Linksys 901 Manual

Linksys IP Phones
Admin Guide
Schmooze Com Inc.
901, 92X, 94X and 962
1
#
*0
2
ABC 3
DEF
6
MNO
4
GHI 5
JKL
7
PQRS 8
TUV 9
WXYZ
redial dnd
cfwd
dir
l1
b1
IP PHONE SPA921

How To Find IP Address
Quick Steps
1.Select the menu button.
2.Scroll down to Network and press the Select softkey.
3.Scroll down and you will see the IP Address.
How To Find MAC Address
Quick Steps
1.Select the menu button.
2.Scroll down to Product Info and press the Select softkey.
© Copyright Schmooze Com, 2012
3.Scroll down and you will see the MAC address.
How To Set the Configuration Server
Quick Steps
1.Find the IP Address of the device and open a web browser to the IP address of the phone.
2.Login with the phone user password.
3.Click on the Admin option at the top and login with the admin user
select cancel
9 Network
10 Product Info
11 Status
12 Reboot
Setup
cancel
1 WANConnection Type
DHCP
2 Current IP
10.4.0.165
Network
4.Click on the Advanced option at the top
5.Click on Provisioning tab at the top
6.Define the Profile Rule to your PBX. Generally this would be tftp://IPADDRESS/spa$MA.xml
such as tftp://10.10.0.1/spa$MA.xml in our example and press the Save button at the bottom.
How To Factory Default
Quick Steps
1.Select the menu button.
2.Scroll down to Factory Reset and press the Select softkey.

How To Find IP Address
Quick Steps
1.Select the menu button.
2.Scroll down to Network and press the Select softkey.
3.Scroll down and you will see the IP Address.
How To Find MAC Address
Quick Steps
1.Select the menu button.
2.Scroll down to Product Info and press the Select softkey.
3.Scroll down and you will see the MAC address.
How To Set the Configuration Server
Quick Steps
1.Find the IP Address of the device and open a web browser to the IP address of the phone.
2.Login with the phone user password.
3.Click on the Admin option at the top and login with the admin user
© Copyright Schmooze Com, 2012
select cancel
9 Network
10 Product Info
11 Status
12 Reboot
Setup
cancel
1 MAC Address
XXXXXXXXXXXX
2 Client Cert
Installed
Product Info
The server 10.4.0.168:80 requires a username and
password. The server says: spa admin.
User Name:
Password:
Cancel Log In
admin
••••••
4.Click on the Advanced option at the top
5.Click on Provisioning tab at the top
6.Define the Profile Rule to your PBX. Generally this would be tftp://IPADDRESS/spa$MA.xml
such as tftp://10.10.0.1/spa$MA.xml in our example and press the Save button at the bottom.
How To Factory Default
Quick Steps
1.Select the menu button.
2.Scroll down to Factory Reset and press the Select softkey.

How To Find IP Address
Quick Steps
1.Select the menu button.
2.Scroll down to Network and press the Select softkey.
3.Scroll down and you will see the IP Address.
How To Find MAC Address
Quick Steps
1.Select the menu button.
2.Scroll down to Product Info and press the Select softkey.
3.Scroll down and you will see the MAC address.
How To Set the Configuration Server
Quick Steps
1.Find the IP Address of the device and open a web browser to the IP address of the phone.
2.Login with the phone user password.
3.Click on the Admin option at the top and login with the admin user
4.Click on the Advanced option at the top
5.Click on Provisioning tab at the top
6.Define the Profile Rule to your PBX. Generally this would be tftp://IPADDRESS/spa$MA.xml
such as tftp://10.10.0.1/spa$MA.xml in our example and press the Save button at the bottom.
© Copyright Schmooze Com, 2012
How To Factory Default
Quick Steps
1.Select the menu button.
2.Scroll down to Factory Reset and press the Select softkey.
Linksys Telephone Configuration
System Phone User
User Login Admin | advanced
Personal Directory Call History
Info
System Information
Provision Enable: Resync On Reset:
Resync Random Delay: Resync Periodic:
Resync Error Retry Delay: Forced Resync Delay:
Resync from SIP: Resync After Upgrade Attempt:
Resync Trigger 1:
Resync Trigger 2:
Resync Fails On FNF:
Profile Rule:
yes
yes
yes
yes
2
3600
86400
14400
tftp://10.10.0.1.spa$MA.xml
Regional Phone Ext 1 Ext 2 Ext 3 Ext 4 User
Linksys Telephone Configuration
System SIP
User Login basic | advanced
Personal Directory Call History
Info
System Information
Provision Enable: Resync On Reset:
Resync Random Delay: Resync Periodic:
Resync Error Retry Delay: Forced Resync Delay:
Resync from SIP: Resync After Upgrade Attempt:
Resync Trigger 1:
Resync Trigger 2:
Resync Fails On FNF:
Profile Rule:
yes
yes
yes
yes
2
3600
86400
14400
tftp://10.10.0.1.spa$MA.xml
Linksys Telephone Configuration
Info System SIP Regional Phone Ext 1 Ext 2 Ext 3 Ext 4 User
User Login basic | advanced
Personal Directory Call History
Provisioning
Configuration Profile
Provision Enable: Resync On Reset:
Resync Random Delay: Resync Periodic:
Resync Error Retry Delay: Forced Resync Delay:
Resync from SIP: Resync After Upgrade Attempt:
Resync Trigger 1:
Resync Trigger 2:
Resync Fails On FNF:
Profile Rule:
yes
yes
yes
yes
2
3600
86400
14400
tftp://10.10.0.1.spa$MA.xml

How To Find IP Address
Quick Steps
1.Select the menu button.
2.Scroll down to Network and press the Select softkey.
3.Scroll down and you will see the IP Address.
How To Find MAC Address
Quick Steps
1.Select the menu button.
2.Scroll down to Product Info and press the Select softkey.
3.Scroll down and you will see the MAC address.
How To Set the Configuration Server
Quick Steps
1.Find the IP Address of the device and open a web browser to the IP address of the phone.
2.Login with the phone user password.
3.Click on the Admin option at the top and login with the admin user
4.Click on the Advanced option at the top
5.Click on Provisioning tab at the top
6.Define the Profile Rule to your PBX. Generally this would be tftp://IPADDRESS/spa$MA.xml
such as tftp://10.10.0.1/spa$MA.xml in our example and press the Save button at the bottom.
How To Factory Default
Quick Steps
1.Select the menu button.
2.Scroll down to Factory Reset and press the Select softkey.
© Copyright Schmooze Com, 2012
select cancel
9 Restart
10 Factory Reset
11 Custom Reset
12 SetPassword
Setup

VOICE MAIL
LINE 1
LINE 2
LINE 3
LINE 4
Schmooze Com Inc.
http://schmoozecom.com
