Lippert Components OneControl Unity Board M Series User manual

OneControl®
Unity Board™M Series
Rev. Q (Thor)
OWNER'S MANUAL

Rev: 03.06.19 Page 2 CCD-0001540
TABLE OF CONTENTS
Introduction 2
Safety 2
Operation 3
Awning 3
Bed Lifts 3
Fans 4
Generator 4
HVAC (Heating, Ventilation, Air Conditioning) 5
Lighting 7
Monitor Panel 7
Slides 7
Stabilizers 7
Bluetooth Connection 8
Lockout 9
Troubleshooting 9
Introduction
The OneControl® Touch Panel is a touchscreen device that accesses system controls and monitoring
software for recreational vehicles. The OneControl Unity Board™ is an electronic control system that
provides direct power, control, monitoring and diagnostics for coach functions, including awnings,
lighting, fans, HVAC, generators, water tanks, water pumps, tank heaters and battery levels. Each slide-out is
controlled by its own module that is linked to the system via CAN network. Powering up the coach will also
turn on the OneControl Touch Panel and the various controllers throughout the coach.
Additional information about this product can be obtained from lci1.com/support or by downloading
the free myLCI app. The app is available on iTunes® for iPhone® and iPad® and also on Google Play™ for
Android™ users.
iTunes®, iPhone®, and iPad® are registered trademarks of Apple Inc. Google Play™ and Android™ are
trademarks of Google Inc.
Safety
Read and understand all instructions and safety labels outlined in this manual before operating the system.
Contact LCI Customer Service if there are questions or concerns about the procedures in the manual.
The “WARNING” symbol above is a sign that an installation procedure has a safety risk involved and
may cause death, serious personal injury or severe product or property damage if not performed
safely and within the parameters set forth in this manual.
Moving parts can pinch, crush or cut. Keep clear and use caution.

Rev: 03.06.19 Page 3 CCD-0001540
Operation
The OneControl Touch Panel will be launched upon startup of the coach. The home screen will appear on
startup (Fig. 1) with icons representing systems controlled by the Unity Board.
The device can be powered on or off using the power button (Fig. 1A) on the front of the touch panel.
NOTE: Stabilizers are optional equipment on some models/floor plans. The Stabilizers icon will only
populate if that feature is available.
To operate a system, press the icon representing that system. After accessing and adjusting a system via a
touchscreen icon, push the Home icon in the center of the bottom row of the touchscreen to return to the
OneControl home screen.
Fig. 2
Fig. 1
A
Awning
1. Press the Awning icon.
2. Press the EXTEND (+) button (Fig. 2A)
to extend the awning and press the
RETRACT (-) button (Fig. 2B) to retract the
awning.
Bed Lifts
1. Press the Bed Lifts icon to access the Bed
Lift screen.
2. Press RAISE (Fig. 3A) to raise the bed and
press LOWER (Fig. 3B) to lower the bed.
Fig. 3
A
B
A
B

Rev: 03.06.19 Page 4 CCD-0001540
B
A
Fans
1. Press the Fan icon to access the
Fan screen.
2. Select a fan and then press the
button to turn on the fan (Fig. 4).
Press again to turn the fan off.
Generator
1. Press the Generator icon to access the Generator screen (Fig. 5).
2. Press the SETTINGS button (Fig. 5A).
3. Adjust the generator according to user preference (Fig. 6).
4. Press the START/STOP icon (Fig. 5B) on the right side of the screen to run or stop the generator.
Fig. 6
Fig. 4
Fig. 5

Rev: 03.06.19 Page 5 CCD-0001540
C
D
A
B
C
C
A
BD
HVAC (Heating, Ventilation, Air Conditioning)
1. Press the HVAC icon.
2. Press the Climate zone displayed (Fig. 7).
3. There are two boxes on the left side of the screen (Fig. 8). The top box (Fig. 8A) controls the heating/
cooling mode. The bottom box (Fig. 8B) controls the fan. Press the top box to choose the HVAC mode.
A large box will populate with available options for that climate zone (Fig. 8).
A. Heat/Cool: This mode provides High and Low set points. The HVAC system will operate to keep the
temperature between these two set points. Refer to step 5C.
B. Heat (Fig. 8C): This mode has a single set point and the furnace or heat pump will operate to keep
the temperature at that set point.
NOTE: If equipped with a heat pump, users will be prompted to choose a heat source (Fig. 8D). The options
are Gas or Heat Pump.
C. Cool (Fig. 9A): This mode has a single set point and the air conditioning will operate to maintain
the temperature at this point.
D. Off (Fig. 9B): Tapping this button turns off the HVAC system.
E. Once the desired mode is selected, press the CLOSE button (Fig. 9C) on the right.
4. Press the bottom of the two boxes on the left (Fig. 8B) to choose the Fan mode. A large box will
populate with available fan settings (Fig. 10).
A. High (Fig. 10A): The fan will run continuously on high until another setting is chosen.
B. Low (Fig. 10B): The fan will run continuously on low until another setting is chosen.
C. Auto (Fig. 10C): The fan will run when the HVAC system calls for heating or cooling, then shuts off
after the set point is reached.
NOTE: The fan will continue to run for two minutes after the set point has been reached in order to cool the
compressor or furnace.
D. Once the desired fan setting has been selected, press the CLOSE button (Fig. 10D) on the right.
Fig. 7 Fig. 8
Fig. 9 Fig. 10
A
B

