Littleway MINI User manual

Manual
www.littlewayteam.com,Page,, 1,
,
ENGLISH

Manual
www.littlewayteam.com,Page,, 2,
,
- SECURITY
• Before using this product read these instructions
carefully.
• Pay attention to folding and sliding trailer parts for
entrapment hazard.
• Make sure all pins are as indicated in these instructions.
• Do not exceed the maximum authorized weight.
• Connect the lights to the vehicle and place the license
plate and lights bracket whenever you are going to
circulate with the trailer.
• Make sure the vehicle load is securely tied down.
• Maintain the wheels according to the maintenance
instructions in this manual.
• Do not leave any element hanging (straps, cables ... etc)
from the trailer that could be caught by the wheels.
• To drive with the t railer ho oked to t he vehi cle, the t iller
must be fully extended and with the pins positioned as
indicated in this manual.
• When folding or unfolding the trailer, do it in a clear
place with no one nearby.

Manual
www.littlewayteam.com,Page,, 3,
,
• Never leave the trailer folded in intermediate positions,
always in its fully folded position and with the safety
pin.
- PARTS OF THE TRAILER
These are the main parts of the trailer:

Manual
www.littlewayteam.com,Page,, 4,
,
- UNPACKING:
1st Remove the straps that hold the trailer to the
pallet.

Manual
www.littlewayteam.com,Page,, 5,
,
2nd The wheel stop is in the retracted position.
Without unfolding the trailer and provided with
two 19mm spanners, turn the wheel stop until it is
in the position you see in the drawing. You must
tighten the nuts tightly.
3rd Remove pins 1 and 2. The trailer is now ready
to be lowered from the pallet.
4th (Two people advisable) Hold tightly the top
of the trailer (a) and gently push forward until the
lance is detached from the pallet. Carefully lower
the trailer and lay the tiller straight until the
wheels are on the ground

Manual
www.littlewayteam.com,Page,, 6,
,

Manual
www.littlewayteam.com,Page,, 7,
,
- LOAD
STEP 1: Anchor the trailer to the ball of the vehicle.

Manual
www.littlewayteam.com,Page,, 8,
,
STEP 2: Remove the license plate and lights support ramp
and place it in the center to raise the motorcycle.
STEP 3: Raise the motorcycle and replace the license
plate and place the knobs with a security key.

Manual
www.littlewayteam.com,Page,, 9,
,
VERTICAL POSITION
STEP 1: Remove the tilt pins

Manual
www.littlewayteam.com,Page,,10,
,
STEP 2: (Two people advisable). Raise the trailer
until the tiller is vertical and the header is resting
on the ground.
STEP 3: Place the safety pin so that the lance is fully
fixed.

Manual
www.littlewayteam.com,Page,,11,
,
- MAINTENANCE
• Maintain the pressure of the wheels at a minimum
pressure of 4.8 bar and a maximum of 5.4 bar.
• Periodically check that the wheels are in good condition.
• Check the tightening of the wheel fixing bolts every
10,000 km.
• Spray lubricate sliding and rotating elements

Manual
www.littlewayteam.com,Page,,12,
,
• Periodically check that the trailer lighting is correct.
• Hardware maintenance launches every 10,000 km.
o The lance is fixed to the frame by means of an
M14x80 screw and an M14 self-locking nut that
must have a tightening torque of 90 Nm.
o The head is fastened to the lance by means of 2
M12x80 screws and 2 M12 flanged nuts that
have to have a tightening torque of 70 Nm.
