Linksys WRT54GP2A-AT - Wireless-G Broadband Router... User manual

A Division of Cisco Systems, Inc.
®
Model No.
Broadband Router
Wireless-G
WRT54GP2A-AT
User Guide
WIRELESS
GHz
2.4
802.11g
with 2 Phone Ports

Wireless-G Broadband Router with 2 Phone Ports
Copyright and Trademarks
Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco
Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2004 Cisco Systems, Inc. All
rights reserved. Other brands and product names are trademarks or registered trademarks of their respective
holders.
How to Use this Guide
Your guide to the Wireless-G Broadband Router with 2 Phone Ports has been designed to make understanding
networking with the Router easier than ever. Look for the following items when reading this User Guide:
In addition to these symbols, there are definitions for technical terms that are presented like this:
Also, each figure (diagram, screenshot, or other image) is provided with a figure number and description, like
this:
Figure numbers and descriptions can also be found in the “List of Figures” section.
This exclamation point means there is a caution or
warning and is something that could damage your
property or the Router.
word: definition.
This checkmark means there is a note of interest and
is something you should pay special attention to while
using the Router.
This question mark provides you with a reminder about
something you might need to do while using the Router.
Figure 0-1: Sample Figure Description
WRT54GP2A-AT-UG-40907A JL
WARNING: This product contains chemicals, including lead, known
to the State of California to cause cancer, and birth defects or other
reproductive harm. Wash hands after handling.

Wireless-G Broadband Router with 2 Phone Ports
Table of Contents
Chapter 1: Introduction 1
Welcome 1
What’s in this Guide? 2
Chapter 2: Planning Your Wireless Network 4
Network Topology 4
Ad-Hoc versus Infrastructure Mode 4
Network Layout 5
Chapter 3: Getting to Know the Router 6
The Back Panel 6
The Front Panel 7
Chapter 4: Connecting the Router 8
Overview 8
Connecting the Router to Your Broadband Modem 8
Connecting One Router to Another 9
Chapter 5: Configuring the Router 11
Overview 11
How to Access the Web-based Utility 13
The Setup Tab - Basic Setup 13
The Setup Tab - DDNS 18
The Setup Tab - MAC Address Clone 19
The Wireless Tab - Basic Wireless Settings 20
The Wireless Tab - Wireless Security 21
The Wireless Tab - Wireless MAC Filter 23
The Wireless Tab - Advanced Wireless Settings 24
The Security Tab - Firewall 25
The Security Tab - VPN 26
The Access Restrictions Tab - Internet Access 27
The Applications & Gaming Tab - Port Range Forward 29
The Applications & Gaming Tab - Port Trigger 30
The Applications & Gaming Tab - UPnP Forward 31
The Applications & Gaming Tab - DMZ 33
The Administration Tab - Management 34

Wireless-G Broadband Router with 2 Phone Ports
The Administration Tab - Log 36
The Administration Tab - Diagnostics 37
The Administration Tab - Factory Defaults 38
The Administration Tab - Backup and Restore 39
The Administration Tab - Reboot 39
The Status Tab - Router 40
The Status Tab - Local Network 41
The Status Tab - Wireless 42
The Status Tab - Voice 43
Chapter 6: Signing up for AT&T CallVantagesm Service 44
Overview 44
Instructions 44
Appendix A: Troubleshooting 45
Common Problems and Solutions 45
Frequently Asked Questions 55
Appendix B: Wireless Security 59
Security Precautions 59
Security Threats Facing Wireless Networks 59
Appendix C: Windows Help 62
Appendix D: Finding the MAC Address and IP Address for Your
Ethernet Adapter 63
Windows 98 or Me Instructions 63
Windows 2000 or XP Instructions 63
For the Router’s Web-based Utility 64
Appendix E: Glossary 65
Appendix F: Specifications 72
Appendix G: Warranty Information 74
Appendix H: Regulatory Information 75
Appendix I: Contact Information 77
AT&T 77
Linksys 77

