Bytes
Buffer Memory 512kb (EF2S16 v2), 768kb (EF2S24 v2)
Cabling Type UTP Category 5 or Better
LEDs Power, FX,
FDX/Col (per Port),
Link/Act (per Port)
Environmental
Dimensions 17.3” x 7.3” x 1.7”
Unit Weight 4.6 lbs. (EF2S16)
4.8 lbs. (EF2S24)
Power Input 100-260V AC, 50-60Hz
Power Consumption 25 watts
Certifications FCC Class A,
CE Mark Commercial
Operating Temp. 0ºC to 40ºC (32ºF to 104ºF)
Storage Temp. -20ºC to 70ºC (-4ºF to 158ºF)
Operating Humidity 10% to 85%, Non-Condensing
Storage Humidity 5% to 90%, Non-Condensing
Package Contents
Optional
• EtherFast IITM Switch
100BaseFX SC Module
(Model Number: EF2SSC)
• EtherFast IITM Switch
100BaseFX ST Module
(Model Number: EF2SST)
Instant EtherFast IITM 10/100 Switches
• One 10/100 16 or 24-Port Switch
• Mounting Brackets & Bracket Screws
• One Power Cord
• User Guide and Registration Card
(Model No.: EF2S16 v2, EF2S24 v2)
