LION LRD 6110C User manual

M echanicalDetail
Tw o-YearWarranty details at:www.lionprecision.com /warranty.html
User’s Guide
forthe
LRD 6110C LabelSensor
with Analog O utput
from
Lion Precision
Lion Precision
563 Shoreview Park Road
St.Paul,MN 55126
651-484-6544
www.lionprecision.com
Docum entNum ber:M 015-3391.002
5.50"
140mm
1.00"
25.4mm
Gap 0.03"
0.76mm
1.20"
30.5mm
0.60"
15.2mm
0.20"
5.1mm 0.60"
15.2mm
M4x.7
(x4)

Description
The LION PRECISION LRD6110C is an electronic capacitive sensorused to monitorlabelregistration
and/orcountlabels. The sensorwilloutputa signalindicating the leading ortrailing edge ofthe
labelas itpasses through the sensor.This custom ized sensorincludes an analog outputwhich is
proportionalto the am ountofmaterialin the sensor.
Connecting to the Sensor
Warnings:
Sensorbody is connected to Ground.
U nused wires mustbe insulated from contactwith otherobjects.
Allpow ermustbe offwheninstalling the sensor.
Gray wire (OutputPolarity,pin 5)mustbe connected to +VorGround forreliable operation.
Wire
Color
Connection N otes
1 (Brow n) +Vin (11-28VDC) 50m A m ax.
2 (White) NPN Output 150m A m ax.
3 (Blue) Ground Connected to
sensorbody
4 (Black) Analog Output 0V to +Vin
5 (Gray) OutputPolarity
(light/dark
sw itching)
+V– Dark
Sw itching (NC)
Ground – Light
Sw itching (NO)
Warning:Gray wire (pin 5)mustbe connected to
+VorGround forreliable operation.
Specifications
Pow ersupply Voltage 11-28 VDC (reverse polarity protected)
Current 50m A
Response time on oroff 10µs m ax
Sw itching Frequency 10kHzm ax
Output
Analog Output 0V to +Vin
Sw itching output NPN,dark orlightsw itching,150m A
m ax,(overload protected)
Tem perature Operating Range 40°F to 140°F (4°C to 60°C)
Protections Supply Inverse Polarity Protection
Sw itching output ShortCircuitand Overload Protection
Setup Procedure
1. Webmustrem ain in contactwith the m ounting plate.
2. Labelmustpass underthe [-SENSOR-]indicator.
3. Sm alllabels should be centered underthe [-SENSOR-]indicator.
4. Whenproperly setup,the lights willmovebetw een WEBand LA B EL.The lights in the “X”
region should only lightbriefly during the transition betw een WEBand LA B EL regions.
SensorSetup
1. Turn Span atleastfourturns counter-clockw ise,then two
turns clockw ise (this is the mid-pointofthe adjustment
range)
2. Place web(liner)only in sensor
3. AdjustShiftuntilLED #2is on,then adjustShift
justto the
pointwhere LED #1is on.
4. Slow ly movea labelgap through the sensorand verify that
the indicatorlights LED # 1 as the gap passes through the
sensor.Ifitdoes not,adjustShiftas necessary untilitdoes.
5. Setup com plete
Ifthe setup does notgive reliable results (usually forlabels less
than 1"),turn Span fourturns clockw ise (m aximum gain)and
repeatsteps 2-5.Itis im portantthatthe indicatoronly cross the
“X ” regi
on during transition from webto label.
Notes:
1) The LRD6110 maynotwork reliably with solid foil
labels.Som e inks,usually black,have a high carbon
content.Ifthe labelis flood coated (100% coverage)
with the ink itm ay behave like a solid foillabel.
2) Forsoli
d foillabels,use the UltraLRD V2
Connectoron rearofsensor
LA B EL
SPAN
+
W
_
L
SHIFT
WEB
6110
LED#
LED# 2
21
43 5