Wireless-G Broadband Router with 2 Phone Ports
List of Figures
Figure 3-1: Back Panel 6
Figure 3-2: Front Panel 7
Figure 4-1: Connect the Broadband Modem 8
Figure 4-2: Connect a Telephone 8
Figure 4-3: Connect a PC 8
Figure 4-4: Connect the Power 8
Figure 4-5: Router Connected to Another Router 9
Figure 4-6: Connect the Broadband Modem 10
Figure 4-7: Connect a Telephone 10
Figure 4-8: Connect the Other Router 10
Figure 4-9: Connect the Power 10
Figure 5-1: Router’s IP Address 13
Figure 5-2: Router Login 13
Figure 5-3: Setup Tab - Basic Setup - Automatic Configuration (DHCP) 13
Figure 5-4: Static IP 14
Figure 5-5: PPPoE 14
Figure 5-6: PPTP 15
Figure 5-7: Setup Tab - DDNS (DynDNS.org) 18
Figure 5-8: Setup Tab - DDNS (TZO.com) 18
Figure 5-9: Setup Tab - MAC Address Clone 19
Figure 5-10: Wireless Tab - Basic Wireless Settings 20
Figure 5-11: Wireless Tab - Wireless Security (WPA Pre-Shared Key) 21
Figure 5-12: Wireless Tab - Wireless Security (WPA RADIUS) 21
Figure 5-13: Wireless Tab - Wireless Security (RADIUS) 22
Figure 5-14: Wireless Tab - Wireless Security (WPA RADIUS) 22
Figure 5-15: Wireless Tab - Wireless MAC Filter 23
Figure 5-16: MAC Address Filter List 23
Figure 5-17: Wireless Client MAC List 23

Wireless-G Broadband Router with 2 Phone Ports
Figure 5-18: Wireless Tab - Advanced Wireless Settings 24
Figure 5-19: Security Tab - Firewall 25
Figure 5-20: Security Tab - VPN 26
Figure 5-21: Access Restrictions Tab - Internet Access 27
Figure 5-22: Internet Policy Summary 27
Figure 5-23: List of PCs 28
Figure 5-24: Applications & Gaming Tab - Port Range Forward 29
Figure 5-25: Applications & Gaming Tab - Port Trigger 30
Figure 5-26: Applications & Gaming Tab - UPnP Forward 31
Figure 5-27: Applications & Gaming Tab - DMZ 33
Figure 5-28: Administration Tab - Management 34
Figure 5-29: Administration Tab - Log 36
Figure 5-30: Administration Tab - Diagnostics 37
Figure 5-31: Ping Test 37
Figure 5-32: Traceroute Test 37
Figure 5-33: Administration Tab - Factory Defaults 38
Figure 5-34: Administration Tab - Backup and Restore 39
Figure 5-35: Administration Tab - Reboot 39
Figure 5-36: Status Tab - Router 40
Figure 5-37: Status Tab - Local Network 41
Figure 5-38: DHCP Clients Table 41
Figure 5-39: Status Tab - Wireless 42
Figure 5-40: Wireless Client MAC List 42
Figure 5-41: Status Tab - Voice 43
Figure 6-1: Website for AT&T CallVantage Service 44
Figure D-1: IP Configuration Screen 63
Figure D-2: MAC Address/Adapter Address 63
Figure D-3: MAC Address/Physical Address 64
Figure D-4: Access Restrictions - MAC and IP Addresses 64
Figure D-5: MAC Address Clone 64

