LiteOn LVW-5001 User manual

LVW-5001 / LVW-5005XS
User's Manual
http://www.liteonit.com/DC/english/liteonit.htm
USA: LITE-ON (USA) International Inc.
42000 Christy Street, Fremont, CA 94538
Tel: [phone] Fax: [phone]
Customer Call Center: 1-888-8-LITEON (1-888-854-8366)
1-866-269-5113 (French)
Service e-mail: [email protected]
P/N 7819901179A

1
Table of contents
Getting started
Accessories .......................................................................... 1
Important safety instructions ............................................... 2
Warnings, cautions and others ............................................ 3
Disk information .................................................................. 4
Controls and displays
Remote control .................................................................... 5
Front panel connections ...................................................... 6
Display window ................................................................... 6
Rear panel connections ...................................................... 7
Connecting up
Connecting the antenna cable and television .................... 8
For better picture ................................................................. 9
Component out ......................................................... 9
S-Video out ............................................................... 9
For better sound ................................................................ 10
Connection to a stereo audio amplifier or receiver ...... 10
Connection to a digital audio device .......................... 10
Digital out optical ..................................................... 10
Digital out coaxial .................................................... 10
Connecting satellite receiver or cable box ....................... 11
Quick setup
Initial setup ........................................................................ 12
Aspect ratio ........................................................................ 12
Video outptut ..................................................................... 12
Audio ............................................................................... 12
TV channel setup
Automatic TV channel search ........................................... 13
Adding or deleting TV channel manually ......................... 13
Fine-tuning TV channel manually..................................... 13
Swapping TV channel manually (following TV) ............... 13
Channel Editing ................................................................. 14
Recording
Before recording ............................................................... 15
Recording television programs ......................................... 15
Adding new recordings ..................................................... 16
Changing chapter intervals ............................................... 16
Playback with the DVD menu ........................................... 16
Recording from a VCR or V8 / Hi8 / DV ............................. 17
The front panel and rear panel connection ................. 17
DV recording ..................................................................... 18
Use “Easy Guider” to record DV signal ...................... 18
“One touch record” to record the DV signal ..................... 19
DV control .......................................................................... 19
Record on CD-R/CD-RW discs ............................................ 20
Create a correct disc format ..................................... 20
VCD/SVCD recording ............................................... 20
Audio CD recording .................................................. 20
Timer recording
Setting the timer ................................................................ 21
Playback
Basic playback .................................................................. 22
POWER, OPEN/CLOSE, PLAY, F.F., REW. ........... 22
NEXT, PREVIOUS ................................................... 22
PAUSE/STEP, STOP, DISPLAY .............................. 22
TOP MENU, MENU ................................................. 22
Navigation operation ......................................................... 23
SLOW, SEARCH .................................................... 23
A-B REPEAT,SUBTITLE .......................................... 23
AUDIO, ANGLE ....................................................... 23
INFORMATION ........................................................ 23
JPEG/MP3 file and Audio CD playback
JPEG file playback ............................................................ 24
MP3 file playback .............................................................. 24
Audio CD playback ............................................................ 24
Slide show .................................................................. 24
Editing
DVD menu and Edit menu ................................................. 25
Naming a title .................................................................. 25
Protecting a title ................................................................ 25
Overwrite a title ................................................................. 25
Erasing a title .................................................................. 25
Easy Guider
Playback ............................................................................ 26
Record on DVD .................................................................. 26
Record on CD-R/CD-RW ..................................................... 27
VCD/SVCD/Audio CD recording ............................... 27
Erase ............................................................................... 28
Finalize .............................................................................. 28
GUI operation
Firmware update
Glossary
Specifications
Troubleshooting Guide
Accessories
Please check and identify the supplied accessories.
1x Remote control 1x AC Power cord 2x Batteries