Rev: 03.06.19 Page 6 CCD-0001540
Counterclockwise
Clockwise
A
Cool Heat
5. Adjust the set points for the climate zone by updating the display.
NOTE: The adjusted temperature for the climate zone will be displayed inside a radius with a white dot on
it (Figs. 11 and 12).
A. Press and hold the white dot, then drag it around the radius (Figs. 11 and 12) to set the climate
zone's temperature set point.
I. Dragging the dot counterclockwise will lower (cooler) (Fig. 11) the set temperature.
II. Dragging the dot clockwise around the radius will raise (hotter) (Fig. 12) the set temperature.
B. Once the desired set point is reached, release pressure on the white dot.
C. Two white dots will appear (Fig. 13) when in Heat/Cool mode (Fig. 13A).
I. Set the low end (cool) of the temperature range by moving the left dot counterclockwise.
II. Set the high end (heat) of the temperature range by moving the right dot clockwise.
Fig. 11 Fig. 12
Fig.13

Rev: 03.06.19 Page 7 CCD-0001540
A
Lighting
1. Press the Lighting icon to access the
Lighting screen (Fig. 14).
NOTE: Individual light status is displayed by
a light bulb to the left of the light's
name (Fig. 14A). The light icon will
display a lit bulb if the light is on or a
dim bulb if the light is off.
2. Pressing the individual light buttons will
turn that light on or off.
3. Pressing the highlighted ALL ON or ALL
OFF icons (Fig. 14B) will turn all lights on
or off.
Monitor Panel
1. Press the Monitor Panel icon to access the
Tank Monitor screen (Fig. 15).
2. The monitored systems (Fig. 15A) will
display the status of the various tanks.
3. Press the buttons on the right to turn on
or off a specific component (Fig. 15B).
NOTE: The icons will light up when the
corresponding device is in use.
Slides
1. Press the Slides icon to access the Slides
screen (Fig. 16).
2. Select a slide-out to operate.
A. Press the OUT (+) button (Fig. 16A) to
extend the slide-out.
B. Press the IN (-) button (Fig. 16B) to
retract the slide-out.
Stabilizers
1. Press the Stabilizers icon to access the
Stabilizers screen (Fig. 17).
2. Select a stabilizer to operate.
A. Press EXTEND (Fig. 17A) to extend the
stabilizer.
B. Press RETRACT (Fig. 17B) to retract the
stabilizer.
A
B
Fig. 16
A
B
Fig. 14
Fig. 15
Fig. 17
B
B
A

Rev: 03.06.19 Page 8 CCD-0001540
A
A
A
A
A
Fig. 18 Fig. 19
Fig. 20 Fig. 21
Fig. 22 Fig. 23
Bluetooth Connection
After installing the LCI OneControl app from the Apple app store or the Google Play store, open OneControl
to start the procedure to connect a smart device to Bluetooth.
NOTE: The minimum requirements for the smart device are IOS 9.0 or Android 5.0 with Bluetooth 4.0.
1. Tap the I ACCEPT button (Fig. 18A) on the End User License Agreement (EULA) view.
2. Tap the GET STARTED button (Fig. 19A) on the Welcome screen.
3. Select BLUETOOTH (Fig. 20A) when prompted.
4. Find the system name (Fig. 21A) that matches the ID supplied on the OneControl Bluetooth system.
5. Enter the password (Fig. 22A) included on the OneControl wireless system.
6. Type in a PIN number (Fig. 23) to prevent unintended access to the coach.
7. After OneControl has successfully connected, tap the CONTINUE button to finish the setup.

Rev: 03.06.19 Page 9 CCD-0001540
What Is Happening? Why? What Should Be Done?
Missing icons
Power disconnected Verify adequate 12V power and ground to the
appropriate module.
Loose CAN harness
connections
Verify the CAN data harnesses are connected. Remove the
data harnesses and re-seat them. Make sure connector pins
are not loose.
Missing slide icon Bad or disconnected
controller
Verify all slide controllers are connected and functional. Replace
bad controller.
Selected function
does not operate
Function is
locked out
If the icon is present, but will not operate on the touchscreen, it
may be locked out because the ignition is on. Turn ignition off.
Function already
open
If icon is present, but grayed out, the function could be open
on a smart device connected to the OneControl app. Close
function on smart device.
Wrong fuse setting In the configurator, verify the fuse has been set to the
appropriate setting for that function.
On/Off feature turns
on, but immediately
turns off
Wrong fuse value In the configurator, make sure the proper fuse value has been
set for that output.
Touch panel will not
power up
No fuse Make sure the 5A fuse in the power center is present and intact.
Loose fuse Re-seat loose fuse.
Blown fuse Replace fuse.
Heat pump will
not operate and
switches to gas heat
Defaults to gas heat
because certain
conditions are not
met
The outside temperature must be above 47 degrees.
The set point cannot be more than 8 degrees above the current
zone temperature; e.g., climate zone temperature is 68 degrees,
then the set point cannot exceed 76 degrees.
Fig. 24
Lockout
There may be lockout capability from a motorized ignition if the brake system is wired into the controller.
If a signal is received, the Unity Board will lock out several functions to prevent operation of the devices
during transit.
If this occurs, there will be a padlock displayed at the top right-hand corner of the home screen (Fig. 24A),
and a padlock will also be shown to the right of the functions that are locked (Fig. 25A).
Troubleshooting
Fig. 25
A
A

The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (“LCI”).
LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an
authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty.
The information contained in this manual is subject to change without notice and at the sole discretion of LCI.
Revised editions are available for free download from lci1.com.
Please recycle all obsolete materials.
For all concerns or questions, please contact
Lippert Components, Inc.
Ph: [phone] | Web: lci1.com | Email: [email protected]