1
Chapter 1: Introduction
Welcome
Wireless-G Broadband Router with 2 Phone Ports
Chapter 1: Introduction
Welcome
Thank you for choosing the Wireless-G Broadband Router with 2 Phone Ports. This Router can direct and control
communications for your wiredand wireless networks, sharing Internet access, files andfun, easily and securely.
Plus, after you have set up your Internet phone service, make phone or fax calls using your Internet connection.
How does the Router do all of this? A router is a device that allows access to an Internet connection over a
network. With the Wireless-G Broadband Router, this accesscan be shared over the four switched ports or via the
wireless broadcast at either up to 11Mbps for Wireless-B or up to 54Mbps for Wireless-G. In addition, the WPA
standard provides greater security opportunities while the whole network is protected through NAT technology.
Full configurability, including these security features, are accessed through the easy-to-use, web-based utility.
But what does all of this mean?
Networks are useful tools for sharing Internet access and computer resources. Multiple computers can share
Internet access, so you don’t need more than one high-speed Internet connection. After you set up your Internet
phoneservice, you canalso make Internet phone or fax calls,even while you’resurfingtheInternet. Plus, youcan
accessoneprinter from different computers andaccessdatalocated on another computer’sharddrive.Networks
are even used for playing multiplayer video games. All the while, the Router protects your networks from
unauthorized and unwelcome users. So, networks not only are useful in homes and offices, but also can be fun.
PCs on a wired network create a LAN, or Local Area Network. They are connected with Ethernet cables, which is
why the network is called “wired”.
PCs equipped with wireless cards or adapters can communicate without cumbersome cables. By sharing the
same wireless settings, within their transmission radius, they form a wireless network, which is sometimes
calleda Wireless Local Area Network(WLAN).The Router bridges wirelessnetworks of both 802.11band 802.11g
standards and wired networks, allowing them to communicate with each other.
To create your network, install and set up the Router. To guide you through the process, Linksys strongly
recommends that you runthe SetupWizard onthe Setup CD-ROM.Ifyoupreferto manually setup the Router, use
the instructions in the Quick Installation or this User Guide to help you. These instructions should be all you need
to get the most out of the Wireless-G Broadband Router.
ethernet: an IEEE standard network protocol that
specifies how data is placed on and retrieved from
a common transmission medium
lan (local area network): the computers and
networkingproductsthatmakeupthenetwork
in your home or office
802.11b: an IEEE wireless networking standard
that specifies a maximum data transfer rate of
11Mbps and an operating frequency of 2.4GHz
802.11g: an IEEE wireless networking standard
that specifies a maximum data transfer rate of
54Mbps, an operating frequency of 2.4GHz, and
backward compatibility with 802.11b devices
browser: an application program that
provides a way to look at and interact with all
the information on the World Wide Web
mbps:onemillionbitspersecond;aunitof
measurement for data transmission
nat (network address translation): NAT
technology translated IP addresses of a
local area network to a different IP address
for the Internet
wpa (wi-fi protected access): a wireless
security protocol using TKIP (Temporal Key
IntegrityProtocol)encryption,whichcanbe
used in conjunction with a RADIUS server
NOTE: If you want to sign up for Internet phone service or activate your account, visit
http://www.att.com/linksys after you have installed and configured the Router. Refer to
“Chapter 6: Signing up for AT&T CallVantagesm Service” for more information.

2
Chapter 1: Introduction
What’s in this Guide?
Wireless-G Broadband Router with 2 Phone Ports
What’s in this Guide?
This user guide covers the basic steps for setting up a network with a router. After going through “Chapter 3:
Getting to Know the Router,” most users will only need to use the following chapters:
• Chapter 4: Connecting the Router
This chapter instructs you on how to connect the Router to your cable or DSL modem and PCs. After you
create your network, then you will connect the telephones (or fax machines) to AT&T CallVantagesm Service
via the Router.
• Chapter 5: Configuring the Router
This chapter explains how to configure the Router using your web browser and the Router’s Web-based
Utility. You will configure the Router using the settings provided by your ISP.
• Chapter 6: Signing up for AT&T CallVantagesm Service
When you are ready to sign up for or activate your AT&T CallVantage Service account, refer to the instructions
in this chapter.
When you’re finished with the basic steps, then you are ready to connect to the Internet.
You also have other chapter available for reference:
• Chapter 1: Introduction
This chapter describes the Router’s applications and this User Guide.
• Chapter 2: Planning Your Wireless Network
This chapter describes the basics of wireless networking.
• Appendix A: Troubleshooting
This appendix describes some possible problems and solutions, as well as frequently asked questions,
regarding installation and use of the Router.
• Appendix B: Wireless Security
This appendix explains the risks of wireless networking and some solutions to reduce the risks.
• Appendix C: Windows Help
This appendix describes how you can use Windows Help for instructions about networking, such as installing
the TCP/IP protocol.

3
Chapter 1: Introduction
What’s in this Guide?
Wireless-G Broadband Router with 2 Phone Ports
• Appendix D: Finding the MAC Address and IP Address for Your Ethernet Adapter
This appendix instructs you on how to find the MAC address or Ethernet address of your PC’s Ethernet
network adapter.
• Appendix E: Glossary
This appendix gives a brief glossary of terms frequently used in networking.
• Appendix F: Specifications
This appendix provides the technical specifications for the Router.
• Appendix G: Warranty Information
This appendix supplies the warranty information for the Router.
• Appendix H: Regulatory Information
This appendix supplies the regulatory information regarding the Router.
• Appendix I: Contact Information
This appendix provides contact information for a variety of Linksys resources, including Technical Support.