2
Important safety instructions
1) Read instructions.Read all the safety and operating
instructions before operating the product.
2) Retain instructions. Keep the safety and operating
instructions for future reference.
3) Heed warnings. Adhere to all warnings on the product and
in the operating instructions.
4) Follow instructions. Follow all operating and use
instructions.
5) Cleaning - Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners. Use
a damp cloth for cleaning.
6) Attachments - Do not use attachments not recommended
by the product manufacturer as they may cause hazards.
7) Water and Moisture - Do not use this product near water
for example, near a bathtub, washbowl, kitchen sink, or
laundry tub, in a wet basement, or near a swimming pool.
8) Accessories - Do not place this product on an unstable
cart, stand, tripod, bracket, or table. The product may fall,
causing serious injury to a child or adult, and serious damage
to the product. Use only with a cart, stand, tripod, bracket, or
table recommended by the manufacturer or sold with the
product. Any mounting of the product should follow the
manufacturer’s instructions and should use a mounting
accessory recommended by the manufacturer.
9) CART - A product and cart combination should be moved
with care. Quick stops, excessive force, and uneven surfaces
may cause the product and cart combination to overturn.
10) Ventilation - Slots and openings in the cabinet provide
ventilation, ensure reliable operation of the product, and
protect it from overheating. Do not block or cover these
openings. The openings should never be blocked by placing
the product on a bed, sofa, rug, or other similar surface. Do
not place this product in a built-in installation such as a
bookcase or rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
11) Power Sources - This product should be operated only from
the type of power source indicated on the marking label. If you
are not sure of the type of power supply to your home, consult
your product dealer or local power company. For products
intended to operate from battery power, or other sources, refer
to the operating instructions.
12) Location - The appliance should be installed in a stable
location.
13) Non-Use Periods - The power cord of the appliance should
be unplugged from the outlet when left unused for a long
period of time.
14) Grounding or Polarization -
• If this product is equipped with a polarized alternating current
line plug (a plug having one blade wider than the other), it
will fit into the outlet only one way. This is a safety feature. If
you are unable to insert the plug fully into the outlet, try
reversing the plug. If the plug should still fail to fit, contact
your electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the polarized plug.
• If this product is equipped with a three-wire grounding type
plug, it will only fit into a grounding type power outlet. This is
a safety feature. If you are unable to insert the plug into the
outlet, contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the grounding
type plug.
15) Power Cord Protection - Power supply cords should be
routed so that they are not likely to be walked on or pinched
by items placed upon or against them, paying particular
attention to cords at plugs, convenience receptacles, and the
point where they exit from the product.
16) Outdoor Antenna Grounding - If an outside antenna or
cable system is connected to the product, be sure the
antenna or cable system is grounded so as to provide some
protection against voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANSI/NFPA 70,
provides information with regard to proper grounding of the
mast and supporting structure, grounding of the lead-in wire to
an antenna discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
17) Lightning - For added protection for this product during a
lightning storm, or when it is left unattended and unused for
long periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will prevent
damage to the product due to lightning and power-line surges.
18) Power Lines - An outside antenna system should not be
located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power
lines or circuits. When installing an outside antenna system,
take extreme care to keep it from touching such power lines
or circuits; contact with them might be fatal.
19) Overloading - Do not overload wall outlets, extension cords,
or integral convenience receptacles. This can result in a risk of
fire or electric shock.
20) ObjectsandLiquids-Do not push objects of any kind
into this product through openings; they may touch
dangerous voltage points or short out parts, resulting in a
fire or electric shock. Liquids of any kind should not be
used on or around this product.
21) Servicing - Do not attempt to service this product yourself.
Opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service
personnel.
22) Damage Requiring Service - Unplug this product from the
wall outlet and refer servicing to qualified service personnel
under the following conditions:
• When the power supply cord or plug is damaged,
• If liquid has spilled or objects have fallen into the product,
• If the product has been exposed to rain or water,
• If the product does not function properly after following the
operating instructions, contact Lite-On Customer Service for
technical support.
• If the product has been dropped or damaged in any way,
• When the product exhibits a distinct change in performance.
This indicates a need for service.
23) Replacement Parts - When replacement parts are
required, be sure the service technician uses replacement
parts specified by the manufacturer or having the same
characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, or other hazards.
24) Safety Check - Upon completion of any service or repairs to
this product, ask the service technician to perform safety
checks to determine that the product is in proper operating
condition.
25) Wall or Ceiling Mounting - Mount the product to a wall or
ceiling only as recommended by the manufacturer.
26) Heat – Keep this product away from heat sources, such as
radiators, heat registers, stoves, or amplifiers.
27) Battery Usage – Battery leakage may result in bodily injury
or damage to the unit. In order to avoid battery problems,
please follow these instructions.
• Install all batteries correctly, with + and - aligned as marked
on the unit.
• Do not mix batteries (old/new, carbon/alkaline, etc.).
• Remove batteries when the unit is not used for a long time.

