Lippert Furrion Trekker 1000 Installation instructions

1
lippert.com 432-LIPPERT (432-547-7378) Rev: 11.09.22
Trekker™1000W
Portable Power Station
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006494
Trekker™1000W
Portable Power
Station
Installation and Owner’s
Manual
(For Aftermarket Applications)
Table of Contents
Introduction ............................................ 2
Safety ................................................... 2
Product Specications ................................ 2
Product Features ....................................... 2
LCD Display Screen .................................... 4
Operation ............................................... 5
Charging Modes ....................................... 5
Product Usage Tips .................................... 6
Recycling ............................................... 6
Maintenance ............................................ 6
Notes .................................................... 6
Part #Part # DescriptionDescription
2022111764 Furrion Trekker 1000

2
lippert.com 432-LIPPERT (432-547-7378) Rev: 11.09.22
Trekker™1000W
Portable Power Station
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006494
Introduction
The Trekker 1000W Portable Power Station has a built-in
high-quality lithium battery that supports DC, USB output,
AC output.
Additional information about this product can be obtained
from Lippert.com/support or by using the LippertNOW app.
Replacement kits can be ordered from https://store.lci1.
com/ or by using the LippertNOW app.
The LippertNOW app is available for free on Apple App
Store®for iPhone®and iPad®and also on Google Play™for
Android™users.
App Store®and iPad®are registered trademarks of Apple
Inc.
Google Play™and Android™are trademarks of Google Inc.
Safety
Read and fully understand all instructions before installing
or operating this product.
Adhere to all safety labels.
Product Specifications
DO NOT COVER THE TREKKER 1000 WITH TOWELS,
CLOTHES, OR OTHER OBJECTS WHEN USING.
PLEASE KEEP THE TREKKER 1000 OUT OF REACH
OF CHILDREN.
THE TREKKER 1000 MAY GENERATE HEAT WHEN
CHARGED. THIS IS NORMAL. USE CAUTION WHEN
HANDLING.
Description Information
Size (L*W*H) 11-81/100” x 6-7/25” x 8-27/100”
Battery Capacity 270000mAh/999Wh
Weight 16.76lbs
Built-in Battery Technology 100% original quality
lithium battery
DC Input DC24V/5.0A
Anderson Port
It supports 30V solar charging,
and it is recommended to use
solar
panel 300W
MPPT Yes
Fully Charged Time About 10hrs
USB Output
USB 1 & 2 (QC3.0): 5V/3A
9V/2A 12V/1.5A
USB-C PD 100W: 5V/3A
9V/3A 12V/3A15V/3A
20V/3A 20V/5A (In/Out)
USB-C PD 24W: 5V/3A 9V/2A
12V/2A
DC Output DC*1+Cig Port*1. 12V/10A (Max)
AC Output AC 120V/60Hz
AC Power Continuous Power: 1000W
Battery Indicator Symbol of battery cell, one cell
represents 25% of power
Ambient Temperature
Charging: 0 - 104°F
Discharging: -50 - 104° F
Storage: 0 - 95°F
Cycle Life 500+ Times

3
lippert.com 432-LIPPERT (432-547-7378) Rev: 11.09.22
Trekker™1000W
Portable Power Station
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006494
1. Anderson Port
2. DC Input Indicator
3. DC Input Port
4. DC Output
5. DC Power Button
6. DC12V Car Cigarette Port
7. AC Power Button
8. AC Output
9. USB Power Button
10. USB-C PD 100W Port
11. USB1 QC3.0 Port
12. USB2 QC3.0 Port
13. USB-C PD 24W Port
14. LCD Display Screen
15. Cooling Fan
12
1
86 7
11
14
13
4
3
15
2
10
Left/Right View
Back View
Front View
5 9

4
lippert.com 432-LIPPERT (432-547-7378) Rev: 11.09.22
Trekker™1000W
Portable Power Station
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006494
A
B C D E F
I
G H
LCD Display Screen
A. - Battery Life Indicator
The battery indicator when full will show four cells within,
with each cell representing 25%. When charging, the cells
will flash to represent the current state of the charging
process. Once complete the screen will display “FUL”.
B. - AC Output Symbol
Long-press the button located by the AC output section of
the unit to activate the outputs. The display will show the
“AC” symbol when activated. To turn off, long-press the AC
button again.
It is important to turn off the AC outputs when not in use
to avoid battery drain. These outputs are supported during
the charging process.
C. - USB Output Symbol
Short-press the button located by the USB section of the
unit to activate the ports.
The display will show either the “USB” symbol or the “USB
TPYE-C” symbol dependent on the device plugged into the
respective port.
To turn off, short-press the button.
D. - High Temperature Alarm Symbol
This icon will be displayed if the operating temperature of
the unit is too high during use.
E. -Type-C Output Symbol
Short-press the button located by the USB section of the
unit to activate the ports. The display will show either the
“USB” symbol or the “USB TYPE-C” symbol dependent
on the device plugged into the respective port. To turn off,
short-press the button.
When charging the unit utilizing the PD 100W port, the
display will show the “USB TYPE-C” symbol.
F. - DC Output Symbol
Short-press the button located by the DC outputs to
activate the ports. The “DC” symbol will be displayed when
device is plugged into either of the ports.
To turn off, short-press the button.
G. OVERLOAD - Overload Alarm Symbol
When the product is overloaded, the overload alarm
symbol will be on, the corresponding port symbol will flash,
the automatic protection will be turned on and the output
will be closed. After the load is removed, the symbol will
be closed, AC will be automatically recovered, and other
buttons can be pressed for recovery.
H. - Real Time Power Display Symbol
Whether the unit is being charged or discharged (powering
devices), the display will represent the amount of power
being used or delivered at the current time. This number
will fluctuate in real time with the plugged in
devices demand.
I. - Real Time Use of Time Symbols
When the unit is being charged, this display will provide
the amount of time estimated until full charge is achieved.
When the unit is being used to power a device, the display
will show the amount of time estimated until charge
is required.