4
Chapter 2: Planning Your Wireless Network
Network Topology
Wireless-G Broadband Router with 2 Phone Ports
Chapter 2: Planning Your Wireless Network
Network Topology
A Wireless Local Area Network (WLAN) is exactly like a regular Local Area Network (LAN), except that each
computer in the WLAN uses a wireless device to connect to the network. Computers in a WLAN share the same
frequency channel and SSID, which is an identification name shared by the wireless devices belonging to the
same wireless network.
Ad-Hoc versus Infrastructure Mode
Unlike wired networks, wireless networks have two different modes in which they may be set up: infrastructure
and ad-hoc. An infrastructure configuration is a WLAN and wired LAN communicating to each other through an
access point. An ad-hoc configuration is wireless-equipped computers communicating directly with each other.
Choosing between these two modes depends on whether or not the wireless network needs to share data or
peripherals with a wired network or not.
If the computers on the wireless network need to be accessible by a wired network or need to share a peripheral,
such as a printer, with the wired network computers, the wireless network should be set up in Infrastructure
mode. The basis of Infrastructure mode centers around an access point or wireless router, such as the
Wireless-G Broadband Router with 2 Phone Ports, which serves as the main point of communications in a
wireless network. The Router transmits data to PCs equipped with wireless network adapters, which can roam
within a certain radial range of the Router. You can arrange the Router and multiple access points to work in
succession to extend the roaming range, and you can set up your wireless network to communicate with your
Ethernet hardware as well.
If the wireless network is relatively small and needs to share resources only with the other computers on the
wireless network, then the Ad-Hoc mode can be used. Ad-Hoc mode allows computers equipped with wireless
transmitters and receivers to communicate directly with each other, eliminating the need for a wireless router or
access point. The drawback of this mode is that in Ad-Hoc mode, wireless-equipped computers are not able to
communicate with computers on a wired network. And, of course, communication between the wireless-
equipped computers is limited by the distance and interference directly between them.
infrastructure: a wireless network
that is bridged to a wired network via
an access point
ssid: your wireless network’s name
ad-hoc: a group of wireless devices
communicating directly to each other
(peer-to-peer) without the use of an
access point
access point: a device that allows wireless-
equipped computers and other devices to
communicate with a wired network. Also used
to expand the range of a wireless network
adapter: a device that adds
network functionality to your PC
ethernet: IEEE standard network protocol that
specifies how data is placed on and retrieved
from a common transmission medium
network: a series of computers or devices
connected for the purpose of data sharing,
storage, and/or transmission between users

5
Chapter 2: Planning Your Wireless Network
Network Layout
Wireless-G Broadband Router with 2 Phone Ports
Network Layout
The Router has been specifically designed for use with both your 802.11b and 802.11g products. It is compatible
with all 802.11b and 802.11g adapters, such as the Notebook Adapters (WPC54G, WPC11) for your laptop
computers, PCI Adapter (WMP54G, WMP11) for your desktop PC, and USB Adapter (WUSB54G, WUSB11) when
you want to enjoy USB connectivity. The Router will also communicate with the Wireless PrintServer (WPS54GU2,
WPS54G, WPS11) and Wireless Ethernet Bridges (WET54G, WET11).
Whenyou wish to connectyour wireless network withyour wired network, you canuse the Router’sfour Ethernet
network ports. To add more ports, any of the Router's Ethernet network ports can be connected to any of
Linksys's switches (such as the EZXS55W or EZXS88W).
With these, and many other, Linksys products, your networking options are limitless. Go to the Linksys website at
www.linksys.com for more information about products that work with the Wireless-G Broadband Router with
2 Phone Ports.

6
Chapter 3: Getting to Know the Router
The Back Panel
Wireless-G Broadband Router with 2 Phone Ports
Chapter 3: Getting to Know the Router
The Back Panel
The Router’s ports and the Reset button are located on the back panel of the Router.
Internet This Internet port connects to your cable or DSL modem.
Phone1 Foryour primary Internetphone line,the Phone1 port allows you to connect the Routerto your
telephone (or fax machine) using an RJ-11 telephone cable (not included).
Phone2 If you have a second Internet phone line, the Phone2 port allows you to connect the Router to
your second telephone (or fax machine) using an RJ-11 telephone cable (not included).
Ethernet 1-4 These four Ethernet ports connect to network devices, such as PCs, print servers, or
additional switches.
Reset Button There are two ways to reset the Router to its factory default settings. Either press the Reset
button for approximately five seconds, or restore the defaults from the Administration tab -
Factory Defaults of the Router's Web-based Utility.
Power The Power port is where you will connect the power adapter.
Figure 3-1: Back Panel
IMPORTANT: If you reset the Router, all of
your settings, including Internet connection,
Internet phone service, and security settings,
will be deleted and replaced with the factory
defaults. Do not resettheRouter if youwantto
retain these settings.
(If you have an active Internet phone service
account and reset the Router, then the Router
will automatically download its Internet phone
service settings once it is connected to the
Internet again.)

