Lites Lites4 Instruction Manual

Lites
Lites 4
Owner's and service manual
Read this manual totally and carefully follow all the instructions contained. File this manual for future
use.It is essential to read all the information contained to ensure installation, service and full operation
of the Lites 4. Operations must be accomplished, handled and carried out by qualified personnel only
OT COMPLY IG WITH GIVE OTICE WILL VOID WARRA TY A D WILL FREE THE MA UFACTURER OF
A Y SORT OF RESPO SABILITY A D LIABILITY.
http://www.litessrl.com - www.ilites.eu

Page 2 / 8
Unpacking
Unpack the carton and gently remove Lites 4 rom the box. Ensure Lites 4 is received in all its parts.
In the event the lites 4 shows any damage, do not use it and contact immediately your transporter as well as your
seller.
Items in the carton consist o :
− Lites 4
− This owner's manual
Safety information for the use of the Lites4 and periodical maintenance of unit .
Lites4 is NOT or domestic use. Lites4 can only be used or pro essional applications
Installation, use and all operations o Lites4 must be accomplished, handled and carried out by quali ied personnel only
Do NOT install Lites4 on lammable sur aces
Minimum distance rom any lammable source is o 0.25m.
Minimum throw distance rom illuminated sur ace: 0.5m.
Always connect Lites4 to mains itted with sa ety device switch/breaker that cuts power o in case o danger
The Lites4 does NOT and CAN NOT be operated via Phase control dimmer
Earth connection on Lites4 as well as on all Lites srl products is mandatory|
Warning High voltage hazard, always disconnect Power be ore any handling and any servicing o the Lites4
These alerts and warnings are applicable on all Lites srl products
Do not and never handle Lites4 with humid/wet hands or near to any water or any kind o moisture sources
IP20 protecting rating.
Installation o the unit(s), must be secured with adequate clamps, sa ety cords, nuts and bolts to bear at least twice
the weight o the unit(s).
Install Lites4 in ventilated ambient which temperature must not exceed 35°C
Warning: Lites4 outer parts can reach temperatures o up to 70°C
An Essential and Periodically throughout cleaning o the Lites4 is recommended. This practice avoids that layers o dust
and other impurity jeopardise and reduce the correct operation o the unit. Lenses must be cleaned to remove layers
o dust that may impede and or reduce the passage o the light through the lenses. The correct and periodically
maintenance keeps vents and coolong ribs clean thus keeping the Lites4 in its best per ormance conditions.
CE Approvals
Lites4 ixture meets the requirements o European directives :
2006/95/CE
Low Voltage 2006/95/CE
Electro-Magnetic Compatibility 2004/108/CE
Rhos 2011/65/UE
Periodical service & maintenance
To ensure the correct HPLED operation, we suggest the ollowing periodical maintenance operations:
Remove dust or any kind o other dirt rom the ans and loop-holes, this operation ensures the correct air low
Remove dust rom lenses using a clean cloth. This will ensure the maximum light e iciency
Replace damaged protection screen and lenses when necessary
ever shake nor jolt Lites4 as sensitive parts could be irreversebly damaged
WARRA TY!
A 12-month warranty is granted on the Lites4 rom purchase’s date. Warranty covers abrication de ects only.
Warranty is immediately voided i the Lites4 has been handled by unquali ied personnel. Any improper and
unauthorised use, such modi ication(s) or misapplication o the Lites4 will also void the warranty o the product(s).
Silver colour label, showing technical data and serial number, i removed or i data are impaired to render details
illegible, it will also immediately void the warranty. Warranty does not provide or replacement o the unit. To receive
assistance rom the owned product read serial n and other In ormation printed on the silver label.