5
lippert.com 432-LIPPERT (432-547-7378) Rev: 11.09.22
Trekker™1000W
Portable Power Station
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006494
Operation
PLEASE STAY AWAY FROM TV, RADIO AND
OTHER EQUIPMENT TO AVOID INTERFERENCE
DURING CHARGING.
Charging Modes
Plug the Power Adapter (Fig. 1A) into the wall outlet (Fig. 1B).
Next plug the power adapters round plug into the DC input
(Fig. 1C). The Trekker 1000W is fully charged in about 9
hours.The Battery Life indicator will show full when this is
achieved (Fig. 1D).
To charge the Trekker 1000W with the USB-C PD 100W
input (Fig.3C), plug charger (sold separately) (Fig.3A) into the
PD 100W input to begin the charging process. The Trekker
1000W is fully charged in about 5-7 hours. The Battery Life
indicator will show full when this is achieved (Fig. 3D).
Fig.1
Fig.2
A B C
D
A
B C
D
Plug the car charger (Fig. 4A) into the car charging unit in
the vehicle (Fig. 4B). Then plug the power adapter’s round
plug into the DC input (Fig. 4C). The Trekker 1000W is fully
charged in about 9 hours. The Battery Life indicator will
show full when this is achieved (Fig.4D).
Fig.3
A B C D
NOTE: When Storing the Trekker 1000W for extended
periods of time, be sure to disconnect all cables prior to
storage.
NOTE: To maintain the battery health of the Trekker
1000W, it is recommended to charge the unit every 3
months or at least once in a 6-month period.
Fig.4
A B
C
B
When utilizing solar panels (sold separately) to charge
the Trekker 1000W, it is important panel wattage does not
exceed 1000W/18V (Fig. 5A). Plug the solar panel into the DC
Input (Fig. 5B). The Trekker 1000W is fully charged in about
10-15 hours. The Battery Life Indicator will show full when
this is achieved (Fig. 5D).
To charge the Trekker 1000W with the optional Rapid Charger
(sold separately) (Fig. 2A), plug charger into the Anderson
Port input (Fig.2C) to begin the charging process. The Trekker
1000W is fully charged in about 5 hours. The Battery Life
indicator will show full when this is achieved (Fig. 2D).
A B D
C
When utilizing solar panels (sold separately) to charge
the Trekker 1000W, it is important panel wattage does
not exceed 1000W/30V (Fig. 6A). Plug the solar panel into
the Anderson Input (Fig. 6B). The Trekker 1000W is fully
charged in about 10-15 hours. The Battery Life Indicator
will show full when this is achieved (Fig. 6D).
A
C
Fig.5
Fig.6

6
lippert.com 432-LIPPERT (432-547-7378) Rev: 11.09.22
Trekker™1000W
Portable Power Station
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006494
Product Usage Tips
• Please observe ambient temperature range of 50-68 F
for optimal performance/charging.
• Be aware of electronic inference which can potentially
disrupt the unit during the charging process.
• When Storing the Trekker 1000W for extended periods of
time, be sure to disconnect all cables prior to storage.
• To maintain the battery health of the Trekker 1000W, it
is recommended to charge the unit every 3 months or at
least once in a 6-month period.
Recycling
Follow proper recycling guidelines for disposal of this
product.
Maintenance
PLEASE AVOID STORING THIS DEVICE WITH COINS,
BRACELETS, KEYS AND OTHER METAL OBJECTS.
STORING WITH THESE ITEMS CAN CAUSE A SHORT
CI RCUIT.
• Do not heat the Trekker 1000 or submerge in water or
other liquids and avoid high temperatures, including direct
exposure to the sun.
• Do not use or store the Trekker 1000 in a highly humid
or dusty environment.
• Do not drop, place heavy objects on or damage the
Trekker 1000.
• Please dispose of the end-of-life Trekker 1000
according to regulations, and do not dispose of the built-
in battery as household waste.
• Use the Trekker 1000 as directed and avoid electric
shock.

7
lippert.com 432-LIPPERT (432-547-7378) Rev: 11.09.22
Trekker™1000W
Portable Power Station
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006494
Notes
lippert.com 432-LIPPERT (432-547-7378) Rev: 11.09.22CCD-0006494

8
lippert.com 432-LIPPERT (432-547-7378) Rev: 11.09.22
Trekker™1000W
Portable Power Station
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006494
Manual information may be distributed as a complete
document only, unless Lippert provides explicit consent
to distribute individual parts.
All manual information is subject to change without
notice. Revised editions will be available for free
download at lippert.com. Manual information is
considered factual until made obsolete by a revised
version.
Please recycle all obsolete materials and contact
Lippert with concerns or questions.