7
Chapter 3: Getting to Know the Router
The Front Panel
Wireless-G Broadband Router with 2 Phone Ports
The Front Panel
The Router’s LEDs, which inform you about network activities, are located on the front panel.
Power Green. The Power LED lights up when the Router is powered on. If the LED is flashing, the
Router is booting up or running a system self-test.
WLAN Green. The WLAN LED lights up whenever there is asuccessful wireless connection. If the LED
is flashing, the Router is actively sending or receiving data over the wireless network.
Ethernet 1-4 Green. The Ethernet LED serves two purposes. If the LED is solidly lit, the Router is connected
to a device through the corresponding port (Ethernet 1, 2, 3, or 4). If the LED is flashing, the
Router is sending or receiving data over that port.
Phone 1-2 Green. The Phone LED is solidly lit when a telephone or fax machine has a registered
connection to AT&T through the corresponding port (Phone 1 or Phone 2). (The connection is
registered if your Internet phone service account is active.) This LED is not lit when there is no
registered connection. It flashes when the phone is being used or an incoming call has been
detected.
Internet Green. The Internet LED lights up when the Router is connected to your cable or DSL modem.
If the LED is flashing, the Router is sending or receiving data over the Internet port.
Proceed to “Chapter 4: Connecting the Router.”
Figure 3-2: Front Panel

8
Chapter 4: Connecting the Router
Overview
Wireless-G Broadband Router with 2 Phone Ports
Chapter 4: Connecting the Router
Overview
This chapter includes two sets of instructions. If the Wireless-G Broadband Router with 2 Phone Ports will be the
only router in your network, follow the instructions in “Connecting the Router to Your Broadband Modem.” If you
already have a router in your network and want to add the Wireless-G Broadband Router with 2 Phone Ports,
follow the instructions in “Connecting One Router to Another.”
Connecting the Router to Your Broadband Modem
1. Make sure that all of your hardware is powered off, including the Router, PCs, and broadband modem.
2. Connect your broadband modem’s Ethernet cable to the Router’s Internet port.
3. Plug a standard telephone into the Router’s Phone1 port.
4. Connect one end of an Ethernet network cable to one of the numbered ports on the back of the Router.
Connect the other end to an Ethernet port on a network device, e.g., a PC, print server, or switch.
Repeat this step to connect more PCs or other network devices to the Router.
5. Power on the broadband modem.
6. Connect the included power adapter to the Router’s Power port, and then plug the power adapter into an
electrical outlet. The Power LED on the front panel will light up as soon as the Router powers on.
7. Power on your PC(s).
Proceed to “Chapter 5: Configuring the Router.”
Figure 4-1: Connect the Broadband Modem
Figure 4-2: Connect a Telephone
Figure 4-3: Connect a PC
NOTE: Make sure your telephone is set to its tone setting (not pulse).
IMPORTANT: Do not connect the Phone port to a telephone wall jack. Make sure you only connect
a telephone or fax machine to the Phone port. Otherwise, the Router or the telephone wiring in your
home or office may be damaged.
Figure 4-4: Connect the Power

9
Chapter 4: Connecting the Router
Connecting One Router to Another
Wireless-G Broadband Router with 2 Phone Ports
Connecting One Router to Another
If you already have a router (for example, a wireless router) and want to add the Wireless-G Broadband Router
with 2 Phone Ports, then you should use the Wireless-G Broadband Router with 2 Phone Ports as your primary
router so the Internet phone calls will be routed properly. For example, the following connection diagram shows
the Wireless-G Broadband Router with 2 Phone Ports connected to a wired router, phone, and desktop PCs.
Figure 4-5: Router Connected to Another Router
Phone
Wireless-G
Broadband Router
with 2 Phone Ports
Broadband Modem
Internet
PCs
Wired Router