3
Warnings, cautions and others
THE FOLLOWING APPLIES ONLY FOR U.S.A.
CAUTION!
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
IMPORTANT FOR LASER PRODUCTS
1) CLASS 1 LASER PRODUCT
2) DANGER: Visible and invisible laser radiation when open
and interlock failed or defeated. Avoid direct exposure to beam.
3) CAUTION: Do not open the top cover. There are no user
serviceable parts inside the Unit; leave all servicing to qualified
service personnel.
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN THE COVER AND DO NOT REPAIR YOURSELF
REFER SERVICING TO QUALIFIED PERSONNEL.
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR
PRODUCT DAMAGE, DO NOT EXPOSE THIS APPARATUS TO
MOISTURE AND ENSURE THAT OBJECTS FILLED WITH LIQUIDS,
SUCH AS VASES, SHALL BE PLACED AWAY FROM THE
APPARATUS.
The lighting flash with arrowhead symbol,
within an equilateral triangle, is intended
to alert the user to the presence of
uninsulated “dangerous voltage” within the
product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to humans.
The exclamation point within an equilat-
eral triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION! –– POWER button
Disconnect the mains plug to shut the power off completely.
The POWER button in any position does not disconnect the
main line. Power can be controlled from the remote.
CAUTION!
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE THE COVER OF THIS UNIT.
THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby
Laboratories.
CAUTION!
• CD-R/RW discs recorded using a personal computer or a CD
Recorder may not play if the disc is damaged or dirty, or if
there is dirt or condensation on the player’s lens.
• Unfinalized CD-R/RW discs can be played, but not all time
information (playing time, etc.) will be displayed.
• Check the copyright laws in your country before recording
from DVD VIDEO, SVCD, Video CD, Audio CD, MP3 and
JPEG discs. Recording of copyrighted material may infringe
copyright laws.
Legal Notices Regarding
Macrovision’s Property Rights
“U.S. Patent Nos. 4,631,603; 4,577,216; 4,819,098; 4,907,093;
and 6,516,132.”
“ This product incorporates copyright protection technology
that is protected by U.S. patents and other intellectual
property rights. Use of this copyright protection technology
must be authorized by Macrovision, and is intended for
home and other limited viewing uses only unless otherwise
authorized by Macrovision. Reverse engineering or disas-
sembly is prohibited.”
PRODUCTS WITH 525P PROGRESSIVE SCAN OUTPUTS
NOTICE REQUIREMENTS
“CONSUMERS SHOULD NOTE THAT NOT ALL HIGH DEFINITION
TELEVISION SETS ARE FULLY COMPATIBLE WITH THIS
PRODUCT AND MAY CAUSE ARTIFACTS TO BE DISPLAYED IN
THE PICTURE. IN CASE OF 525 PROGRESSIVE SCAN PICTURE
PROBLEMS, IT IS RECOMMENDED THAT THE USER SWITCH
THE CONNECTION TO THE “STANDARD DEFINITION” OUTPUT.
IF THERE ARE QUESTIONS REGARDING OUR TV SET COMPAT-
IBILITY WITH THIS MODEL 525P DVD PLAYER, PLEASE
CONTACT OUR CUSTOMER SERVICE CENTER.”

4
Playable Disc types
Disc information
Video System (NTSC & PAL)
This DVD-Recorder supports both NTSC&PAL system.
Aspect Ratio
4:3 (Letter Box) Standard
4:3 Pan&Scan
16:9 (Wide-Screen)
Others
Audio : Appears at the beginning of a scene record with
multiple audio languages.
Subtitle : Appears at the beginning of a scene recorded
with multiple subtitle languages.
Angle : Appears at the beginning of a scene recorded
from multiple angles.
All Write Technology (LVW-5005XS model only)
“ALL WRITE” technology makes it alright to record on almost
all of the recordable discs. (DVD+RW, DVD+R, DVD-RW,
DVD-R, CD-RW or CD-R discs)
Note:
The DVD-Video/DVD+RW/DVD+R/DVD-R/DVD-RW/CD-R/CD-RW
Logos are trademarks of the respective companys.
For best result use discs with the above logos and that conform to
specifications. The unit cannot play other discs correctly. Do not
use irregular shaped discs (e.g. heart-shaped), as these can
damage the unit.
It may not be possible to play CD-R, CD-RW, DVD-R, DVD-RW,
DVD+R, DVD+RW in all cases due to the type of disc or condition
of the recording.
Unplayable disc types
The unit does not play back discs listed below. If you try to play
back these discs, excessive noise may cause damage to
speakers.
1) Unfinalized discs from other DVD-Recorder.
2) DVD-ROM, DVD AUDIO, CD-ROM, PHOTO CD, SACD
3) DVD-RAM, DVD-VR format
Region Code of DVD-Video
This unit can playback DVD-VIDEO discs compatible with
the region code is printed on the rear of the unit.
Examples of playable DVD-VIDEO discs:
Notes:
Audio System
Dolby Digital Linear PCM
DTS (Digital Theater Systems)
Recordable Disc types
Disc Types Logos Characteristics
DVD-VIDEO This unit can playback DVD-Video discs and the
region code is printed on the rear of the unit.
DVDЁR/RW
DVDЀR/RW
DVDЁR, DVDЁRW and DVDЀR, DVDЀRW, discs
written in the DVD-Video format and finalized.
Video CD (VCD)
Super Video CD (SVCD)
Video with CD sound, VHS quality & MPEG-1
compression technology.
Audio CD (CD-DA) CD is recorded as a Digital Signal with better audio
quality, less distortion and less deterioration of audio
quality over time.
CD-R/RW (JPEG/MP3) This unit can play CD-R and CD-RW discs recorded
with Audio CD or Video CD format, or with
JPEG/MP3 files. Close the sessions or finalize the
disc after recording.
Disc Types Logos Characteristics
DVDЀR/RW
DVDЀR disc written in the DVDЀVR format.
DVDЀRW disc written in the DVDЀVR format.
DVDЁR/RW
(LVW-5005XS model only)
DVDЁR disc written in the DVDЀVR format.
DVDЁRW disc written in the DVDЀVR format.
CDЁR/RW
(LVW-5005XS model only)
CDЁR/CDЁRW disc written in the MPEG1 or MPEG2
video format or written in PCM Audio mode.
“DVD DualTM” &
“AllWriteTM”
(LVW-5005XS model only)
“DVD Dual” -- Written on both DVDЀR/DVDЀRW/
DVDЁR/DVDЁRW disc.
“All Write” – Written on all recordable DVD disc and
CDЁR/CD-RW disc.

