LITETRONICS FL Series User manual

Flood Light
Installation Instructions
FL-Series
SAFETY INSTRUCTIONS AND WARNINGS
WHEN USING ELECTRICAL EQUIPMENT, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE OBSERVED.
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Litetronics fixtures must be wired in accordance with the National Electrical Code and all applicable local codes.
Risk of fire or electric shock. Flood light installation requires knowledge of luminaires electrical systems. If not qualified,
do not attempt installation. Contact a qualified electrician.
Be certain electrical power is OFF before and during installation and maintenance.
Flood light must be connected to a wiring system with an equipment – grounding conductor.
Make sure the supply voltage is the same as the rated luminaire voltage.
Only the open holes indicated in the photographs and/or drawings may be made or altered as a result of this kit
installation. Do not leave any other open holes in an enclosure of wiring or electrical components.
To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or sharp objects.
Suitable for wet locations.
WHAT COMES IN THE BOX
Photocell (60W, 100W, & 150W models)
Pluggable sensor socket (150W, 255W & 330W models)
Shorting cap (255W & 330W models)
Cable (See chart below)
Installation Instructions
TOOLS NEEDED
Phillips Screwdriver
CABLE LENGTHS
Part Number Length
FL0601 1.15 Ft.
FL1001 1.65 Ft.
FL1501 1.65 Ft.
Part Number Length
FL2552 1.65 Ft.
FL3302 1.65 Ft.
ATTENTION
1. Please check if there is any damage during shipping. If so, please contact Litetronics customer service.
2. Please read the installation instruction carefully to check whether all the accessories are included.
3. After confirmation, install the fixture according to installation steps.

2
INSTALLATION PROCEDURE
60W-100W-150W 255W-330W
WIRING DIAGRAM
Figure 2
GROUND
LINE 1 (HOT)
LINE 2 (HOT)
GREEN
WHITE
BLACK
480V
*For 347V, follow 120-277V wiring instructions
120V & 277V
Figure 1
*For 240V, follow 480V wiring instructions
As for the wire color
of DIM+ and DIM-, please
check the fixture label.
Purple:DIM+
Pink:DIM-
Black/Brown:ACL
Green/Yellow
White/Blue:ACN
Warning: Min. 75 °C supply conductors. 60W, 100W and 150W models suitable for operation in ambient not exceeding 50°C.
FUNCTION ADJUSTMENTS (60W, 100W, 150W MODELS)
1. Open the metal plug and plastic plug counterclockwise with a screwdriver (Figure 3) , then slide the switch up and down to
adjust the power controller, CCT selector or photocell controller for your application. (Figure 4)
2. After adjusting the required control function(figure 5), tighten the metal plug and the plastic plug clockwise.(Figure 6)
Figure 3
Figure 6Figure 5
CCT Selector Photocell and power controller
Figure 4
CCT SLIDE S
WITCH SETTINGS
CCT SLIDE S
WITCH SETTINGS
CCT SLIDE S
WITCH SETTINGS
WATTAGE SLIDE
SWITCH SETTINGS
WATTAGE SLIDE
SWITCH SETTINGS
WATTAGE SLIDE
SWITCH SETTINGS
3K
4K
5K
3K
4K
5K
3K
4K
5K
60W
45W
30W
100W
80W
60W
150W
120W
100W
Note: Watts default setting set to 60W.
CCT defaults setting set to 5000K.
Note: Watts default setting set to 100W.
CCT defaults setting set to 5000K.
Note: Watts default setting set to 150W.
CCT defaults setting set to 5000K.
FL0601 FL1001 FL1501

3
INSTALLATION PROCEDURE
FUNCTION ADJUSTMENTS (255W, 330W MODELS)
1. Open the metal plug and plastic plug counterclockwise with a screwdriver (figure 8) , then slide the switch up and down to
adjust the power controller, CCT selector for your application. (Figure 9)
2. After adjusting the required control function (Figure 10), tighten the metal plug and the plastic plug clockwise (Figure 11).
Figure 8 Figure 9
Figure 10 Figure 11
Power Controller CCT Selector
WIRING INSTALLATION
1. Assure power is off during wiring connections, follow wiring diagram Figure 1 and Figure 2.
2. Make sure the installation is completed and secure before turning on the power.
INSTRUCTIONS FOR SHORTING CAP)
1. Turn off power.
2. Unless optional Photocell device (ordered separately) is to
be installed, shorting cap should be installed on the back
of light. (Figure 7)
3. Make sure the installation is complete and secure before
turning on the power.
Figure 7 Fixture
Receptacle
255W
200W
150W
CCT SLIDE S
WITCH SETTINGS
CCT SLIDE S
WITCH SETTINGS
WATTAGE SLIDE
SWITCH SETTINGS
WATTAGE SLIDE
SWITCH SETTINGS
5K
4K
3K
5K
4K
3K
255W
200W
150W
330W
290W
250W
Note: Watts default setting set to 255W.
CCT defaults setting set to 5000K.
Note: Watts default setting set to 330W.
CCT defaults setting set to 5000K.
FL2552 FL3302

11/10/23 - V1.6
The information and product specifications contained in these instructions
are based upon data believed to be accurate at the time of printing. This
information is subject to change without notice and without incurring liability.
If you have questions regarding specific product details, please contact us at
800-860-3392 or via email at [e-mail].
To check for an updated version of these instructions,
please visit www.litetronics.com.
WWW.LITETRONICS.COM
[e-mail] or 1-800-860-3392
