Litelume Flood Light Small User manual
Flood Light Small
Installation Instructions
LITELUME™ seeks to deliver the most advanced and efficient LED technology. Due to
technology progression, specifications may change. We reserve the right to update product
specifications without notice. Contact LITELUME™ for the most up-to-date data.
www.litelume.com
833.LED.LUME
Page 1/2
Rev Date: 08/17/2018
©Lite Lume Corporation 2018
Warning
1.To avoid electric shock, disconnect power at source prior to installation.
2.The installation should be performed by qualified electricians or lighting technicians.
3.This product must be installed in accordance with the national electric code (NEC) and all applicable federal, state and local
electric codes and safety standards.
4.Disconnect product and allow cooling prior to servicing.
5.Any alteration or modification of this product is expressly forbidden as it may cause serious personal injury, death, property
damage and/or product malfunction.
6.To prevent product malfunction and/or electrical shock this product must be properly grounded.
7.Suitable for operation in ambient temperatures ranging from -40°c to 45°c.
8.This product must be installed in accordance with the applicable installation code by a person familiar with the construction and
operation of the product and the hazards involved.
1/2” Knuckle Mount Installation
Silicone gasket
1/2 Screw bracket
1/2 Nut
Waterproof ring
Screw
Wire Connection
Black
White Neutral
Green/Yellow Green
Ground
Live
1. Mount this fixture to any metal 1/2’’ NPS threaded mounting (supplied by others) , please mount the fixture prior to make wiring
connection.
2. Route electrical leads through the mounting hole.
3. Seal knuckle threads with sealing compound (provided by others). Secure the mounting fitter to fixture with lock nut.
4. Make wire connection (see wiring diagram above).
5. Adjust aiming angle of the fixture by loosening the pivot screw. Use visual angle indicators to set desired angle, then tighten
pivot screw.
Trunnion Mount Installation
Screw Trunnion
1. Fix trunnion on the wall by screws.
2. Wire Live and Neutral Cable respectively. Watch out for joint point and screw them well in case of electric leakage.
3. Adjust light by loosening screws to achieve different installation angle.
4. Waterproof measurement are necessary when connecting to external power supply cord.
Troubleshooting
1. Check that the line voltage at the fixture is correct. Refer to wiring diagram above.
2. Is the fixture grounded properly?
3. Be sure the photocell, if used, is functioning properly.
Flood Light Small
Installation Instructions
LITELUME™ seeks to deliver the most advanced and efficient LED technology. Due to
technology progression, specifications may change. We reserve the right to update product
specifications without notice. Contact LITELUME™ for the most up-to-date data.
www.litelume.com
833.LED.LUME
Page 2/2
Rev Date: 08/17/2018
©Lite Lume Corporation 2018
Wiring Diagram
For 0-10V Dimming Version, please refer to wiring diagram below.
Troubleshooting
1. Check that the line voltage at the fixture is correct. Refer to wiring diagram above.
2. Is the fixture grounded properly?
3. Be sure the photocell, if used, is functioning properly.