5
Controls and displays
The Remote Control
1) Open/Close button ( OPEN/CLOSE)
2) CH button (Channel)
3) Display button (DISPLAY)
4) Setup button (SETUP)
5) Top menu button
6) Easy Guider button ( Guider)
7) Pause/Step button ( PAUSE/STEP)
8) Play button ( PLAY)
9) F.F./REW. button( F.F/ REW.)
10) Source buttons ( SOURCE)
11) Record button ( RECORD)
12) Power button ( POWER)
13) Numbered button (1~9, 0)
14) Menu button (MENU)
15) Cursor (), Enter button (ENTER)
16) Navigation button ( NAVI)
17) Next/Previous button
( NEXT/ PREVIOUS)
18) Stop button ( STOP)
19) Edit button (EDIT)
20) Timer button (TIMER)
Remote Control
To install batteries
Open the battery compartment and
insert the batteries. Make sure the
polarity (+ and -) matches the marks
inside the remote control.
Do not use rechargeable type batteries.
Remote sensor
The remote has a range of
approximately 3M and works
best when pointed directly at
the unit. (at angles up to 30°
from the front of the unit)

6
Front panel connections
(for reference only)
Display window
Names of parts and controls
1) POWER ON/OFF Button
Turns the recorder on and off.
2) OPEN/CLOSE Button
Opens or closes the disc tray.
3) DISC TRAY
Holds discs securely during recording or playback
operations.
4) PLAY Button
Plays a disc.
5) STOP Button
Stops playing or recording a disc.
6) PAUSE Button
Pauses playback or recording.
7) DISPLAY Window
Operation indicators are displayed here.
8) REC Button
Starts recording.
9) SOURCE Button
Select equipment connected to the line inputs.
10) DV-LINK (IEEE-1394) Jack
Connects digital video camcorders to this DVD Recorder.
11) LINE IN 1 (VIDEO/AUDIO L/R) Jacks
Connects the video and audio input to external equipment.
CONTROLS AND DISPLAYS
Display window function
1) Play indicators
2) DVD indicators
3) SVCD indicators
4) VCD indicators
5) CD indicators
6) MP3 indicators
7) JPEG indicators
8) DVD+RW/DVD-RW/CD-RW indicators
9) DVD+R/DVD-R/CD-R indicators
10) Record indicators
11) Pause indicators
12) Multi-information window
13) Timer recording mode

7
Controls and Displays
Rear panel connections
Names of parts
1) VHF/UHF IN/OUT jacks
Antenna cables input and output.
Note:
Playback signals don’t go through here. Make
proper connections before using this DVD Recorder.
2) LINE IN (S-VIDEO) jack
S-Video signal input.
3) AV2 Rear IN (VIDEO/AUDIO L/R) jacks
Composite signal input.
4) COMPONENT VIDEO OUTPUT (Y/Pb/Pr) jacks
Component signal output.
5) LINE OUT (VIDEO/AUDIO L/R) jacks
Composite signal output.
6) LINE OUT (S-VIDEO) jack
S-Video signal output.
7) DIGITAL AUDIO OUT (COAXIAL) jack
Connects an amplifier or receiver having a digital input jack.
8) DIGITAL AUDIO OUT (OPTICAL) jack
Connects an amplifier or receiver having a digital input jack.
9) AC IN terminal

8
Connecting up
Before making connections
1) Do not connect the AC power cord until all other connections are made.
2) Connect VIDEO OUT of the unit directly to the video input of your TV. Connecting VIDEO OUT of the unit to a TV via a VCR may cause
a viewing problem when playing back a copy-protected disc. You may also have a viewing problem when connecting the unit to an
integrated TV/Video system.
Note:
1. Do not place this unit on top of other equipment that may generate heat. Excessive heat may cause malfunction of this unit.
2. For Digital Cable and Satellite TV users please connect your decoder’s output to this unit’s input.
Connecting to the antenna outlet and the television
Before using the unit, follow the steps below to connect the unit to the antenna cable and TV.
Connecting to a TV with COMPOSITE jacks
Use a RF cable (supplied) to connect the RF IN on the unit to the antenna outlet.
Use a RF cable (same as supplied) to connect the RF OUT on the unit to the RF input on the television.
Use AUDIO/VIDEO cables (supplied) to connect the AUDIO/VIDEO output on the unit to the audio/video input on the television.

