Lithium Grim Clean Blade Boost Instruction Manual

Clean Blade Boost
Building instructions
V1.0

Clean Blade Boost v1.0
2
Table of contents
Components ............................................................................................................................................ 3
General guideline for components.......................................................................................................... 4
General building tips ............................................................................................................................... 4
Offboard wiring ....................................................................................................................................... 6
Biasing transistors ................................................................................................................................... 7
Troubleshooting ...................................................................................................................................... 7
Schematic ................................................................................................................................................ 8
Before starting your build, read the entire document!
Last update: 26-08-2016

Clean Blade Boost v1.0
3
Components
Part
Value
Comment
Part
Value
Comment
C1
100p
Multilayer Ceramic
IC1
ICL7660S
C2
220n
SMF
Q1
2N5484
C3
10u
35V+ Electrolyte
Q2
2N5484
C4
220n
SMF
R1
1M
C5
220n
SMF
R2
1M
C6
1n
MKT
R3
680R
C7
15n
SMF
R4
1M
C8
10u
35V+ Electrolyte
R5
680R
C9
10u
35V+ Electrolyte
R led
3k3
C10
10u
35V+ Electrolyte
VOLUME
B250K
Linear (Alpha DPDT combi pot)
D1
1n5817
VR2
B25k
Linear 6mm trimpot
D2
1n5817
VR3
B25k
Linear 6mm trimpot

Clean Blade Boost v1.0
4
General guideline for components
Capacitors: All values under 1nF should be ceramic disks. From 1nF up to 1uF should be SMF
or MKT (foil/metal film capacitors) and over 1uF use electrolyte caps 35V+ rated and watch
out for polarity!
Resistors: use 1% metal film for the best results.
Socket all transistors and the voltage regulator. This way you can easily mod them or replace
them if they brake.
Orientation of the transistors: the white stripe on the PCB indicates where the flat side of the
transistor should be.
General building tips
Before starting, do note that height might become an issue during this build. Try to solder everything
as close to the PCB as possible. It might be a good idea to solder the transistors to the board after
you selected the best ones to your taste. If you want to keep them socketed then you’ll need to bend
them. Same goes for the electrolyte capacitors. So examine the maximum height of the components
before starting your build. Also note that the 3PDT should can be placed on both the bottom as the
top side of the PCB. The components should be placed on the top side. By default it is advised to
mount the 3PDT on the bottom side, however If your enclosure is very small it might be a good idea
to mount the 3PDT on the topside. Decide this before starting your build.
Soldering this board can be complicated for some people since the solder pads can be very close
together. Use a magnifying glass to make the job easier.
Start by soldering the resistors (not yet VR2 and VR3) and the diodes. Now solder the capacitors
starting with the smallest. Next, solder the sockets for the transistors and voltage regulator. For the
transistors you can buy a 20 pin SIL socket and cut of the pins you need.

Clean Blade Boost v1.0
5
If you want to make it a 100% copy of the original then you’ll need to replace VR2 and VR3 with 4k7
resistors. Connect these resistors between pin 2 and 3 of the VR’s. The Pins are clearly marked on the
PCB. Else it is now time to solder VR2 and VR3. Try to pre-set them at 4k7 by measuring the
resistance between pin 2 and 3. (PS the schematic on page 7 shows 10k pots but in practice 25k is
much better for biasing different transistor types)
Finish by soldering the electrolyte capacitors. Place the transistors and you are almost ready to rock.
If you are going to use a 250k alpha pot with integrated DPDT than you will need to drill the hole in
the side of the enclosure and not the top of the enclosure as the DPDT pots are too tall for a 1590B
or BB enclosure!
Besides the components mentioned in the table on the first page, you will need:
2 input jacks. 2 mono jacks if you are not going to use a battery and only the 9V adapter. 1
mono (for output) and 1 stereo jack (for input) if you will be using both a 9V battery and the
9V adapter.
3PDT footswitch (9 pins).
2,1mm DC jack (isolated).
9v battery clip (optional).
22 gage stranded hook-up wire.
Hammond 1590B case (or similar) in your favourite colour.

Clean Blade Boost v1.0
6
Offboard wiring
S
M
Cathode (short leg)
Anode (long leg)
The LED requires a resistor (R led in the diagram) depending on the type of
LED you are using. An ultra-bright red or blue LED requires a 1k5 resistor, a
normal Green requires 680R and an ultra-bright Green might need a 4k7.

Clean Blade Boost v1.0
7
Biasing transistors
To bias the boost to your liking you can turn trim pots VR2 and VR3 to get it set to your liking. The
best way to start is to set them both to 4k7 between pin 2 and 3. This is the same value as the
original and should work if you are using the 2N5484. Try to get the drain (D) voltage around 9V. But
remember, if 9V does not sound good to you… try another value!
As alternatives you can try J201, 2N5485,2N5457, 2N5458, MPF102. It is reported however that the
2N5484 is still the best option.
NB. Even transistors of the same type may vary a lot in specs. I advise you to have at least 10
transistors per type to allow you to find the right ones for your circuit. So, if you cannot bias a
2N5484 to 9V, try another one!
Troubleshooting
All PCB’s have been e-tested 100% in the factory, so there should not be a connection problem on
the PCB itself.
The board is not working (at all), what now?
Check if your 9V is plugged in correctly (and/or soldered correctly on the board).
Check that you oriented the capacitors, IC’s ,transistors and diodes the right way. MKT
capacitors and resistors do not need to be oriented.
Check if you used the correct values of the components. For resistors you can look here:
http://www.diyaudioandvideo.com/Electronics/Color/
Double and triple check your soldering! A lose or cold solder can be really bad for your board.
Replace the IC’s and transistors, one might be defective. Before doing that first unplug the 9V
and wait 5 seconds.

Clean Blade Boost v1.0
8
Schematic
