Little Seeds B346859103COM2 User manual

B346859103COM2

2
6859103COM
6 Drawer Dresser
Keep this Assembly Manual for future reference.
Two adults
recommended
for assembly
Do NOT return this product.
For missing or broken parts
- Visit littleseedskids.com
- Call 1-800-489-3351
Follow little seeds on
This product is not intended for commercial use.

3
littleseedskids.com
Tube
You
Call us!
1-800-489-3351
Monday-Friday
9am - 5pm CST
- Open your item in the area you plan to keep it for less heavy lifting
- Identify, sort and count the parts before attempting assembly
- Compression dowels are tapped in with a hammer
- Slides are labeled with a R (right) and L (left) for proper placement
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge
- Use all the nails provided for the back panel and spread them out equally
- Back panel must be used to make sure your unit is sturdy
- Do NOT use harsh chemicals or abrasive cleaners on this item
- Never push, pull, or drag your furniture
Helpful Hints
Visit littleseedskids.com to view the
limited warranty valid in the U.S. and Canada.
Assembly Tips
Contact our friendly customer service team first for help.
Do NOT return this product!
PEOPLE NEEDED FOR ASSEMBLY: 2
ESTIMATED ASSEMBLY TIME: 2 HOURS

4
littleseedskids.com
Before You Start
Cam Lock Fastening System
This Cam Lock Fastening System will be used throughout the assembly process.
P
P
P
P
1
34
2
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Caution: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is tight.
Failure to do so may result in stripping the screw.
P

5
littleseedskids.com
Board Identification
Left Panel
36859103010
I
H
GJ
F
E
D
C
B
A
Right Panel
36859103020
Partition
36859103030
Top
36859103040
Bottom
36859103050
x2
Stringer
36859103060
x2
Front Leg
36859103070
x2
Rear Rail
36859103080
x4
Horizontal Molding
36859103090
x6
Drawer Front
36859103100

6
littleseedskids.com
Board Identification
x6
Drawer Back
39991140057340B
x12
Drawer Side
39991140346200C
x6
Drawer Bottom
36859331150
O
Back Panel
K685900000
This piece is paper board construction. It is not
made from wood but is required for the
assembly of your unit.
P
DWR
SIDE
DWR
BACK

7
littleseedskids.com
Board Identification
A
B
C
D
E
F
G
H
J
F
G
H
I
I
I
I
O
P
This piece is paper board construction. It is
not made from wood but is required for
the assembly of your unit.
DWR
BACK
DWR
SIDE
DWR
SIDE

8
littleseedskids.com
Parts List
Actual Size
x15
#A12420
5/8" pan head
x8
#A12950
1-1/8" flat head
x24
#A21970
drive fastener
x12
#A17400
7/8" screw
x11
#A23030
2" confirmat screw
x34
#A21110
nail
x10
#A22620
cam lock
x10
#A22610
cam bolt
x8
#A22910
connector bolt
x10
#A21660
wood dowel
x60
#A11080
7/16" flat head
x48
#A12120
7/16" pan head
x8
#A22920
connector
12345
6
7
8
9
10
11
12 13

9
littleseedskids.com
Parts List
Not Actual Size
left cabinet
member
right cabinet
member
x6
#A56750
Drawer Slide Package
left drawer
runner
right drawer
member
x5
#A44390
leg
x12
#A54510
drawer brackets
x1
#A84050
safety bracket kit
x6
#A50520
rope pull
x6
#A50435
handle
14a
14
14b 14c 14d
15
16
17
17a
17b
17c
17d
18 19

10
littleseedskids.com
Step 1
* raw edges are shaded
x6
#A22610
x4
#A22910
D
Screw six cam bolts and four connector bolts into the top (D) using the holes shown.
Attached the safety bracket to the top as shown.
Do not tighten
this screw.
x1
#A84050
12
12
2
2
2
17a 17b
17b
17b
17a

11
littleseedskids.com
Step 2
x4
#A22620
x4
#A21660
Fx2
Insert two cam locks and two wood dowels into both the stringers (F) as shown.
3
3
3
1
1
1
Proper orientation of CAM LOCK
Tip
Assembly
Quick

12
littleseedskids.com
Step 3
* raw edges are shaded
x3
#A56750
x9
#A11080
A
Attach three left cabinet members to the left panel (A) as shown with nine screws.
4
4
4
4
4
4
4
4
4
4
14a
14a
14a
14a

13
littleseedskids.com
Step 4
* raw edges are shaded
x2
#A22620
x2
#A21660
Insert two cam locks and two wood dowels into the left panel (A) as shown. Attached a
cam bolt into the hole shown.
x1
#A22610
A
2
2
3
3
3
1
1
Proper orientation of CAM LOCK
Tip
Assembly
Quick

14
littleseedskids.com
Step 5
* raw edges are shaded
x3
#A56750
x9
#A11080
Attach three right cabinet members to the right panel (B) as shown with nine screws.
B
4
4
4
4
4
4
4
4
4
4
14b
14b
14b
14b

15
littleseedskids.com
Step 6
* raw edges are shaded
x2
#A22620
x1
#A22610
x2
#A21660
Insert two cam locks and two wood dowels into the right panel (B) as shown. Attached a
cam bolt into the hole shown.
B
2
2
3
3
3
1
Proper orientation of CAM LOCK
Tip
Assembly
Quick
1

16
littleseedskids.com
Step 7
* raw edges are shaded
x4
#A12950
A
G
H
Using four screws, attach the front leg (G) and rear
rail (H) to the left panel (A) as shown. Please note
that the screws will screw into pilot holes in the
front leg (G) and rear rail (H). Be sure top edges are
flush with each other.
7
7
7

17
littleseedskids.com
Step 8
* raw edges are shaded
x4
#A12950
Using four screws, attach the front leg (G) and rear
rail (H) to the right panel (B) as shown. Please note
that the screws will screw into pilot holes in the
front leg (G) and rear rail (H). Be sure top edges are
flush with each other.
G
H
B
7
7
7
7

18
littleseedskids.com
Step 9
x3
#A56750
x18
#A11080
x3
#A56750
finished edge
CC
right surface
left surface
Attach three right cabinet members to the left surface and three left cabinet members
to the right surface of the partition (C) using screws as shown.
4
44
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
14b
14b
14b
14b
14a
14a
14a
14a

19
littleseedskids.com
Step 10
x2
#A22620
x2
#A22610
x2
#A21660
Insert two cam locks into the hole on the right surface and a wood dowel into both ends
of the partition (A) as shown. Attached a cam bolt to both surfaces as shown.
finished edge
CC
left surface right surface
2
2
2
3
3
3
Proper orientation of CAM LOCK
Tip
Assembly
Quick
1
1

20
littleseedskids.com
Step 11
* raw edges are shaded
x15
#A12420
Attach five legs to the bottom surface of the bottom (E) with screws as shown.
E
x5
#A44390
615
15
15
15
15
15
6
6
6
