Toshiba 46WM48 Series Use and maintenance manual

TOSHIBA
Simple at-a-glance reference of your remote control
Quick Set Up Guide and Remote Control
2358 9663
Remove the back cover to insert the batteries, make
sure they are inserted the right way round.
Suitable battery types for this remote are:
UM-4, AAA, IEC R03 1.5V.
Printed on recycled paper.
100% Chlorine free.
To mute the sound
Teletext control buttons
To exit Menus
Bass Boost/Super Woofer
Stereo/Bilingual reception
To bring up on-screen information and
for the teletext initial/index function
To select input from external sources
To access sub-pages when in teletext
mode
To select mode
On-screen Menus
Selectable picture preferences Widescreen viewing
Number buttons
To return to the previous programme
For On/Standby mode
To display teletext
When using a TOSHIBA VCR or DVD:
press
m
to PAUSE
press
w
to EJECT
press
l
q
to SKIP-REWIND
press
s
l
to SKIP-FORWARD
press
r
to PLAY
press
p
to STOP
press
q
to REWIND
press
s
to FAST FORWARD
To change programme positions and
teletext pages
To alter the volume
When using menus the arrows move
the cursor on the screen up, down, left
or right. OK to confirm your selection
When in TV mode:
8
/
9
Time display
When in Teletext mode:
r
To reveal concealed text
q
To hold a wanted page
s
To enlarge teletext display size
8
/
9
To select a page whilst viewing a
normal picture
K8481 46/52WM48 QSUG 17/9/04 14:21 Page 1

Auto Tune – 46/52WM48 Series
Quick Set Up Guide and Remote Control
TOSHIBA
Plug the aerial directly into the AERIAL INPUT on the television set. Ensure all other
products are standby before continuing.
Connect the television to the mains, the red LED will light up.
The Quick setup screen will appear, this may take a few moments.
If the screen does not appear press the standby button on the
remote control.
Using Sor Rselect your language and press OK.
Then using Sor Rselect your country and press OK.
To start Auto tuning press OK.
The search will begin for all available stations.
The slide bar will move along the line as the
search progresses.
You must allow the television to complete
the search.
When the search is complete the TV will
automatically return to programme position 1
and the Quick setup screen will reappear.
Press OK to select Programme sorting.
With the list of stations now showing use
Qor Pto highlight the station you want to
move and press R. The selected station will be
moved to the right of the screen.
Use Qor Pto move through the list to your
preferred position. As you do so the other stations
will move to make room. Press Sto set your move.
Repeat as necessary, then press EXIT. Auto tuning is
now complete. To select programmes press the number buttons.
In some areas of the UK duplicate TV stations are received, if the Autosort has put these
in adjacent numbers e.g. BBC1 in positions 1 and 2, simply re-order using the
Programme Sorting feature. For details of this and further operations plus equipment
connections please refer to the TV Owner’s Manual.
Quick setup
Select your language.
Language English
EXIT Watch TV Next
1
2
3
4
5
6
7
Auto tuning
Searching
Channel : 6 Station :
EXIT Stop
Programme sorting
Prog. Channel Station
1 22 BBC1
225 ITV
328 BBC2
432 CH4
569
669
Sort Store
MENU Back EXIT Watch TV
Quick setup
Auto Tuning complete.
Press OK to access the
Programme sorting menu.
EXIT Watch TV Next
K8481 46/52WM48 QSUG 17/9/04 14:21 Page 2