10
Chapter 4: Connecting the Router
Connecting One Router to Another
Wireless-G Broadband Router with 2 Phone Ports
To connect the Wireless-G Broadband Router with 2 Phone Ports to another router, follow these instructions:
1. Make sure that all of your hardware is powered off, including both routers, PCs, and broadband modem.
2. Disconnect your existing router from the broadband modem, PCs, and other network devices.
3. Connect your broadband modem’s Ethernet cable to the Internet port on the back of the Wireless-G
Broadband Router with 2 Phone Ports.
4. Plug a standard telephone into the Router’s Phone1 port.
5. Connect one end of an Ethernet network cable to one of the numbered ports on the back of the Router.
Connect the other end to the Internet port on the back of the other router.
Repeat this step to connect PCs or other network devices to the Router.
6. Power on the cable or DSL modem.
7. Connect the included power adapter to the Router’sPower port, and then plug the power adapter into an
electrical outlet. The Power LED on the front panel will light up as soon as the Router powers on.
8. Power on the other router.
9. Power on your PC(s).
Proceed to “Chapter 5: Configuring the Router.”
Figure 4-9: Connect the Power
Figure 4-8: Connect the Other Router
NOTE: Make sure your telephone is set to its tone setting (not pulse).
IMPORTANT: Do not connect the Phone port to a telephone wall jack. Make sure you only connect
a telephone or fax machine to the Phone port. Otherwise, the Router or the telephone wiring in your
home or office may be damaged.
Figure 4-6: Connect the Broadband Modem
Figure 4-7: Connect a Telephone

11
Chapter 5: Configuring the Router
Overview
Broadband Router with 2 Phone Ports
Chapter 5: Configuring the Router
Overview
Linksys recommends using the Setup CD-ROM for first-time installation of the Router. If you do not wish to run
the Setup Wizard on the Setup CD-ROM, then you can use the Web-based Utility to configure the Router. For
advanced users, you may configure the Router’s advanced settings through the Web-based Utility.
This chapter will describe each web page on the Utility and each page’s key functions. The Utility can be
accessed via your web browser through use of a computer connected to the Router. For a basic network setup,
most users only have to use the following screens of the Utility:
• Basic Setup. On the Basic Setup screen, enter the Internet connection settings provided by your ISP. If you do
not have this information, you can call your ISP to request the settings. Once you have the setup information
for your specific type of Internet connection, then you can configure the Router.
• Management. Click the Administration tab and then the Management tab. The Router’s default password is
admin. To secure the Router, change the Password from its default.
There are six main tabs: Setup, Security, Access Restrictions, Applications & Gaming, Administration, and Status.
Additional tabs will be available after you click one of the main tabs.
Setup
• Basic Setup. Enter the Internet connection and network settings on this screen.
• DDNS. Enable the Router’s Dynamic Domain Name System (DDNS) feature on this screen.
• MAC Address Clone. If you need to clone a MAC address onto the Router, use this screen.
Wireless
• Basic Wireless Settings. Enter the basic settings for your wireless network on this screen.
• Wireless Security. Enable and configure the security settings for your wireless network.
NOTE: If you want to sign up for Internet phone service or activate your account, visit
http://www.att.com/linksys after you have installed and configured the Router. Refer to
“Chapter 6: Signing up for AT&T CallVantagesm Service” for more information.

12
Chapter 5: Configuring the Router
Overview
Broadband Router with 2 Phone Ports
• Wireless MAC Filter. Wireless access can be filtered by using the MAC addresses of the wireless devices
transmitting within your network’s radius.
• Advanced Wireless Settings. For advanced users, you can alter data transmission settings on this screen.
Security
• Firewall. On this screen, you can configure a variety of filters to enhance the security of your network.
• VPN. To enable or disable IPSec, PPTP, and/or L2TP Passthrough, use this screen.
Access Restrictions
• Internet Access. This screen allows you to permit or block specific kinds of Internet usage and traffic.
Applications & Gaming
• Port Range Forward. Set up public services or other specialized Internet applications on your network.
• Port Trigger. To set up triggered ranges and forwarded ranges for Internet applications, click this tab.
• UPnP Forward. Use this screen to alter UPnP forwarding settings.
• DMZ. Click this tab to allow one local user to be exposed to the Internet for use of special-purpose services.
Administration
• Management. On this screen, alter the Router’s password and access privileges, as well as the SNMP and
UPnP settings.
• Log. If you want to view or save activity logs, click this tab.
• Diagnostics. Use this screen to check the connections of your network components.
• Factory Defaults. If you want to restore the Router’s factory defaults, then use this screen.
• Backup and Restore. You can back up and restore the Router’s configuration if necessary.
• Reboot. Use this screen to remotely reboot the Router from your computer.