9
For better picture
1. Connecting to a TV via S-Video out
Connecting to a TV with a S-Video jack
Use a S-Video cable (not supplied) to connect the S-Video output on the unit to the S-Video input on the television.
Note:
1.Enter system setup to enable S-Video (refer to the section titled “Quick Setup”).
2. When using S-Video connections, please remove all other video output connections.
3. In this configuration, the Red and White audio connections are required.
There are two types of connections (S-Video, and Component video) that provide higher quality
viewing.
2. Connecting to a TV via COMPONENT out
Connecting to a TV with component jacks
Use COMPONENT cables (not supplied) to connect the COMPONENT output on the unit to the COMPONENT input on the
television.
Note:
1. Enter system setup to enable COMPONENT (refer to the section titled “Quick Setup”).
2. When using COMPONENT connections, please remove all other video output connections.
3. In this configuration, the Red and White audio connections are required.

10
For better sound
Connecting to a stereo audio amplifier or receiver
Use an audio cord (same as supplied) to connect the AUDIO OUT
on the DVD recorder to the audio input on a stereo amplifier or a
receiver.
There are two types of audio connections, analog and digital.
Connecting to a digital audio device
Connect an amplifier with Dolby Digital and DTS decoders to
enjoy surround sound.
Digital out optical
Use a fiber-optic cable (not supplied) to connect the DIGITAL
OUT OPTICAL (digital optical output) on the DVD recorder to
the digital optical input on an stereo amplifier or a receiver.
Digital out coaxial
Use a coaxial cable (not supplied) to connect the DIGITAL OUT
COAXIAL (coaxial digital output) on the DVD recorder to the
coaxial digital input on an stereo amplifier or a receiver.

11
CONNECTING SATELLITE RECEIVER OR CABLE BOX
Connecting the cable box/satellite box and television
Before using the unit, follow the steps below to connect the unit to the cable box and TV.
Connecting to a satellite box or a cable box with COMPOSITE jacks
Use a RF cable (supplied) to connect the RF IN on the cable box/satellite receiver to the antenna outlet.
Use a RF cable (same as supplied) to connect the RF OUT on the cable box/satellite receiver to the RF input on the DVD Recorder.
Use a RF cable (same as supplied) to connect the RF OUT on the DVD Recorder to the RF IN on the television.
Use AUDIO/VIDEO cables (supplied) to connect the AUDIO/VIDEO output on the unit to the audio/video input on the television.

12
Quick setup
Manually setting the date and time
Set the date manually
1. Press [Setup] on the remote control. The setup menu will
appear.
2. Select “System” using [] or [] and press [ENTER].
3. Select “Date” using [] or [] and press [ENTER].
4. Change the day/month/year in the highlighted field using []
or [] or the number buttons 0..9 on your remote control
and confirm with [ENTER]
5. When all settings are correct, press [] until return to the
main level.
6. To exit the setup menu, press [Setup].
Set the time manually
1. Press [Setup] on the remote control. The setup menu will
appear.
2. Select “System” using [] or [] and press [ENTER].
3. Select “Time” using [] or [] and press [ENTER].
4. Change the “hour/minute/second” in the highlighted field
using [] or [] or the number buttons (0~9) on your remote
control.
5. Change the “AM/PM” using [] or [] and confirm with
[ENTER].
6. When all settings are correct, press [] until return to the
main level.
7. To exit the setup menu, press [Setup].
Note:
Check that the clock is correctly set before setting the timer
recording. If not, the timer recording cannot be made.
Audio
Digital Output
PCM / Bit Stream
(Enable digital audio output with PCM or encoded data)
DTS Out
ON / OFF
Progressive scan mode
You can change the video output mode when you press
[SETUP] button and to select the “System-->Video
Output-->Progressive”.
(Video will not be displayed correctly if connected to an
incompatible television.)
Video output mode:
480I: Interlace video
480P: Progressive video
Notes:
You must connect to the component video input
terminals on a 480P compatible television.
Setting video output
1. Press the [Setup] button and the setup menu will be
displayed.
Aspect ratio
Select “4:3” (regular) or “16:9” (widescreen) to suit your
television. If you have a regular 4:3 television, you can also
select how video on some discs is presented.
4:3 Letter Box
(select when you connect the unit to a
normal (4:3) TV.)
When playing back a DVD-VIDEO disc
recorded in wide picture format, the
picture is shown with black bars at the
top and bottom.
4:3 Pan & Scan
(select when you connect the unit to a
normal (4:3) TV.)
When playing back a DVD-VIDEO disc
recorded in wide picture format, the
picture is zoomed to fill the screen
vertically, and the left and right sides of
the image are chopped off. Note, however, that the picture will
be shown in the 4:3 LB mode even if you select the 4:3 PS
mode depending on the disc.
16:9 Wide Screen
(select when you connect the unit to a
wide-screen (16:9) TV.)
Note:
You cannot change the “Aspect Ratio” setting during playback.
2.
Selectystem ?using [
T
] or [] and press [ENTER].
3. Select “video output” as “COMPONENT” or “PROGRESSIVE”
using [] or [] and press [ENTER].
4. When all settings are correct, press [] to return to the
main menu.
5. To exit the setup menu, press the [Setup] button.
Initial setup
Remote control & Setup menu
Confirm the antenna is connected correctly, and follow the steps
below to make the personal adjustments for using the DVD-
Recorder.
1. Press [ POWER] to turn on the unit.
2. Press [SETUP] to display the setup menu.
3. Press [] [] to select the “System”, “Language”,
“Playback”, “Record”, “Audio”, “TV Tuner” and press [] or
press [] to return to the previous or next menu.
4. Press [] [] to select the item that you want to change
and press [] or press [Enter].
System --- Video Output
System --- TV Type ---> Date ---> Time
Language --- OSD
Playback -- Aspect Ratio
Audio --- Digital Output (PCM / Bit Stream)
Record --- Quality ( HQ, SP, EP and SLP )
5. Press [ENTER] to confirm the setting.
6. Press [SETUP] to exit the setup menu or press [] to return
to the previous menu.
Note:
To record TV programs using the timer record feature, you must
set the time accurately.