Page 3 / 8
Technical specifications
Power Supply: 100/240V~ 50/60Hz (autosetting)
Maximum power consumption: 65W
4x15 W RGBW Ostar LED
Stand-by power consumption: 4W Cos Ø 0,95
Optional angles “Gaggione collimators”: 8°/20°/30° (speci y when ordering)
Minimum ambient temperature: -15°C
Maximum ambient temperature: 35°C
Maximum body temperature: 70°C
Net weight: Kg 1,6
M8 yoke screw (tighten using a 13mm spanner)
Working position: any
Protecting rating: IP 20
DMX 512 & or RDM protocols
Power: 1,8m cable & shuko plug
Data connectors: IN/OUT XRL5 neutrik connectors
User inter ace: 4-digit and 4-button display
Manual operation via 4-button display
FANLESS unit
LED requency control : LED requency re resh
Optional 4-lea barndoor (speci y when ordering)
compliant
Product physical dimensions (view ig) :

Page 4 / 8
Lites4 installation
Lites4 is delivered with a yoke with a 11mm drilled hole; utilize either a suitable M10 screw or an appropriate G-
clamp to sustain/install the Lites4; Ensure G-Clamp can bear 4 times the weight o the Lites4 and always secure
Lites4 with sa ety /chain/cord using the provided ring. (view ig.) Lites4 yoke may rotate o 360° on the projector
axis. To hold yoke rotation thigthen M8 screw using a 13 mm spanner.
Lites4 operates in any position, nevertheless to optimzie Lites4 e icency and heat dissipation; we suggest Lites4 it
should be installed having heat-sik cooling ins set to vertical position.
4-leaf barndoor mounting
Secure 4-lea barndoor at the ront o the Lites4 and lock it in position using the 4 x M3 screws.

Page 5 / 8
Connection to mains
WAR I G ! Installation(s) must be accomplished, handled and
carried out by qualified personnel only and must comply with all norms
in force in the installation's country.
Lites4 is delivered with a 1,8 mt cable and itted with Shuko plug. Always and
only connect lites4 mains with sa ety circuit braker. Lites4 is a class 1 xture
there ore earth connection is mandatory.
Signal control connection
Lites4 accept either DMX and or RDM ready protocols. For daisy
chain DMX line use a 2x 0,5 mm (sqmm) lead wire plus shield.
Connection scheme:
Pin 1 to ground / Pin 2 data - / Pin 3 data+/ Pin 4 & 5 are not
connected. Ensure that shielded power pins and protection
covers do not touch/inter ere. XRL5 or DMX are NOT included.
Important notice :
A still point light on the le t bottom side o the display con irms
DMX active. I o no DMX active.
Lites4 settings
When Lites4 is powered , the set-up display will show so tware
release version. The UP/DOWN/ETER/ESC buttons allow or
Lites4 operations
The UP/DOWN keys allow to browse through menu options, the
ENTER key is to con irm selection. The ESC key is to return to
previous menu or to quit previous settings.
RDM – Remote Device Management
RDM Controllers allows or remote standard operations
RDM de ault options include:
standard RDM:
DEVICE_I FO
IDE TIFY DEVICE (LIGHT FLASHES TO IDENTIFY THE SELECTED DEVICE)
DMX_START_ADDRESS
SOFTWARE_VERSIO _LABEL
SUPPORTED_PARAMETERS
PARAMETER_DESCRIPTIO
DMX PERSO ALITY
DMX_PERSO ALITY_DESCRIPTIO
Collegamento
connettore XLR 5
poli
descrizione
1 GND
2 DMX-
3 DMX+
4 NC
5 NC
UP
DOWN
ENTER
ESC