13
Chapter 5: Configuring the Router
How to Access the Web-based Utility
Broadband Router with 2 Phone Ports
Status
• Router. This screen provides status information about the Router.
• Local Network. This provides status information about the local network.
• Wireless. The settings for your wireless network are displayed on this screen.
• Voice. This screen provides status information about the Internet phone lines.
How to Access the Web-based Utility
To access the Web-based Utility of the Router, launch Internet Explorer or Netscape Navigator, and enter the
Router’s default IP address, 192.168.15.1, in the Address field. Press the Enter key.
A screen will appear asking you for your User Name and Password. Leave the User Name field blank, and enter
admin in the Password field. Then click the OK button.
Make the necessary changes through the Utility. When you have finished making changes to a screen, click the
Save Settings button to save the changes, or click the Cancel Changes button to undo your changes. For help
information on a tab, click Help.
The Setup Tab - Basic Setup
The Basic Setup screen is the first screen you see when you access the Web-based Utility.
Internet Setup
The Internet Setup section configures the Router for your Internet connection type. This information can be
obtained from your ISP.
Internet Connection Type
The Router supports four connection types: Automatic Configuration (DHCP), Static IP, PPPoE, and PPTP. Each
Basic Setup screen and available features will differ depending on what kind of connection type you select.
Automatic Configuration (DHCP)
By default, the Router’s Internet Connection Type is set to Automatic Configuration (DHCP), and it should be
used only if your ISP supports DHCP or you are connecting through a dynamic IP address.
Figure 5-2: Router Login
Figure 5-1: Router’s IP Address
Figure 5-3: Setup Tab - Basic Setup -
Automatic Configuration (DHCP)

14
Chapter 5: Configuring the Router
The Setup Tab - Basic Setup
Broadband Router with 2 Phone Ports
Static IP
If you are required to use a permanent IP address, then select Static IP.
Internet IP Address. This is the IP address that the Router has, when seen from the Internet. Your ISP will
provide you with the IP Address you need to specify here.
Subnet Mask. This is the Router’s Subnet Mask, as seen by external users on the Internet (including your
ISP). Your ISP will provide you with the Subnet Mask.
Default Gateway. Your ISP will provide you with the Default Gateway Address.
Static DNS 1-2. Your ISP will provide you with at least one DNS (Domain Name System) Server IP Address.
PPPoE
Some DSL-based ISPs use PPPoE (Point-to-Point Protocol over Ethernet) to establish Internet connections for
end-users. If you use a DSL line, check with your ISP to see if they use PPPoE. If they do, you will have to
enable it.
User Name and Password. Enter the User Name and Password provided by your ISP.
Connect on Demand and Max Idle Time. You can configure the Router to cut the Internet connection after it
has been inactive for a specific period of time (Max Idle Time). If your Internet connection has been
terminated due to inactivity, Connect on Demand enables the Router to automatically re-establish your
connection as soon as you attempt to access the Internet again. If you wish to activate Connect on Demand,
click the radio button. If you want your Internet connection to remain on at all times, enter 0in the Max Idle
Time field. Otherwise, enter the number of minutes you want to have elapsed before your Internet access
disconnects.
Keep Alive and Redial Period. This option keeps your Internet access connected indefinitely, even when it
sits idle. If you select this option, the Router will periodically check your Internet connection. If the connection
is down, then the Router will automatically re-establish the connection. To use this option, click the radio
button next to Keep Alive. The default Redial Period is 30 seconds.
When you are finished, click the Save Settings button. Then click the Status tab, and click the Connect
button to start the connection.
Figure 5-4: Static IP
Figure 5-5: PPPoE
static ip address: a fixed address
assigned to a computer or device
connected to a network.
pppoe: a type of broadbandconnectionthat
provides authentication (username and
password) in addition to data transport
subnet mask: an address code that
determines the size of the network
default gateway: a device that forwards
Internet traffic from your local area network
NOTE: For DSL users, if you need to enable PPPoE support, remember to remove any PPPoE
applications that are installed on your PCs.