13
TV channel setup
Automatic TV channel search
When the automatic channel search function is activated, the TV
channels are searched and stored in a specific order. If the channel
assignments of your TV content provider changes or if you are
reinstalling the DVD-Recorder, you may need to start this proce-
dure again.This will replace the stored TV channel with the new
ones.
1.Ensure the antennas are securely connected to
the DVD-Recorder.
2.Switch on the TV set and the DVD-Recorder.
3.Press [SETUP] to bring up the “SETUP” menu,
press [] [] to select the “TV TUNER” and
press [].
4.Press [] [] to select “Utilities” and press
[].
5.Press [] [] to select “START SCAN” and
press [ENTER] to start auto channel search.
6.The auto TV channel search starts. The proce-
dure may take a few minutes.
7.When all the TV channel have been searched
and stored, press [SETUP] to exit.
Adding or deleting TV channel manually
After you have performed the automatic channel search, you may
like to add or delete some of the TV channels. This function allows
adding or deleting channel manually.
1.Press [SETUP] to display the “SETUP” menu,
press [] [] to select “TV TUNER” and press
[].
2.Press [] [] to select “Uilities” and press
[].
3.Press [] [] to select “Add/Delete” and press
[ENTER] to bring up the add/delete menu.
4.Press [] [][] [] to select the channel(s)
that you want to add or delete and press
[ENTER] to confirm it.
Move the cursor to the TV channel and you can press [ENTER]
again to cancel delete operation.
5.Press [] [][] [] to select “EXIT” and
press [ENTER] to save setting and exit the add/
delete menu.
Fine-tuning TV channel manually
After you have performed the automatic channel search you may
like to fine-tune the TV channel signal manually. Follow the steps
below to complete fine tune.
1.Press [SETUP] to bring up the “SETUP” menu,
press [] [] to select the “TV TUNER” and
press [].
2.Press [][] to select “FINE” and press [].
3.Press [][] to fine-tune the channel signal.
Swapping TV channel manually (following TV)
This function allows users to manually swap the TV channel order
stored in DVD-Recorder to match the TV channel order stored in
users’ TV set.
1.Press [SETUP] to display the “SETUP” menu,
press [] [] to select the “TV TUNER” icon
and press [].
2.Press [] [] to select “Swap” and press
[ENTER] to bring up the “SWAP” menu.
3.Select the TV channel(s) to be swapped and
press [ENTER] to mark it/them.
4.Press [] [][] [] to select a new channel
position and press [ENTER] to swap.
5.To swap more TV channels, repeat step “3” to
complete the settings.
6.Select “EXIT” to save the setting and exit the
“SWAP” menu.

14
Channel Editing
Before channel editing
Ensure that the antenna cables are securely hooked up to the
unit.
Adding or deleting TV channel manually
1.Turn on the TV set and the DVD-Recorder,
and press [Source] to switch the input signal
source of the unit to “TV.”
2.Press [EDIT] to bring up the “Channel Editor”
menu, press [] [] to select one of the TV
channels and press [ENTER].
Move the cursor to the TV channel to make the selection and
press [ENTER] again to cancel the delete operation.
Inserting the TV channels
1.Press [EDIT] to bring up the “Channel Editor”
menu, press [] [] to select one of the TV
channels and press [].
2.Press [] [] to select “Insert to” and press
[ENTER].
3.Press [] [][] [] to enter the “Channel
number,” and press [ENTER]. The channel will
be moved to where you want to.
Swapping TV channels
This function allows you to manually swap the TV channel order
stored in the unit to match the TV channel order stored in your TV
set.
1.Press [EDIT] to bring up the “Channel Editor”
menu, press [] [] to select one of the “TV
Channel” and press [].
2.Press [] [] to select “Swap with” and
press [ENTER].
3.Press [] [][] [] to enter the “Channel
number,” and then press [ENTER] to swap. The
order of the channels will be swapped with the
channel number selected.
4.To swap other TV channels, repeat step 3 to
complete the settings.
5.Press [] [][] [] to select “EXIT,” press
[ENTER] to save the setting and exit the
“Channel Editor” menu.
Moving up or moving down the TV channel
1.Press [EDIT] to appear the “Channel Editor”
menu, press [] [] to select one of the “TV
Channel” and press [].
2.Press [] [] to select the “Move Up” or
“Move Down” and press [ENTER].
The TV channel will change the address.
Each time you press [] or [] the item changes as follows.
Renaming TV channels
1.Press [EDIT] to bring up the “Channel Editor”
menu, press [] [] to select one of the TV
channels and press [].
2.Press [] [] to select “Rename” and press
[ENTER]. The display for entering a title name appears.
3.Select the desired characters from the
keypad. Press [ENTER] after each entry.
4.When you finish
entering the title
name, press [] []
[] [] to select
“Finish.”
Note:
You only can enter up to 5
characters for a name.

