Vaporizer Unit Instruction Manual
VU-0450N Series
Safety Precautions
Incorrect handling can cause serious injury or death.
(1) Before connecting the fittings, check that no damage or defects are found
on the fittings. Make connections properly and make sure that a leak test is
conducted before actual operation to prevent liquid and gas from leaking
into the atmosphere.
(2) DO NOT apply any corrosive fluid to materials exposed to liquid and gas.
Corrosion may cause liquid or gas to leak into the atmosphere. Please
confirm the physical properties of liquid or gas before using.
(3) This device is not designed as an explosion-proof structure. DO NOT use
this device in a place where explosion-proof structures are required. Doing
so may cause fire or explosion.
(4) Prepare temperature controller unit when operating Vaporizer/Heat Exchanger
and do not set the temperature over than maximum operating temperature.
Wring temperature setting may cause fire or destruction of thedevice. It is
recommended to add abnormal overheating detectorifnecessary.
(5) This device must be earthed before use. Otherwise, there is the rink of
electric shock.
(6) Thermal switch is equipped in Vaporizer/Heat Exchanger to prevent
overheating. However, the operating temperature of thermal switch would
vary due to operating conditions and ambient temperature.
(7) Attach/remove connector and terminals, please make sure that power
supply turning off. It may cause fire or shock hazard.
Incorrecthandlingcancausemedium or slight injury or
maycause damageto,orlossof,facilitiesorequipment.
(1) Observe the precautions listed in the WARNING (above).
(2) Not using the voltage can cause fire, damage to sensors or malfunction or
cause electric shock.
(3) This device is not designed to be waterproof. DO NOT locate this product
outdoors or in a place where it may be splashed with water. Doing so may
cause fire, trouble or malfunction of this product.
(4) DO NOT modify this product. It may cause fire or other problems.
(5) A warm-up period of 60 minutes is recommended after reaching the set
temperature. Otherwise, the output gas temperature will be low.
(6) This device is a precious device, please handle it carefully. Dropping
down or handling it carelessly will cause damage. Please use assist
instrument while moving or setting the device.
(7) Depends on the character of the liquid and process condition, the temperature
of tube, carrier gas, and the VU, also the flow rate of carrier gas should be
set properly.
(8) Please use Helium (He) to pressure liquid. It easily lead to bubbles if use N2,
Ar, O2, etc, that have higher than Helium (He) solubility to pressure.
(9) Regular maintenance is recommended for the steady use of this product.
This product uses a seal material made from the Kalrez®, in order to
reduce leakage, Changing the seals annually is recommended. The
maintenance cycle changes according to precursor type and operating
conditions, so please consult about the maintenance cycle for the steady use
of this device.
1. Introduction
This instruction manual explains the basic operation of Vaporizer unit VU-0450N
series(Hereafter called “VU”). Please read through this manual carefully to
become familiar with the features of this device.
2. Features
The VU has the following features.
(1) By using the VU in combination with the liquid mass flow meter
(Hereafter called “LM”) and the gas mass flow controller (Hereafter
called “MFC”), precise flow control and effective vaporization can be
assured.
(2) The functions details of LM are described in the special function
manual.
(3) It is vaporized by carrier gas (atomizer gas).
Use a MFC to control the gas flow rate.
3. Specification/ Dimensions
(1) Specification
Product name
Vaporizer
Model name
VU-0450N
Precursor Type
All type of precursor (In corrosive precursor)
Power supply
L01: AC100 to 120V
L02: AC200 to 240V
Heater
L01:800W
L02:800W
Thermal switch (Note1)
Over 230±10°C OPEN
Return operating temperature 200±15°C CLOSE
Electrical rating (With resistance load)
AC125V/15A,250V/10A Min:1A
Maximum operating temperature of VU
200°C
Withstanding pressure (Gauge pressure)
1 MPa(G)
Leak integrity (External Leak)
Less than 1.0×10-11 Pa·m3/sec (He)
Fittings
Precursor inlet
3.2mm (1 /8” ) VCR female
Carrier gas inlet
6.35mm (1/4” ) VCR male
Vapor outlet
12.7mm (1/2” ) VCR female
Thermocouple for temperature controller
K Type × 1piece
Recommended temperature controller
PID control
Wetted materials
StainlessSteel316L,Au,Ni-Co,Polyimide(SP-1)orPEEK
Mounting direction
Liquid inlet and gas outlet line : horizontal.