Page 6 / 8
Menu list
display Value menu mode
Addr
001….512 Dmx setting value rom 1 to 512
Auto
Automatic
mode
co01
co02
co03
co04
co05
co06
co07
co08
co09
co10
co11
co12
Preset 1 red
Preset 2 orange
Preset 3 yellow
Preset 4 light green
Preset 5 green
Preset 6 cyn
Preset 7 light blue
Preset 8 azure
Preset 9 blue
Preset 10 Fuxia
Preset 11 magenta
Preset 12 white
Fixed colours set up without DMX 512.
values rom co01 to ……co12 is to select
its related colour
When Lites4 is switched o the selected
preset remains stored.
Preset colour levels maybe be changed
by selecting enter - use UP/Down keys to
change the 4 colour level values o each
individual channel rom 0/255. To
con irm selecton press enter
Values: 0 to 255
r.000=red
g.000=green
b.000=blue
U.000=white
S.000=strombe
n.000=rainbow
d.000=dimmer
Pr01
Pr02
Pr03
Pr04
Pr05
Pr06
Pr07
Pr08
Program 1 automatic
Program 2 automatic
Program 3 automatic
Program 4 automatic
Program 5 automatic
Program 6 automatic
Program 7 automatic
Program 8 automatic
Sel -operation without DMX 512.
Select Pr01 and……Pr08 Select now
program to run Program consists o 8
di erent scenes. Colour level, time and
ade(speed) maybe changed on each
program. - use UP/Down keys to change
the 4 colour level values o each
individual channel rom 0/255. To
con irm selecton press enter
Scn.1 :scene
number o
selected program
……..……………
Scn.9 scene n o
selected program.
P.00.0 pause
duration (sec) or
each scene.
F.00.0 ade
duration (sec) or
each scene.
1.c00 color set-up
o scene 1
……………………
9.c00 color set-up
o scene 9
MaSL
Master Mode
Same procedures & eatures as in the “Auto Mode” except when Lites4s are connected to daisy-
chain mode. All slave Lites4s ollow eatures o the Lites4 Master set to DMX001
Mode
0.rG7 (D) RGBW 7 ch
Dmx mode (view next page)
1.r7b RGBW 7 ch (compatible mode)
2.Ch1 1 ch
3.rG8 RGBW 8 ch
4.r13 RGBW 13 ch (16 bit)
5.rG4 RGBW 4 ch
6.HS4 HSV 4 ch
7.Cm5 CMYK 5 ch
TEMP
….°C reads metalcore temperature
booS
O
on
When OFF, LED max lux
: 80%
When ON, LED max lux : 100%
SMOO
000
……
020
Dimmer latency reaction adjustment or Dmx values transmitted by controller. (00) ast
dimming….(20) smooth dimming
GAMM
001
002
001 selection: Smooth dimming
002: coarse dimming (replicate traditional tungsten lamp t)
PUMF
1K
2K
3K
4K
5K
6K
7K
8K
9K
10K
LED operation requence
FAn
0.Aut
1.on
2.o
Idle (Lites4 is totally FANLESS)
dEF
canc
Rese “Rese”: reset Lites4 to de ault
Vers
so tware version
Sern
Display serial n
Resv
entry code to access concealed menu

Page 7 / 8
DMX Channel assignements
7 modes available to operate Lites4 as well as each associated channel
mode 0.RGBW 7 ch (default)
Ch
Function
dmx
levels
1
red
0..255
From 0 to max 255
2
green
0..255
From 0 to max 255
3
blue
0..255
From 0 to max 255
4
white
0..255
From 0 to max 255
5
strobo
0…15
Strobe disingaged
16…85
Pulse up rom slow (16) to ast (85)
86…155
Slow strobe (86 to ast (155)
156…225
Pulse down rom slow (156) to ast (225)
226
…230
O position
231…250
Strobo random rom slow (231) to ast (250)
251…255
Strobo disingaged
6
Rainbow
0..15
Rainbow disingaged
16..191
Set colours rom red (16) to …
Magenta (191)
192..255
Rainbow rom slow (192) to ast (255)
7
dim
mer
0..255
From 0 to max 255
mode 1.RGBW 7 ch (compatible)
Ch
Function
dmx
levels
1
red
0..255
From 0 to max 255
2
green
0..255
From 0 to max 255
3
blue
0..255
From 0 to max 255
4
white
0..255
From 0 to max 255
5
strobo
0…15
Strombo dis
ingaged
16…255
From slow strobo (16) to ast strobe (255)
6
Rainbow
0..9
Rainbow disingaged
10..255
From slow strobo (10) to ast strobe (255)
7
dimmer
0..255
From 0 to max 255
mode 2 .ch 1 ch
Ch
Function
dmx
levels
1
Rainbow
0…15
OFF p
osition
16…191
Set colours rom red (16) to …
Magenta (191)
192…247
From slow Rainbow (192) to ast (247)
248…255
white
mode 3.RGBW 8 ch
Ch
Function
dmx
levels
1
red
0..255
From 0 to max 255
2
green
0..255
From 0 to max 255
3
blue
0..255
From 0 to max 255
4
white
0..255
From 0 to max 255
5
strobo
0…15
disingaged
16…85
Pulse up rom slow (16) to ast (85)
86…155
Strobo rom slow (86) to ast (155)
156…225
Pulse down rom slow (156) to ast (225)
226…230
O (
spento)
231…250
Strobo random rom slow (231) to ast (250)
251…255
Strobo disingaged
6
Rainbow
0..15
Rainbow disingaged
16..191
Set colours rom red (16) to …
Magenta (191)
192..255
Rainbow rom slow (192) to ast (255)
7
dimmer
0..25
5
From 0 to max 255
8
Bianco dinamico
0…15
Colour temperature: Disabled
16…255
From white 2300°k to 7200°k
mode 4.RGBW 13 ch
Ch
Function
dmx
levels
1
red
0..255
From 0 to max 255
2
Red ine
0..255
Red ine tune adjustment
3
green
0..255
From 0 to max 255
4
Green ine
0..255
Green ine tune adjustment
5
blue
0..255
From 0 to max 255
6
Blue ine
0..255
Blue ine tune adjustment
7
white
0..255
From 0 to max 255

