DATA SHEET
SVR200
Model No.
Wireless-G ADSL/Ethernet Services Router with 4-
Port PoE Switch
and 1 FXS +
1 FXO
Linksys One is a
complete, affordable,
easy-to-install
communications solution
for growing businesses
that delivers telephones,
data networking,
applications, and the
Internet through one
high-speed connection
from a single provider. Business-class
communications services are delivered
by a Linksys One Services Router, which
requires only one internet connection for all service, including low-cost phone service. The Linksys One Services
Router is the core for your network and is present in all Linksys One solutions.
Linksys One Service Routers are easy and cost-effective to install, manage and expand. You are not required
to have specialized technical expertise. Linksys One technology is automatic and self-configuring – plug in a
Linksys One phone or other device to the Services Router and your business is ready to communicate. The
Linksys One Communications Solution enables a high-speed office network and phone service to be up and
running in very little time. The Linksys One SVR200 Services Router has on-board software that integrates
security, reliability and quality of service to support business-quality Linksys One communications services.
The SVR200 delivers 4 ports of fast Ethernet LAN switching with full support for IEEE 802.3af Power over
Ethernet on each port (three at one time) with a power budget of ~60 watts. All Linksys One IP phones and voice
gateways can be fully powered over these ports without a separate power adapter. The SVR200 has one
ADSL2/ADSL2+ WAN interface and one 10/100 WAN port to provide access to the Internet either directly or
through a separate broadband router or bridge device.
The SVR200 is the ideal network infrastructure "office-in-a-box" solution for remote SOHO teleworkers or small
offices because it integrates an 802.11g access point, FXS/FXO ports*, integrated broadband access
interfaces, Power over Ethernet, and an SPI Firewall with hardware-accelerated VPN services. The SVR200
enables an easier, more complete business communications solution that’s far more affordable for smaller
offices.
*United States only for CPE Software Release 1.3
Integrated ADSL2/
ADSL2+ with 10/100
Ethernet WAN options
for flexible deployment
SPI Firewall, wireless
security, and hardware-
accelerated VPN
support makes your
network secure
Broadcast SSIDs and
VLANs provide
separate secure
networks
Provides auto-discovery,
remote management,
and auto configuration
of Linksys One devices
Wireless-G ADSL/Ethernet Services
Router
Advanced QoS support
for real-time
applications, including
802.1p, DiffServ, &
traffic shaping

©2007 Cisco Systems, Inc. All rights reserved. Linksys is a registered trademark and the Linksys One logo is a trademark of Cisco Systems, Inc.
• Integrated ADSL2/ADSL2+ and 10/100 Ethernet WAN interfaces
• Four-port 10/100 Ethernet switch with 802.1q (VLAN) and 802.3af (Power over Ethernet)
• Supports SSID mapping to a specific data VLAN to create separate, secured networks
• 802.11g supports data rates up to 54 Mbps
• SPI firewall with DNS and DHCP proxy support
•SSLsupportforVPN
• Fanless passive-cooling design for virtually silent operation
Features
Linksys One-DS-7030910NC-KO
Model
Memory
CPU
Operating System
Standards
Ports
Buttons
Cabling Type
LEDs
Antennae
Security features:
Wireless
IP
SVR200
256 MB SDRAM & 512 MB Internal Flash
Broadcom 6358, 300MHz
Linux
IEEE 802.1p, 802.1q, 802.1x, 802.11b, 802.11g, 802.3, 802.3af
ADSL2/ADSL2+ (Annex A)
Ethernet
FXS*
FXO*
Antenna
Power
Reset and system on/off
Cat5, ADSL, FXS, FXO (RJ-11)
Power, DMZ, Wireless, Internet, LAN 1-4
Two omni-directional, removable, WMM. 802.11e-ready
WEP 64bit/128bit
802.1x - Radius (MD5, SHA1, TLS, TTLS, PEAP) dynamically-varying encryption keys
ACL capability
SPI firewall
IPSec NAT-T
3DES/AES encryption
MD5/SHA1 authentication
*United States only for CPE Software Release 1.3
Specifications

©2007 Cisco Systems, Inc. All rights reserved. Linksys is a registered trademark and the Linksys One logo is a trademark of Cisco Systems, Inc.
Package Contents
• Wireless-G ADSL2+ VPN router with 2 Removable Antennae
• Cables (5): Ethernet, RJ-11
• Power adaptor
•CD
• Quick Installation Guide
Linksys
A Division of Cisco Systems, Inc.
18582 Teller Avenue
Irvine, CA 92612 USA
E-mail: [email protected]
[e-mail]
Web: http://www.linksysone.com
Specifications are subject to change without notice.
Linksys One-DS-7030910NC-KO
Dimensions
Unit Weight
Power
Certification
Operating Temp.
Storage Temp.
Operating Humidity
Storage Humidity
12.1" x 7.08" x 1.73" (308 mm x 180 mm x 44 mm)
3.03 lbs. (1.376 kg)
External power adaptor: 100-240VAC/50-60 Hz universal input, 48V DC output
FCC/IC (USA/Canada) EMI: Part 15B/ICES-003
FCC (USA) Telecom, Part 68; Wireless, Part 15C
IC (Canada) Telecom, CS-03; Wireless, RSS-210
UL/cUL (USA/Canada) Safety: UL 60950-1
CE (Europe) EMI EN 55022, EN 55024, EN 60950-1
CE (Europe) Telecom, TBR21; Wireless, EN 301 489-17, EN300 328-2
Frequency Authority for 28 Country
C-tick (Australia and New Zealand) AS/NZS CISPR22
CB (worldwide) IEC6090-1
CE mark
32º F to 104º F (0º C to 40º C)
-4º F to 158º F (-20º C to 70º C)
10% to 90% non-condensing
5% to 95% non-condensing
Environmental