15
Recording continues until you stop the recording or when disc is
full.
To stop recording
When you press [ STOP], it may take a few moments for
recording to stop and the session to close.
To pause recording
Press [ PAUSE] to pause recording, and press [ PAUSE]
to resume recording.
To change the recording mode.
Press [SETUP].
Notes:
The new setting cannot change the current recording mode but will
be activated during the next session.
To check the disc status while recording
Press [DISPLAY] , the recording information appears.
Recording
1.Press [ POWER] to turn the unit on.
2.Press [ OPEN/CLOSE] to open the tray and
insert a recordable DVD disc.
Press the button again to close the tray.
When you insert a new recordable DVD disc, the DVD-Recorder
will automatically start the disc preparation process.
3.Press [SOURCE] to change the “signal-input
source” and select the “TV” input.
4.Press [ CH ] or press [] [] to select
the channel you want to record.
Note:
You can also use the number buttons to select a channel.
5.Press [RECORD] to start recording.
After pressing [RECORD], it may take a few moments to initialize.
Before recording
LVW-5001 DVD Recorder records on both DVD+R and DVD+RW
discs. Please use qualified recordable DVD+R/RW discs to ensure
best recording quality. Check our website for the list of qualified
discs.
LVW-5005XS DVD Recorder is a versatile DVD-Recorder that
employs the “ALL WRITE” technology to make it alright to record
on almost all of the recordable discs. You may use DVD+RW,
DVD+R, DVD-RW, DVD-R, CD-RW or CD-R discs to record.
Please use qualified recordable DVD+R/RW disc to ensure the
best recording quality. Check our website for the list of qualified
discs.
Note:
1.CD-R, DVD+R & DVD-R are write-once DVD discs.
2.CD-RW, DVD+RW & DVD-RW are re-writable DVD discs.
3.You cannot add new recording to a DVD-R/DVD-RW/DVD+R
disc after the disc is finalized.
4.In some cases, you may not be able to add new recording to the
recordable DVD discs that contain recordings recorded by other
DVD-Recorders.
Recording televison programs
LVW-5001 model only
LVW-5005XS model
only
One-touch recording
Use one-touch recording to start recording immediately in 30
minute blocks. Each time you press the record button, the
recording time is extended by another 30 minutes.

16
Recording
Playback with the DVD menu
Selecting a recorded session on a disc
The “DVD Menu” displays all the titles (programs) recorded on the
disc and you can select the one you want to play.
1.Press [ PLAY] or [ GUIDER]
The “DVD Menu” menu appears when you press [ PLAY] or
when you press [ GUIDER] to select “PLAYBACK” icon, and
display all of the title (program) on the recordable DVD disc.
2.Press [] [] to select a title (program) you
want to play and press [ENTER].
To scroll the “DVD Menu” display by page.
Press [] [] [] [] to select “ ” or “ ” icon or press [
NEXT] or [ PREVIOUS] , and the entire “DVD Menu” advances
to the next/previous page of recorded titles (programs).
Note:
1.If a power failure occurs, the program you are recording may be
lost.
2.Before you start, please check if the disc has enough available
space for the recording.
3.You cannot change the channel or recording mode during
recording.
4.Before playing a DVD+R disc on another player, you need to
finalize the disc.
LVW-5005XS model only
Before playing a DVD+R/DVD-R/DVD-RW disc on compatible
equipment, you will need to finalize the disc.
Adding new recordings after other recording
sessions.
Press [RECORD] to start recording, and press
[ STOP] at the point you want to stop.
Note:
Each new recording session is placed after the previous session
unless a certain recording title is set to be overwritten.
Changing Chapter Interval
Creating chapters while recording
The DVD-Recorder can automatically divide a session into
chapters by inserting chapter marks at 5/10/15/20/25/30-minute
interval during the recording process.
1.Press [SETUP] to display the “SETUP” menu.
2.Press [] [] to select the “RECORD” and
press [].
3.Press [] [] to select the “CHAPTER MARK”
icon and to set up the time.
4.Press [SETUP] to exit the “SETUP” menu.
Note:
1.During recording, press [EDIT] to add chapter mark(s) in the
recorded session manually.
2.You can also start recording using the “Easy Guider menu.”
Press [ GUIDER], select “RECORD” and then press [ENTER].
Follow the steps to set the recording mode.
3.Before you start, please ensure that the disc has enough
available space for the recording.
4.You cannot change the channel or recording mode during
recording.
Adding new recordings