Page 8 / 8
8
White ine
0..255
White ine tune adjustment
9
strobo
0…15
inactive
16…85
Pulse up rom slow (16) to ast (85)
86…155
Fast Strobo (86) to slow strobe (155)
156…225
Pulse down da lento (156) a veloce (225)
226…230
O (spento)
231…250
Strobo random rom slow (231) to ast (250)
251…255
Strobo : inactive
10
Rainbow
0..15
Rainbow :inactive
16..191
Set
-
up Colors rom red (16) to …
Magenta (191)
192..255
Rainbow rom slow (192) to ast (255)
11
dimmer
0..255
Global light intensity adjustment
12
Dimmer
ine
0..255
Adjust
ement o global ine light intensity
13
Bianco dinamico
0…15
Colour temperature: inactive
16…255
Tunable white rom 2300°k to 7200°k
mode 5.RGBW 4 ch
Ch
Function
dmx
levels
1
red
0..255
From 0 to max 255
2
green
0..255
From 0 to max 255
3
blue
0..255
From 0 to max 255
4
white
0..255
From 0 to max 255
mode 6.HSV 4 ch
Ch
Function
dmx
levels
1
Hue
0..255
Rgb color
2
Saturation
0..255
Rgb:saturation (or .white, 255 ull saturation)
White: max (0) to black (255)
3
Value
0..255
From
OFF (level 0) to max (255)
4
strobo
0…15
Inactive
16…85
Pulse up rom slow (16) to ast (85)
86…155
Strobe rom slow (86) to ast (155)
156…225
Pulse down rom slow (156) to slow (225)
226…230
O
231…250
Strobo random rom slow (
231) to ast (250)
251…255
Strobe: disingaged
mode 7.CMYW 5 ch
ch
Function
dmx
levels
1
Cyan
0..255
From 0 to max 255
2
Magenta
0..255
From 0 to max 255
3
Yellow
0..255
From 0 to max 255
4
Black
0..255
From 0 to max 255
5
strobo
0…15
Inactive
16…85
Pulse up rom slow (16) to ast (85)
86…155
Strobe rom slow (86) to ast (155)
156…225
Pulse down rom slow (156) to ast (225)
226…230
O (spento)
231…250
Strobo random rom slow (231) to ast (250)
251…255
Strobe
: disignaged
Periodical maintenance
To ensure the correct Lites4 operation, we suggest the ollowing periodical maintenance operations:
Remove dust or any kind o other dirt rom heat-sink ins and loop-holes, this operation ensures the correct air low
Remove dust rom lenses using a clean cloth. This will ensure the maximum light e iciency
Replace damaged protection screen and lenses when necessary
Do not touch nor clean the LED iwith solvent
Device disposal information
At the end o its li e, Lites4 must be disposed to an appropriate electrical and electronic
equipment waste collection centre. Eco- riendly disposal, helps to avoid possible negative
impact on the environment and human health and promotes the reuse and/or recycling o the
materials making up the product. Illegal disposal involves administrative sanctions provided by
laws enacted.
Manu acture declines any sort o personal/corporate responsibility/liability or damages caused by the
inadequate/misuse o the product as well as i the product has been handled by unquali ied personnel. Not complying
with security norms/periodical maintenance as expressed in the owner's/service manual will also totally ree
personal/corporate responsibility/liability .
Lites 4 29/08/2014 UK rev.00