Connector vertical and up.
(Please confirm the outline dimension drawing)
Standard accessories
Thermocouple
connector
CMP01-K (RKC) ×1
Heater/Thermal
switch connector
SRCN6A16-7S (JAE) ×1
LM-VU connect
cable
CC-LV-3-3M ×1
Note1) The temperature of thermal switch may be different from the temperature of a point of
controlling of VU.
(2) Dimensions (This figure is for "Valve type C: Control valve stand-alone type")
Figure1 External dimensions and components

4. Ordering Information
VU –0450N -C 01 -03 P NNL01 T23 NNN
[1] [2] [3] [4] [5] [6] [7] [8] [9] [10]
[1] Series model VU:Vaporizer
[2] Valve type
A: Control valve and Shut-off valve all-in-one type
C: Control valve stand-alone type
F: Shut-off valve stand-alone type
[3] Carrier gas
01: Carrier gas type 1 to 09: Carrier gas type 9
[4] Capillary
03: Capillary type 3 05: Capillary type 5
10: Capillary type 10
[5] Valve
P: Polyimide E: PEEK
[6] Seal
N: Au K: Kalrez®
[7] Internal surface treatment
N: No treatment M: Electrical polishing(EP)
[8] Heater
L01: AC100 to 120V L02: AC200 to 240V
[9] Thermal switch
T23: 230±10°C
[10] Option
NNN: Standard specifications
※Notation other than NNN means customer options. The specification will be different
from this specification sheet, please refer to specific specification sheet. Please notice
that the pin assignment may be different as well.
5. Electrical Connection
(1) Heater/Thermal switch connector
Mounted connector : SRCN2A16-7P (JAE)
Pair connector : SRCN6A16-7S (JAE)
Pin No.
Signal name
1
Heater power supply
2
Heater power supply
3
N.C.
4
N.C.
5
Thermal switch
6
Thermal switch
7
Case Gnd.
(2) LM-VU connector
Mounted connector : HR-10-7R-4P (73) (Hirose)
Pair connector : HR-10-7P-4S (73) (Hirose)
Pin No.
Signal name
1
Valve control signal
2
Valve control signal (-15VDC)
3,4
N.C.
Cable: CC-LV-3-3M
(3) Thermocouple connector
Mounted connector : CMP03-K (RKC Instrument Inc.)
Pair connector : CMP01-K (RKC Instrument Inc.)
Pin No.
Signal name
K
K Type Thermo-couple (-)
+
K Type Thermo-couple (+)
6. Connection diagram
7. Preparation and Operational Procedure
(1) Check the liquid type and install the VU according to the mounting direction,
then attach the VU fittings in the direction of the fluid flow.
(2) Attach filters to liquids and carrier gases lines.
(3)Prepare a LM and attach to the upstream of the VU.
(4) Prepare a MFC including a power supply indicator and cables etc. for
carrier gas and attach to the carrier gas line of the VU.
If preheating of the carrier gas is required, attach the LINTEC
heat exchanger HX-10A between the MFC and the VU.
(5) Prepare all of the temperature control units and connect to the VU and the
outlet tubing heaters.
(6) Electrical connections should be made correctly, taking account of power
source voltage, polarity and capacity.
(7) Check that there are no leaks from the fittings using a helium (He) leak detector.
(8) Supply power to the LM and the MFC, and warm-up for 30 minutes.
(9) Turn on the VU and the HX-10A heaters, and 30 to 60 minutes later check
that the temperature has reached the set temperature.
(10) Evacuate and purge the tubing line, the LM and the VU to remove moisture,
thoroughly.
(11) Control the LM and MFC and introduce the liquid, then vaporized gas will be
transported from the outlet. (Note2)
※Please refer to Figure3 for the example of tube connecting.
Figure3 An example of tube connection
Note2) It is necessary to set the temperature of the VU and the line and carrier gas flow rates
to appropriate values according to the physical properties of the liquid and the process
conditions.
·Helium (He) gas is recommended for the pushing gas of the liquid container.