17
Recording
Recording from a VCR or Camcorder/ Hi8 / DV
Before starting to record
This DVD-Recorder can accept standard CVBS (RCA) analog
audio/video cable or IEEE-1394 cable and record Camcorder onto
DVD in the digital video format of your choice. The unit functions
much like a digital VCR. Examples of use include archiving
videotapes or transferring from a Video Cassette Recorder or DV/
V8 Camcorder to a recordable DVD disc.
This DVD-Recorder allows basic DV control with the DVD
Recorder’s remote control when connected via the DV Link.
The front panel and rear panel connection
Connect a Video Cassette Recorder or Camcorder to the unit’s
input terminals.
To start recording
1.Press [SETUP] to select “RECORD” to set the
recording mode. ( HQ, SP, EP or SLP )
2.Place a recordable DVD disc on the tray with
the disc’s label facing up.
3.Press [SOURCE] to select the signal-input
(TV, AV1-Front, AV2-Rear, S-Video, DV).
Notes:
4.Start to play on the VCR or Camcorder.
5.Press [RECORD] on the DVD-Recorder to
record your video/audio signal from the VCR or
V8 Camcorder onto a recordable DVD disc.
6.Press [ STOP] to stop recording.
To pause recording
Press [ PAUSE] to pause recording, and if you want to restart
recording, press the [ PAUSE] button to resume recording.

18
Recording
DV recording
Before starting to record DV contents
This DVD Recorder allows basic DV control functions with the
remote control. The DVD Recorder is equipped with a
camcorder control (Play, Stop, FF or Reverse) feature via the DV
Link connection. Simply move the screen cursor to the desired
function and press [ENTER] on DV input screen.
1.Power on your TV and this DVD-Recorder.
2.Place a recordable disc on the tray. Make sure
the disc’s label is facing up.
3.Connect the DV cable (IEEE-1394 4-pin cable) to
both the DV Camcorder and the DVD-Recorder.
Note:
1.The DV-Link input jack on this unit is for use with DV compatible
camcorder only.
2.Only DV signals can be input to the DV-Link jack on this DVD
Recorder.
3.Do not connect a MICRO MV format video camcorder to this DV-
Link (IEEE-1394) jack.
4.You cannot connect more than two pieces of video input sources
at a time to the front panel connector of this DVD-Recorder.
4.Power on the DV Camcorder. Start “Playback
mode” on the DV Camcorder.
5.“Pause” the DV Camcorder where you want to
record.
6.Press [ GUIDER] on the remote control. This
actives the Easy Guider menu.
7. Press [] [] and to select the “RECORD”
icon, and press [ENTER] to confirm.
8.Press [] [] to select “DV” Input, and press
[ENTER] to confirm.
9.Press [] [] to select a recording quality and
press [ENTER] to confirm.
10.Press [ENTER] to start recording.
Notes:
This DVD-Recorder will stay in “Pause” mode when no DV input
signal is detected.
11.To pause recording.
Press [ PAUSE ] on the remote control to pause recording .
Press [ PAUSE ] again, if you want to resume recording.
12.To stop recording.
Press [ STOP]
Use “Easy Guider” to record DV signal
LVW-5001 model
Before playing a DVD+R disc on compatible equipment, you
will need to finalize the disc.
LVW-5005XS model
Before playing a DVD+R/DVD-R/DVD-RW disc on compatible
equipment, you will need to finalize the disc.

19
After recording is stopped, a DV control bar will
appear on the screen. This allows basic DV
control utilizing the DVD Recorder’s remote
control.
1.Press [] [] to select ( ) , to fast-forward
the DV Camcorder.
2.Press [] [] to select ( ) , to rewind the DV
Camcorder.
3.Press [] [] to select ( ) , to stop the DV
Camcorder playing.
4.Press [] [] to select ( ) , to start the DV
Camcorder playing.
5.Press [] [] to select ( ) , to pause the DV
Camcorder playing.
DV control
Recording
“One Touch Record” to record DV contents
Before starting to record DV contents
When you do not need to operate your DV, this unit allows basic
DV control on DVD Recorder Remote control.
1.Power on your TV and this DVD-Recorder.
2.Place a recordable DVD disc in the tray. Make
sure the disc’s label is facing up.
3.Connect the DV Cable (IEEE-1394 4-pin cable)
to both the DV Camcorder and the DVD-
Recorder.
4.Power on the DV Camcorder. Set “Playback
mode” on the DV Camcorder.
5.“Pause” the DV Camcorder where you want to
record.
6.Press [SOURCE] to change the “Signal-Input
source” and select the “DV” input.
7.Resume DV Camcorder playback and press
[RECORD] to start recording.
8.To pause recording.
Press [ PAUSE ] on the remote control to pause recording .
Press [ PAUSE ] again, if you want to resume recording.
9.To stop recording.
Press [ STOP]
